MitraStar DSL-2401HN2-E1C User manual

1st Edition, Mar ,2017
DSL-2401HN2-E1C
User’s Guide

IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
Graphics in this book may differ slightly from the product due to differences in operating systems,
operating system versions, or if you installed updated firmware/software for your device. Every
effort has been made to ensure that the information in this manual is accurate.

Contents 3
Contents
7 Chapter 1: Introduction
7Overview
7 Hardware Connection
9 LEDs (Lights)
11 Chapter 2: Introducing the Web Configurator
11 Overview
11 Accessing the Web Configurator
12 The Network Map Screen
14 The Status Screen
15 The Web Configurator Layout
15 Title Bar
15 Main Window
17 Chapter 3: WAN
17 The WAN Screen
19 Edit ADSL Ethernet Connection
24 Edit VDSL Ethernet Connection
28 Chapter 4: Wireless 2.4GHz
28 Wireless General Screen
30 No Security
31 Basic (WEP Encryption)
31 More Secure (WPA2-PSK or WPA/WPA2 PSK mixed)
33 More AP Screen
34 Edit More AP
35 MAC Authentication Screen
36 The WPS Screen
38 The WDS Screen
39 The WMM Screen
40 Scheduling Screen
41 Add or Edit Schedule
42 Advanced Screen
43 Chapter 5: LAN
43 The LAN Setup Screen
45 The Static DHCP Screen

Contents 4
46 The IP Alias Screen
47 The UPnP Screen
48 The IPv6 LAN Setup Screen
52 Chapter 6: Static Route
52 Configuring Static Route
53 Add/Edit Static Route
53 IPv6 Static Route
54 Add/Edit IPv6 Static Route
55 The DNS Route Screen
55 Add/Edit DNS Route
56 The Current Route Screen
57 Chapter 7: Quality of Service (QoS)
57 The QoS General Screen
58 The Queue Setup Screen
59 Edit a QoS Queue
59 The Class Setup Screen
61 Add/Edit QoS Class
65 The QoS Monitor Screen
66 Chapter 8: Network Address Translation (NAT)
66 The General Screen
66 The Port Forwarding Screen
67 The Port Forwarding Screen
68 The Port Forwarding Add/Edit Screen
69 The Address Mapping Screen
70 The Address Mapping Rule Edit Screen
71 The DMZ Screen
71 The ALG Screen
73 Chapter 9: Dynamic DNS
73 The Dynamic DNS Screen
75 Chapter 10: Filter
75 The IP/MAC Filter Screen
77 The IPv6/MAC Filter Screen
79 Chapter 11: Firewall
79 Firewall General Screen
80 Add/Edit Interface Default Policy Screen
80 Rules Screen
83 Rules Edit Screen

Contents 5
84 DoS Screen
85 The DoS Advanced Screen
86 Chapter 12: Parental Control
86 The Parental Control Screen
88 Add/Edit a Parental Control Rule
90 Chapter 13: Certificates
90 Local Certificates
91 Trusted CA
92 Trusted CA Import
93 View Certificate
95 Chapter 14: VoIP
95 The SIP Account Screen
96 Edit SIP Account
99 The SIP Service Provider Screen
100 Edit SIP Service Provider
105 Phone Screen
106 Call Rule Screen
107 Chapter 15: System Monitor
107 The Log Screen
108 The WAN Traffic Status Screen
109 The LAN Traffic Status Screen
110 The NAT Traffic Status Screen
111 The VoIP Status Screen
113 Chapter 16: User Account
113 Overview
113 The User Account Screen
114 Chapter 17: System
114 The System Screen
115 Chapter 18: Time Setting
115 The Time Setting Screen
117 Chapter 19: Log Setting
117 The Log Setting Screen
120 Chapter 20: Firmware Upgrade
120 The Firmware Upgrade Screen

Contents 6
122 Chapter 21: Backup/Restore
122 The Backup/Restore Screen
124 The Reboot Screen
125 Chapter 22: Remote Management
125 The General Screen
125 The WWW Screen
127 Telnet Screen
127 FTP Screen
129 SNMP Screen
130 DNS Screen
131 ICMP Screen
132 SSH/SCP/SFTP Screen
134 Chapter 23: Troubleshooting
134 Overview
134 Power, Hardware Connections, and LEDs
135 Router Access and Login
136 Internet Access
137 Wireless Internet Access
138 Phone Calls and VoIP
139 Appendix A: Safety Warnings

1
Chapter
Chapter 1 Introduction 7
CHAPTER 1
Chapter 1 Introduction
1.1 Overview
The DSL-2401HN2-E1C is a VDSL2 router with high-speed Internet access and wireless
networking capability. It has a phone port for making calls over the Internet (Voice over IP or
VoIP).
The following figure shows an application example of the Router:
The Router provides wired and wireless Internet access to home devices on the LAN as well as VoIP
service.
Figure 1 Application Example
VoIP Phone
DSL-2401HN2-E1C
1.2 Hardware Connection
Make sure to use the proper cables and power adapter to connect the
Router.
Figure 2 The Rear Panel

Chapter 1 Introduction 8
The following table explains the connectors and buttons on the rear panel:
Table 1 The Rear Panel
CONECTOR DESCRIPTION
RESET Use this button to restore the default settings of the Router. Press this button for 5
seconds to restore default values. Press 1 second or longer to restart it.
Note: If you reset the Router, you will lose all configurations that you had previously
and the password will be reset to the defaults.
WPS/WLAN Use this button to enable or disable the WiFi and WPS features on the Router.
The WiFi feature is enabled by default. Press this button for 1 second to turn it off.
To enable the WPS feature, press the button for 5 seconds The WPS LED on the front
panel will flash yellow while the Router sets up a WPS connection with the wireless
device.
Note: To activate WPS, you must enable WPS in the Router and in another wireless
device within two minutes of each other.
ON/OFF Use this button to turn the Router on or off.
POWER Connect the provided power adapter to the 12V-1A power connector. Attach the
power adapter to a proper power source.
VOIP Use a telephone cable to connect the Router to a VoIP phone for VoIP service.
LAN4-1 Use an Ethernet cable to connect a computer to one of these ports for initial
configuration and/or Internet access.
DSL Use an RJ-11 telephone wire to connect this port to a telephone jack for VDSL WAN
access.

Chapter 1 Introduction 9
1.3 LEDs (Lights)
The following graphic displays the labels of the LEDs.
Figure 3 Front Panel LEDs
Table 2 LED Descriptions
LED COLOR STATUS DESCRIPTION
POWER Green On The Router is receiving power and ready for use.
Red On The Router has hardware failure.
Blinking The Router detected an error while self-testing.
Off The Router is not receiving power.
LAN1-4 Green On The Router has a successful Ethernet connection with a device on
the LAN.
Blinking The Router is sending or receiving data to/from the LAN.
Off The Router does not have an Ethernet connection with the LAN.
WPS/WLAN Green On The wireless network is activated.
Blinking The Router is communicating with other wireless clients.
Off The wireless network is not activated.
Yellow Blinking The Router is setting up a WPS connection.
DSL Green On The Router is connected and synchronized with the central system.
Slow Blinking The Router is detecting a VDSL line.
Fast Blinking The Router is negotiating VDSL line parameters.
Off The Router is off line or not connected to the central system.

Chapter 1 Introduction 10
Internet Green On The Router has an IP connection but no traffic.
It has a WAN IP address (either static or assigned by a DHCP server),
PPP negotiation was successfully completed (if used).
Blinking The Router is negotiating the connection.
Fast Blinking The Router is sending or receiving IP traffic.
Red On The Router attempted to make an IP connection but failed. Possible
causes are no response from a DHCP server, no PPPoE response,
PPPoE authentication failed.
Off There is no Internet connection.
VOIP Green On The SIP registration is successful.
Blinking The Router is negotiating the SIP registration.
Fast Blinking There is incoming or outgoing voice traffic.
Red On The Router has failed to register the VoIP service. There is problem
with the SIP account.
Off There is no VoIP service.
Table 2 LED Descriptions (continued)
LED COLOR STATUS DESCRIPTION

2
Chapter
Chapter 2 Introducing the Web Configurator 11
CHAPTER 2
Chapter 2 Introducing the Web Configurator
2.1 Overview
The web configurator is an HTML-based management interface that allows easy device setup and
management via Internet browser. Use Internet Explorer 6.0 and later versions, Mozilla Firefox 3
and later versions, or Safari 2.0 and later versions. The recommended screen resolution is 1024 by
768 pixels.
In order to use the web configurator you need to allow:
• Web browser pop-up windows from your device. Web pop-up blocking is enabled by default in
Windows XP SP (Service Pack) 2.
•JavaScript (enabled by default).
•Java permissions (enabled by default).
2.1.1 Accessing the Web Configurator
1Make sure your Router hardware is properly connected.
2Launch your web browser.
3T
ype "https://192.168.1.1:8000" as the URL.
4A password screen displays. Type “admin” as the default Username and the first 6 digits of the
Router’s MAC address as the default password to access the device’s Web Configurator. Click Login.
If you have changed the password, enter your password and click Login.
Figure 4 P
assword Screen
 For security reasons, the Router automatically logs you out if you do not use the web
configurator for five minutes (default). If this happens, log in again.

Chapter 2 Introducing the Web Configurator 12
2.2 The Network Map Screen
After you log into the Web Configurator, the Network Map screen appears. This shows the network
connection status of the Router and clients connected to it.
Use this screen to view the network connection status of the device and its clients. A warning
message appears if there is a connection problem.
You can configure how often you want the Router to update this screen in Refresh Interval.
Figure 5 Network Map: Icon Mode
By clicking a client’s name in the Icon Mode, you can do the following:

Chapter 2 Introducing the Web Configurator 13
• if you want to view information about a client, click the client’s name and Info.
• Click Parental Control to open the following screen where you can block web sites with the
specific URLs. See Chapter 12 on page 86 for more information on this feature.
If you prefer to view the status in a list, click List View in the Viewing mode selection box.
Figure 6 Network Map: List Mode

Chapter 2 Introducing the Web Configurator 14
2.3 The Status Screen
Click Status to display the System Info screen, where you can view the Router’s interface and
system information. You can use the Status screen to look at the current status of the Router,
system resources, and interfaces (LAN, WAN, and WLAN).
Figure 7 System Info

Chapter 2 Introducing the Web Configurator 15
2.4 The Web Configurator Layout
Click Connection Status > System Info to show the following screen.
Figure 8 Web Configurator Layout
B
C
A
a
b
As illustrated above, the main screen is divided into these parts:
•A- title bar
•B- main window
•C- navigation panel
2.4.1 Title Bar
The title bar shows the Logout icon in the upper right corner. Click it to log out of the web
configurator.
2.4.2 Main Window
The main window displays information and configuration fields. It is discussed in the rest of this
document.

Chapter 2 Introducing the Web Configurator 16
Click Ne
twork Map on the System Info screen (ain Figure 8 on page 15) to display the Network
Map sc
reen. See Section 2.2 on page 12 for more information.
Click Virtual Device on the System Info screen (bin Figure 8 on page 15) to display a visual graphic
showing the connection status of the Router’s ports.
Figure 9 Virtual Device

3
Chapter
Chapter 3 WAN 17
CHAPTER 3
Chapter 3 WAN
3.1 The WAN Screen
The Router must have a WAN interface to allow users to use the Ethernet connection to access the
Internet. Use the WAN screen to manage WAN interfaces. Click Network Setting > WAN.
Figure 10 Network Setting > WAN
Table 3 Network Setting > WAN
LABEL DESCRIPTION
ADSL Connections Table
Active This shows whether the ADSL connection is activated.
Name This is the service name of the ADSL connection.

Chapter 3 WAN 18
IP This shows the WAN IP address.
Release Click the Release button to release this Ethernet connection. Click the Renew
button to renew it.
VID/VCI This displays the Virtual Path Identifier (VPI) and Virtual Channel Identifier (VCI)
numbers the connection uses.
Encapsulation This shows the method of encapsulation used by this connection.
NAT This shows whether NAT is activated or not for this connection. NAT is not available
when the connection uses the bridging service.
Modify Click the Edit icon to configure the connection.
VDSL Connections Table
Active This shows whether the VDSL connection is activated.
VLAN This is the service name of the connection.
IP This shows the WAN IP address.
Release Click the Release button to release this Ethernet connection. Click the Renew
button to renew it.
VID/Priority This is the VLAN ID and IEEE 802.1p priority.
Encapsulation This shows the method of encapsulation used by this connection.
NAT This shows whether NAT is activated or not for this connection. NAT is not available
when the connection uses the bridging service.
Modify Click the Edit icon to configure the connection.
Table 3 Network Setting > WAN (continued)
LABEL DESCRIPTION

Chapter 3 WAN 19
3.1.1 Edit ADSL Ethernet Connection
In Network Setting > WAN, click the Edit icon next to an ADSL Ethernet connection to display the
following screen. Use this screen to configure an ADSL connection.
Figure 11 Network Setting > WAN: ADSL: Edit

Chapter 3 WAN 20
Table 4 Network Setting > WAN: ADSL: Edit
LABEL DESCRIPTION
Line
ADSL Mode Select the kind of connection your Router uses to connect to the ISP.
Use Auto Sync-Up if you are not sure which mode to choose from. The Router dynamically
diagnoses the mode supported by the ISP and selects the best compatible one for your
connection.
Use ADSL2+ or T1.413 if you know the specific type of DSL the Router uses to connect to the
ISP.
Other options are VDSL2, ADSL2, G.DMT, T1.413 and G.lite.
Annex M Select this if your ISP supports it.
General
Active Select this to have the Router use the Ethernet connection.
Node Name Specify the name for this WAN interface.
Mode Select Router (default) if your ISP gives you one IP address only and you want multiple
computers to share an Internet account. Select Bridge when your ISP provides you more than
one IP address and you want the connected computers to get individual IP address from the
ISP’s DHCP server directly. If you select Bridge, you cannot use Firewall, DHCP server and NAT
on the Router.
Encapsulation Select the method of encapsulation used by your ISP. Choices vary depending on the mode
you select in the Mode field.
If you select Router in the Mode field, select ENET ENCAP,IPoA, PPPoE, or PPPoA.
If you select Bridge in the Mode field, method of encapsulation is not available.
User Name (PPPoE encapsulation only) Enter the user name exactly as your ISP assigned. If assigned a
name in the form user@domain where domain identifies a service name, then enter both
components exactly as given.
Password (PPPoE or PPPoA encapsulation) Enter the password associated with the user name above.
Service Name (PPPoE or PPPoA encapsulation) Type the name of your PPPoE or PPPoA service here.
Multiplex Select the method of multiplexing your ISP uses. Choices are VC-Mux or LLC.
By prior agreement, a protocol is assigned a specific virtual circuit, for example, VC1 will carry
IP. If you select VC-Mux, specify separate VPI and VCI numbers for each protocol.
For LLC-based multiplexing or PPP encapsulation, one VC carries multiple protocols with
protocol identifying information being contained in each packet header. In this case, only one
set of VPI and VCI numbers need be specified for all protocols.
IPv6/IPv4 Dual
Stack Select IPv4 if you want the Router to run IPv4 only.
Select IPv4/IPv6 to allow the Router to run IPv4 and IPv6 at the same time.
Select IPv6 if you want the Router to run IPv6 only.
