MINN KOTA TERROVA User manual

TERROVA
BOW-MOUNT TROLLING MOTOR
USER MANUAL

WARRANTY ON MINN KOTA FRESHWATER TROLLING MOTORS
Johnson Outdoors Marine Electronics, Inc. (“JOME”) extends the following limited warranty to the original retail purchaser only. Warranty coverage is not
transferable.
MINN KOTA LIMITED TWO-YEAR WARRANTY ON THE ENTIRE PRODUCT
JOME warrants to the original retail purchaser only that the purchaser’s new Minn Kota freshwater trolling motor will be materially free from defects in materials
and workmanship appearing within two (2) years after the date of purchase. JOME will (at its option) either repair or replace, free of charge, any parts found by
JOME to be defective during the term of this warranty. Such repair, or replacement shall be the sole and exclusive liability of JOME and the sole and exclusive
remedy of the purchaser for breach of this warranty.
MINN KOTA LIMITED LIFETIME WARRANTY ON COMPOSITE SHAFT
JOME warrants to the original retail purchaser only that the composite shaft of the purchaser’s Minn Kota trolling motor will be materially free from defects in
materials and workmanship appearing within the original purchaser’s lifetime. JOME will provide a new composite shaft, free of charge, to replace any composite
shaft found by JOME to be defective during the term of this warranty. Providing a new composite shaft shall be the sole and exclusive liability of JOME and the
sole and exclusive remedy of the purchaser for breach of this warranty; and purchaser shall be responsible for installing, or for the cost of labor to
install, any new composite shaft provided by JOME.
EXCLUSIONS & LIMITATIONS
This limited warranty does not apply to products that have been used in saltwater or brackish water, commercially or for rental purposes. This limited warranty
does not cover normal wear and tear, blemishes that do not affect the operation of the product, or damage caused by accidents, abuse, alteration, modification,
shipping damages, acts of God, negligence of the user or misuse, improper or insufficient care or maintenance. DAMAGE CAUSED BY THE USE OF
OTHER REPLACEMENT PARTS NOT MEETING THE DESIGN SPECIFICATIONS OF THE ORIGINAL PARTS WILL NOT BE COVERED BY
THIS LIMITED WARRANTY. The cost of normal maintenance or replacement parts which are not in breach of the limited warranty are the responsibility
of the purchaser. Prior to using products, the purchaser shall determine the suitability of the products for the intended use and assumes all related risk and
liability. Any assistance JOME provides to or procures for the purchaser outside the terms, limitations or exclusions of this limited warranty will not constitute
a waiver of the terms, limitations or exclusions, nor will such assistance extend or revive the warranty. JOME will not reimburse the purchaser for any expenses
incurred by the purchaser in repairing, correcting or replacing any defective products or parts, except those incurred with JOME’s prior written permission.
JOME’S AGGREGATE LIABILITY WITH RESPECT TO COVERED PRODUCTS IS LIMITED TO AN AMOUNT EQUAL TO THE PURCHASER’S
ORIGINAL PURCHASE PRICE PAID FOR SUCH PRODUCT.
MINN KOTA SERVICE INFORMATION
To obtain warranty service in the U.S., the product believed to be defective, and proof of original purchase (including the date of purchase), must be presented
to a Minn Kota Authorized Service Center or to Minn Kota’s factory service center in Mankato, MN. Any charges incurred for service calls, transportation or
shipping/freight to/from the Minn Kota Authorized Service Center or factory, labor to haul out, remove, re-install or re-rig products removed for warranty service,
or any other similar items are the sole and exclusive responsibility of the purchaser. Products purchased outside of the U.S. must be returned prepaid with
proof of purchase (including the date of purchase and serial number) to any Authorized Minn Kota Service Center in the country of purchase. Warranty service
can be arranged by contacting a Minn Kota Authorized Service Center or by contacting the factory at 1-800-227-6433 or email [e-mail].
Products repaired or replaced will be warranted for the remainder of the original warranty period [or for 90 days from the date of repair
or replacement, whichever is longer]. For any product that is returned for warranty service that JOME finds to be not covered by or not
in breach of this limited warranty, there will be a billing for services rendered at the prevailing posted labor rate and for a minimum of at
least one hour.
NOTE: Do not return your Minn Kota product to your retailer. Your retailer is not authorized to repair or replace products.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THESE LIMITED WARRANTIES. IN NO EVENT SHALL ANY IMPLIED
WARRANTIES INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE, EXTEND
BEYOND THE DURATION OF THE RELEVANT EXPRESS LIMITED WARRANTY. IN NO EVENT SHALL JOME BE LIABLE FOR PUNITIVE,
INDIRECT, INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES. Without limiting the foregoing, JOME assumes no responsibility for
loss of use of product, loss of time, inconvenience or other damage.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above
limitations and/or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other legal rights which vary from state
to state.
FEATURES
Adjustable Depth Collar
Lifetime
Warranty Flexible
Composite Shaft
Cool Quiet
Power Motor
Weedless Wedge 2 Propeller
AutoPilot Indicator
(functional on equipped motors only)
System Ready
Indicator
Stow/Deploy Lever
Low Profile
Foot Pedal
Specifications subject to change without notice.
*This diagram is for reference only and may differ from your actual motor.
Fall Away Ramps
Push-to-Test Battery Meter

MOUNT INSTALLATION
TOOLS AND RESOURCES REQUIRED:
• #3 Phillips Screw Driver
• Drill
• 9/32” Drill Bit
• 7/16” Box End Wrench
• A second person to help with the installation
1. Remove the four sideplate screws. Remove the right sideplate and swing the left sideplate out and away from the base
extrusion.
2. Place the motor on the bow of the boat in the deployed position.
a. We recommend that the motor be mounted as close to the centerline of the boat as possible.
b. Make sure that the area under the mounting location is clear and unobstructed
for drilling and accessible for you to attach nuts and washers.
c. Make sure the mount is positioned so that the shaft is out beyond the rub rail of the boat by 1-1/2”. The lower unit, as it is
lowered into the water or raised into the boat, must not encounter any obstructions.
CAUTION: Make sure the motor is mounted on a level surface and is not connected to
a power source. Use the rubber washers to create a leve surface if necessary.
3. Once in position, mark four of the six holes (two on each side) provided in the bow mount base for drilling. If possible, use the
four holes that are farthest apart. Drill through the marked holes using the 9/32” drill bit.
4. Mount the plate to the bow using the provided bolts, nuts, and washers.
5. Replace the sideplates and sideplate screws.
Mounting Holes
(3 Per Side)

BOAT RIGGING & PRODUCT INSTALLATION
For safety and compliance reasons, we recommend that you follow American Boat and Yacht Council (ABYC) standards when
rigging your boat. Altering boat wiring should be completed by a qualified marine technician. The following specifications are for
general guidelines only:
CAUTION: These guidelines apply to general rigging to support your Minn Kota motor. Powering multiple motors or additional
electrical devices from the same power circuit may impact the recommended conductor gauge and circuit breaker size. If you are
using wire longer than that provided with your unit, follow the conductor gauge and circuit breaker sizing table below. If your wire
extension length is more than 25 feet, we recommend that you contact a qualified marine technician.
An over-current protection device (circuit breaker or fuse) must be used. Coast Guard requirements dictate that
each ungrounded current-carrying conductor must be protected by a manually reset, trip-free circuit breaker or fuse. The type
(voltage and current rating) of the fuse or circuit breaker must be sized accordingly to the trolling motor used. The table below gives
recommended guidelines for circuit breaker sizing.
Reference:
United States Code of Federal Regulations: 33 CFR 183 – Boats and Associated Equipment
ABYC E-11: AC and DC Electrical Systems on Boats
CONDUCTOR GAUGE AND CIRCUIT BREAKER SIZING TABLE
Motor Thrust /
Model Max Amp Draw Circuit Breaker Wire Extension Length *
5 feet 10 feet 15 feet 20 feet 25 feet
30 lb. 30 50 Amp @ 12 VDC 10 AWG 10 AWG 8 AWG 6 AWG 4 AWG
40 lb., 45 lb. 42 10 AWG 8 AWG 6 AWG 4 AWG 4 AWG
50 lb., 55 lb. 50 60 Amp @ 12 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
70 lb. 42 50 Amp @ 24 VDC 10 AWG 10 AWG 8 AWG 8 AWG 6 AWG
80 lb. 56 60 Amp @ 24 VDC 8 AWG 8 AWG 8 AWG 6 AWG 6 AWG
101 lb. 46 50 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 101 50 60 Amp @ 36 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
112 lb. 52 60 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 160 116 (2) x 60 Amp @ 24 VDC 2 AWG 2 AWG 2 AWG 2 AWG 2 AWG
E-Drive 40 50 Amp @ 48 VDC 10 AWG 10 AWG 10 AWG 10 AWG 10 AWG
This conductor and circuit breaker sizing table is only valid for the following assumptions:
1. No more than 3 conductors are bundled together inside of a sheath or conduit outside of engine spaces.
2. Each conductor has 105° C temp rated insulation.
3. No more than 5% voltage drop allowed at full motor power based on published product power requirements.
*Wire Extension Length refers to the distance from the batteries to the trolling motor leads.
BATTERY WIRING & INSTALLATION

BATTERY WIRING & INSTALLATION
CONNECTING THE BATTERIES IN SERIES (IF REQUIRED FOR YOUR MOTOR)
24 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “0”).
2. Two 12 volt batteries are required.
3. The batteries must be wired in series, only as directed in wiring
diagram, to provide 24 volts.
a. Connect a connector cable to the positive ( + ) terminal of
battery 1 and to the negative ( – ) terminal of battery 2.
b. Connect positive ( + ) red motor lead to
positive ( + ) terminal on battery 2.
c. Connect negative ( – ) black motor lead to
negative ( – ) terminal of battery 1.
4. For safety reasons do not switch the motor on until the propeller is in the water. If installing a leadwire plug, observe proper
polarity and follow instructions in your boat owner’s manual. See wiring diagram on following pages.
CAUTION
• For safety reasons, disconnect the motor from the battery or batteries when the motor is not in use or while
the battery/batteries are being charged.
• Improper wiring of 24/36 volt systems could cause battery explosion!
• Keep leadwire wing nut connections tight and solid to battery terminals.
• Locate battery in a ventilated compartment.
To trolling motor negative
24 Volt Series Connection
Battery #1 (Low Side)
Neg - Neg -Pos + Pos +
Battery #2 (High Side)
+24 Volts to trolling motor
positive (or circuit breaker)
Two 12-volt batteries connected in series for 24 volts
SELECTING THE CORRECT BATTERIES
The motor will operate with any lead acid, deep cycle marine 12 volt battery/batteries. For best results, use a deep cycle, marine
battery with at least a 105 ampere hour rating. Maintain battery at full charge. Proper care will ensure having battery power
when you need it, and will significantly improve the battery life. Failure to recharge lead-acid batteries (within 12-24 hours) is the
leading cause of premature battery failure. Use a multi-stage charger to avoid overcharging. We offer a wide selection of chargers
to fit your charging needs. If you are using a crank battery to start a gasoline outboard, we recommend that you use a separate
deep cycle marine battery/batteries for your Minn Kota trolling motor.
Advice Regarding Batteries:
• Never connect the (+) and the (–) terminals of the same battery together. Take care that no metal object can fall onto the
battery and short the terminals. This would immediately lead to a short and extreme fire danger.
• It is highly recommended that a circuit breaker or fuse be used with this trolling motor. Refer to “Conductor Gauge and Circuit
Breaker Sizing Table” in the previous section to find the appropriate circuit breaker or fuse for your motor. For motors requiring
a 60-amp breaker, the Minn Kota MKR-19 60-amp circuit breaker is recommended.
CONNECTING THE BATTERIES
12 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “OFF” or “0”).
2. Connect positive ( + ) red lead to positive ( + ) battery terminal.
3. Connect negative ( – ) black lead to negative ( – ) battery terminal.
4. For safety reasons do not switch the motor on until the propeller is in the water.
CAUTION:
For safety reasons, disconnect the motor from the battery/batteries when the motor is not in use or while the
battery/batteries are being charged.

CONNECTING THE BATTERIES IN SERIES (IF REQUIRED FOR YOUR MOTOR)
24 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “0”).
2. Two 12 volt batteries are required.
3. The batteries must be wired in series, only as directed in wiring
diagram, to provide 24 volts.
a. Connect a connector cable to the positive ( + ) terminal of
battery 1 and to the negative ( – ) terminal of battery 2.
b. Connect positive ( + ) red motor lead to
positive ( + ) terminal on battery 2.
c. Connect negative ( – ) black motor lead to
negative ( – ) terminal of battery 1.
4. For safety reasons do not switch the motor on until the propeller is in the water. If installing a leadwire plug, observe proper
polarity and follow instructions in your boat owner’s manual. See wiring diagram on following pages.
CAUTION
• For safety reasons, disconnect the motor from the battery or batteries when the motor is not in use or while
the battery/batteries are being charged.
• Improper wiring of 24/36 volt systems could cause battery explosion!
• Keep leadwire wing nut connections tight and solid to battery terminals.
• Locate battery in a ventilated compartment.
To trolling motor negative
24 Volt Series Connection
Battery #1 (Low Side)
Neg - Neg -Pos + Pos +
Battery #2 (High Side)
+24 Volts to trolling motor
positive (or circuit breaker)
Two 12-volt batteries connected in series for 24 volts
36 VOLT SYSTEMS:
1. Make sure that the motor is switched off
(speed selector on “0”).
2. Three 12 volt batteries are required.
3. The batteries must be wired in series, only as
directed in wiring diagram, to provide 36 volts.
a. Connect a connector cable to the positive
( + ) terminal of battery 1 and to the
negative ( – ) terminal of battery 2 and
another connector cable from the positive
( + ) terminal of battery 2 to the negative
( – ) terminal of battery of battery 3.
b. Connect positive ( + ) red motor lead to positive ( + ) terminal on battery 3.
c. Connect negative ( – ) black motor lead to negative ( – ) terminal of battery 1.
4. For safety reasons do not switch the motor on until the propeller is in the water. If installing a leadwire plug, observe proper
polarity and follow instructions in your boat owner’s manual. See wiring diagram on following pages.
CAUTION
• Improper wiring of 24/36 volt systems could cause battery explosion!
• Keep leadwire wing nut connections tight and solid to battery terminals.
• Locate battery in a ventilated compartment.
• For safety reasons, disconnect the motor from the battery or batteries when the motor is not in use or while
the battery/batteries are being charged.
To trolling motor negative
24 Volt Series Connection 36 Volt Series Connection
Battery #1 (Low Side)
Neg - Neg - Neg -Pos + Pos + Pos +
Battery #2 (Middle) Battery #3 (High Side)
+36 Volts to trolling motor
positive (or circuit breaker)
Three 12-volt batteries connected in series for 36 volts
BATTERY WIRING & INSTALLATION
PUSH-TO-TEST BATTERY METER
This motor is equipped with a “push-to-test” battery meter. The LED light provides an accurate
display of the remaining charge in the battery. It is only accurate when the motor is off.
The meter reads as:
• One light indicates recharge.
• Two lights indicate low charge.
• Three lights indicate good charge.
• Four lights indicate full charge.

MOTOR WIRING DIAGRAM
NOTE: This is a universal, multi-voltage diagram. Double check your motor's voltage for proper connections. Over-Current
Protection Devices not shown in this illustration.
B+
M+
B-
M-
12v
24v
36v
BATTERY GAUGE STEERING MOTOR
COMPASS
RED
BROWN
BLACK
BLACK M-
RED M+
SENSOR
BOARD
AUTOPILOT ON EQUIPPED MOTORS ONLY
COIL CORD
UNIVERSAL SONAR 2 EXTENSION WIRE*
ACCESSORY PLUG
BROWN*
RED M+
BLACK M-
MOTOR
FUSE*
UNIVERSAL
SONAR 2 WIRE*
* UNIVERSAL SONAR2 MOTORS ONLY
BATTERY 1 BATTERY 2 BATTERY 3
BATTERY 1 BATTERY 2
BATTERY 1
BLACK B-
RED B+
WHITE
BLACK
ACCESSORY PLUG
AUTOPILOT INDICATOR, RED
SYSTEM READY, INDICATOR, GREEN
REED SWITCH
FOOT PEDAL
CONTROL BOARD
AUTOPILOT INDICATOR, RED
MOMENTARY/CONSTANT
INDICATOR, GREEN
SPEED ADJUSTMENT
KNOB
CONTROL BOARD

USING & ADJUSTING THE MOTOR
STOWING AND DEPLOYING THE MOTOR
WARNING:
When raising or lowering the motor, keep fingers clear of all hinge and pivot points and all moving parts.
GENERAL
System Ready (green LED): The motor is equipped with a system ready indicator. Indicator light will be on when motor is
deployed and power is applied to the motor. When the motor is properly stowed the indicator light will go off indicating all power
has been turned off to the motor. If this indicator light does not come on when deployed, check that motor is connected to battery
properly and motor is completely deployed. If indicator light does not go off when stowed, be sure that stow/deploy lever is fully
latched and locked into the stowed position.
TO DEPLOY THE MOTOR
Push in and rotate the stow/deploy lever down. Gently slide the motor out from the ramps. Lower the motor to the desired depth,
making sure that it clicks into a secure, verticle position. The System Ready indicator light (green) will be lit, indicating motor is
ready for operation.
TO STOW THE MOTOR
Push and hold the stow/deploy lever down. Gently tilt and pull the composite shaft or control head until the motor engages the
motor ramps. Motor should rest on the motor ramps and lock into place. The stow/deploy lever should latch automatically into the
stowed position. The system ready indicator light (green) MUST go off for the motor to be stowed properly.
TRANSPORTATION
In conditions where the stowed motor is subject to high levels of shock or vibration, ensure the motor is securely stowed. Move
the depth collar snug against the steering motor and tighten.
STOW/DEPLOY LEVER OPERATION:
1. Push in
2. Push down
Fall Away Ramps
System Ready
Indicator
Stow/Deploy
Lever
1
2
Depth Collar Steering Housing

USING & ADJUSTING THE MOTOR
AUTOPILOT™ CONTROLS
(ON AUTOPILOT EQUIPPED MOTORS ONLY)
The Minn Kota AutoPilot™uses a magnetic compass and a microprocessor chip to keep the trolling motor pointed in the direction
you want to go. Each time the wind or water current moves the boat off course, the AutoPilot senses the change and steers itself
back to the original heading. The AutoPilot direction is set every time a steering change is made. To change direction, steer until
the control head points to the desired course. The AutoPilot will pull the bow of the boat around and correct automatically until
the boat is moving in the direction you chose.
1. This unit has an automatic steering shutdown for safety. In conditions where an obstruction prevents the trolling motor from
turning, or in extremely windy conditions, the automatic steering may stop. Any steering input will reset the system to normal.
2. When the AutoPilot is on and the trolling motor is pulled out of the water to the stow position, the steering motor will continue
to run until the motor is stowed properly. Once the motor is stowed properly, AutoPilot will turn off and the System Ready
indicator will go off.
3. This unit uses a magnetic compass to detect direction of travel. The compass can be adversely affected by magnets or large,
ferrous metal objects near (within 12” of) the trolling motor control head.
4. After steering to a new direction, there is a short delay before the direction is locked in to allow the compass to stabilize.
5. Obstructions on the propeller may cause excessive vibration of the motor head. This vibration can cause the compass to
wander and erratic steering to occur. Clear the obstruction to return the motor to normal operation.
6. When broad speed changes are made, the motor heading may change slightly. This is normal.
ADJUSTING THE DEPTH OF THE MOTOR
When setting the depth be sure the top of the motor is submerged
at least 12” to avoid churning or agitation of surface water. The
propeller must be completely submerged.
1. With the motor deployed, firmly grasp the composite shaft above
the mount.
2. Loosen the adjustable depth collar until the shaft slides freely.
3. Raise or lower the motor to the desired depth.
4. Turn the motor control head to the desired position.
5. Tighten adjustable depth collar to secure the motor in place.
Adjustable Depth Collar
Motor Mount
Composite Shaft
12” Minimum Depth

AUTOPILOT™ CONTROLS
(ON AUTOPILOT EQUIPPED MOTORS ONLY)
The Minn Kota AutoPilot™uses a magnetic compass and a microprocessor chip to keep the trolling motor pointed in the direction
you want to go. Each time the wind or water current moves the boat off course, the AutoPilot senses the change and steers itself
back to the original heading. The AutoPilot direction is set every time a steering change is made. To change direction, steer until
the control head points to the desired course. The AutoPilot will pull the bow of the boat around and correct automatically until
the boat is moving in the direction you chose.
1. This unit has an automatic steering shutdown for safety. In conditions where an obstruction prevents the trolling motor from
turning, or in extremely windy conditions, the automatic steering may stop. Any steering input will reset the system to normal.
2. When the AutoPilot is on and the trolling motor is pulled out of the water to the stow position, the steering motor will continue
to run until the motor is stowed properly. Once the motor is stowed properly, AutoPilot will turn off and the System Ready
indicator will go off.
3. This unit uses a magnetic compass to detect direction of travel. The compass can be adversely affected by magnets or large,
ferrous metal objects near (within 12” of) the trolling motor control head.
4. After steering to a new direction, there is a short delay before the direction is locked in to allow the compass to stabilize.
5. Obstructions on the propeller may cause excessive vibration of the motor head. This vibration can cause the compass to
wander and erratic steering to occur. Clear the obstruction to return the motor to normal operation.
6. When broad speed changes are made, the motor heading may change slightly. This is normal.
INSTALLING AN EXTERNAL TRANSDUCER
An external sonar transducer can be installed onto the motor as shown.
1. Transducer cables should be routed through the coil cable as
depicted in the illustration to the right.
2. Leave enough slack for proper stow and deploy.
3. Mount transducer according to transducer instructions.
Note: An external transducer is not included with your trolling motor.
Your trolling motor may be pre-installed with a Universal Sonar 2
transducer system. In this case, the transducer is integrated into the
motor unit.
ACCESSORY RECOMMENDATIONS:
• Minn Kota Transducer Mounting Kit (MKR-15)
Leave slack
Leave slack
Tie wrap cable
Tie wrap cable
Transducer
Transducer
cable
USING & ADJUSTING THE MOTOR

All the controls in the foot pedal are easy to operate by either foot or hand. A light touch is all that is necessary.
MOMENTARY
A toe touch on either of the two momentary buttons
turns the propeller on. Let up and the propeller stops.
MOM/CON SWITCH
A toe touch to the Mom/Con button toggles the motor
between momentary and constant. When the motor
is in constant the propeller will run continuously with
out keeping your foot on the pedal. When the motor
is in momentary, a toe touch is required to one of the
momentary on buttons to turn the propeller on. The
Constant On indicator light will be lit when the motor is
in constant state.
RIGHT/LEFT
Place your foot in the center of the heel/toe pedal, rocking forward steers right. Rocking back steers left. Left and right steering
control can also be done with the Left/Right steering buttons. Holding the left or right steering button down steers left or right.
Small steering changes of less than one degree can be made by quickly and lightly tapping the left or right steering controls.
NOTE: The steering system is designed to turn your motor 360°. Be careful to avoid over-wrapping the coil cord around the
composite shaft.
FORWARD/REVERSE
The propeller always turns in the forward direction. You can reverse the direction of thrust by turning the motor 180˚.
SPEED CONTROL
The speed selector is the rotating knob on the right side of the foot pedal. The speed control knob provides variable speed
control. Use your hand or foot to rotate the knob to adjust speed.
AUTOPILOT (AUTOPILOT MODELS ONLY)
A toe touch to the AP button toggles the AutoPilot On and Off. The AutoPilot On indicator light will be lit on the foot pedal and
the center console of the motor when AutoPilot is on.
NON-CARPETED BOAT USE
Enclosed with your motor are four (4) rubber bumpers. If the foot pedal is to be used primarily on non-carpeted surfaces, insert
the rubber bumpers into the keyhole slots on the underside of the pedal. Slide the bumpers into the slot until they are locked into
position.
Momentary on
AutoPilot
“ON” / “OFF”
Momentary / Constant
“ON” / “OFF”
Left steer
Heel/toe
steering
Variable speed
control
Right
steer
Momentary on
USING THE FOOT PEDAL

Propeller
Slot End
Drive Pin
Prop Nut
Washer
PROPELLER REPLACEMENT
TOOLS AND RESOURCES REQUIRED:
• Box End Wrench
- 1/2” for motors with 70 lbs thrust or lower.
- 9/16” for motors with 80 lbs thrust or higher.
• Screwdriver (optional)
CAUTION:
Disconnect the motor from the battery
before beginning any prop work or
maintenance.
NOTE: The propeller on your motor may differ from
the one pictured.
1. Disconnect the motor from all sources of power prior to changing the propeller.
2. Hold the propeller and loosen the prop nut with pliers or a wrench.
3. Remove the prop nut and washer. If the drive pin is sheared or broken, you will need to hold the shaft stationary with a blade
screwdriver pressed into the slot on the end of the shaft.
4. Turn the old prop to horizontal (as illustrated) and pull it straight off. If drive pin falls out, push it back in.
5. Align the new propeller with the drive pin.
6. Install the prop washer and prop nut.
7. Tighten the prop nut 1/4 turn past snug [25-35 inch lbs.] Do not over tighten as this can damage the prop.
GENERAL MAINTENANCE
• After use, the entire motor should be rinsed with freshwater. This series of motors is not equipped for saltwater exposure.
• The composite shaft requires periodic cleaning and lubrication for proper retraction and deployment. A coating of an aqueous
based silicone spray will improve operation.
• The propeller must be inspected and cleaned from weeds and fishing line after every use.
Fishing line and weeds can get behind the prop, damage the seals and allow water to enter the motor.
• Verify the prop nut is secure each time the motor is used.
• To prevent accidental damage during transportation or storage, disconnect the battery whenever the motor is off of the water.
For prolonged storage, lightly coat all metal parts with an aqueous based silicone spray.
• For maximum battery life recharge the battery(s) as soon as possible after use. For maximum motor performance restore
battery to full charge prior to use.
• Keep battery terminals clean with fine sandpaper or emery cloth.
• The propeller is designed to provide weed free operation with very high efficiency. To maintain this top performance, the
leading edge of the blades must be kept smooth. If they are rough or nicked from use, restore to smooth by sanding with fine
sandpaper.
All the controls in the foot pedal are easy to operate by either foot or hand. A light touch is all that is necessary.
MOMENTARY
A toe touch on either of the two momentary buttons
turns the propeller on. Let up and the propeller stops.
MOM/CON SWITCH
A toe touch to the Mom/Con button toggles the motor
between momentary and constant. When the motor
is in constant the propeller will run continuously with
out keeping your foot on the pedal. When the motor
is in momentary, a toe touch is required to one of the
momentary on buttons to turn the propeller on. The
Constant On indicator light will be lit when the motor is
in constant state.
RIGHT/LEFT
Place your foot in the center of the heel/toe pedal, rocking forward steers right. Rocking back steers left. Left and right steering
control can also be done with the Left/Right steering buttons. Holding the left or right steering button down steers left or right.
Small steering changes of less than one degree can be made by quickly and lightly tapping the left or right steering controls.
NOTE: The steering system is designed to turn your motor 360°. Be careful to avoid over-wrapping the coil cord around the
composite shaft.
FORWARD/REVERSE
The propeller always turns in the forward direction. You can reverse the direction of thrust by turning the motor 180˚.
SPEED CONTROL
The speed selector is the rotating knob on the right side of the foot pedal. The speed control knob provides variable speed
control. Use your hand or foot to rotate the knob to adjust speed.
AUTOPILOT (AUTOPILOT MODELS ONLY)
A toe touch to the AP button toggles the AutoPilot On and Off. The AutoPilot On indicator light will be lit on the foot pedal and
the center console of the motor when AutoPilot is on.
NON-CARPETED BOAT USE
Enclosed with your motor are four (4) rubber bumpers. If the foot pedal is to be used primarily on non-carpeted surfaces, insert
the rubber bumpers into the keyhole slots on the underside of the pedal. Slide the bumpers into the slot until they are locked into
position.
Momentary on
AutoPilot
“ON” / “OFF”
Momentary / Constant
“ON” / “OFF”
Left steer
Heel/toe
steering
Variable speed
control
Right
steer
Momentary on
SERVICE & MAINTENANCE

1. Motor fails to run or lacks power:
• Check battery connections for proper polarity.
• Make sure terminals are clean and corrosion free. Use fine sandpaper or emery cloth to clean terminals.
• Check battery water level. Add water if needed.
2. Motor loses power after a short running time:
• Check battery charge. If low, restore to full charge.
3. You experience prop vibration during normal operation:
• Remove and rotate the prop 180°. See removal instructions in the Propeller Replacement Section.
4. Experiencing interference with your fishfinder:
TROUBLESHOOTING & REPAIR

Part #2324951 ECN 36894
This page provides Minn Kota® WEEE compliance disassembly instructions.
For more information about where you should dispose of your waste equipment
for recycling and recovery and/or your European Union member state require-
ments, please contact your dealer or distributor from which your product was
purchased.
Tools required, but not limited to: flat head screw driver,
Phillips screw driver, socket set, pliers, wire cutters.
TERROVA 80
80 LBS THRUST - 24 VOLT - 45”/54”/60”/72” SHAFT
210
215 220
AutoPilot
Equipped
Motors Only
225
230
235
245
250
270
260
255
265
275
321 315
305
300
200
325
415
420
410
425
430
330
345
335
350
355
370
380
385
390
395
405
400
435
440
445
430
425
420
450
410
465
485
480
495
490475
500
470
640
635
645
685
630
660
665
670
680
675
650
655
625
620
530
525
535 540
550
555
575
605
570
565
560
600
580
690
725
715
700
695 710
735
730
636
595
757
750
590
585
580
755
775 780
760
765
770
850
860
851
865
870
880
936
930
935
915
925
940
980
975
985 990
950
970
965
960
955
920
900
910
885
875
240
137
136
135
745
740
455
500
720
545
510
585
320
205
30
70
10
5
20
115
120
85
65
50
110
90
80
60
35
100
95
15
25
40
1010
1000
1020
1015
1
125
526
527
528
241
590
945
571
PARTS DIAGRAM

TERROVA 80
80 LBS THRUST - 24 VOLT - 45”/54”/60”/72” SHAFT
ITEM QTY PART
NUMBER DESCRIPTION
1 1 2777000 24V MOTOR 45” FW
12777001 24V MOTOR 54” FW
12777002 24V MOTOR 60” FW
12777005 24V MOTOR US2 45”
12777003 24V MOTOR US2 54”
12777004 24V MOTOR US2 60”
12777013 24V MOTOR US2 72”
5 1 2-100-214 ARMATURE ASSEMBLY
10 1140-010 BEARING
15 1788-040 RETAINING RING
20 INCLUDED IN #200 ASSY
25 12-300-170 BRUSH END HSING ASSY
30 1421-276 PLAIN END HSING ASSY STD
19421-284 PLAIN END HOUSING US2 45”
19421-285 PLAIN END HOUSING US2 54”
19421-286 PLAIN END HOUSING US2 60”
19421-291 PLAIN END HOUSING US2 72”
35 1144-017 FLANGE BEARING
40 2880-025 SEAL
50 2188-094 BRUSH
60 12-600-193 BRUSH PLATE ASSEMBLY 45”
2-600-192 BRUSH PLATE ASSEMBLY 54”
2-600-199 BRUSH PLATE ASSEMBLY 60”
65 2975-041 BRUSH SPRING
70 2701-043 MOTOR O-RING
80 2701-009 O-RING — THRU-BOLT
85 2830-027 SCREW, 10-32 X 2
90 2830-094 THRU-BOLT
2830-095 THRU-BOLT SONAR ONLY
95 2990-051 WASHER — STEEL
100 2990-052 WASHER — NYLATRON
110 2973-025 SPACER — BRUSH PLATE
115 2992-010 WASHER — BELLEVILLE
120 1990-045 SPACER — THRUST
125 1582-013 CLIP, RETAINING, SHORT
135 1640-013 LEADWIRE — BLACK 45”
1640-017 LEADWIRE — BLACK 54”
1640-025 LEADWIRE — BLACK 60”
1640-024 LEADWIRE — BLACK 72”
136 1640-117 LEADWIRE — RED 45”
1640-132 LEADWIRE — RED 54”
1640-133 LEADWIRE — RED 60”
1640-125 LEADWIRE — RED 72”
137 1640-315 GROUNDWIRE — BROWN, US2 ONLY 45”
1640-316 GROUNDWIRE — BROWN, US2 ONLY 54”
1640-317 GROUNDWIRE — BROWN, US2 ONLY 60”/72”
200 12777096 COMPOSITE TUBE 60” FW
12777097 COMPOSITE TUBE 72” FW
205 INCLUDED IN #200 ASSY
ITEM QTY PART
NUMBER DESCRIPTION
210 22325665 DECAL — COVER
215 12325674 DECAL — CTRL BOX 80
12325675 DECAL — CTRL BOX 80 US2
12325676 DECAL — CTRL BOX 80 AUTOPILOT
12325677 DECAL — CTRL BOX 80 AUTOPILOT & US2
220 12320200 COVER, CTRL BOX
225 12324032 CTRL BOARD, COMPASS, AUTOPILOT ONLY
230 32302960 GROMMET — COMPASS AUTOPILOT ONLY
235 22065400 WIRE INSULATOR
240 12218200 FUSE HOLDER — US2 ONLY
241 22375400 SHRINK TUBE — 1/4” OD X 1 3/4”
245 32372100 SCREW — 8-18 X .625
250 32052510 CABLE CLAMP
255 12322500 CTRL BOX
260 12332102 SCREW — 10-24
265 42372100 SCREW — 8-18 X .625
270 12333101 NUT — 10-24
275 12224700 PLUG — CTRL BOX SMALL HOLE - US2
12224702 PLUG — CTRL BOX NO HOLE
12224704 PLUG — CTRL BOX LARGE HOLE - US2/LINK
300 12211415 UNIVERSAL SONAR 2 EXTENSION CABLE
305 12771500 DEPTH COLLAR ASSY
315 12260906 KNOB (INCLUDED IN #305)
320 12321702 WASHER (INCLUDED IN #305)
321 12323102 NUT (INCLUDED IN #305)
325 12997020 STEERING HOUSING
330 12326501 STEERING HOUSING TOP
335 12324604 O-RING, CASE SEAL
345 42305605 ROLL PIN 5/16
350 12308601 BREATHER, FILTER
355 12328610 CRADLE, MOTOR
370 12777020 MOTOR, STEERING ASSY
380 12302255 GEAR CLUSTER (3RD STAGE)
385 12302250 GEAR CLUSTER (2ND STAGE)
390 12302245 GEAR CLUSTER (1ST STAGE)
395 12302610 GEAR SHAFT (1ST STAGE)
400 12302620 GEAR SHAFT (3RD STAGE)
405 12302615 GEAR SHAFT (2ND STAGE)
410 22321704 WASHER — THRUST
415 12321515 LINER — OUTPUT TUBE
420 22324608 O-RING — 224
425 22321720 SHIM — O-RING
430 22327308 SEALED BALL BEARING
435 12322200 GEAR — OUTPUT
440 12324601 O-RING — OUTPUT GEAR
445 12322030 TUBE — OUTPUT MACHINED
450 12321510 COLLAR, DRIVE BOTTOM
455 12326506 STEERING HOUSING, BOTTOM
465 12322600 PIN — LATCH, ZINC PLATE
470 12322602 PIN — PIVOT, ZINC PLATE
475 22327310 BUSHING, PIVOT PIN
480 22321702 WASHER, FLAT .375
PARTS LIST

ITEM QTY PART
NUMBER DESCRIPTION
485 22263011 E-RING .375
490 22322702 SPRING — LATCH PIN
495 12323410 SCREW, 8-32 X .75
500 72323408 SCREW, 8-32 X 2
510 12090651 LEADWIRE — 10 GA
525 12991274 COIL CORD, US2, 45”
12991272 COIL CORD, US2, 54” / 60” / 72”
526 12325401 SHRINK TUBE — 3/4” ID X 2” W/ADHS
527 12307313 BEAD — FERRITE
528 12320710 TERMINAL AMP (T-TAB)
530 12320202 CAP, DUST, COIL CORD —NON-AP ONLY
535 12325641 DECAL, SIDEPLATE, LEFT
540 42323404 SCREW, 1/4-20
545 12321915 SIDEPLATE, LEFT
550 22323403 SCREW, 1/4-20 X .375
555 12321925 SKID, LEFT
560 22323422 SCREW, 10-24 X .375
565 22321700 WASHER, #10 SS
570 22322920 STAND-OFF, ALUM PLAIN
571 12323405 SCREW, 1/4” - 20 X 1/2” MCH SS
575 12323905 RAMP — 4” LEFT
580 42325115 PAD — RUBBER REST
585 42321706 WASHER, #8
590 42323412 SCREW, 8-18 X .25
595 22324705 INSERT — RAMP
600 12994202 RELEASE ARM ASSEMBLY
605 22322710 SPRING — EXTENSION
n12770250 COVER — SPEED CONTROL WITH DECAL
620 12325650 DECAL, SPEED CONTROL
625 12320210 COVER, SPEED CONTROL
630 12322901 STRAIN RELIEF
635 12324019 CONTROL BOARD, 24-36V STANDARD (2 PLUGS)
12324023 CONTROL BOARD, 24-36V IPILOT & LINK (1 PLUG)
n2884050 SWITCH — REED REPAIR KIT
636 12320208 DUST PLUG
640 12320203 CAP, DUST, CTRL BOARD
645 22323406 SCREW, 10-24 X .50 CRPH SS
650 12321315 HOLDER, CONNECTOR
655 22332103 SCREW, 6-20 X .375
660 12074071 BATTERY METER, 24V
665 42323402 SCREW, 1/4-20 X .375
670 12321940 BRACKET, STRAIN RELIEF
675 12321310 STRAIN RELIEF, WIRE
680 12323405 SCREW, 1/4-20 X .5
685 22013100 SPEED NUT, .375
690 12320215 HANDLE, RELEASE CVR
695 12301700 BUSHING, SPACER - RELEASE LEVER - BRASS
700 12322701 TORSION SPRING
710 12320400 HANDLE, RELEASE FW
715 22322712 RELEASE HANDLE SPRING
720 22322604 BUSHING, HANDLE
725 22332104 SCREW, 1/4-20 X .625
ITEM QTY PART
NUMBER DESCRIPTION
730 22323000 E-CLIP, 3/16, SS
735 12322606 PIN, FOLLOWER, HANDLE
740 12321905 BASE EXTRUSION, MACH
745 22322912 SPRING PIN,
750 12321950 BRACKET, SIDEPLATE
755 12323900 RAMP — 4” RIGHT
757 12994204 ARM, RELEASE, RIGHT
760 12321920 SKID, RIGHT
765 32301310 SCREW, 8-18 X .5
770 12320220 COVER, ACCESS, FW
775 12321910 SIDEPLATE, RIGHT
780 12325640 DECAL, SIDEPLATE, RIGHT
850 12994720 FOOT PEDAL
851 12326710 PLUG, FOOT PEDAL
860 12324400 PEDAL, HEEL-TOE
865 12322714 SPRING, MOMENTARY
870 22321300 CLAMP
875 42223430 SCREW, 8 X .75
880 12328600 FLEX FINGER
885 12323710 BUTTON, MOMENTARY, LEFT
900 12325660 DECAL, FOOT PEDAL
910 12320205 COVER, HEEL-TOE
915 12323725 BUTTON, AP
920 12323715 BUTTON, MOM/CON
925 12320100 KNOB, SPEED, FOOT PEDAL
930 22332103 SCREW, 6-20 X .375
935 12324021 CONTROL BOARD, FT PEDAL
936 12320207 DUST CAP
940 12322900 STRAIN RELIEF, FT PEDAL
945 12324500 BASE PLATE, FT PEDAL
950 10 2301310 SCREW, #8 X .5
955 12323730 BUTTON, STEER, LEFT
960 12323735 BUTTON, MOMENTARY
965 12323701 BUTTON, STEER, RIGHT
970 52322704 SPRING, FOOT PEDAL
975 12994859 BUMPER, BAG ASSY
980 22322706 SPRING, BARREL
985 22323420 SCREW, 8-18 X .375
990 22372100 SCREW, 8-18 X .625
n1378132 PROPELLER KIT WW2
n2994876 PROPELLER BAG ASSY
1000 12331160 PROPELLER WW2
1010 12262658 DRIVE PIN, LARGE
1015 12091701 WASHER, PROP, LARGE
1020 12093101 NUT, NYLOCK, PROP, LARGE
n2994864 MOUNTING HARDWARE BAG ASSY
n2889460 SEAL & ORING KIT
TERROVA 80
80 LBS THRUST - 24 VOLT - 45”/54”/60”/72” SHAFT
PARTS LIST

ENVIRONMENTAL COMPLIANCE STATEMENT:
It is the intention of JOME to be a responsible corporate citizen, operating in compliance with known and applicable
environmental regulations, and a good neighbor in the communities where we make or sell our products.
WEEE DIRECTIVE:
EU Directive 2002/96/EC “Waste of Electrical and Electronic Equipment Directive (WEEE)” impacts most distributors, sellers,
and manufacturers of consumer electronics in the European Union. The WEEE Directive requires the producer of consumer
electronics to take responsibility for the management of waste from their products to achieve environmentally responsible
disposal during the product life cycle.
WEEE compliance may not be required in your location for electrical & electronic equipment (EEE), nor may it be required
for EEE designed and intended as fixed or temporary installation in transportation vehicles such as
automobiles, aircraft, and boats. In some European Union member states, these vehicles are considered
outside of the scope of the Directive, and EEE for those applications can be considered excluded from the
WEEE Directive requirement.
This symbol (WEEE wheelie bin) on product indicates the product must not be disposed of with other
household refuse. It must be disposed of and collected for recycling and recovery of waste EEE. Johnson
Outdoors Inc. will mark all EEE products in accordance with the WEEE Directive. It is our goal to comply
in the collection, treatment, recovery, and environmentally sound disposal of those products; however, these requirement do
vary within European Union member states. For more information about where you should dispose of your waste equipment for
recycling and recovery and/or your European Union member state requirements, please contact your dealer or distributor from
which your product was purchased.
COMPLIANCE STATEMENTS

• 60-Amp Circuit Breaker
• Mounting Brackets
• Stabilizer Kits
• Extension Handles
• Battery Connectors
• Battery Boxes
• Quick Connect Plugs
RECOMMENDED ACCESSORIES
ON-BOARD & PORTABLE BATTERY CHARGERS
Stop buying new batteries and start taking care of the ones you’ve got. Many chargers can actually damage your battery
over time – creating shorter run times and shorter overall life. Digitally controlled Minn Kota chargers are designed to provide the
fastest charge that protect and extend battery life.
TALON SHALLOW WATER ANCHOR
Talon deploys faster, holds stronger and runs quieter than any other shallow water anchor. Available in depths up to 12’ and bold color
options including camo, it boasts an arsenal of features and innovations that no other anchor can touch:
MINN KOTA ACCESSORIES
We offer a wide variety of trolling motor accessories, including:
MK210DMK345PC MK110P
• Vertical, Multi-Stage Deployment
• User-Selectable Anchoring Modes
• 2x Anchoring Force
• Fast Deploy
• Auto Up/Down
• Triple Debris Shields
• Built-In Wave Absorption
• Noise Dissipation
• Versatile Adjustments
