Miranda picoLink Series Instruction Manual

picoLink series
FOE-871p
Fiber Optic to HD/SD
Converter
Guide to Installation and Operation
M734-9900-102
17 Mar 2009
Miranda
Technologies Inc.
3499 Douglas-B.-Floreani
St-Laurent, Québec, Canada H4S 1Y6
Tel. [phone]
Fax. [phone]
www.miranda.com
© 2009 Miranda Technologies Inc.

GUIDE TO INSTALLATION AND OPERATION
FOE-871p
Radio Frequency Interference and Immunity
This unit generates, uses and can radiate radio frequency
energy. If the unit is not properly installed and used in
accordance with this guide, it may cause interference with radio
communications. Operation with non-certified peripheral devices
is likely to result in interference with radio and television
reception. This equipment has been tested and complies with the
limits in accordance with the specifications in:
FCC Part 15, Subpart B
CE EN50081-1:1992
CE EN50082-1:1992
Contact Miranda
For technical assistance, please contact the Miranda
Technical Support centre nearest you:
Americas
Telephone:
[phone]
e-mail:
[email protected]
Asia
Telephone:
[phone]
e-mail:
[email protected]
Europe, Middle East, Africa, UK
Telephone:
[phone]
e-mail:
[email protected]
China
Telephone:
[phone]
e-mail:
[email protected]
France (only)
Telephone:
[phone]
e-mail:
[email protected]
Visit our web site at www.miranda.com

GUIDE TO INSTALLATION AND OPERATION
FOE-871p
Table of Contents
1FOE-871p Fiber Optic to HD/SD Converter....................... 1
1.1 Introduction........................................................................ 1
1.2 Features ............................................................................ 1
2Overview .............................................................................. 2
3Installation ........................................................................... 3
3.1 Power Supply .................................................................... 3
3.2 Fiber Input ......................................................................... 4
3.3 HD/SD Digital Video Output .............................................. 4
4Operation ............................................................................. 5
4.1 Status LED ........................................................................ 5
5Specifications...................................................................... 6

GUIDE TO INSTALLATION AND OPERATION
FOE-871p

GUIDE TO INSTALLATION AND OPERATION
FOE-871p | 1
1 FOE-871p Fiber Optic to HD/SD Converter
1.1 Introduction
The FOE-871p is a compact stand-alone solution receiving
Standard Definition digital video (SMPTE 259M SDI 270 Mbps)
as well as High Definition signals (SMPTE 292M up to 1.5 Gbps)
through an SMPTE 297M fiber optic link. When combined with
the FEO-871p, the solution reaches distances up to 15 km
(depending on the optical link) on single mode fiber, allowing
transparent digital transmission for short haul applications. The
FOE-871p can be used stand-alone or can be mounted in a
special rack tray that allows the picoLink fiber converters to
become an optical-to-electrical patch field. The fiber picoLink
converters' flexible packaging makes them ideal for both
temporary and permanent, intra and inter-facility fiber optic links.
Figure 1: FOE-871p functional block diagram
1.2 Features
•Supports any serial data rate from 5 Mbps (ATSC) to 1.5
Gbps (HD SDI)
•Reclocked serial digital video from 143 Mbps to 1.5 Gbps
•Supports SMPTE 259M, SMPTE 292M, SMPTE 305,
SMPTE 310M, DVB-ASI
•Supports single mode fiber optic @ 1310 nm and 1550 nm
•Status LED indication
•Cost effective solution, compact and lightweight
•Stand-alone mounting
•Optional rack mount tray turns picoLink into optical patch
field

GUIDE TO INSTALLATION AND OPERATION
2| FOE-871p
2 Overview
Figure 2 illustrates the FOE-871p's major parts and their
locations. The optical fiber input is connected using a single-
mode SC connector, and the HD/SD digital video output appears
on a BNC connector. Error status is provided by the status LED.
Finally, the power source is connected to the lockable power
connector.
Figure 2: Overall view of the FOE-871p
Out
p
ut BNC
Power connector
Input SCStatus LED

GUIDE TO INSTALLATION AND OPERATION
FOE-871p | 3
3 Installation
3.1 Power Supply
The LKS-WSU power supply provides power to the FOE-871p
for 110 V and 220 V operation. The power supply is a regulated
+5 [email protected] A power source. The FOE-871p employs a mini
XLR-3 connector for its power needs. Figure 3 shows a detailed
pinout of the male connector.
Figure 3: Power connector pinout

GUIDE TO INSTALLATION AND OPERATION
4| FOE-871p
3.2 Fiber Input
Connect an optical signal to the SC connector labeled FIBER IN.
Class 1 laser product
Hazards for the Operator
Active optic fibers emit radiation invisible to the naked eye.
Never look directly at the end of an active optic fiber.
Caution
Although not considered overly dangerous for the
eye, avoid accidental exposure to the optical beam
emitted from the fiber optic cable connected to the
FOE-871p input.
3.3 HD/SD Digital Video Output
A reclocked high-definition or standard-definition digital video
signal appears on the BNC labeled HD/SD SDI OUT.
•The high-definition serial digital output signal conforms to
the SMPTE 292M standard.
•The standard-definition serial digital output signal
conforms to the SMPTE 259M-ABCD standard or the
DVB-ASI (270 Mbps).

GUIDE TO INSTALLATION AND OPERATION
FOE-871p | 5
4 Operation
There are no operating controls on the FOE-871p.
4.1 Status LED
The bi-colored status LED, located next to the BNC output
connector, is provided to identify any input errors. The following
situations are flagged:
Off: No DC power
Green: Laser light detected with valid SDI / HD-SDI
signal
Red (steady): Laser light detected but no valid SDI / HD-SDI
signal
Red (blinking): No laser light detected

GUIDE TO INSTALLATION AND OPERATION
6| FOE-871p
5 Specifications
Optical Input
Signal: Optical Laser
Wavelength: 1310 nm and 1550 nm
Sensitivity: -16 dB
Fiber type: Single Mode
Connector: Optical SC/PC
Electrical Output
Signal: SMPTE 259M-A-C (143, 270 Mbps)
SMPTE 292M (1.485 Gbps and
1.485/1.001 Gbps)
SMPTE 305M (SDTI)
SMPTE 310M (5Mbps to 40 Mbps)
DVB-ASI
Return loss: >15 dB up to 1.485 Gbps
Jitter: <0.2UI
Connector: 75 ΩBNC (1)
General specifications
Processing delay: 3 ns @ 1.485 Gbps
Power voltage: 5VDC
Consumption: 2 W
Temperature
operating range: 0 – 30° C
