MP-WF100M User Guide
Wi-Fi Digital Mobile DVR
MISUMI
MISUMI
Manufacturer & Exporter

TABLE OF CONTENTS
PACKAGE CONTENTS
PACKAGE CONTENTS
DIMENSION
DIMENSION
IMPORTANT
IMPORTANT
OVERVIEW
OVERVIEW
STORAGE SLOT
STORAGE SLOT
CONNECTING WITH CAMERA
CONNECTING WITH CAMERA
TURNING THE DVR SWITCH
TURNING THE DVR SWITCH
TO RECORD A VIDEO
TO RECORD A VIDEO
WiFi FUNCTION
WiFi FUNCTION
SPECIFICATION
SPECIFICATION
BATTERY
BATTERY
1-1. Removing the battery
1-2. Inserting the battery
1-3. Charging the battery
WiFi SETTING MENU
WiFi SETTING MENU
1-1. Status
1-2. Admin
1-3. Wireless
1-4. LAN
1-6. Firewall
1-7. Routing
1-8. Misc
1-9. Webcam
1-10. Storage
2
3
3
4
4
4
5
5
6
6
7
7
8
8
9
10
11
17
20
21
24
26
26
27
33
34
1-5. NAT
POWER BANK FUNCTION
POWER BANK FUNCTION

IMPORTANT SAFETY INSTRUCTIONS
This symbol intends to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
The symbol on the product or on its packaging indicates that this
product must not be disposed of with your other household waste.
Instead, it is your responsibility to dispose of your waste equipment
by handing it over to a designated collection point for the recycling
of waste electrical and electronic equipment. The separate collection
and recycling of your waste equipment at the time of disposal will
help to conserve natural resources and ensure that it is recycled in a
manner that protects human health and environment
This symbol intends to alert the user to the presence of unprotected
“Dangerous Voltage” within the product’s enclosure that may be
strong enough to cause a risk of electric shock.
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER.
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION

PACKAGE CONTENTS
DIMENSION(mm)
Unit : mm (+0.5)
64
112
2.5
2.5
2
12
4.30

OVERVIEW
RJ45
Record button/
Stop button
Power bank button
Power charging
(Micro USB )
Power output 1
for discharging
(USB A type-5V/2A)
battery slot
Power output 2
for UVC camera
(USB A type-5V/1A)
Micro SD card slot
(support up to 32GB)
Power OFF
LED
indicator
WiFi mode
REC. mode
BATTERY
The DVR uses a rechargeable battery. How long the battery can last before it needs recharging
depends on how you use the DVR.
The DVR can work about 6hr when the battery power is full.
Removing the battery
1. Pull out the battery male connector according to the diagram.

Inserting the battery
1. Insert the battery male connector to the DVR battery port according to the diagram.
Charging the battery
1. When the battery power is low(20% ,less than 3.2V), DVR LED1 indicator will flash, please
charge the battery immediately.
2. The battery will be fully charged in approximately 3.5 hours(5V/2A), and LED1 and LED2
indicators will be on.
(To enable faster charging time, please do not use DVR while charging.)
DVR LED1 and LED 2 indicators will flash consecutively when the battery is charging.
LED1 indicator
LED2 indicator
1.Make sure the battery is charging correctly. Check that battery male connector
is properly inserted to DVR battery port.
2.DVR can work while charging.
3. When battery capacity is charged to 60% (which means more than 3.7V),
LED1 indicator will be on.
Red (supply input voltage 2.8V to 5.5V, ambient temperature range -40ºC~85ºC)
Black (GND)
White (battery temperature sensor setting)

STORAGE SLOT
DVR storage slot supports microSD card up to 32GB. Use the microSD card to store
your photos, videos.
Inserting microSD card
1. Please insert microSD card according to the diagram and push it until it clicks into place.
CONNECTING WITH CAMERA
Connecting with USB 2.0 digital camera directly.
(MD-N20XX SERIES-order in advance)
Removing microSD card
1. Push the microSD card to eject it from its slot.
1.When microSD card is not inserted, the DVR cannot work.
1.WF100 DVR is only compatible with UVC signal cameras made with
291B, 292A and 292B IC.

TURNING THE DVR SWITCH
Turning the DVR switch on
1. DVR switch has 3 functions as shown below:
Power off
REC. mode
(See” RECORD” to find out how)
WiFi mode
(See” WiFi” to find out how)
POWER BANK FUNCTION
1. Using USB 2.0 A-type cable to connect device and DVR.
2. Press “discharging button”.
3. The current output is 5V/2A
LED display when discharging.
LED1
DVR
Battery capacity
N/A
50%
turn on
turn on
Discharging
button
turn on100%
LED2
1.Please check the connected device charging display when DVR discharging.
2.When the battery is fully charged, DVR will stop and the LED indicator will
turn OFF automatically.

TO RECORD A VIDEO
Two ways to record a video:
1. Switch to REC function.
2. Switch to WiFi function. (SEE “WiFi ” to find out how)
WiFi FUNCTION
Any wifi equipment can preview video via DVR WiFi function.
User can adjust setting of Admin, wireless, LAN, NAT, Firewall, Routing, Misc, camera video, storage.
Switch to REC function.
1. Switch to REC function, LED4(blue) indicator will flash.
2. Recording video: press power bank button, then press “REC. button”.
3. When DVR is recording, LED3(red) indicator will be on.
1.Make sure to plug in your microSD card and connect with external camera before
start recording. Videos captured will be stored into your microSD card.
2.If you have not yet inserted your microSD card to the DVR, see "STORAGE SLOT"
to find out how.
LED4 indicator
Power bank button
LED3 indicator REC. button
REC. function

How to connect to DVR Wi-Fi
1. On PC: Search DVR wifi SSID network and select [connect].
2. On smartphone: Turn smartphone wifi on, search DVR wifi SSID “Demo_AP_511204” network
and link.
(PC) (On smartphone)
(PC) (On smartphone)
192.168.0.1
3. Open IE or Firefox or google chrome browser and type in “192.168.0.1”
on URL bar. and log into your account.
4. Login account user name is “admin”, password is “admin”.
Click “OK” to enter wifi setting menu.
1.Change SSID name, see “Wireless-Basic Settings” to find out how.
1.Change account name and password, see “Admin-Managment” to find out how.
192.168.0.1
click
9

WiFi SETTING MENU
Status
1. Firmware Version:
Firmware Version:
The version number of the firmware currently installed is displayed here.
2. IP Address, Subnet Mask, and Default Gateway:
IP Address, Subnet Mask, and Default Gateway:
The Internet IP Address, Subnet Mask, and
Default Gateway IP Address of the router, as seen by external users on the Internet, are displayed.
3. DNS:
DNS:
The DNS (Domain Name System) IP Addresses currently used by the router are shown here.
Multiple DNS IP settings are common. In most cases, the first available DNS entry is used.
Status-Log
1. The log file keeps a running log of events and activities occurring on the device.
You may want to save the log files by clicking on Log Setting. When the device is rebooted,
the logs are automatically cleared.
10

Admin-Working Mode
1. There are three mode: AP, WISP, STA.
Admin-Management(How to change login account name and password)
Here user can change login account username and password.
1. Click Admin -> management
2. To change the user name, type a new name in the User Names box.
(System default username is “admin”)
3. Type current password. (System default current password is “admin”)
4. Type a new password in the New Password box. Type again new password in the
Re-type-Password and click OK to apply your changes.
11

Admin-Working Mode: AP
Access point (AP) is a device that allows wireless devices to connect to a wired network using
Wi-Fi, or related standards.
Admin-Working Mode: WISP
Clients connect wirelessly to an AP and transmit data through AP to access the Internet.
1. Click survey button.
2. Look for available wireless network in AP List then click choose.
3. Type wireless network password in Pre-shared Key box and click OK.
12

1.Wireless SSID
Wireless SSID
- The SSID of the AP your Router is going to connect to as a client.
You can also use the search function to select the SSID to join.
2.Survey
Survey
- Click this button, you can survey the AP which runs in the current channel.
3.Security Mode
Security Mode
- This option should be chosen according to the AP's security
configuration. It is recommended that the security type is the same as
your AP's security type.
4.Pre-shared Key
Pre-shared Key
- If the AP your Router is going to connect needs password, you
need to fill the password in this blank.
Admin-System Settings
NTP Server:
NTP Server:
Enter the address of an NTP server to receive time updates.
Time Zone:
Time Zone:
Select the time zone for your location.
Admin-Working Mode: STA
Do not suggest to modify this mode, in order to device work normally.
13

Admin-Firmware Upgrade
You can upgrade the firmware of the device using this tool. Make sure that the firmware you want
to use is saved on the local hard drive of the computer. Click on Browse to search the local hard
drive (.img) for the firmware to be used for the update.
Admin-Configuration
Restore Factory Default:
Restore Factory Default:
System is reset to the factory default settings.
14

Backup Settings:
Backup Settings:
To Select this setting , system will pop-up a windows, and click "save" button
to save file(.bin) to your specified path.
Restore Settings:
Restore Settings:
To use previous setting, please make sure you have saved setting file (.bin).
Then, browse to search restore setting file (.bin) in the local hard drive.
Admin-Tools
If for any reason the device is not responding correctly, you may want to restart the unit by
clicking on the Reboot button.
15

Admin-Log Settings
Log Settings:
Log Settings:
Not only does the device display the logs of activities and events, it can also be
setup to send these logs to another location. The logs can be sent via email to a
specific email account.
SMTP Server:
SMTP Server:
The address of the SMTP (Simple Mail Transfer Protocol) server that will be used to
send the logs.
Email Address:
Email Address:
The email address the logs will be sent to. Click on Email Log Now to send the email.
Admin-Language
Specify language of the device menu.
16

Wireless-Basic Settings
Select the appropriate “wireless network Mode” based on the wireless clients in your network.
The drop-down menu options are 802.11b, 802.11g, 802.11n, Mixed 802.11b, 802.11g,
Mixed 802.11b, 802.11g, 802.11n. Auto channel selection is the default setting. User select
a wireless channel.
Admin-Logout
Log out user account if you want to change setting. Re-type your account and password.
17

Wireless-MAC Filtering
MAC (Multimedia Access Control) addresses are unique sets of codes assigned to electronic
devices that identify the devices on a network. Use MAC filters to allow or deny wireless clients.
Wireless-Security
Security mode includes different levels of security which you can use to protect your
data from intruders.
1. Disable 2. WEP (Wired Equivalent Privacy)
3. WPA-PSK(Pre-Shared Key) 4. WPA2-PSK(Pre-Shared Key 2)
5. WPA-PSK/ WPA2-PSK 6. WAPI-PSK,
7. WPA-802.1X, 8. WPA2-802.1X,
9. WPA-802.1X/WPA2-802.1X
18

Wireless-Advanced Settings
User can set Wireless-Advanced Settings item: 1. Radio Preamble, 2. Channel Width, 3. Basic Rate,
4. Transmission power , 5. Fragmentation Threshold, 6. RTS Threshold, 7. Beacon Period
8. DTIMPeriod, 9. WMM, 10.UAPSD, 11. Green Field, 12. Short Guard Interval
Wireless-WPS
Wi-Fi Protected Setup (WPS) is a network security that allow users to connect wireless client device.
1. Select enable WPS.
2. Click Generate PIN Code button to get WPS pin code and use it to connect network.
19
