Miniatures Spring Run 83041 User manual
#83041 Spring Run Farmhouse Kit
designed by Adam Koch of Dollhouse Therapy
Available exclusively at miniatures.com
Step-by-step assembly instructions
Copyright miniatures.com 2022
GENERAL INSTRUCTIONS
•Identify and inspect all parts using the Parts List and Parts Diagram.
•Read the directions completely before beginning the project.
•If possible, it is most ideal to have a dedicated work area so that you are
not packing, unpacking, and moving the project from place to place.
•Choose a work surface that is level, flat, clean, dry, and protected
from glue spills.
•Do a dry fit, using masking tape to hold parts in place, to make sure
everything fits together correctly before permanent assembly.
Tip: Plan the finishes for the interior and exterior at the dry-fit stage,
before final/permanent assembly. It is easier to finish the panels as flat
surfaces. Disassemble and finish as desired, then reassemble using glue.
See miniatures.com for nishing ideas and materials
SUPPLIES NEEDED:
Masking tape
Glue (such as #1249 Weldbond)
Wood Filler
Door hardware
Exterior nishes
Assembly Instructions
Foundation
Parts you will need in this section:
Foundation Floor
Wall FFB x2
Wall FR
Wall FLA
Wall FLB
Wall FLC
Brace x2
Ground Floor
1. Place Foundation Floor flat on the work surface. Orient it so that its two
groves are facing up and are running horizontally. The edge of the Floor
that is facing forward is the Front of the house.
2. Glue a Wall FFB to Floor. It goes on the forward-facing edge of Floor
and parallel with the grooves in Floor. Its notch sits over the edge of Floor.
3. Glue Wall FR to the right edge of Floor and to the adjacent Wall FFB
that is already in place.
4. Align all joints and tape in place.
5. Glue the second Wall FFB to the back edge of Floor. It will run parallel
with the grooves in Floor. Also glue Wall to the adjacent Wall FR that is
already in place.
6. Align all joints and tape in place.
7. Glue Wall FLA to the left edge of Floor and to the adjacent Wall FFB
that is already in place.
8. Align all joints and tape in place.
2|©2022 miniatures.com |1-800-926-6464 |[email protected]
9. Repeat with Wall FLB. Note that this
wall may be left removable to allow
access to wiring.
10. Repeat with Wall FLC.
11. Align all joints and tape in place.
12. Fit and glue both Braces into the
grooves on the Floor and between the
Walls. Tape in place.
13. Orient the foundation assembly so
that the front is facing forwards.
14. Orient Ground Floor so that the two
grooves are on the left and the single
groove is on the right. The house front
will be facing forwards.
15. Glue Ground Floor on top of all Walls
and Braces. The edges of Floor are flush
with the outside of all Walls.
16. Align all joints, tape in place, and let
the glue dry.
Ground Level
Parts you will need in this section:
Wall G1
Wall G2
Wall G3
Corner
Arch Filler x2
First Floor
1. Orient the foundation assembly so that the two grooves of
the Ground Floor are on the left and the single groove is on
the right. The front of the house will be facing forwards.
2. Fit and glue Wall G1 into the longest groove on Floor. Orient
Wall so that the small doorway is towards the back of the
house. The back edge of Wall is flush with the notch on Floor
along the back of the house. Use a straight edge to assure
Wall does not extend into this notch. Use a heavy tall object to
temporarily help keep Wall vertical.
3. Fit and glue Wall G2 into the back left groove on Floor and
into its corresponding grove on Wall G1. It is flush with the
outside edge of Floor.
4. Align all joints and tape in place.
5. Fit and glue Wall G3 into the right groove on
Floor and into its corresponding grove on Wall G1.
It is flush with the outside edge of Floor.
6. The Corner can be used or not as desired. Also, it
can be attached permanently or made removable.
The space behind it is useful as a chase for wiring.
7. Fit and glue the Arch Fillers into the exposed
grooves under both arches.
8. Fit and glue First Floor on top of all Walls. The
edges of Floor are flush with the side edges of all
Walls.
9. Align all joints, tape in place, and let the glue dry.
1st Level
Parts you will need in this section:
Wall 1A
Wall 1B
Wall 1C
Corner
Second Floor
1. Orient the assembly so that the front is forward facing.
2. Fit and glue Wall 1A onto First Floor. It fits into the middle
groove that runs from side to side on Floor. Orient it so that
the doorway that is closest to the wall edge is at the left of the
house. The side edges of Wall are flush with the side edges of
Floor. Use a heavy tall object to temporarily help keep Wall
vertical.
3. Fit and glue Wall 1B into the front groove on Floor and its
corresponding groove on Wall 1A. Orient it so that the doorway
is towards the front of the house. Its front edge is flush with the
front edge of Floor.
6. Fit and glue Second Floor on top of all
Walls. The edges of Floor are flush with side
walls and overhang front and back walls.
7. Align all joints, tape in place, and let the
glue dry.
4. Fit and glue Wall 1C into the back groove on Floor
and into the groove on Wall 1A.
5. The Corner can be used or not as desired. Also, it
can be attached permanently or made removable.
The space behind it is useful as a chase for wiring.
2nd Level
Parts you will need in this section:
Wall 2A
Wall 2B
Wall 2C
Wall 2D
1. Orient the assembly so that the front is forward facing.
2. Fit and glue Wall 2A onto Second Floor. It fits into the groove
on Floor that runs from front to back of the house. Orient Wall
so that the angled edge is towards the font of the house. The
back edge of Wall is flush with the back edge of Floor. Use a
heavy tall object to temporarily help keep Wall vertical.
3. Fit and glue Wall 2B onto Floor. It goes against the left side of
Wall 2A at the back of the house. It fits into the notch on Floor
and is flush with the outside edge of Floor.
4. Align all joints and tape in place.
5. Fit and glue Wall 2C onto Floor. It goes against the left edge
of Wall 2B at the back of the house. It fits into the notch on
Floor and is flush with the outside edge of Floor.
6. Align all joints and tape in place.
7. Fit and glue Wall 2D onto Floor. It goes into the right front
groove on Floor and against the right side of Wall 2A.
8. Align all joints, tape in place, and let the glue dry.
4|©2022 miniatures.com |1-800-926-6464 |[email protected]
Outer Walls
Parts you will need in this section:
Front Wall
Front-Door Wall
Gable Wall
Back Wall
Wall Filler x2
9. Fit and glue both Wall Fillers into the
grooves at the 1st and 2nd levels in the
stairwell.
1. Fit and glue Back Wall in place. It sits in the notch on
Ground Floor. It receives First Floor into its groove, and
it receives Second Floor into its notch at the top edge.
Its side edges are flush with the edges of all Floors.
2. Align all joints and tape in place.
3. Fit and glue Front Wall in place. It sits in the notch on
Ground Floor. It receives First Floor into its groove, and it
receives Second Floor into its notch at the top edge. Its
left edge is flush with the left edges of all Floors.
4. Align all joints and tape in place.
5. Fit and glue Front-Door Wall in place.
It fits in the groove on Ground Floor. It
receives First Floor into its groove, and
it receives Second Floor into its notch at
the top edge.
6. Align all joints and tape in place.
7. Fit and glue Gable Wall in place. It fits
in the notch on Ground Floor. It receives
First Floor and Second Floor into its two
grooves.
8. Align all joints and tape in place.
Main Roof
Parts you will need in
this section:
Roof A
Roof B
Wall Q x4
Support Q x2
Floor Filler x2
Roof C
Roof D
Chimney
1. Place Roof A and Roof B flat on the work surface.
Orient them so that they are side by side with their
beveled edges facing down, touching, and aligned.
2. Tape them together, edges touching, with several
pieces of tape.
3. Gently flip the assembly over so that the beveled
edges are now facing up.
4. Add glue to both beveled surfaces.
7. Place all four Walls Qflat on the
work surface.
8. Glue two Walls together at their
angled edges to form a peak.
9. Align the joint and tape in place.
10. Repeat for the other two Walls.
11. Gently fit and glue the two wall
assemblies into the roof assembly.
They fit into the grooves that are on
the underside of the roof and towards
the outer edges of the roof.
12. Glue a Support Q over the peak joint
and on the inside so that it is out of view.
13. Repeat for the other Support Q on
the other wall assembly.
14. Align all joints and tape in place.
5. Gently lift the assembly while closing
it like a book. Continue until the beveled
edges come together to form the roof
peak. Stand up the roof assembly, like an
open book, on either edge.
6. Tape in place and set the roof assembly
aside while letting the glue set.
15. Place the roof assembly on top of the house. Use the gable-
roof line for orientation. Walls Qfit into the notches on the side
edges of Second Floor. The roof hangs over the outer walls to
form the eaves.
16. Align all joints and tape in place.
6|©2022 miniatures.com |1-800-926-6464 |[email protected]
20. Glue Roof D to Roof C and to Gable
Wall. Its groove receives Gable Wall. The
beveled peak of Roof D fits under the
beveled peak of Roof C.
21. Align all joints, tape in place, and let
dry.
22. Place the chimney on the roof. It can
go anywhere along the roof line.
17. Add Floor Fillers into notches on both
side edges of Second Floor.
18. Glue Roof C to Roof A and to Gable
Wall. It is flush with the inside edge of
Roof A. Its groove receives Gable Wall.
19. Align all joints and tape in place.
Dormer Roofs
Parts you will need in this section:
Large-Dormer Wall x2
Large-Dormer Roof
Small-Dormer Wall x4
Small-Dormer Roof x2
1. Glue both Large-Dormer Walls into the
dormer cut out of Roof B. Their top points rest
on the beveled edge of Roof and their bottom
points rest on the top edge of Back Wall. The
long edge of Large-Dormer Walls is flush with
the inside of Roof B.
2. Align all joints and tape in place.
3. Glue Large-Dormer Roof to Roof B and to
the top edges of both Large-Dormer Walls
and to the top edges of Walls 2A and 2B. It
rests on the outside of Roof B and its side
edges are flush with the Large-Dormer Walls.
4. Align all joints, tape in place, and let glue dry.
5. Glue Small-Dormer Walls into the dormer
cut outs of Roof A. The wall sits on the roof and
is flush with the window opening.
6. Align all joints and tape in place.
7. Glue both Small-Dormer Roof to Roof A
and to the top edges of all four Small-Dormer
Walls.
8. Align all joints, tape in place, and let glue dry.
1st Level Stairs
Parts you will need in this section:
Steps
Treads x16
Spindles x15
Handrail
Newel Post x2
Hall Handrail
• Paint or stain and otherwise finish
all stair parts before assembly.
1. Glue Treads onto Steps. Each Tread is flush with each step on
the left and overhangs on the right.
2. Insert Spindles into tread holes.
3. Glue a tall Newel Posts to the bottom steps.
4. Glue a short Newel Post to the top step.
5. Align all joints and tape in place.
6. Prop the assembly up on the work surface so that the
Spindles and Newel Post are standing upright.
7. Add glue sparingly to the Handrail inside and at the tips.
Place Handrail on top of Spindles and against Newel Posts.
8. Put the assembly aside to dry.
• Finish all floors and walls before permanently installing stair
and hall handrail assemblies.
2nd Level Stairs
1. Repeat 1-7 of the 1st
Level Stairs.
2. Glue the Hall Handrail
onto First Floor. It is flush
with the inside edge of
the stairwell.
Outdoor Stairs
Parts you will need in this section:
Entrance Stair x2
1. Place an Entrance Stair in front of the porch between the
entry pergola columns.
2. Place the other Entrance Stair in front of the back door.
Windows
Parts you will need in this section:
W1 x6
W2 x2
W3 x2
W4 x2
W5
W6
S1 x12
S2 x4
S3 x4
Block x20
Inside trim
Windowpanes
1. Match all window Inside Trim with Windows.
Note that W4 does not have inside window trim.
2. Assemble all window Inside Trim. Doing so on graph paper can help assure the assembly is square.
3. Paint the outside and inside frames of all Windows.
4. Paint the front and back of all Shutters.
5. Once your dollhouse’s exterior walls are painted and finished, add a couple of drops of glue in and around the exterior
window openings. Place the windows into the openings, according to the diagrams provided here, so that the exterior frames sit
on the exterior of the dollhouse. Tape in place.
6. Once your dollhouse’s interior walls are painted and finished, insert the Windowpanes, and glue the inside frame assembly
onto the walls. This secures the window assemblies in the place.
7. Glue a Block to the back center of every Shutter.
8. Glue Shutters to the outside walls and along the outside edges of all Windows W1, W2, and W3.
8|©2022 miniatures.com |1-800-926-6464 |[email protected]
Doors
Parts you will need in this section:
Front Door
Back Door
Transom Doors x6
Regular Doors x3
Transom Arch x2
Inside Trim
1. Match all door Inside Trim to Doors.
2. Assemble all door Inside Trim and Transom Arch. Doing so on graph paper can help keep
the assemblies square.
3. Paint or stain all Doors before installing them. Finish the walls before installing the Doors.
4. Place the Doors into their wall openings. When deciding which way a door will swing, and so
on which side of the wall to place the Door, remember that a door usually swings into a room.
5. Glue the Doors in place.
6. Use the included trim to mirror the door frame on the back side of the wall.
• Finish Doors with hardware of your choice (not included).
Pergola
Parts you will need in this section:
Column x4
Rafter x2
Batten x7
Long Beam x2
Short Beam
Long Fence
Short Fence
Jig
• Note that working on
graph paper will help
assure the work is square.
1. Place two Columns flat on the work surface. The ends furthest
away will be the top of the columns. The forward-facing ends will
be the bottom of the columns.
2. Glue the Short Beam between the Columns. Place it about one
inch down from the top of the Columns. Distance from the top of
the Columns is a personal preference
3. Glue the Short Fence between the Columns. Place it about 3/8”
up from the bottom of the Columns. Distance from the bottom of
the Columns is a personal preference..
4. Align all joints, tape in place, and let the glue dry.
5. Place the pergola assembly flat on
the work surface. Prop it up on its side so
that it forms a right angle with the work
surface. Fix it in this position by taping it
to the work surface.
6. Place a Long Beam to the left of the
assembly and at the exact same height
as the Short Beam in the assembly.
7. Place the Long Fence to the left of the
assembly and at the exact same height
as the Short Fence in the assembly.
8. Glue the Long Beam and Long Fence
to the Column and at a right angle to
the assembly. This forms the Pergola’s
corner.
9. Place another Column to the left of
and parallel with the assembly.
10. Glue the Column to the left side of
the assembly at the Beam and Fence.
11. Square up the assembly, align all
joints and tape in place.
12. Glue the last Long Beam to the left
of the assembly and at the exact same
height as the Beams in the assembly.
13. Glue the last Column to the left of
and parallel with the assembly.
14. Glue a Rafter to the tops of all three
Columns that are laying on the work
surface and in the assembly. The left
end of the Rafter will be flush with the
outer edge of the left most Column.
15. Square up the assembly, align all
joints, tape in place, and let the glue dry.
16. Place the Jig flat on the work surface.
Align it so that the slot that is closest to
the edge is on the right side.
17. Place all Battens into the slots on the Jig.
18. Glue the remaining Rafter to the row of Battens. The
forward-facing side of the Rafter is flush with the forward-
facing ends of the Battens. The right facing end of the Rafter
is flush with the right facing side of the Jig.
19. Glue the pergola assembly to the row of Battens. The
assembly is flush with the right facing side of the Jig.
20. Square up the assembly, align all joints, tape in place, and
let the glue dry.
Right Trim
Parts you will need in this
section:
TC2 X2
TB4
1. Orient the house so that the right side is facing forward.
2. Glue TB4 to Wall FR. Its outside edges are flush with Back
Wall and Front Wall.
3. Glue TC2 to the left edge of the house. Its outside edge is
flush with Gable Wall. Its bottom end is flush with TB4.
4. Glue the other TC2 to the right edge. Its outside edge is flush
with Back Wall. Its bottom end is flush with TB4.
Left Trim
Parts you will need in this
section:
TC8
TC2 x 2
TD2
TB1
TB2
TB3
1. Orient the house so that the left side is facing forward.
2. Glue TB3 to Wall FLA. One end is flush with Back Wall.
3. Glue TB2 to Wall FLB and to TB3.
4. Glue TB1 to Wall FLC and to TB2.
5. Glue TC2 to the left edge. Its outside edge is flush with
Back Wall. Its bottom end is flush with TB3.
6. Glue another TC2 to the right edge. Its outside edge is
flush with Front Wall. Its bottom edge is flush with TB1.
10 |©2022 miniatures.com |1-800-926-6464 |[email protected]
1. Orient the house so that the front is facing forward.
2. Glue both TD4s onto Gable Wall.
3. Align the angled joint at the peak and tape in place.
4. Glue a TA1 to the top of Gable Wall and tightly against
both TD4s. TA1 will be flush with the outside edges of Gable
Wall.
5. Glue TD3 to the top of Front Wall. It will be flush with the
left edge of Front Wall.
6. Put the pergola in place.
7. Glue TC6 to the top left edge of Front Wall. It joins
the TD3 and runs down along the edge of the house. It
overlaps TC2 to form a clean corner.
8. Glue TC7 to the bottom left edge of Front Wall. It run up
from the porch floor along the left edge of the house and
overlaps Side Trim TC2 to form a clean corner. Note that
the Rafter fits between TC6 & TC7.
9. Glue TA2 to the front left corner of the porch. Its top edge
is flush with the floor of the porch. Its left edge overlaps TB1
to form a clean corner.
Back Trim
Parts you will need in
this section:
TC1 x2
TD1
TA3
TA4
1. Orient the house so that the back is facing forward.
2. Glue TA4 to the bottom left of Back Wall. It overlaps TB4 to
form a clean corner.
3. Glue TA3 to the bottom right of Back Wall. It overlaps TB3 to
form a clean corner. Note that the back stair will fit in the gap.
4. Glue TC1 to the left edge of Back Wall. It runs down along the
edge of the house and overlaps TC2 to form a clean corner.
5. Glue another TC1 to the right edge of Back Wall. It runs down
along the edge of the house and overlaps TC2 to form a clean
corner.
6. Glue TD1 to the top of Back Wall. It will be flush to the left
side edges of wall. It overlaps TC2 on both sides to form a clean
corner.
Front Trim
Parts you will need in this section:
TA1 x2
TA2
TD3
TD4 x2
TC1 x2
TC6
TC7
TD2
TC8
TC3
10. Glue TD2 to the top of Front Door Wall. Its outside edge will
be flush with Gable Wall.
11. Glue TC8 to the top left-facing edge of the Gable Wall. Its
outside edge is flush with the front surface of Gable Wall. Note
that the bottom of TC8 will join the pergola.
12. Glue TC3 to the bottom left-facing edge of Gable Wall. Its
outside edge is flush with the front surface of Gable Wall. Note
that the top of TC3 will join the pergola.
13. Glue TC1 to the top left of Gable Wall. It joins TA1 and runs
down along the edge of Gable Wall. It overlaps TC3 and TC8 to
form a clean corner.
14. Glue TC1 to the right edge of Gable Wall. It joins the TA1 and
runs down along the edge of the house. It overlaps TC2 to form
a clean corner.
15. Glue TA1 to the bottom of Gable Wall and tightly against
TC5 and TC1. It overlaps TB4 to form a clean corner.
Assembly is now complete.
Part List
Foundation
Foundation Floor
Wall FFB x2
Wall FR
Wall FLA
Wall FLB
Wall FLC
Brace x2
Ground Floor
Ground Floor
Wall G1
Wall G2
Wall G3
Corner
Arch Filler
First Floor
1st Level
Wall 1A
Wall 1B
Wall 1C
Corner
Second Floor
2nd Level
Wall 2D
Wall 2A
Wall 2B
Wall 2C
Outer Walls
Front Wall
Front-Door Wall
Gable Wall
Back Wall
Wall Filler x2
Main Roof
Roof A
Roof B
Wall Q x4
Support Q x2
Floor Filler x2
Chimney
Roof C
Roof D
Dormer Roofs
Large-Dormer Wall x2
Large-Dormer Roof
Small-Dormer Wall x4
Small-Dormer Roof x2
Stairs
Steps x2
Treads x32
Spindles x30
Handrail x2
Hall Handrail
Tall Newel Post x2
Short Newel Post x2
Outdoor Stairs
Entrance Stair x2
Windows
W1 x6
W2 x2
W3 x2
W4 x2
W5
W6
S1 x12
S2 x4
S3 x4
Block x20
Windowpane x12
Window Inside Trim
(not for W4)
Doors
Front Door
Back Door
Transom Doors x4
Regular Doors x3
Transom Arch x2
Inside Trim
Pergola
Jig
Column x4
Rafter x2
Batten x7
Long Beam x2
Short Beam
Long Fence
Short Fence
Trim
TA1 x2
TA2
TA3
TA4
TB1
TB2
TB3
TB4
TC1 x4
TC6
TC7
TC2 x4
TC3
TC8
TD1
TD2
TD3
TD4 x2
12 |©2022 miniatures.com |1-800-926-6464 |[email protected]
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Roof A
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Roof B
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Roof Large Dormer
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Roof D
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Roof C
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Roof Small
Dormer
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
First Floor
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Foundation Floor
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Ground Floor
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Second Floor
Parts Diagram
Note: Not to scale
Support Q
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Wall Q
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Front Wall
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Wall G1
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Wall G2
Wall G3
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Front
Door
Wall
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Gable Wall
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Back Wall
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Wall 1C
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Wall 1B
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Wall 1A
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Wall 2D
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Wall 2A
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Wall 2B
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Wall 2C
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Corner
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Large
Dormer Wall
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Small Dormer
Wall
Parts Diagram
Note: Not to scale
14 |©2022 miniatures.com |1-800-926-6464 |[email protected]
Parts Diagram
Note: Not to scale
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
FFB
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Arch Filler
Wall Filler
Floor Filler
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
FR
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Brace
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
FLC
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
FLB
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
FLA
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Pergola Column
Pergola Rafter
Pergola Batten
Pergola Beam
Pergola Beam
Chimney
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Entrance Stair
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Jig
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Pergola Fence Short
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Pergola Fence Long
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Hall Handrail
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Spindles
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Lower
Newel
Post
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Upper
Newel
Post
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Steps
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Back Door
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4 Transom Arch
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Interior
Regular
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Front
Door
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Shutter
for W1
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Shutter
for W2
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Shutter
for W3
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
W3
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
W2
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
W1
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Railing
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Stair
Treads
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
Interior
Transom
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
W4
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
W5
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
D4
J1354
Wall E
J1355
Wall F
J1356
Wall G
J1357
Wall H
J1358
Wall J
J1359
Wall K
J1360
Wall L
J1361
Wall M
J1362
Wall N
J1363
Wall P
J1364 Wall Q
J1365
Wall R
J1366
Dormer Wall
J1367
W4 Side Panel
J1458
Wall S (Wall Q Support)
J1350
Wall A
J1351
Wall B
J1352
Wall C
J1353
Wall D
J1374 Pergola Column R389 Pergola Fence A
R390 Pergola Fence B
J1459 Template for pergola
Assembling
R388 Entrance Stair
R387 Chimney
J1375 Pergola Rafter
J1376 Pergola Batten
J1377 Pergola Beam
J1378 Pergola Beam
J1318 Top Railing
R375 16-Steps Stair
T0202 Stair Treads
R371
D1 Exterior
Transom
Door
R370 W1
R383
Shutter
for W1
R384
Shutter
for W2
R385
Shutter
for W3
R379 W2 R380 W3 R381 W4 R382 W5 #5007 Traditional
24-Light Window
R372
D2 Interior
Transom
Door
R374 B
D3 Interior
Regular
Door
R386
D4 Transom Arch
R391
D5 Back Door
J1299 L
J1287 L
J1388 L
J1454
J1454
J1454
J1455 L
J1456
J1457
J1455 R
J1388 R
J1287 R
J1300
J1288
J1289
J1288
J1289
J1299 R
J1299 L
J1323 L
J1314 L
J1314 R
J1323 R
J1323 L
J1323 R
J1300
J1300
J1428
J1300
J1299 R
J1319 Lower Newel Post
7019X Spindles R376 Interior Land Rail,
Assembled
7012N Upper Newel Post
WALL PERGOLA OTHER
INTERIOR STAIR SET
DOOR
WINDOW
W6
TA1
TA2
TA3
TA4
TB1 TB2
TB3 TB4
TC6
TC7
TC8
TC3
TC2
TC1
TD1
TD2
TD3
TD4
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
J1341 Front/Rear
J1342 Right
J1453 Base Support
J1343
Left1 J1368 Roof A
J1370 Roof C
J1433 AA1, EE1
J1437 BB1
J1438 BB2
J1439 BB3
J1440 BB4
J1443 DD1
J1444 FF1
J1445 GG1
J1446 HH1, HH2
J1441 CC6
J1442 CC7
J1448 CC5
J1449 CC13
J1450 CC1, CC3+CC4, CC10, CC11
J1447 CC2, CC8, CC9, CC12
J1434 AA2
J1435 AA3
J1436 AA4
J1371 Roof D J1372 Roof E J1373 Roof F&G
J1369 Roof B
J1348 FLOOR2
J1346 FLOOR0 J1347 FLOOR1
J1349 FLOOR3
J1259 D4 Groove Filling Piece
J1451 Stair Wall Groove Filling Piece
J1452 Wall Q Groove Filling Piece
J1344
Left2
J1345
Left3
BASE
FLOOR
Groove Filling Piece ROOF
TRIM
Parts Diagram
Note: Not to scale
We hope you enjoy your Spring Run Farmhouse kit!
For finishing tips and more information, visit miniatures.com.
Table of contents
Other Miniatures Toy manuals
Popular Toy manuals by other brands
Fisher-Price
Fisher-Price R7872 instruction sheet
Swalkertech
Swalkertech S1 user manual
Eduard
Eduard Zoom SB2C-4 Helldiver quick start guide
ROBBE
ROBBE Lightning 46 Assembly instructions
CYmodel
CYmodel Siai Marchetti SF-260 instruction manual
Little Tikes
Little Tikes SPARKLE BAY Splash Fountain Blowfish 638299M quick start guide
