Missing Link ML-3G2DVI User manual

ML-3G2DVI
SDI to DVI Converter
User Manual
Made in Taiwan

~ 1 ~
Safety and Notice
The ML-3G2DVI SDI to DVI Converter has been tested for conformance to safety regulations and
requirements, and has been certified for international use. However, like all electronic equipments, the
ML-3G2DVI should be used with care. Please read and follow the safety instructions to protect yourself from
possible injury and to minimize the risk of damage to the unit.
Follow all instructions and warnings marked on this unit.
Do not attempt to service this unit yourself, except where explained in this manual.
Provide proper ventilation and air circulation and do not use near water.
Keep away the objects that might damage the device and assure that the placement of this unit is on a
stable surface.
Use only the power adapter, power cords and connection cables designed for this unit.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before
cleaning.

~ 2 ~
The ML-3G2DVI SDI to DVI Converter with Loopout provides a cost effective way to convert
3G/HD/SD-SDI signal to DVI signal. The conversion between SDI and DVI is pure digital and guarantees no
loss transformation for both audio and video. Plus, with up to 8 channels audio support, 7.1 channel or 5.1
channel audio becomes available. The ML-3G2DVI also provides 1 low jitter and re-clocked outputs for daisy
chain or a monitor.
Features
Supported high-definition (HD) formats:
NTSC [email protected], PAL 625@50, 720p@50,[email protected], 720p@60(recommand), 1080i@50,
[email protected], 1080i@60, [email protected], 1080p@24, 1080p@25, [email protected], 1080p@30, 1080p@50,
[email protected], 1080p@60(recommand)
Bit Rate: 2.97 Gbps, 2.967 Gbps, 1.485 Gbps, 1.4835 Gbps, 270 Mbps
Auto 3G/HD/SD-SDI detection
One SDI compliant output and two DVI compliant output
Introduction

~ 3 ~
Specifications & Package Contents
Model Name
ML-3G2DVI
Technical
Role of usage
SDI to DVI Converter
SDI standards
SD-SDI, HD-SDI & 3G-SDI
Input Video bandwidth
2.970Gpbs, 2.970/1.001Gbps
Input Video support
[3G] 1080p @50/59.94/60Hz (4:2:2)
[HD] 720p @50/59.94/60Hz, 1080i @50/59.94/60Hz, 1080p @24/30Hz
[SD] NTSC @59.94Hz, PAL @50Hz
Audio support
Yes
PCB stack-up
6-layer board [impedance control —differential 100; single 50]
Input
1x BNC [SDI]
Output
2x DVI&1xBNC
BNC connector
3G 75Ωinter-locked socket
DVI connector
DVI [29-pin female digital only]
Control Switch
8-level rotary switch for color space setting
Mechanical
ML-3G2DVI
Housing
Metal enclosure
Weight
Package
Dimensions
[L x D x H]
Carton
450 x 370 x 300mm [1’5.7" x 1’2.6" x 11.8"]
Model
107.5 x 95.6 x 25.2mm [4.2”x 3.7”x 0.9”]
Package
270 x 175 x 80mm [10.6”x 6.9”x 3.2”]
Weight
Model
250g [8.8oz]
Package
Power supply
5V 2A DC
Power consumption
3 Watts [max]
Operation temperature
0~40C [32~104F]
Storage temperature
-20~60C [-4~140F]
Relative humidity
20~90% RH [no condensation]

~ 4 ~
3G INPUT
1080p @ 50/ 59.94 / 60Hz
SMPTE 424M, SMPTE 425M
HD INPUT
720p @ 50Hz
SMPTE 296M -3
720p @ 60 / 59.94Hz
SMPTE 296M -1, -2
1080i @ 50Hz
SMPTE 274M -6
1080i @ 60 / 59.94Hz
SMPTE 274M -4, -5
1080p @ 24 / 23.98Hz
SMPTE 274M -10, -11
1080p @ 25Hz
SMPTE 274M -9
1080p @ 30 / 29.97Hz
SMPTE 274M -7, -8
SD INPUT
NTSC
PAL B,D,G,H,I
Supported Resolutions

~ 5 ~
Front Panel
1. +5V DC:Dip Switch for audio output ON/OFF
2. Signal LED –
<red> Power LED
<green> Signal LED
3. SDI IN: 3G/HD/SD-SDI input
4. SDI OUT: 3G/HD/SD-SDI output
Rear Panel
5. DVI OUT: connect to digital DVI display
6. DVI OUT: connect to digital DVI display
7. MODE: 8-level rotary switch for color space settings
Panel Descriptions
0: color space Auto
1: color space force YCbCr
2: color space force RGB
3~7: Reserved

~ 6 ~
The SELLER warrants the ML-3G2DVI SDI to DVI Converter to be free from defects in the material and
workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this
product fail to be in good working order within 1 year warranty period, The SELLER, at its option, repair or
replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized
modifications including static discharge and power surges.
Unit that fails under conditions other than those covered will be repaired at the current price of parts and
labor in effect at the time of repair. Such repairs are warranted for 90 days from the day of reshipment to the
BUYER. If the unit is delivered by mail, customers agree to insure the unit or assume the risk of loss or
damage in transit. Under no circumstances will a unit be accepted without a return authorization number.
The warranty is in lieu of all other warranties expressed or implied, including without limitations, any
other implied warranty or fitness or merchantability for any particular purpose, all of which are expressly
disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan are responsible for
shipping charges to and from the SELLER. Cables are limited to a 30 day warranty and cable must be free
from any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be accurate. However, The
SELLER assumes no responsibility for any inaccuracies that may be contained in this manual. The SELLER will
NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or
omission in this manual, even if advised of the possibility of such damages. Also, the technical information
contained herein regarding the ML-3G2DVI features and specifications is subject to change without further
notice.
Limited Warranty
