Mission Z-60 Instruction Manual

Z-60
Administration Manual

Environment
The equipment you have purchased must not be disposed of with household waste. You
should return these to your distributor if they are to replace or dispose of them in an
approved recycling centre.
FCC Statement
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions in this manual, may cause interference to radio
communications. This equipment has been tested and found to comply with the limits for a
Class B computing device pursuant to Subpart J of Part 15 of FCC rules, which are
designed to provide reasonable protection against radio interference when operated in a
commercial environment. Operation of this equipment in a residential area is likely to cause
interference, in which case the user, at is own expense, will be required to take whatever
measures are necessary to correct the interface.
CE Declaration of Conformity
This equipment complies with the requirements relating to electromagnetic compatibility,
EN55022 class B for ITE and EN 50082-1. This meets the essential protection requirements
of the European Council Directive 89/336/EEC on the approximation of the laws of the
Member States relating to electromagnetic compatibility.
Copyright Notice
All rights reserved. No part of this publication may be reproduced, transmitted, transcribed,
stored in retrieval system or translated in to any language or computer language, in any form
or by any means, electronic, mechanical, magnetic, optical, chemical, manual, or otherwise,
without the prior written permission of Company.
Company reserves the right to revise the publication and make changes from time to time in
the contents hereof without obligation of this company to notify person of such revision or
changes. The material contained herein is supplied without representation or warranty of
any kind. The Company therefore assumes no responsibility and shall have no liability of
any kind arising from the supply or use of this document or the material contained herein.
Trademarks
Windows 98/NT/2000/XP/7™ and Internet Explorer™ are registered trademarks of Microsoft
Corporation. All other company, brand and product names, like Netscape Navigator™ are
trademarks or registered trademarks of their respective owners.
ISO-9001ISO-9001

WARNING!
1. Read these installation instructions carefully before connecting the equipment to its
power adapter.
2. To reduce the risk of electric shock, do not remove the cover from the equipment or
attempt to dismantle it. Opening or removing covers may expose you to dangerous
voltage levels. Equally, incorrect reassembly could cause electric shock on re-use of the
appliance.
3. Do not expose the equipment to fire, direct sunlight or excessive heat.
4. Do not expose the equipment to rain or moisture and do not allow it to come into contact
with water.
5. Do not install the equipment in an environment likely to present a Threat of Impact.
6. You may clean the equipement using a fine damp cloth. Never use solvents (such as
trichloroethylene or acetone), which may damage the equipement’s plastic surface.
Never spray the equipment with any cleaning product whatsoever.
7. The equipment is designed to work in temperatures from 0oC to 45oC (32oF to 104oF).
8. The equipment must be installed at least 1 meter from radio frequency equipment, such
as TVs, radios, hi-fi or video equipments (which radiate electromagnetic fields).
9. Do not connect the LAN/WAN port to any network other than an Ethernet network.
10.Do not attempt to upgrade your equipment in an unstable power environment. This could
cause unexpected damages.
11.Do not work on the system during lightning storms. Please disconnect all cables.
12.Children don't recognize the risks of electrical appliances. Therefore use or keep the
equipment only under supervision of adults or out of the reach from children.
13.No repair can by performed by the end user, if you experience trouble with this
equipment, for repair or warranty information, please contact your supplier.
Electrical Powering:
The Z-60 can be powered with correct power adaptor, the power adaptor must be 12V/1.5A.
Any damage caused to the Z-60 as a result of using unsupported power adaptors will not be
covered by the manufacturer’s warranty.
Product Disposal Warning:
Ultimate disposal of this product, accessories, packing, especially the batteries should be
handled carefully for recycle and nature protection in accordance with national laws and
regulations.
!

Table of Contents
Introduction...........................................................................................................................................................................2
Z-60 Hardware Overview......................................................................................................................................................3
FrontPanel..................................................................................................................................................................3
Z-60 LED Indications............................................................................................................................... 3
RearPanel ..................................................................................................................................................................4
Z-60 Connectors..................................................................................................................................... 4
Z-60 Specifications................................................................................................................................................................5
Z-60 PortUsage..........................................................................................................................................................7
Z-60 Quick Installation Wizard...............................................................................................................................................9
BeforeyouBegin.........................................................................................................................................................9
AccessControl(UserIDsandPasswords)...................................................................................................................9
HardwareConnections ..............................................................................................................................................10
BrowserConnection ..................................................................................................................................................10
Z-60SetupWizard(QuickInstallation).......................................................................................................................11
Update the Z-60 Configuration Using a Saved Configuration File ........................................................ 11
Manual Setup (Initial Configuration).................................................................................................... 12
WAN Settings....................................................................................................................................... 13
LAN Settings......................................................................................................................................... 16
Wireless Basic ......................................................................................................................................17
Internet Time.......................................................................................................................................18
Numbering Plan ................................................................................................................................... 19
IP Trunk................................................................................................................................................ 20
Trunk DID............................................................................................................................................. 21
Call Routing Table ................................................................................................................................ 22
Wizard Setup Finished ......................................................................................................................... 23
Z-60 Features Description ..................................................................................................................................................25
AccessControl ..........................................................................................................................................................25
AlarmClock...............................................................................................................................................................25
AlphanumericDisplay................................................................................................................................................25
AnsweringPosition....................................................................................................................................................26
AutoAnswer..............................................................................................................................................................26
AutoHold...................................................................................................................................................................26
Auto-Provisioning......................................................................................................................................................26
Automated Attendant andVoiceMail......................................................................................................................27
Automated Attendant Menus.............................................................................................................. 27
Voice Mailboxes................................................................................................................................... 27
AutomatedAttendant/VoiceMail ServiceNumber....................................................................................................28
BusyNumberCallback(IP20xxOnly) ........................................................................................................................28
CallBlocking..............................................................................................................................................................28
CallFork....................................................................................................................................................................28
CallForward..............................................................................................................................................................29
CallHandling.............................................................................................................................................................31
CallLog.....................................................................................................................................................................31
Call Park / Call Park Answer......................................................................................................................................31

Call Pick-Up –Group.................................................................................................................................................31
CallPick-Up–Individual............................................................................................................................................32
Call Restriction Based onClass ofService ................................................................................................................32
Call Restriction Flow Chart........................................................................................................................................33
CallRouting...............................................................................................................................................................33
CallWaiting/Camp-On...............................................................................................................................................34
CallerIDNameand NumberDetection/Generation....................................................................................................34
ClassofService(CoS)...............................................................................................................................................34
Class of Service (CoS) Change ..............................................................................................................34
COFlash...................................................................................................................................................................35
Conference–3-Way..................................................................................................................................................35
Day/NightServiceMode............................................................................................................................................35
DaylightSavingsTime...............................................................................................................................................36
Default(SystemDefault)............................................................................................................................................36
Direct InwardDialing (DID) ........................................................................................................................................36
Direct Inward System Access (DISA)........................................................................................................................37
DirectStationSelection..............................................................................................................................................37
DistinctiveRinging.....................................................................................................................................................37
Do Not Disturb (DND)................................................................................................................................................37
DynamicDNS............................................................................................................................................................38
EmergencyCall.........................................................................................................................................................38
ExtensionNumber.....................................................................................................................................................38
ExtensionPassword..................................................................................................................................................38
Fax/Modem...............................................................................................................................................................39
FeatureAccessCodes...............................................................................................................................................39
FeatureKeyProgramming.........................................................................................................................................42
FeatureReset............................................................................................................................................................43
FileServer.................................................................................................................................................................44
Firewall......................................................................................................................................................................44
Flash –Analog Port (SLT) Flash Recognition.............................................................................................................44
Headset.....................................................................................................................................................................44
Hold...........................................................................................................................................................................44
HoldReminder...........................................................................................................................................................44
Hotline.......................................................................................................................................................................45
Hot Dial Pad ..............................................................................................................................................................45
IntercomCalling.........................................................................................................................................................45
LCDBacklightTimer..................................................................................................................................................45
LCDand InteractiveKeys..........................................................................................................................................46
LiveRecording(OneTouchRecord)..........................................................................................................................46
MessageWaitingIndication(MWI).............................................................................................................................46
Multi-LineAppearance...............................................................................................................................................46
Music on Hold (MoH).................................................................................................................................................47
Mute..........................................................................................................................................................................47
NetworkAddressTranslation(NAT)...........................................................................................................................47
NumberingPlan.........................................................................................................................................................47
On-HookDialing ........................................................................................................................................................48
OperatorCall(Call Attendant)....................................................................................................................................48
OutsideLineCalling...................................................................................................................................................49
Paging.......................................................................................................................................................................49
Paging(All/Group)/Paging Answer...........................................................................................................................49
Paging Allow / Deny...................................................................................................................................................49
ParentalControl.........................................................................................................................................................50

PauseInsertion..........................................................................................................................................................50
PhoneBook...............................................................................................................................................................50
PhoneLock/Unlock....................................................................................................................................................50
Phone Reset–Default...............................................................................................................................................51
Phone Reset –Feature Keys.....................................................................................................................................51
Feature Access Code:........................................................................................................................... 51
Plug & Play................................................................................................................................................................51
PrintServer ...............................................................................................................................................................51
PSTNBackup............................................................................................................................................................51
PSTN(FXO)Lines.....................................................................................................................................................52
QualityofService (QoS)............................................................................................................................................52
Registration Server...................................................................................................................................................52
ReminderTone..........................................................................................................................................................52
RemoteSIPPhone Connection .................................................................................................................................53
Remote IP20xx Programming Examples .............................................................................................. 53
Router.......................................................................................................................................................................54
ServiceModeChange ...............................................................................................................................................55
SIPTrunk ..................................................................................................................................................................55
StationMessageDetailedRecording(SMDR)............................................................................................................56
SystemSpeedDial....................................................................................................................................................56
System Time and Date ..............................................................................................................................................56
Z-60SystemNetworking (IGW Group).......................................................................................................................57
IGW Group Characteristics................................................................................................................... 57
Transfer/Recall........................................................................................................................................................57
TrunkGroup ..............................................................................................................................................................58
TrunkRingType........................................................................................................................................................58
UCD(Uniform Call Distribution) Group (or Hunt Group).............................................................................................58
UCD Group Login / Logout ................................................................................................................... 59
Universal Plugand Plan (UPNP)................................................................................................................................59
VolumeControl..........................................................................................................................................................59
WebManagement .....................................................................................................................................................60
WizardSetup.............................................................................................................................................................60
Auto-Attendant and Voice Mail System Overview...............................................................................................................61
AutomatedAttendant(AA)Features ..........................................................................................................................61
Automated Attendant Service Mode...................................................................................................61
Automated Attendant Service Menus ................................................................................................. 61
Automated Attendant Single Digit Table ............................................................................................. 62
Dial by Name........................................................................................................................................ 62
DTMF Digit Detection........................................................................................................................... 63
Automated Attendant Call Routing Destination .................................................................................. 63
VoiceMail(VM)Features ..........................................................................................................................................64
32 Hours Recording Time..................................................................................................................... 64
50 Extension Voice Mailboxes .............................................................................................................64
50 Virtual Voice Mailboxes .................................................................................................................. 64
200 Voice Mail Messages per Mailbox.................................................................................................64
AnnouncementMessage .....................................................................................................................64
Email Notification ................................................................................................................................65
Voice Mailbox Access........................................................................................................................... 65
ReviewingMessages............................................................................................................................66
Forward Messages to Other Mailboxes ...............................................................................................66
Leave a Message at Another Extension(s) ........................................................................................... 67

Message Folders ..................................................................................................................................67
Personal Greeting ................................................................................................................................ 68
Personal Voice Mail Password .............................................................................................................68
Reply to a Message.............................................................................................................................. 68
Message Backup ..................................................................................................................................68
ManagementMenu....................................................................................................................................................68
AdministratorMailbox......................................................................................................................... 68
Program a Mailbox as an Administrator: .............................................................................................69
AdministratorLogin: ............................................................................................................................69
Change the Greeting Mode.................................................................................................................. 69
Recording Automated Attendant Greetings ........................................................................................ 69
Add a Virtual Mailbox .......................................................................................................................... 69
Delete a Mailbox.................................................................................................................................. 70
Change a Personal Password ............................................................................................................... 70
VoiceMessages........................................................................................................................................................70
Two Language Service..........................................................................................................................70
Upload a Music on Hold (MoH) File ..................................................................................................... 70
File Storage .......................................................................................................................................... 70
VoiceMail/ AutomatedAttendantFlowcharts............................................................................................................72
AutomatedAttendant.......................................................................................................................... 72
Make an Outside Call........................................................................................................................... 73
Dial by Name........................................................................................................................................ 74
Subscriber Voicemail Flowchart...........................................................................................................75
Leave a Message.................................................................................................................................. 76
Mailbox Administer Flowchart............................................................................................................. 77
Listening to Messages.......................................................................................................................... 78
Delete All Messages............................................................................................................................. 79
Record a Personal Greeting .................................................................................................................80
Change a Mailbox Password................................................................................................................81
Record Your Name............................................................................................................................... 82
Leave a Message at Another Extension ............................................................................................... 83
Transfer a Message to Another Mailbox.............................................................................................. 84
Message Reply ..................................................................................................................................... 85
System Administrator’s Voicemail Flowchart ......................................................................................86
Change the Greeting Mode.................................................................................................................. 87
RecordingGreetings ............................................................................................................................88
Add a Virtual Number .......................................................................................................................... 89
Delete a Mailbox.................................................................................................................................. 90
Change Mailbox Password................................................................................................................... 91
Recording Voice Prompts..................................................................................................................... 92
Z-60 Programming Overview..............................................................................................................................................93
Logging Into the Z-60.................................................................................................................................................93
BrowserConnection ..................................................................................................................................................93
Programming Menu Overview............................................................................................................................................95
DeviceInfo ................................................................................................................................................................96
Summary .............................................................................................................................................97
LAN ...................................................................................................................................................... 97
WAN .................................................................................................................................................... 98
Route ................................................................................................................................................... 98
ARP .................................................................................................................................................... 101

DHCP.................................................................................................................................................. 101
AdvancedSetup......................................................................................................................................................102
WAN .................................................................................................................................................. 103
Advanced –WAN (DHCP Mode) ........................................................................................................ 104
Advanced –WAN (PPoE Mode) ......................................................................................................... 105
LAN .................................................................................................................................................... 106
NAT ....................................................................................................................................................107
Port Triggering ................................................................................................................................... 109
DMZ Host........................................................................................................................................... 110
Security.............................................................................................................................................. 111
Parental Control................................................................................................................................. 113
Quality of Service (QoS) ..................................................................................................................... 115
Bandwidth Control............................................................................................................................. 116
Routing .............................................................................................................................................. 117
Dynamic Domain Name Server (Dynamic DNS) ................................................................................. 118
UPNP.................................................................................................................................................. 120
File Server ..........................................................................................................................................120
Print Server ........................................................................................................................................ 124
Wireless............................................................................................................................................. 127
Station Info ........................................................................................................................................ 136
Power Saving ..................................................................................................................................... 137
MobileNetwork........................................................................................................................................................137
Voice.......................................................................................................................................................................138
Phone ................................................................................................................................................ 139
Phone Extension ................................................................................................................................139
Trunk .................................................................................................................................................142
IP Trunk.............................................................................................................................................. 143
Trunk DID........................................................................................................................................... 147
Trunk Group.......................................................................................................................................148
AnsweringPosition ............................................................................................................................ 149
Call Routing........................................................................................................................................150
Call Restriction................................................................................................................................... 152
EmergencyNumbers.......................................................................................................................... 153
System ...............................................................................................................................................154
Numbering Plan ................................................................................................................................. 154
Service Mode ..................................................................................................................................... 161
Transmission...................................................................................................................................... 163
IGW (Intelligent Gateway) Group ...................................................................................................... 166
SMDR.................................................................................................................................................170
UCD Call Log....................................................................................................................................... 171
VoiceMail................................................................................................................................................................171
General .............................................................................................................................................. 172
Phone Extension ................................................................................................................................178
Virtual Extension................................................................................................................................ 181
Update MoH File................................................................................................................................ 182
Update Voice File............................................................................................................................... 183
Holiday............................................................................................................................................... 183
Advanced........................................................................................................................................... 184
Registered Phone............................................................................................................................... 184
Management...........................................................................................................................................................185

Settings –Backup, Update, Restore Default ......................................................................................185
System Log......................................................................................................................................... 188
WAN Management Protocol TR-069 Client........................................................................................ 190
Time Settings –Internet Time............................................................................................................ 191
Time Settings –Daylight Saving Time.................................................................................................192
Access Control ................................................................................................................................... 193
Services.............................................................................................................................................. 194
IP Addresses....................................................................................................................................... 195
Password ........................................................................................................................................... 195
PTC Configure .................................................................................................................................... 196
Update Software................................................................................................................................196
Reboot ............................................................................................................................................... 197
Diagnostics .............................................................................................................................................................198
Refresh Mode .................................................................................................................................... 200
NetworkConnection.......................................................................................................................... 200
PSTN Line / IP Trunk Line / AA / FXS .................................................................................................. 200
Logout.....................................................................................................................................................................200
IP2061 IP Telephone User Guide......................................................................................................................................201
GettingStarted ........................................................................................................................................................201
Front View of the IP2061 .........................................................................................................................................202
LEDOverview..........................................................................................................................................................202
LCDOverview .........................................................................................................................................................203
Rear View of the IP2061..........................................................................................................................................204
IP2061I/OPorts......................................................................................................................................................205
HardwareInstallation...............................................................................................................................................206
Desktop Stand....................................................................................................................................206
Handset Connection .......................................................................................................................... 206
Connecting the IP2061.......................................................................................................................207
Power-over-Ethernet (PoE) Connection.............................................................................................207
5V/2A Power Adapter........................................................................................................................ 208
Extended Dial Module (EDM).............................................................................................................208
IP2061 Factory Default ...................................................................................................................... 209
Install the IP2061 Using DHCP............................................................................................................209
BasicOperation.......................................................................................................................................................210
Introduction....................................................................................................................................... 210
Z-60Registration................................................................................................................................ 210
Calls ...................................................................................................................................................210
Caller ID & User ID ............................................................................................................................. 210
BasicCallFeatures..................................................................................................................................................211
Making a Call: .................................................................................................................................... 211
Receiving a Call: .................................................................................................................................211
Conference: .......................................................................................................................................211
Do Not Disturb (DND): ....................................................................................................................... 211
Hold: .................................................................................................................................................. 212
Last Number Redial:........................................................................................................................... 212
Mute:................................................................................................................................................. 212
Transfer (Blind Transfer): ...................................................................................................................212
Transfer (Supervised Transfer):..........................................................................................................212
Voice Mail: .........................................................................................................................................212
Volume Adjustment While on a Call: ................................................................................................. 213

AdvancedCallFeatures...........................................................................................................................................213
Auto Answer: .....................................................................................................................................213
Call Blocking Based on Caller ID: ........................................................................................................ 213
Call Forward:......................................................................................................................................213
Call Log:.............................................................................................................................................. 214
Phonebook: .......................................................................................................................................214
Ring Type ........................................................................................................................................... 214
Speed Dialing .....................................................................................................................................214
IP2061StationInformation.......................................................................................................................................215
IP2061 Phone Settings...........................................................................................................................................216
Network Settings ............................................................................................................................... 216
IP2061WebProgramming.......................................................................................................................................219
Login Information .............................................................................................................................. 219
IP2061 Web Login Procedure.............................................................................................................220
IP2061WebProgrammingTabs..............................................................................................................................221
Information Tab ................................................................................................................................. 221
Network Tab ...................................................................................................................................... 221
Phone Tab.......................................................................................................................................... 223
SW (Software) Upgrade Tab ..............................................................................................................228
SIP Tab ............................................................................................................................................... 229
System Tab.........................................................................................................................................234
EDM Tab ............................................................................................................................................ 236
Phonebook Tab..................................................................................................................................237
IP2061Specifications ..............................................................................................................................................239
Main Unit........................................................................................................................................... 239
LAN and PC Ports ...............................................................................................................................239
Power Supply ..................................................................................................................................... 239
Voice Handling................................................................................................................................... 239
Tone Function.................................................................................................................................... 240
Appendix.................................................................................................................................................................241
Z-60 Gateway Wall Mount Template .................................................................................................241
Feature Access By Phone Type........................................................................................................... 242

1
Z-60 Technical Manual

2
Introduction
The Z-60 is an all-in-one total office solution that provides small offices and multiple location
business with a phone system, firewall/router, 802.11 access point, DHCP server and LAN port in
one product.
Features and functions essential to most business including auto-attendant, voice mail, multi-line
appearances, three way call conferencing, intercom calling, music on hold, call-forwarding and
much more are included as standard features.

3
Introduction
Z-60 Hardware Overview
Front Panel
The Z-60 front panel contains multiple LEDs to indicate the system’s current status.
Z-60 LED Indications
LED
Color
Status
Description
POWER
Red
Solid
Firmware update in progress
Blue
Flashing
System boot up
Blue
Solid
Run
Off
Power off
WIRELESS
Blue
Solid
Wireless LAN active
Off
Wireless LAN inactive
Line 1 - Line 6
Blue
Solid
PSTN line in use
Off
PSTN line idle
TEL
Blue
Solid
FXS port in use
Off
FXS port idle
LAN
Blue
Flashing
Active LAN traffic
Blue
Solid
LAN connected
Off
LAN not connected
WAN
Blue
Flashing
Active WAN traffic
Blue
Solid
WAN is connected. IP address obtained
Red
Solid
WAN not connected

4
Hardware Overview
Rear Panel
The Z-60 rear panel contains Ethernet ports, Line connectors, analog, USB, and power connections.
Z-60 Connectors
Label
Connector Type
Description
WAN
RJ-45
Gigabit Ethernet WAN/remote network
connection. 10/100/1000-BASE-T
Ethernet port for connection to fiber,
cable modem, DSL modem, etc.
LAN
RJ-45
10/100-BASE-T Ethernet port for
connection to LAN.
LINE 1-6
RJ-11
PSTN telephone line interface for lines 1
through 6.
TEL
RJ-11
Analog station port for connection of
single line telephone or analog fax
machine.
USB
USB
USB port for connection of external
storage or USB printer.
Power
Connection of manufacturer-supplied
power connector.

5
Z-60 Specifications
Interfaces
WAN Interface: 10BaseBASE-T/100BASE100Base-
TX/1000BaseBASE-T Gigabit Ethernet port
CO Interface: 6 FXO (Loop Start, for PSTN)
Analog Device Interface: 1 FXS (for analog telephone
or fax machine)
LAN Interface: 1 Ethernet (10BASE10Base-
T/100BASE100Base-TX)
Built-in 802.11b/g/n WiFi access point
USB Interface: Connects to your USB storage devices;
USB printer or 3G dongle.
Terminals
1 Analog Terminal (Analog Telephone or analog fax
machine)
49 IP Stations (Wired or WiFi IP-Phone)
TCP/IP Protocols
IP Protocol (791)
ARP (RFC 826) / RARP (RFC 903)
ICMP (RFC792)
TCP (RFC 793)
UDP (RFC 768)
SNTP
DNS
HTTP
Telnet
TFTP
RTP
Static Routing
NAT with ALGs
IP Address Assignment
Static
Dynamic
Subnet Mask
PPPoE Client (RFC 2516)
Primary and Secondary DNS
DHCP Server (RFC 2131-2132)
DHCP Client (RFC 2132)
Routing
RIP v1/v2
Static routing
DHCP Server/Relay/Client
DNS Relay
NAT/NAPT
Virtual Server
Virtual Server
Port Trigger
DMZ
QoS
IP QoS function (RFC 1349)
IP Precedence
Bandwidth Control
VoIP Protocols
SIP (RFC 3261)
SDP(RFC2327, RFC3264)
Real Time Protocol (RTP ; RFC 1889)
MD5 (RFC3261 HTTP) digest authentication
Echo Cancellation
Voice Codec: G.711u, G.711a, G726-16, G726-24,
G726-32 and G.726-40
Support FAX/modem tone detection and auto-fallback
to G.711
T.38
IP Trunks
Support up to 12 IP Trunks
Bandwidth required 100Kbps for G.711 calls
SIP messages including INVITE, re-INVITE, ACK,
CANCEL, OPTIONS, BYE, REGISTER, INFO, REFER,
SUSCRIBE/NOTIFY and REPLACE messages.
SIP Outbound Proxy,
SIP Proxy and Registrar
Auto-Registration when power-on
Session Timer support
Support IP address, domain name, user name, display
name for SIP URL
Audio Codecs
Codec: G.711 a-law/mu-law 100Kbps, G.726-
16/24/32/40 Kbps
SIP Call Offer /Answer: Codec auto capacity exchange
Echo Cancellation: G.168 for each voice line
Silence Detection/Suppression
Comfort Noise Generation
Adaptive jitter buffer
Different frame size support (10,20,30,40, 50, and
60ms)
Packet loss concealment
Out-band (RFC2833) and In-band DTMF
Security
Password protected system management
User authentication for PPP (PAP/CHAP/MSCHAP)
Firewall
VLAN Tagging
Packet Filtering
Access Control List

6
Z-60 Specifications
Wireless Security:
SupportWEP (64, 128-bit) encryption
802.1x and WPA/WAP2 authentication
MAC Address-based access control
WDS support
Configuration Management
LAN/WAN management via Telnet interface or Web-
based browser interface
Firmware upgrade available by TFTP/ HTTP
Status display and event report from Web-based
management
Configuration Save and Restore
Reset to factory default
Radio - WLAN
Standard: IEEE 802.11b/g/n
Media Access Control : CSMA/CA with ACK
Modulation: OFDM/CCK
Frequency Range (Range depends on different
country)
Remote Diagnostics
Syslog
Device Diagnostic, Enable remote test following:
Test the connection to your local network
The connection to your Internet service provider
PSTN line status
IP trunk line status
VM/AA Line line status
FXS line status
Physical Interfaces
One 10/100/1000BaseT Ethernet port (RJ-45) for WAN
interface
One 10/100BaseT Ethernet port (RJ-45) for LAN
interface
One Telephone interface (RJ-11)
Six PSTN Line interface (RJ-11)
One USB Host interface
LED Status
Power
Voice Paths
Z-60 Gateway SIP Trunk: 12
Z-60 Gateway Analog Trunk: 6
IP2061 Phone: 4
Requirements
Input: Voltage Range 90~230 VAC
Output: 12V DC / 1.5A
Operating Environment
Temperature: 0º-40º Celsius
Humidity: 10% to 90%, non-condensing
Physical Dimensions
190(W) x 280(L) x 34(D) (mm)

7
Z-60 Technical Manual
Z-60 Port Usage
Port Range
TCP/UDP
Description
Customizable
Note
35000-38000
UDP
System RTP Proxy port
5060
UDP
SIP port for IP Trunk
Yes
Trunk signal
30000-30100
UDP
RTP ports for IP Trunk
Yes
Trunk Audio
5070
UDP
Internal SIP Server port for registration
Yes
Sip station
21
TCP
ftp signal port
Yes
23
TCP
telnet port
Yes
80
TCP
http port
Yes
Required for
programming
69
UDP
tftp port
Yes
38600
UDP
private protcol between IGW and PT
38500
UDP
IGDDP port
38700-38800
TCP
Phone register nat port
30005
UDP
TR69 port
Yes
514
UDP
System Log
Yes
40000-40012
UDP
DSP bounding port
5897
UDP
PTC client

8
Z-60 Specifications
