Miratron PC200 Manual

Installation and Setup Instructions
PC200 Dual Output Ramping Proportional Controller
SPECIFICATIONS
General: Power requirement 9-30Vdc, 250mA nominal + power to external loads
Fuse 15-Amp Fuse; total load must not exceed 15-amps
Digital Outputs: Type Sourcing
Output Same as supply voltage, 5 Amps max. each
PWM Outputs: Frequency 1000Hz
Dither 100Hz, 0-10% of maximum current
Output Same as supply voltage, 0-5Amps max.
Adjustments Minimum/Maximum: 0-5A (Can be adjusted for min>max)
Ramp Up/Dn: 0.1-5 Seconds
Joystick Input: +5V OUT Joystick power; 50mA max (1k ohm pot recommended)
+2.5V OUT Tap reference; 50mA max (1k hom pot recommended)
SIGNAL IN 0-5Vdc or 0.5 to 4.5Vdc jumper selectable; 2.5Vdc center
Adjustments Threshold: 0 to +/-2Vdc
Switch Input: FWD Dry contact
REV Dry contact
DISABLE Connect to system power to disable control*
Mounting: (4) #6 x 3/4" self-tapping screws (included)
Environmental: Storage -40degC to 85degC
Operating -10degC to 60degC
* DO NOT USE THIS INPUT FOR SAFETY CONTROL. When using 2 controllers with 2-axis joystick,
AB(+) terminal of one controller can be connected to DISABLE terminal of a second controller to prevent
simultaneous operation of X and Y axis.
DIMENSIONS
4.25"
(108mm)
0.39"
(10mm)
0.71"
(18mm)
4.80"
(122mm)
0.2"
(5mm)
#6 SCREW
BOSS
(TYP OF 4)
0.375"
(9.5mm)
3.85"
(98mm)
3.7"
(94mm)

WIRING
INPUT WIRING
JOYSTICK
JOYSTICK or POTENTIOMETER:
GROUND (1)
POWER (3)
TAP(OPTIONAL)
OUTPUT (2)
OUT
1
MIN
OUT
1
MAX
SINGLE COIL CONTROL - POTENTIOMETER:
Full range of potentiometer rotation controls only OUT 1.
DUAL COIL CONTROL - POTENTIOMETER:
Full range of potentiometer rotation controls OUT 1 and OUT2.
OUT
1
MIN
OUT
1
MAX
OUT
2
MIN
OUT
2
MAX
OUT 1
OUT 2
DUAL COIL CONTROL-INDEPENDENT ADJUSTMENT:
Independent potentiometers for OUT 1 and OUT2.
THRESHOLD
OUT
2
MIN
OUT
1
MAX
OUT
1
MIN
OUT
2
MAX
(1) COMMON
(3) +5V OUT
(2) SIGNAL IN
+2.5V OUT
COMMON
+5V OUT
SIGNAL IN
+2.5V OUT
COMMON
+5V OUT
SIGNAL IN
+2.5V OUT
COMMON
+5V OUT
SIGNAL IN
+2.5V OUT
1
3
2
POTENTIOMETER
(FRONT)
1 2 3
3
2
1
MIN/CCW
MAX/CW
3
2
1
321
3
2
1
OUT 1
OUT 2
SELECT
OUT 1
OUT 2
SWITCH CONTROL - OUT 1 and/or OUT2:
Independent switch inputs for OUT 1 and OUT2. SEND
SW1+
SW1-
SW2+
SW2-
INCREASE OUT 1
DECREASE OUT 1
INCREASE OUT 2
DECREASE OUT 2
SW1
1+
INC OUT 1
1-
INC OUT 1
SW2
2+
INC OUT 2
2-
INC OUT 2
POWER
GROUND
+9-30VDC
GROUND
DISABLE CONNECT TO POWER
TO DISABLE
POWER INPUT IS REVERSE POLARITY PROTECTED
AND FUSED TO 15-AMPS. FOR NORMAL OPERATION,
LEAVE DISABLE TERMINAL OPEN. DISABLE TERM-
INAL NOT FOR SAFETY CONTROL APPLICATIONS.

WIRING
OUTPUT WIRING
+12-24vdc
Ground
NOTE: When using 2 controllers with 2-axis joystick, AB(+) terminal of one controller can be connected to
DISABLE terminal of a second controller to prevent simultaneous operation of X and Y axis.
PROPORTIONAL and DIGITAL VALVE OUTPUTS:
2-WIRE SOLENOIDS 1-WIRE GROUNDED SOLENOIDS
ALTERNATE PROPORTIONAL OUTPUT WIRING:
Combined *OUT1+2 (See table)
A+
A-
A+
A -
NOTE: Wiring diagram applies to all solenoid valve outputs.
CASCADE CONNECTION FOR 2-AXIS JOYSTICK (4-OUTPUTS):
OUT Y
OUT X
TAP
POWER
GROUND
NOTE: Connect one side of coil to
OUT1-, OUT2-, or Ground
OUT1+
OUT1 -
OUT2 +
OUT2 -
A+
A-
B+
B-
AB+
AB-
C+
C-
OUT1+
OUT1 -
OUT2 +
OUT2 -
POWER
GROUND
COMMON
+5V OUT
SIGNAL IN
DISABLE
+2.5V OUT
SEND
SW1+
SW1-
SW2+
SW2-
A+
A-
B+
B-
AB+
AB-
C+
C-
OUT1+
OUT1 -
OUT2 +
OUT2 -
POWER
GROUND
COMMON
+5V OUT
SIGNAL IN
DISABLE
+2.5V OUT
SEND
SW1+
SW1-
SW2+
SW2-

OPERATION
A
INPUT
B
THRESHOLD
THRESHOLD
AB
C
JOYSTICK
REVERSE
JOYSTICK
FORWARD
<<
<<
>
<<
<<
>
>
>
OUT1
5A (ADJUSTABLE)
0A
OUT2
OUT1+2*
A
ON
OFF
B
ON
OFF
AB
ON
OFF
C
ON
OFF
JOYSTICK
CENTER
JOYSTICK
FORWARD
JOYSTICK
REVERSE
ADJUSTABLE
THRESHOLD
*NOTE: OUT1+2 Created by connecting both OUT+ terminals to one side of solenoid and connecting one or
both OUT- terminals to other side of solenoid. (See OUTPUT WIRING diagram.)
5A (ADJUSTABLE)
0A
5A (ADJUSTABLE)
0A
0.5v 2.5v 4.5v
Voltage on SIGNAL teminal

APPLICATIONS
#1: COMBINED PROPORTIONAL AND DIGITAL OUTPUTS WITH TAPPED POTENTIOMETER JOYSTICK
NOTE: APPLICATIONS SHOWN ARE EXAMPLES ONLY. MANY OTHER HYDRAULIC
CIRCUITS AND CONTROL COMBINATIONS ARE POSSIBLE.
#2: COMBINED PROPORTIONAL AND DIGITAL OUTPUTS WITH HALL-EFFECT JOYSTICK
#3: PROPORTIONAL OUTPUT WITH SWITCHES OR DIGITAL JOYSTICK
#4: DIGITAL LATCHING OUTPUT WITH POTENTIOMETER JOYSTICK

MIN
MAX
RAMP UP
RAMP DN
INC
DEC
SELECT
DOWN
THRESHOLD
DITHER
MIN
MAX
RAMP UP
RAMP DN
SELECT
UP
PWM OUT 1
PWM OUT 2
SETUP
Step 1 Apply power to controller.
Step 2 Move JP13 to appropriate input signal range. Use 0.5 to 4.5v for
hall-effect joystick applications. Use 0 to 5v for potentiometer
applications.
Step 3 Press SELECT UP or SELECT DOWN buttons to choose which
parameter to adjust. LED's indicate selected parameter.
Step 4 Press INC or DEC buttons to adjust value of selected parameter.
Display indicates value from 0-99% of adjustment range.
Step 5 Repeat steps 3 and 4 until all parameters have been adjusted to
desired values.
DESCRIPTION OF PARAMETERS:
PWM OUT 1 and PWM OUT 2
MIN: Minimum value for proportional output 0 = Off; 99 = full power
MAX: Maximum value for proportional output 0 = Off; 99 = full power
RAMP UP: Time for output to reach maximum value 0 = 0.1 seconds; 99 = 5 seconds
RAMP DN: Time for output to reach maximum value 0 = 0.1 seconds; 99 = 5 seconds
THRESHOLD: Adjusts how far the joystick/potentiometer 0 = 0 volts (0%); 99 = +/-2 volt (25%)
must be moved from center before output
begins to change. Increase this value to make
the joystick/potentiometer less "touchy."
DITHER: Adjusts the amount of high-frequency signal 0 = none; 99 = +/-10% of max output
applied to the proportional outputs. This
enables ne control of the solenoid by
preventing sticking.
SETUP NOTES:
INPUT JUMPER SETTING:
HI
LO
PWR
0-5vdc INPUT
0.5-4.5vdc INPUT
