Minirig MRM User manual

PORTABLE RECHARGEABLE BLUETOOTH SPEAKER
USER’S GUIDE MRM

WARNING – LISTENING AT HIGH VOLUME FOR A LONG TIME MAY DAMAGE YOUR HEARING
• Never disassemble or attempt to modify the product in any way.
• Do not attempt to submerge the product in water or expose it moisture, water or liquids of any kind.
• Do not drop the product or place the product on its curved side in a location above ground where it may roll and fall.
• Do not cover or restrict ventilation and use only in areas of adequate ventilation with at least 15cm of separation.
• Avoid hot and/or humid environments such as bathrooms, conservatories, cars or in direct sunlight.
• Do not place or install the product near to sources of heat such as radiators or stoves.
• Do not expose the product directly to naked flames, hot surfaces or other apparatus that produce heat.
• The safe operating temperature range of this product is +5°C to +40°C.
• Do not expose the product to objects or forces which may pierce or damage the enclosure.
• For charging, this product requires 0.8A (800mA) at 5V DC. Check USB port power supply specifications before use.
• CAUTION: AC-DC USB power supplies may carry electric shock hazard. Read power supply safety information before use.
• Do not short circuit or connect loads in excess of 0.5A (500mA) to the power cable USB socket (marked “out”) while the cable is
connected to the product.
• Do not daisy chain or connect multiple power cables to any single USB socket or USB power supply.
• Do not connect any other load or device to the power cable USB socket (marked “out”) while the power cable USB plug (marked
“in”) is connected to a USB port power supply.
• Do not stress, bend, pinch or force cables in such a way as to incur damage.
• Do not store the product with a low/flat battery or leave the unit unused for a long period of time.
• Do not leave the product permanently on charge.
• Do not use this product near medical devices or on an airplane.
• Refer all servicing and repair to original manufacturer. Servicing is required when the product is damaged in any way such as
power-supply cord is damaged, liquid has been spilled or objects have fallen onto the unit, the unit has been exposed to rain or
moisture, does not operate normally or has been dropped.
The exclamation point within an equilateral triangle is intended to inform the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
SAFETY INSTRUCTIONS – PLEASE READ BEFORE USE
SAFETY INFORMATION

OTHER INFORMATION
WARRANTY INFORMATION WWW.MINIRIGS.CO.UK/TERMS-AND-CONDITIONS
SUPPORT/CONTACT INFORMATION WWW.MINIRIGS.CO.UK/SUPPORT
MANUFACTURER MINIRIGS LTD, UNIT 4 CITY BUSINESS PARK, BS50SP
All packaging materials are recyclable, please dispose of in accordance with your local recycling regulations. The
product may contain batteries and harmful substances so should not be treated as household waste. Where possible
we will repair any faulty units to keep the product operational for as long as possible. If you wish to dispose of the
product, please contact the original manufacturer to return it for recycling or for advice on suitable recycling methods.
This product contains a 2.4Ghz radio transmitter and should be used in such a manner that human contact is minimised during
normal product operation.
US (FCC) FCC ID: 2AD65MRM Model number: MRM
This equipment complies with FCC radiation exposure limits set forth for portable use conditions.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation. No changes shall be made to the equipment without the manufacturer’s permission as this may void the
user’s authority to operate the equipment.
Canada (Ised) Ic: 12731A-MRM Model number: MRM
This equipment complies with the safety requirements for RF exposure in accordance with RSS-102, issue 5, Annex VII
for portable use conditions. This Class B digital apparatus complies with Canadian ICES-003. Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Cet appareil est conforme aux exigences de sécurité concernant l’exposition aux RF selon la norme RSS-102, 5ème édition,
pour des conditions d’utilisation portable. Cet appareil numérique de la classe B est conforme à la norme ICES-003 du
Canada.
L’utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2)
l’utilisateur du dispositif doit être prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de
compromettre le fonctionnement du dispositif.
EU (CE)
Hereby, Pasce Ltd. declares that the radio equipment Minirig is in compliance with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following internet address: www.minirigs.co.uk/compliance
This product contains a non-serviceable rechargeable lithium ion battery. DO NOT attempt to open or disassemble the unit to replace
or remove the battery yourself. Please refer to original manufacturer for battery servicing and replacement. Follow safety instructions
above carefully. If fluid should leak from the unit or rechargeable battery, do not touch. If fluid comes in contact with eyes, wash
thoroughly with water and seek medical advice. Do not rub eyes. If you suspect that the battery is faulty through unexpected behaviour
such as not holding charge, please turn o and do not attempt to charge or use the product. Contact the original product manufacturer
immediately.
© pasce Ltd 2017
BATTERY
ENVIRONMENTAL
REGULATORY COMPLIANCE STATEMENTS

press link to skip to page
INDEX

A WORD FROM US
First of all we want to oer you a big thank you from everyone here at Minirigs for purchasing a Minirig Mini (MRM) Bluetooth speaker.
We have spent years developing this product, making a truly portable speaker without compromising sound. We hope you get years
of enjoyment out of it. Don’t forget our app unlocks extra features and includes Minirig mixes from international DJs of all genres
streamed directly to your phone, from our Soundcloud page. Download the app today for free, from the Google and Apple app stores
UNPACKING
GETTING TO KNOW YOUR MINIRIG MINI
Before you begin, open up the box and check the contents. You should have:
1. MINIRIG MINI SPEAKER 2. AUX AUDIO CABLE 3.5MM 3. USB POWER
Button / Status LED Lights up to show status. Multifunction button to operate the MRM
AUX socket (high gain) Audio input from audio player or output to another MRM or Subwoofer
Power sockeT Plug supplied, insert power cable in here to charge the MRM (opposite side)
AUX SOCKET (LOW GAIN) Audio input from audio player or output to another MRM or Subwoofer
home

TURN ON/OFF
Press and hold the button for 2 seconds to turn the MRM on,you will
see the LED turn green and hear a tone momentarily. Finally the LED will
settle showing your battery status.
For more information regarding the battery status see:
‘CHARGING’ or PRESS HERE
Press and hold the button for 2 seconds to turn the MRM o,you will
see the LED turn red and hear a tone momentarily.
CONNECT TO BLUETOOTH
Please remove any audio cables before turning your MRM on.
To connect your audio device with the MRM, they have to be “paired” first.
The MRM will always be available for pairing as long as it is on, in Bluetooth mode, and doesn’t have two devices already connected
to it. There is no pairing “mode” unlike other Bluetooth speakers, which makes pairing simpler and easier.
TURN ON BLUETOOTH
MINIRIG MINI
Find and select the “MINIRIG MINI”.
Your device will indicate that they
are “pairing”.
Locate the Bluetooth settings on
your device (E.g. smartphone). Turn
Bluetooth ON and search for device.
Your device will confirm when they
have paired and you can begin
playing music.
The MRM can remember up to 8
paired devices.
CONNECTED
FIND YOUR MINIRIG MINI PLAY SOME MUSIC SHARE WITH FRIENDS
home

You can pair and connect two devices to a MRM at the same time.
To switch between them you need to stop the music on the device
playing, then start playing music on the second device.
CONNECT AUDIO CABLE (AUX MODE)
CONNECT TWO DEVICES TO SHARE MUSIC HIGH AND LOW GAIN SETTINGS
We recommend that you use LOW gain at normal listening
levels for the best sound quality
If your device does not have Bluetooth or you would like to use a wired connection instead, you can connect to the MRM using the
supplied AUX cable. Ensure your MRM is o and remove any audio cables before using cable mode.
PLUG IN A SUBWOOFER WHEN USING BLUETOOTH
The MRM has two gain (volume) settings – LOW and HIGH. In
Bluetooth mode it will always start in HIGH gain. In AUX mode it
will start in LOW or HIGH gain depending on which AUX socket
you plug in to.
HIGH GAIN LOW GAIN
In Bluetooth mode, the MRM will output audio from both AUX
sockets. This allows you to connect to another Minirig, Minirig
Subwoofer or Hi-Fi system.
• Plug one end of the AUX cable into the headphone socket on
your audio device.
• Plug the other end into one of the AUX sockets on the Minirig.
The MRM will turn on when you insert the cable displaying the
green LED There will be no tone. When you unplug the cable
the Minirig will turn o displaying the red LED there will be
no tone.
Please ensure the cable is pushed all the way in when turning on!
TO CHANGE GAIN AT ANY TIME:
• Check that the Minirig is ON and audio is playing
• Press the button once, do not hold it down
• In high gain the LED will be brighter than in low gain
home

HIGH GAIN LOW GAIN
HIGH AND LOW GAIN IN WHEN USING A CABLE LINKING UP MRM (MONO)
LINKING-UP WITH MRM AND SUBWOOFER IN CABLE MODE (STEREO)
The top socket will put the MRM in high gain, the bottom socket
low gain. Push it in firmly to make the connection. You can still
change gain using the button as in Bluetooth mode.
You can turn the Minirig OFF and ON by pressing and holding the
button. However, it will stay in AUX mode until you remove all the
audio cables
In AUX mode, removing the audio cables will also turn the MRM
OFF. Again there will be no tone in AUX mode.
You must do this before you can use the MRM in Bluetooth mode.
In AUX mode you can use the spare audio socket to link out to
another Minirig product as shown. Connected in this way, all
speakers will play a mix of the left and right channels - mono.
You can connect as many speakers as you like. Always ensure all
speakers are set to either high or low gain.
Two MRMs can be configured to
play in stereo using two standard
3.5mm aux cables. Connect the first
MRM to your audio device, then link
out to the second MRM as shown.
To enable stereo mode, double
press the button on BOTH speakers.
They will now play LEFT and RIGHT
as shown. You can also add a
Subwoofer to the chain by placing it
between the two MRM speakers.
home

WARNING: only one Minirig or Sub per USB plug
CHARGING
BLUETOOTH RECEIVER MODE
Plug the round end into the Minirig
power socket. Ensure you push it
in firmly to make the connection.
Next insert the USB plug end into any
powered USB socket.
USB sockets can be found on most
computers and mobile phone chargers.
WHEN ON CHARGE, THE LED WILL FADE ON IN A REPEATING 2 SECOND CYCLE. THE COLOUR REPRESENTS THE BATTERY LEVEL.
A FULL CHARGE WILL TAKE 2-3 HOURS. ONCE THE BATTERY IS CHARGED, THE LED WILL STOP THIS REPEATING CYCLE.
WHEN THE MINIRIG IS ON, THE COLOUR OF THE LED WILL INDICATE THE BATTERY LEVEL.
GREEN: 75-100% CYAN: 50-75% BLUE: 25-50% PURPLE: 5-25% RED: 0%
When the MRM is OFF you can check the battery status by pressing the button once (do not press and hold). At any time you
can charge the Minirig using the supplied power cable
home
Your MRM can be used as a Bluetooth reciever where it will output stereo audio via the 3.5mm jack. To enable this mode you need
to connect your chosen device (e.g. headphones or Hifi) then press the MUTE button on the app to mute the speaker and enable
stereo output.
LINE IN

WIRELESS STEREO PAIRING
Two MRM’s can link up together using the wireless Bluetooth connection. This allows you to create an immersive stereo soundstage or
to double up the sound in dierent areas without any cables.
1 meter
LR
• Turn both MRM’s ON in Bluetooth mode and place them around 1 meter or less apart – they
only need to be close for this pairing process.
• Select which one you want to use as the LEFT (master) speaker. You may already be
connected and playing music through this MRM.
• Press the button TWICE on the LEFT (master) MRM. Just press and release both times, don’t
hold the button. You will hear a “beep beep” tone.
• The MRM will start searching for other Minirigs in the area. The LED will flash white and red.
• At any time you can cancel the process by pressing the button.
• When it has found another MRM you will hear a confirmation tone and the LED will stop
flashing.
• After a few seconds, audio will start playing back in stereo through the two speakers.
• If the pairing is unsuccessful or if the search times out, you will hear a dierent lower “failed”
tone. Please try again or see FAQ for assistance.
home
x2
