Contents
1. Parts Identification
Parts Identification ..................................................................................................................... 1
2. Accessory Identification
Accessory Identification............................................................................................................. 2
3.GettingtoKnowtheBasics
Types of Film and Correct Holders for Placement .................................................................... 3
When Making Copies................................................................................................................. 3
Operating Precautions................................................................................................................ 4
4. Operation Flow
Operation Flow........................................................................................................................... 5
5. Setting up the Projector
Setting up the Projector.............................................................................................................. 6
6. Making Copies From Film
Making Copies From Film......................................................................................................... 7
Setting the Projector Adjustment ............................................................................................. 10
Using a Different Type of Film / Performing Shading Again.................................................. 11
Shutting Down the Projector.................................................................................................... 11
7. Troubleshooting Tips
Copy Image Problems.............................................................................................................. 12
Faulty Shading.......................................................................................................................... 12
Faulty Symptoms...................................................................................................................... 13
Making the Film Standard........................................................................................................ 13
Adjusting Focus........................................................................................................................ 14
Cleaning ................................................................................................................................... 15
8. Specifications
Specifications........................................................................................................................... 16
9. Function Combination Matrix
Function Combination Matrix.................................................................................................. 17
10. Description of Paper Size and Zoom Ratio Table
Description of Paper Size and Zoom Ratio Table.................................................................... 19

1
1. Parts Identification
Parts Identification Power Cord
Plug the Power Cord into a power outlet
when you use the Film Projector. Ground
Film Holder Slot
Place the Holder in this
slot.
Filter Slot
Place the Filter
(Posi/Nega) in this slot.
Film Loading Cover
Open when placing the Film
Holder and Filter in position.
(Keep this cover closed when
the Film Projector is not in
use to prevent entry of dust
and dirt.)
Lens Cover
Open when installing the
Mirror Unit. (Keep this
cover closed when the Film
Projector is not in use to
prevent entry of dust and
dirt.)
Mirror Unit
Refracts light from the
Film Projector to project
the image onto the copier
glass.
Fresnel Lens
Raise when loading
medium or large
format film.
Accessories Storage Area
Keep accessories stored in
this area. (Do not store any
other items other than the
accessories.)
Film Holder Loading Lever
Push this lever to the left
while loading the Film
Holder.
Focus Adjustment Lever
Use when adjusting focus
manually.
Power Switch
Use to turn the Projector
ON or OFF.
1144O205AA

2
2. Accessory Identification
Accessory Identification Lock Lever
This lever is used to secure the film
placed in the Film Holder.
Film Holder
Place the film in this holder,
which comes in three
versions:
•Strip Film Holder
Accommodates up to six
sheets of strip film.
•Mount Film Holder
Accommodates up to five
sheets of positive mount
film.
•Glass Mount Film Holder
Accommodates up to five
sheets of positive glass
mount film.
Spare Mount
Usewhenmakingyour
own film standard.
Film Standard
Use when shading negative film.
ISO-100 film from the following three manufacturers is
available:
• Fuji Photo Film Co., Ltd.
• Agfa-Gevaert N. V.
• Eastman Kodak Co.
Load the Film Standard in the Strip Film Holder.
Filter (Posi = positive;
Nega = negative)
Use the appropriate filter
suited to the film being used
(positive/negative).
Blower Brush
Blows dust and dirt off the
lens and glass surface.
Positioning Sheet
Place this sheet on the Original Glass of the copier when
loading medium or large format film. Cut the sheet to the
correct size of the film.
• If two or more Positioning Sheets are necessary, make
copies of the sheet on 11” ×14” or 11” ×17” paper.
Copying on thick paper makes the job easier.
1144O206AA
1144O224AA

3
3.GettingtoKnowtheBasics
The following pages explain basic information about using the Film Projector.
Types of Film and Correct Holders for Placement
NOTES
Observe the following precautions to protect the film.
• Do not use the same film for more than 30 min.
• Avoid using or storing film at a site with a temperature exceeding 30°C.
• If the film is precious, duplicate it before use.
• Remove the film from its protective bag before use.
Useful Tips
- Types of Film -
• Positive film: When viewed with back light, the light and dark areas of Positive film appear
just as they look on the print.
• Negative film: When viewed with back light, the light areas appear dark and the dark areas
appear light (the opposite of Positive film).
• Slide positive film: 35 mm positive film placed in a slide mount.
• Glass mount film: It has the same configuration as the slide film except that the film is covered with
glass.
When Making Copies
<35 mm film>
Mount film (using the Mount Film Holder) Strip film (using the Strip Film Holder)
Film image size
to be copied
Copy size
(in full size mode):
Equivalent to
Invoice size
Holder Mount Film
Holder Strip Film Holder Glass Mount Film Holder Original Glass
Film Type/Size
35 mm mount film ×××
35 mm glass mount film ×× ×
35 mm strip film ××
Brownie ×××
6×6-cm ×××
4×5” ×××
Max. size (approx. 5-3/4”×8-1/2”) ×××
: This film can be used for this Holder.
× : This film cannot be used for this Holder.
Approx. 33 mm
Approx.
21.5 mm
1144O637CA Approx. 34 mm
Approx. 23 mm
1144O638CA
Approx. 185 mm
Approx.
121 mm
1144O639CA Approx. 191 mm
Approx.
129 mm
1144O640CA

4
3. Getting to Know the Basics
Useful Tips
• To enlarge the film image area being copied, use the Glass Mount Film Holder and adjust the focus
using the Focus Adjusting Lever. Adjusting Focus ☞p. 14
• 35 mm strip film can also be copied from the Original Glass, without using the Mount Holder. In this
case if the max. size is used, up to approx. 20 frames can be copied in a single copy run.
<For sizes other than 35 mm (medium or large format film)>
The image of the film that can be copied is approx. 1 mm inside the frame on the Positioning Sheet as
shown below.
Operating Precautions
• Do not shut off the Projector light.
If an object is placed between the Projector and Mirror Unit, the Projector is unable to project the
correct image.
• Do not jolt the Projector during operation.
If the Projector is jolted (opening and closing a door or cover will produce a shock), especially after
shading, the Projector is unable to project the correct image. If jolted, perform shading once again.
• If the Panel Reset key is pressed while you are using the Projector, it cancels all functions set for the
Projector.
• Keep the Film Standards, Filter, Lens, Holders, Mirror Unit, and Original Glass away from dust and
dirt.
Dust and dirt on any of these parts can make the copy look dirty. Cleaning ☞p. 15
Film Size
60 ×45 mm
60 ×60 mm
60 ×70 mm
60 ×80 mm
60 ×90 mm
4” ×5”
Positioning
Sheet
Frame
Approx.
1mm 1154O017AA
Approx.
1mm
Approx. 1mm

5
4. Operation Flow
Operation Flow
Setting up the Projector. ☞p. 6
Select Projector mode.
On the Basic screen, touch the key.Projector
Select the type and size of film.
35 mm Film
Select the type of Holder. Other Sizes Select the size of the film.
Positive film
Place the Filter (Posi) in position. Negative film Place the Filter (Nega) in position.
Place the Film Standard appropriate
for the film type.
Touch .Shading
Load the film.
35 mm Film
Load the film in the correct Film
Holder.
Other Sizes
Cut out an opening of the size of the film
in the Positioning Sheet and place it on
the copier’s Original Glass.
Place the film in the opening in the
Positioning Sheet.
Select the paper size.
Select the zoom ratio.
Press the Start key to start the
copy cycle.
Select the next operation.
Touch .
Toselectanewfilmtype .........................Touch .
Toperformshadingagain.........................Touch .
Tomakeacopyfromthesamefilmtype.............Touch .
ToshutdowntheProjector........................Touch .
Projector Change Settings
Change Settings
End
NOTE
When placing negative film,
remove the Holder in which the
Film Standard has been placed.

6
5. Setting up the Projector
Setting up the Projector
Plug the Power Cord of the Projector into the
power outlet and turn ON the Power Switch.
NOTES
• Use a power outlet with a capacity of AC 115V
and 5A or more. If using the same power outlet
which the copier uses, it should have a
capacity of AC 115V and 20A or more.
• Be sure to make ground connection.
Gently swing down the Lens Cover.
Mount the Mirror Unit to the Projector,
aligning the holes in the bottom of the
Mirror Unit with the positioning pins
provided inside the Lens Cover.
Slide the tab on the Mirror Unit in the
direction of the arrow and open the Mirror
Unit.
NOTE
DO NOT touch the Fresnel Lens and glass
surfaces of the Mirror Unit. A dirty copy will
result if they are stained with fingerprints, dust
and dirt.
Cleaning ☞p. 15
1
2
Lens Cover
1144O207AA
3
Mirror Unit 1144O208AA
4
1144O209AA

7
6. Making Copies From Film
Making Copies From Film
Touch the key.
If the Projector is ready, touch .
SettinguptheProjector☞p. 6
Select the type and size of the film and then
touch .
Useful Tip
The 35 mm strip film can be copied from the
Original Glass. In this case, select
.
The type (positive or negative) and size (35
mm or any other size) of the film selected
determine the operating procedures that
follow.
<35 mm Film>
Select the Holder type.
<Other Sizes>
Select the film size.
Maximum Size (Max. Frame): 5-3/4” ×
8-1/2”
Touch .
<Positive Film>
Put in the Posi Filter.
1Projector
1154P461CA
2OK
1154P450CA
3OK
1154P431CB
Other Sizes
4
1154P432CA
1154P433CA
5OK
6
1144O210AA
Posi Filter

8
6. Making Copies From Film
<Negative Film>
Put in the Nega Filter.
Place the Film Standard appropriate for the
film in the Strip Film Holder.
NOTE
If the Film Standard appropriate for the film is
not available, make a new film standard.
☞p. 13
Push the Holder Loading Lever to the left
and insert the Film Holder. Align the * mark
on the Holder with the loading position.
Touch .
The lamp turns On and the shading sequence
starts.
Load the film.
<35 mm Film>
Load the film in the correct Film Holder and
lower the top cover of the holder into the
locked position.
Push the Holder Loading Lever to the left
and insert the Film Holder. Slide it up and
down to align the film position.
NOTE
For strip film, face the front side of the film down
(the side which you see film numbers reversed
between right and left is facing up) and align the
break of the film with that of the Holder.
1144O210AA
Nega Filter
1144O212AA
Film Standard
1144O213AA
Holder
Loading
Lever
7Shading
8
1144O214AA
Top Cover
Bottom Back
Front Top
1144O215AA
Top Cover
Mount Film
1144O217AA
Holder
Loading
Lever

9
6. Making Copies From Film
<Other Sizes>
Cut out a piece of the Positioning Sheet the
size of the film and place it on the Original
Glass.
Raise the Fresnel Lens and place the film in
the cutout in the Positioning Sheet.
NOTES
• Face the front side of the film down and press
the Fresnel Lens against the film.
• When placing negative film, remove the Holder
in which the Film Standard has been placed.
Touch .
Touch .
Select the paper size and touch .
If you want to use the Manual Bypass Tray,
see the Operator’s Manual of the copier
separately provided. ☞p. 3-11
Touch .
Use the or keys to set the zoom
ratio.
Useful Tip
When the key is touched, the
image will be enlarged to fit in the entire surface
of the copy paper selected for use.
Touch .
Touch or as necessary.
Touch .
1144O211AA
Positioning Sheet
1144O218AA
Fresnel Lens
Film
9OK
10 Paper
1154P471EA
11 OK
1154P473EA
12 Zoom
13 ▼▲
1154P474EA
Scale to Page
14 Density
15 Lighter Darker
1154P475EA
16 OK

10
6. Making Copies From Film
Set the number of copies to be made and
press the Start key.
You can also use the Color Adjust and
Digital Art functions.See the Operator’s
Manual of the copier separately provided.
☞pp. 3-30, 4-15
NOTES
• When setting Digital Art functions using the
Film Projector, you cannot set X/Y Zoom,
Image Repeat, Multi-Page Enlargement, and
Postcard.
• When the Film Projector is being used, it is
possible to adjust the Projector using the
key that appears on
the Touch Panel.
Setting the Projector Adjustment
Touch .
Touch .
Touch the or
key to select the color which
you want to adjust.
Touch the or key to fine-adjust the
image density.
Touch .
17
Projector Adjustment
1Color Adjust
2Projector Adjustment
1154P455CA
3Negative Film
Positive Film
1154P456CA
4+ –
1154P469CA
5OK

11
6. Making Copies From Film
Using a Different Type of Film /
Performing Shading Again
Touch .
Touch and then touch
.
The screen now allows you to reselect the
type and size of film.
Shutting Down the Projector
Touch .
Touch and then touch .
Return the Mirror Unit, Holder and any
other parts used and close the Lens Cover.
Turn OFF the Power Switch of the Projector.
NOTE
Do not unplug the Power Cord.
1Projector
1154P461CA
2Change Settings
OK
1154P437CB
3
1154P431CB
1Projector
1154P461CA
2End OK
1154P438CB
3
1144O220AA
4

12
7. Troubleshooting Tips
Copy Image Problems
• The film is probably not in the correct position.
Reload the film.
• Adjust focus. ☞p. 14
• Only limited sizes of film can be copied. When
placing the film, make sure all of the areas to be
copied are in position. (See “When Making
Copies” for the film image size to be copied and
copy size. ☞p. 3)
Useful Tip
Use the Glass Mount Film Holder because the
mounted film will make the copy image slightly
larger via focus adjustment.
• The Film Standard, Filter, Lens, Holder, Mirror
Unit or Original Glass may be dirty with dust.
Clean the surface. ☞p. 15
• The Mirror Unit may have been jolted. Perform
shading once again. ☞p. 11
NOTES
• Black lines can occur along the edges of the
image depending on the placement of the film
and Holder. This is the result of the frame of the
Holder or edge of the film being projected.
• Fine streaks can occur on the bright areas of
the copy image when negative film is copied. If
this is the case, the second shading will not
correct the problem.
The Projector reads the subtle conditions of the
film surface. Change the position of the film as
follows.
• Raise and lower the top cover of the holder.
• Move the film placed in position.
• Turn the film upside down (but don’t turn it
over).
The type of film (positive or negative) may not
match with the type of Filter installed (Posi or
Nega).
☞Install the correct Filter according to the type
of film and start the steps over beginning
with shading. ☞p. 11
Faulty Shading
If the Projector fails to perform shading correctly,
the message “Check for correct Filter, Film
Standard (Negative only), and retry SHADING.”
appears on the Touch Panel. Try the following
before touching .
• When making copies from 35 mm positive film,
the shading has been performed with the film
loaded.
☞Remove the Film Holder and perform
shading with nothing loaded in the Projector.
• Shading has been attempted with the Fresnel
Lens in the raised position when large-size film
(other sizes) is being used.
☞Lower the Fresnel Lens and then perform
shading again.
• The light from the Projector is being cut off.
☞Ensure that nothing blocks the light between
the Projector and Mirror Unit or cuts off the
light from the Projector.
• The Mirror Unit is not in position.
☞Reinstall the Mirror Unit correctly.
If all of these procedures do not correct the
problem, see “Faulty Symptoms” that follows on
page 13.
Blurred image
Part of the image is missing.
Lines on the copy
Bands of uneven density
Too light or dark image
Shading

13
7. Troubleshooting Tips
Faulty Symptoms
• The copier cannot be set into the Projector mode.
• The Projector lamp does not light up.
• The Projector lamp remains lit and will not go
out.
• A blank sheet of paper is fed out of the copier
when negative film is used.
• A solid black copy is produced when positive
film is used.
These symptoms are a result of the following;
• The optical fiber cable is loose.
☞Turn OFF the copier as well as the Projector.
Reconnect the optical fiber cable and then
turn the copier and Projector ON.
• The Projector Power Switch is OFF or the Power
Cord is unplugged.
☞Turn the copier OFF. Plug in the Power Cord
of the Projector and turn the copier and
projector ON.
• The lamp is out.
☞Call your Tech. Rep. and have him/her
replace the lamp.
• The copier or Projector is not operating.
☞Call your Tech. Rep.
Making the Film Standard
• Cut off an unexposed frame of the negative film
and place it in the Spare Mount to make a new
Film Standard.
Unexposed
Frame 1144O221AA

14
7. Troubleshooting Tips
Adjusting Focus
Place a blank sheet of paper on the Original
Glass under the Mirror Unit.
Touch the key on the Basic
screen.
Touch .
Touch .
Use the image projected on the blank sheet
of paper to adjust the focus with the Focus
Adjusting Lever.
Touch .
Touch and remove the blank sheet of
paper.
NOTE
Focus can be adjusted only for 35 mm film.
1
2Projector
1154P461CA
3Manual Focus
1154P462CB
4START
1154P439CA
5
1144O219AA
6DONE
1154P440CA
7OK

15
7. Troubleshooting Tips
Cleaning
Dust and dirt on any of the following parts will
produce a bad copy. Use the Blower Brush
provided to remove dust and dirt.
• Film Standard
• Filter
•Holder
•Lens
• Holder and Filter Slots
•MirrorUnit
NOTE
If the Lens, Mirror, or Holder glass surfaces are
stained with fingerprints, wipe the surfaces
clean with a commercially available lens cloth.
• Cleaning the Projector Housing
☞Wipe the surface clean with a soft cloth.
• Cleaning the Original Glass
☞Wipe the surface of the Original Glass clean
with a soft, dry cloth.
1144O223AA
1144O222AA
1144O304AA
1144O026AA

16
8. Specifications
Specifications
Film Projector FP-1
Type Mounted to the right of copier
Projection Modes Projector mode
Back Light mode
Film Size Brownie, 4” ×5”,max.5-3/4”×8-1/2”
Film Type 35 mm film, Brownie, 6 ×6cm,4”×5”
Focus Adjustment Possible
Power Requirements AC 115V (different from copier’s)
Max. Power Consumption 185 W or less
Dimensions Projector: 11-3/4” (W) ×17-1/2” (D) ×8-1/4” (H)
Mirror Unit: 11-3/4” (W) ×9-1/4” (D) ×2” (H)
Mass Projector: 22 lbs. or less
Mirror Unit: 11 lbs. or less
