i3SERIES SENSITIVITY READER i3SERIES
Mircom reserves the right to make changes at any time without notice in prices, colours, materials, components, equipment, specifications and models and also to discontinue models.
Description
The CSENS-RDRA sensitivity reader simplifies detector
inspection with a convenient wireless device. Like all i3
series products, the CSENS-RDRA is intelligent, easy
to use, and provides instant inspection.
Installation (testing) Ease
The CSENS-RDRA utilizes infrared technology to read
the sensitivity of i3 series detectors. Being wireless,
there is no need for a physical connection to the
detector. Also no voltmeter or multi-meter is required,
to further reduce testing time. The CSENS-RDRA is
designed for either hand-held use or may be connected
to a threaded extension pole, to eliminate the need for
a ladder when measuring the detector’s sensitivity.
Intelligence
The CSENS-RDRA provides specific information
related to the sensitivity of the detector. Rather than
displaying a voltage reading, the CSENS-RDRA
indicates the detector’s sensitivity in terms of percent
per foot obscuration. This eliminates the added step
of cross-referencing a voltage reading to a sensitivity
range.
Instant Inspection
The CSENS-RDRA is equipped with an LED and
sounder to indicate when the device has completed
reading an i3 detector. Upon completion, the LCD
screen displays the detector’s sensitivity as well as one
of three text status indications: GOOD, SERVICE, or
REPLACE. Additionally, the CSENS-RDRA provides a
low battery indication when its two AA alkaline batteries
need to be replaced.
Features
Reads sensitivity of i3 series detectors•
Displays sensitivity in percent per foot•
obscuration
Infrared technology does not require a physical•
connection to the detector
Eliminates the need for a voltmeter or multi-•
meter
May be used as a hand-held device or with a•
threaded extension pole
LCD display indicates specific sensitivity•
reading and a status indication
Provides audible and LED indication when•
detector sensitivity has been read
Operates with two AA alkaline batteries•
Includes low battery indication•
Auto shut-off after 30 minutes•
5133
NOT TO BE USED FOR INSTALLATION PURPOSES.
Engineering Specifications
Sensitivity reader shall be an i3 series model number
CSENS-RDRA, listed with Underwriters Laboratories
as a smoke detector accessory. The reader shall be
capable of reading the detector’s sensitivity without
the need for a physical connection to the detector, and
shall not require the use of a voltmeter or multi-meter.
The reader shall offer the capability of hand-held use
or shall accept a threaded extension pole.
The reader shall include an LCD screen which
indicates a detector’s sensitivity in terms of percent per
foot obscuration and a textual status indication. The
reader shall operate with two AA alkaline batteries and
shall be capable of indicating a low battery condition
on the LCD screen.
CATALOG NUMBER
firealarmresources.com

Canada
25 Interchange Way
Vaughan, Ontario L4K 5W3
Telephone: [phone]
Fax: [phone]
Web page: http://www.mircom.com Email: [email protected]
Distributed by:
CAT. 5133
Rev. 3
NOT TO BE USED FOR INSTALLATION PURPOSES.
Ordering Information
Model Description
CSENS-RDRA Sensitivity Reader for i3 Series Smoke Detectors
Figure 1: Reader location on i3 Series detectors Figure 2: Position Reader on i3 Series detectors
POSITION SENS-RDR
VERTICALLY TO
OVAL AREA BY THE
WORD "PAINT"
RECESSED TEST SWITCH
LED
OR
U.S.A.
4575 Witmer Industrial Estates
Niagara Falls, NY 14305
Toll Free: [phone]
Fax Toll Free: [phone]
Specifications
Batteries
2 – AA alkaline batteries
(not included)
Weight
8 oz. (225 grams)
Dimensions
Length: 718 inches (181 mm)
Width: 138 inches (35 mm)
Depth: 118 inches (29 mm)
LCD Status Indications
CSENS-RDRA Operation
Turn the reader on by pressing and holding the button for approximately 2 seconds until the reader sounds.1.
The LCD will display the word “READY”. The “READY” status indicates that the CSENS-RDRA is ready for
accepting data from an i3 Series smoke detector.
Place the reader by the smoke detector being tested. Position the reader above the oval depression near2.
the word “PAINT” (See Figure 1). Position the reader below the detector at an angle (See Figure 2). A ledge
and an anti-skid tip is provided on the reader to maintain the reader in place while it reads the sensitivity.
Hold the reader in this position up to 10 seconds until the reader sounds and the reader’s red LED illuminates.3.
(Note: If the reader does not sound after 10 seconds, verify that the reader is properly positioned, and the
LCD displays “READY”.)
The LED and sounder indicate a valid reading is received. The sensitivity reading and status for the detector4.
will be automatically displayed on the reader. (See “LCD Status Indications” above.) The reader will continue
to display this information for up to 30 minutes, or until the reader is reset. (Note: No further readings may
be taken until the reader is reset.)
To measure the sensitivity of the next detector, reset the reader by momentarily pressing the button. The5.
LCD will again display the word “READY”. Repeat steps 2 through 4, as necessary.
When finished, turn off the reader by pressing and holding the button for approximately 2 seconds until the6.
reader sounds.
Status Indication Action
GOOD The detector is within its sensitivity range. No action is necessary at this time.
SERVICE The smoke detector’s sensing chamber requires cleaning for continued reliable
operation. Refer to the i3 Series manual for proper maintenance procedures.
REPLACE The smoke detector is failing and should be replaced immediately.
