Minuteman X705 User manual

Parts and Instruction Manual
X705 Air Operated U.L.P.A.
15 & 55 Gallon Vacuums

Page 2 X705 Air Operated U.L.P.A. 15 AND 55 Gallon Vacuum
Technical Specifi cations
MODEL C87515-03 C87555-01
Tank Size 15 gal. 55 gal.
Tank Type Stainless Steel Painted
Wet Capacity 10 gal. 45 gal.
Dry Capacity 1.86 cu ft 7.16 cu ft
Filtration .12 micron @99.999% efficiency .12 micron @99.999% efficiency
Static Lift (Max) 180" 180"
Air Flow 166 CFM 166 CFM
Air Line Diameter 1/2" ID 1/2" ID
Max Airline Pressure 100 psi max 100 psi max
Input Air Requirement 42 CFM 42 CFM
Venturi Single Jet Single Jet
Hose Connection Coupler Coupler
Wheel Size Front 3" 5"
Wheel Size Rear 8" 5"
Weight 51 lbs 110 lbs

Page 3
X705 Air Operated U.L.P.A. 15 AND 55 Gallon Vacuum
Table of Contents
TECHNICAL SPECIFICATIONS ................................................................................................... 2
OPERATING INSTRUCTIONS ...................................................................................................... 4
INSPECTION ............................................................................................................................. 4
SPECIAL WARNING ................................................................................................................. 4
AIR PRESSURE AND C.F.M. VOLUME REQUIRED ............................................................. 4
MAINTENANCE AND USAGE ................................................................................................. 4
OPERATION .............................................................................................................................. 4
ASSEMBLY INSTRUCTIONS ....................................................................................................... 5
CLEANING AND EMPTYING INSTRUCTIONS .......................................................................... 5
OVERVIEW ..................................................................................................................................... 7
EXPLODED VIEWS ....................................................................................................................... 8
LID ASSEMBLY ......................................................................................................................... 8
15 GALLON TANK ASSEMBLY .............................................................................................. 10
55 GALLON TANK ADAPTER ASSEMBLY ........................................................................... 12
55 GALLON TANK ................................................................................................................... 14
55 GALLON DOLLY ................................................................................................................ 15
NOTES .......................................................................................................................................... 16
WARRANTY .................................................................................................................................. 18

Page 4 X705 Air Operated U.L.P.A. 15 AND 55 Gallon Vacuum
MODEL X705-15 AND X705-55 AIR OPERATED VACUUM. DRY RECOVERY ONLY.
EQUIPPED WITH U.L.P.A. FILTER 99.99 EFFICIENT AT 0.12 MICRONS
OPERATING INSTRUCTIONS
INSPECTION
Carefully unpack and inspect your machine for shipping damage. Each unit is tested and thoroughly
inspected before shipment, therefore, any damage is the responsibility of the delivering carrier who
should be notifi ed. Read all instructions carefully before operating.
SPECIAL WARNING
Air operated equipment can generate static electricity during use. Static dissipating arcing can be
generated and occur if equipment and accessories are not grounded. Risk of explosion is possible if
operated near explosive materials or vapors. Do not operate this equpment near fl ammable materials
such as solvents, thinners, fuels, grain dust, etc.
AIR PRESSURE AND C.F.M. VOLUME REQUIRED
For maximum performance, operate with 1/2” air pressure line, 80 PSI (max, 100 PSI) and 37 input
C.F.M. Air pressure control valve can be regulated to operate with lower pressure and C.F.M. when
maximum is not required.
MAINTENANCE AND USAGE
Air supplied to vacuum must be clean and dry to avoid contamination, and to maintain optimum
performance.
Empty tank, clean fi lter bag, and replace disposable fi lters regularly. Clogged fi lters restrict air fl ow , and
results in reduced vacuum performance.
Always shut off main air supply, and open air valve at vacuum, to relieve pressure before disconnecting
air pressure line.
OPERATION
Your Minuteman vacuum has been specifi cally designed to clean up fultra fi ne hazardous toxic dust
materials. Special fi lters reduce the incidence of air-borne dust that would be created by any other
method of cleaning.
During the cleanup of toxic dry materials do not sweep, scoop, shovel, or in any manner handle other
than by vacuuming.

Page 5
X705 Air Operated U.L.P.A. 15 AND 55 Gallon Vacuum
Do not at any time attempt to bypass, remove, substitute, or by any other means change the type of
fi lters used in this vacuum. Use only approved Minuteman vacuum fi lters and fi lter bags.
Before attempting to use, and before cleaning, be certain that you fully understand the instructions given
for the setting up and cleaning/changing of fi lters of this vacuum.
Since each facility has its own individual and unique cleaning problems, it is suggested that you use the
following guidelines in determining the length of time between fi lter changes or cleaning the vacuum tank.
ASSEMBLY INSTRUCTIONS
1. Take the paper fi lter protector #4 and insert into tank. Snap the elastic band around
the rim of the tank. Allow two inches to overlap the tank rim.
2. Place cloth fi lter bag assmebly #3 into tank. Center frame of fi lter around tank rim.
3. Turn U.L.P.A. fi lter lid assembly #1 upside down on worktable. Center one pink
impaction fi lter cartridge #2 onto U.L.P.A. fi lter.
4. Place vacuum lid assembly #1 onto tank #5, center and fasten lid latches.
CLEANING AND EMPTYING INSTRUCTIONS
For the benefi t of your health, you should always wear a face mask and protective clothing approved and
recommended by your Safety Department for the particular hazardous waste material you are working
with. Check with your Safety Department or Industrial Hygienist for their instructions before attempting
to clean out vacuum.
1. Shut off main air pressure valve feeding air to vacuum. Open air valve on vacuum
lid to relieve pressure on line. If equipped with quick coupler, disconnect air pressure
line.
2. Carefully, and very slowly, remove vacuum lid only. (Be sure you have not accidentally
lifted the cloth fi lter bag at the same time.) Set lid assembly aside
3. Remove cloth fi lter bag with bag frame. Check for residue on bag. If required,
vacuum clean only. Do not shake bag in open atmosphere.
4. Carefully undo the elastic band on the fi lter protector bag, fold in, and place this
fi lter into proper disposal container.
5. Reach into tank and gently push the collar of fi lter bag off the tube, seal bag opening
with 2” wide duct tape, and carefully remove collector bag into proper disposal
container.

Page 6 X705 Air Operated U.L.P.A. 15 AND 55 Gallon Vacuum
6. Using a wiping cloth dampened with water (not woaking wet), wipe down all of the
exposed surfaces inside the tank; put all wiping material into disposal container.
7. Check pink impaction fi lter in U.L.P.A. fi lter. If impact fi lter shows discoloration due
to dust penetration, remove and place in disposal container.
8. Visually check U.L.P.A. fi lter. If fi lter shows signs of dust penetration, revise cleaning
and fi lter change procedure to be done more frequently. Be absolutely sure all fi lters
and prefi lters are always used and installed properly.
9. CAUTION: Hazardous material must be disposed of properly. Never throw
contaminated debris into your usual trash receptacle. Check with your Safety
Department or Industrial Hygienist for fi nal disposal requirements.
10. Follow asembly procedure.

Page 7
X705 Air Operated U.L.P.A. 15 AND 55 Gallon Vacuum
OVERVIEW










3.*
3.*
3DSHU)LOWHU
3.*
37'

&
55 GALLON

3.*
3.*
3DSHU)LOWHU


15 GALLON

Page 8 X705 Air Operated U.L.P.A. 15 AND 55 Gallon Vacuum
LID ASSEMBLY
EXPLODED VIEWS

Page 9
X705 Air Operated U.L.P.A. 15 AND 55 Gallon Vacuum
LID ASSEMBLY BOM
BILL OF MATERIAL - 707615
ITEM PART NO. QTY DESCRIPTION
1 110030PKG 1 PREFILTER SLEEVE, 829/839, PKG OF 6
2 110029 1 FILTER-ULPA, X829 SERIES
3 260274 1 GROMMET Z-421
4 420008 1 FTG-COMPRESSION 1/2 OD X 3/8 MPT
5 420009 1 FITTING-ELBOW MALE 469F
6 420011 2 FTG-COMPRESSION 1/2 HOSE INSERT
7 420017 1 FITTING-NIPPLE HEX REDUCER 112RFE
8 460000 1 HANDLE 460 LID BLACK
9 480052 1 GASKET,RBR .25X.87X.50
10 480053 1 RING, RUBBER LOCATING
11 700010 1 SINGLE VENTURI ASSY
12 700011 1 VENTURI HOUSING
13 700012 1 VENTURI EXHAUST TUBE
14 700013 1 VENTURI INTAKE
15 700014 1 VENTURI LOCNUT
16 700016 1 FELT LINER
17 700017 1 PERFORATED SHEILD
18 700018 1 DOME FELT
19 700019 1 AIR DEFLECTOR 18GA
20 700021 1 POLYHOSE 32" LONG
21 700022PTD 1 COVER 701 PTD
22 700023PTD 1 OUTTER HOUSING PAINTED
23 700024 1 BOTTOM PAN ASY
24 700026 1 FILTER-EXHAUST
25 700028 1 FTG-ELBOW 90 ST 3/8 FPT X 3/8 FPT BRASS
26 700039 1 HEPA MOUNTING ADAPTOR
27 700044 1 AIR VALVE ASSEMBLY
28 701010 1 COUPLER-MALE .50
29 710178 10 SCR-THMS 1/4-20 X .50 ZP
30 711106 8 SCR-PHSMS 10 X .75 ZP A POINT
31 713002 2 SCR-HH 1/4-20 X .75 ZP 5
32 711505 2 WASHER-FLAT 1/4 ZP
33 711513 2 WASHER-FLAT .689 X 1.06 X .029 SS
34 712105 1 NLA---BLT-U 1/4-20
35 712536 4 SCR-THMS 10-24 X .62 SS
36 712667 15 NUT-NYLOC 1/4-20 SS
37 715003 1 DECAL-AIR PRES 2.00 X 4.00
38 715029 1 DECAL-NAME PLATE MODEL ID
39 829285PLT 1 SPACER-.25 X .875 X .687 PLATED
40 830062 1 FTG-ELBOW 90 3/8 MPT X 3/8 FPT BRASS
41 832106 6 BRKT-MOUNTING TAB

Page 10 X705 Air Operated U.L.P.A. 15 AND 55 Gallon Vacuum
15 GALLON TANK ASSEMBLY
