Mitsubishi Electric Mr. Slim PCA-M KA Series User manual

FOR INSTALLER English
INSTALLATION MANUAL
Packaged Air Conditioners
PCA-M·KA

EN
EN-1
Contents
Note:
The phrase “Wired remote controller“ in this installation manual refers only to the PAR-32MAA.
If you need any information for the other remote controller, please refer to either the installation manual or initial setting manual which are included in these
boxes.
1. Safety precautions
1. Safety precautions..................................................................................... 1
2. Installation location....................................................................................2
3. Installing the indoor unit ............................................................................3
4. Installing the refrigerant piping ..................................................................5
5. Drainage piping work.................................................................................6
6. Electrical work ...........................................................................................6
7. Test run....................................................................................................12
8. Easy maintenance function .....................................................................16
►Beore installing the unit, make sure you read all the “Saety Precautions”.
►The “Saety Precautions” provide very important points regarding saety. Make sure you ollow them.
►Please report to your supply authority or obtain their consent beore connecting this equipment to the power supply system.
Symbols used in the text
Warning:
Describes precautions that should be observed to prevent danger oinjury or
death to the user.
Caution:
Describes precautions that should be observed to prevent damage to the unit.
Warning:
Describes precautions that must be observed to prevent danger o re.
Symbols used in the illustrations
: Indicates a part which must be grounded.
: Be sure not to do.
After installation work has been completed, explain the “Safety Precautions,” use, and
maintenance of the unit to the customer according to the information in the Operation
Manual and perform the test run to ensure normal operation. Both the Installation
Manual and Operation Manual must be given to the user for keeping. These manuals
must be passed on to subsequent users.
MEANINGS OF SYMBOLS DISPLAYED ON INDOOR UNIT AND/OR OUTDOOR UNIT
WARNING
(Risk o re)
This mark is for R32 refrigerant only. Refrigerant type is written on nameplate of outdoor unit.
In case that rerigerant type is R32, this unit uses a fammable rerigerant.
Irerigerant leaks and comes in contact with re or heating part, it will create harmul gas and there is risk o re.
Read the OPERATION MANUAL carefully before operation.
Service personnel are required to carefully read the OPERATION MANUAL and INSTALLATION MANUAL before operation.
Further information is available in the OPERATION MANUAL, INSTALLATION MANUAL, and the like.
Warning:
• Careully read the labels axed to the main unit.
• Ask a dealer or an authorized technician to install, relocate and repair the
unit.
• The user should never attempt to repair the unit or transer it to another loca-
tion.
• Do not alter the unit.
• For installation and relocation work, ollow the instructions in the Installation
Manual and use tools and pipe components specically made or use with
rerigerant specied in the outdoor unit installation manual.
• The unit must be installed according to the instructions in order to minimize
the risk odamage rom earthquakes, typhoons, or strong winds. An incor-
rectly installed unit may all down and cause damage or injuries.
• The unit must be securely installed on a structure that can sustain its weight.
• The appliance shall be stored in a well-ventilated area where the room size
corresponds to the room area as specied or operation.
• Ithe air conditioner is installed in a small room or closed room, measures must
be taken to prevent the rerigerant concentration in the room rom exceed-
ing the saety limit in the event orerigerant leakage. Should the rerigerant
leak and cause the concentration limit to be exceeded, hazards due to lack
of oxygen in the room may result.
• Keep gas-burning appliances, electric heaters, and other re sources (igni-
tion sources) away from the location where installation, repair, and other air
conditioner work will be perormed.
Irerigerant comes into contact with a fame, poisonous gases will be released.
• Ventilate the room irerigerant leaks during operation. Irerigerant comes
into contact with a fame, poisonous gases will be released.
• All electric work must be perormed by a qualied technician according to
local regulations and the instructions given in this manual.
• Use only specied cables or wiring. The wiring connections must be made
securely with no tension applied on the terminal connections. Also, never
splice the cables or wiring (unless otherwise indicated in this document).
Failure to observe these instructions may result in overheating or a re.
• When installing or relocating, or servicing the air conditioner, use only the
specied rerigerant written on outdoor unit to charge the rerigerant lines.
Do not mix it with any other refrigerant and do not allow air to remain in the
lines.
If air is mixed with the refrigerant, then it can be the cause of abnormal high
pressure in the refrigerant line, and may result in an explosion and other
hazards.
The use oany rerigerant other than that specied or the system will cause
mechanical ailure or system malunction or unit breakdown. In the worst
case, this could lead to a serious impediment to securing product safety.
• The appliance shall be installed in accordance with national wiring regulations.
• This appliance is not intended or use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack oexperience and
knowledge, unless they have been given supervision or instruction concern-
ing use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appli-
ance.
• The terminal block cover panel othe unit must be rmly attached.
• Ithe supply cord is damaged, it must be replaced by the manuacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
• Use only accessories authorized by Mitsubishi Electric and ask a dealer or
an authorized technician to install them.
• Ater installation has been completed, check or rerigerant leaks. Ireriger-
ant leaks into the room and comes into contact with the fame oa heater or
portable cooking range, poisonous gases will be released.
• Do not use means to accelerate the derosting process or to clean, other than
those recommended by the manufacturer.
• The appliance shall be stored in a room without continuously operating igni-
tion sources (or example: open fames, an operating gas appliance or an
operating electric heater).
• Do not pierce or burn.
• Be aware that rerigerants may not contain an odour.
• Pipe-work shall be protected rom physical damage.
• The installation opipe-work shall be kept to a minimum.
• Compliance with national gas regulations shall be observed.
• Keep any required ventilation openings clear oobstruction.
• Do not use low temperature solder alloy in case obrazing the rerigerant
pipes.
• When perorming brazing work, be sure to ventilate the room suciently.
Make sure that there are no hazardous or fammable materials nearby.
When perorming the work in a closed room, small room, or similar location,
make sure that there are no rerigerant leaks beore perorming the work.
Irerigerant leaks and accumulates, it may ignite or poisonous gases may
be released.
For safe and correct use, read this manual and the outdoor unit installation manual thoroughly before installing the air-conditioner unit.

EN
EN-2
1.1. Beore installation (Environment)
Caution:
• Do not use the unit in an unusual environment. Ithe air conditioner is installed
in areas exposed to steam, volatile oil (including machine oil), or suluric gas,
areas exposed to high salt content such as the seaside, the performance can
be signicantly reduced and the internal parts can be damaged.
• Do not install the unit where combustible gases may leak, be produced, fow,
or accumulate. Icombustible gas accumulates around the unit, re or explo-
sion may result.
• Do not keep ood, plants, caged pets, artwork, or precision instruments in the
direct airfow othe indoor unit or too close to the unit, as these items can be
damaged by temperature changes or dripping water.
• When the room humidity exceeds 80% or when the drainpipe is clogged,
water may drip from the indoor unit. Do not install the indoor unit where such
dripping can cause damage.
• When installing the unit in a hospital or communications oce, be prepared or
noise and electronic intererence. Inverters, home appliances, high-requency
medical equipment, and radio communications equipment can cause the air
conditioner to malunction or breakdown. The air conditioner may also aect
medical equipment, disturbing medical care, and communications equipment,
harming the screen display quality.
1.2. Beore installation or relocation
Caution:
• Be extremely careul when transporting the units. Two or more persons
are needed to handle the unit, as it weighs 20 kg or more. Do not grasp the
packaging bands. Wear protective gloves as you can injure your hands on
the ns or other parts.
• Be sure to saely dispose othe packaging materials. Packaging materials,
such as nails and other metal or wooden parts may cause stabs or other
injuries.
• Thermal insulation othe rerigerant pipe is necessary to prevent condensa-
tion. If the refrigerant pipe is not properly insulated, condensation will be
formed.
1.3. Beore electric work
Caution:
• Be sure to install circuit breakers. Inot installed, electric shock may result.
• For the power lines, use standard cables osucient capacity. Otherwise, a
short circuit, overheating, or re may result.
• When installing the power lines, do not apply tension to the cables.
• Be sure to ground the unit. Ithe unit is not properly grounded, electric shock
may result.
1.4. Beore starting the test run
Caution:
• Turn on the main power switch more than 12 hours beore starting operation.
Starting operation just ater turning on the power switch can severely damage
the internal parts.
• Beore starting operation, check that all panels, guards and other protective
parts are correctly installed. Rotating, hot, or high voltage parts can cause
injuries.
• Do not operate the air conditioner without the air lter set in place. Ithe air
lter is not installed, dust may accumulate and breakdown may result.
• Do not touch any switch with wet hands. Electric shock may result.
• Do not touch the rerigerant pipes with bare hands during operation.
• Ater stopping operation, be sure to wait at least ve minutes beore turning
o the main power switch. Otherwise, water leakage or breakdown may result.
• Place thermal insulation on the pipes to prevent condensation. Ithe drain-
pipe is installed incorrectly, water leakage and damage to the ceiling, foor,
furniture, or other possessions may result.
• Do not clean the air conditioner unit with water. Electric shock may result.
• Tighten all fare nuts to specication using a torque wrench. Itightened too
much, the fare nut can break ater an extended period.
• Use circuit breakers (ground ault interrupter, isolating switch (+B use), and
molded case circuit breaker) with the specied capacity. Ithe circuit breaker
capacity is larger than the specied capacity, breakdown or re may result.
1. Safety precautions
2. Installation location
W
2.1. Outline dimensions (Indoor unit) (Fig. 2-1)
Select a proper position allowing the following clearances for installation and main-
tenance.
(mm)
Models W
M35, 50 960
M60, 71 1280
M100, 125, 140 1600
Warning:
Mount the indoor unit on a ceiling strong enough to withstand the weight of
the unit.
2.2. Outline dimensions (Outdoor unit)
Refer to the outdoor unit installation manual.
(mm)
Fig. 2-1
Min.300
Max. 250
Min. 270
Min. 500
Min. 1800

EN
EN-3
3. Installing the indoor unit
1 2 3
4 5 6
7 8
A
A
B C
D
F
H
G
J
E
236
B
2
75
80320
680
2
19046
6
233
246 C
D
233
246
IF
E
E
H G
H
G
86 285
138
126
19046
3.1. Check the indoor unit accessories (Fig. 3-1)
The indoor unit should be supplied with the following accessories
(contained in the inside othe intake grille).
Accessory name Q’ty
1Washer 4 pcs
2Pipe cover 1 pc Large size (For gas tubing)
3Pipe cover 1 pc Small size (For liquid tubing)
4Band 4 pcs
5Joint socket 1 pc Marked with “UNIT”
6Socket cover 1 pc
7Drain tubing cover 1 pc
8Flare nut 1 pc ø6.35 (M60 only)
3.2. Preparation or installation (Fig. 3-2)
3.2.1. Suspension bolt installing spacing
(mm)
Models A B
M35, 50 917 960
M60, 71 1237 1280
M100, 125, 140 1557 1600
3.2.2. Refrigerant and drain tubing location
(mm)
Models C D
M35, 50 184 203
M60 179 203
M71-140 180 200
AFront side outlet FLeft drain tubing
BLeft side outlet GGas tubing
CRight side outlet HLiquid tubing
DIndependent piece (Removable) IRubber plug
ERight drain tubing Jwith Joint socket 5
In case of the rear pipe arrangement, make sure to remove the shaded portions from
the Dindependent piece. Then put the Dindependent piece back in initial position.
(The heat exchanger might be clogged because odust)
Fig. 3-1
UNI T
Fig. 3-2
(mm)

EN
EN-4
3. Installing the indoor unit
B
AD
E
H
G
2
J
L
KM
C
1F
(mm)
a g
e
g
e
f
b
10 –20
dc
e
g
A
a
b
B
D
E
A
C
B
125
175
190
70
80 ø65 ø100
7~12
B
C
A
D
E
F
A
G
C
3.3. Installing the indoor unit (Fig. 3-5)
Use a proper suspending method depending on the presence or absence of ceiling
materials as follows.
AIn the presence of ceiling materials cCeiling
BIn the absence of ceiling materials dSuspending bolt
aSuspending bracket eWasher 1
bUnit fWasher (Local procurement)
gDouble nuts
1) Directly suspending the unit
Installing procedures
1. Install the washer 1(supplied with the unit) and the nuts (to be locally procured).
2. Set (hook) the unit through the suspending bolts.
3. Tighten the nuts.
Check the unit installing condition.
• Check that the unit is horizontal between the right and let sides.
• Check that the ront and the rear osuspending brackets are horizontal.
(To keep drainage,the unit is inclined to the suspending brackets. The unit slopes
continuously downward rom the ront to the rear is the right installation position.)
2) Installing the suspending bracket rst onto the ceiling (Fig. 3-6)
Installing procedures
1. Remove the suspending brackets and U-shaped washers from the unit.
2. Adjust the suspending bracket holding bolts on the unit.
3. Attach the suspending brackets to the suspending bolts.
4. Check that the suspending brackets are horizontal (ront and rear/right and let).
5. Set (hook) the unit to the suspending brackets.
6. Tighten xed bolts othe suspending brackets.
wBe sure to install the U-shaped washers.
ASuspending bracket holding bolt
BUnit
CU-shaped washer
DSuspending bolt
EWasher 1
FDouble nuts
3.2.3. Selection osuspension bolts and tubing positions (Fig. 3-3)
Using the pattern paper provided for installation, select proper positions for suspen-
sion bolts and tubing and prepare relative holes.
APattern paper
BSuspension bolt hole
CIndoor unit width
Secure the suspension bolts or use angle stock braces or square timbers for bolt
installation.
DUse inserts of 100 kg to 150 kg each.
EUse suspension bolts of W3/8 or M10 in size.
3.2.4. Indoor unit preparation (Fig. 3-4)
1. Install the suspending bolts. (Procure the W3/8 or M10 bolts locally.)
Predetermine the length from the ceiling (1within 100 mm).
ACeiling surface BSuspending bolt CSuspending bracket
2. Remove the intake grille.
Slide the intake grille holding knobs (at 2 or 3 locations) backward to open the
intake grille.
3. Remove the side panel.
Remove the side panel holding screws (one in each side, right and let) then slide
the side panel forward for removal.
DIntake grille JSlide the side panel forward.
EIntake grille holding knob KSide panel
FSlide LRemove the side panel holding screws.
GHinge MRemove the protective vinyl of vane.
HPushing the hinge, pull out the intake grille.
2Forcing open the intake grille or opening it to an angle of more than 120° may
damage the hinges.
Fig. 3-4
Fig. 3-5
Fig. 3-3
Fig. 3-6
(mm)
GM35, 50 882-887
M60, 71 1202-1207
M100-140 1522-1527

EN
EN-5
4. Installing the refrigerant piping
G
C
D
E
F
C
B
A
DE
E
F
B
A B
C
D
A
45 2
4.3. Indoor unit (Fig. 4-3)
Installing procedures
1. Slide the supplied pipe cover 2over the gas tubing until it is pressed against the
sheet metal inside the unit.
2. Slide the provided pipe cover 3over the liquid tubing until it is pressed against
the sheet metal inside the unit.
3. Tighten the pipe covers 2and 3at the both ends (20 mm) with the supplied
bands 4.
AGas tubing EPipe cover 3
BLiquid tubing FPress the pipe cover against the sheet metal.
CBand 4GRefrigerant tubing heat insulating material
DPipe cover 2
4.4. For twin/triple combination
Refer to the outdoor unit installation manual.
4.1. Precautions
For devices that use R32/R410A rerigerant
• Use ester oil, ether oil or alkylbenzene oil (small amount) as the rerigeration
oil applied to the fared sections.
• Use C1220 copper phosphorus or copper and copper alloy seamless pipes,
to connect the rerigerant pipes. Use rerigerant pipes with the thicknesses
specied in the table below. Make sure the insides othe pipes are clean
and do not contain any harmful contaminants such as sulfuric compounds,
oxidants, debris, or dust.
Warning:
When installing or relocating, or servicing the air conditioner, use only the
specied rerigerant written on outdoor unit to charge the rerigerant lines. Do
not mix it with any other refrigerant and do not allow air to remain in the lines.
If air is mixed with the refrigerant, then it can be the cause of abnormal high
pressure in the rerigerant line, and may result in an explosion and other hazards.
The use oany rerigerant other than that specied or the system will cause
mechanical ailure or system malunction or unit breakdown. In the worst case,
this could lead to a serious impediment to securing product safety.
M35, 50 M60-140
Liquid pipe ø6.35 thickness 0.8 mm ø9.52 thickness 0.8 mm
Gas pipe ø12.7 thickness 0.8 mm ø15.88 thickness 1.0 mm
• Do not use pipes thinner than those specied above.
4.2. Connecting pipes (Fig. 4-1)
• When commercially available copper pipes are used, wrap liquid and gas pipes
with commercially available insulation materials (heat-resistant to 100 °C or more,
thickness o12 mm or more).
• The indoor parts othe drain pipe should be wrapped with polyethylene oam insula-
tion materials (specic gravity o0.03, thickness o9 mm or more).
• Apply thin layer orerigerant oil to pipe and joint seating surace beore tightening
fare nut.
• Use 2 wrenches to tighten piping connections.
• Use rerigerant piping insulation provided to insulate indoor unit connections. Insulate
carefully.
• Ater connecting the rerigerant piping to the indoor unit, be sure to test the pipe
connections for gas leakage with nitrogen gas. (Check that there is no refrigerant
leakage rom the rerigerant piping to the indoor unit.)
• Use fared nut installed to this indoor unit.
• In case oreconnecting the rerigerant pipes ater detaching, make the fared part
of pipe re-fabricated.
BFlare nut tightening torque
Copper pipe O.D.
(mm)
Flare nut O.D.
(mm)
Tightening torque
(N·m)
ø6.35 17 14-18
ø6.35 22 34-42
ø9.52 22 34-42
ø12.7 26 49-61
ø12.7 29 68-82
ø15.88 29 68-82
CApply rerigerating machine oil over the entire fare seat surace.
Do not apply refrigerating machine oil to the screw portions.
(This will make the fare nuts more apt to loosen.)
DUse correct fare nuts meeting the pipe size othe outdoor unit.
Available pipe size
M35, 50 M60 M71-140
Liquid side ø6.35 Οø6.35 —
—ø9.52 Οø9.52 Ο
Gas side ø12.7 Οø15.88 Οø15.88 Ο
Ο: Factory fare nut attachment to the heat exchanger.
AFlare cutting dimensions
Copper pipe O.D.
(mm)
Flare dimensions
øA dimensions (mm)
ø6.35 8.7 - 9.1
ø9.52 12.8 - 13.2
ø12.7 16.2 - 16.6
ø15.88 19.3 - 19.7
Copper pipe O.D.
(mm)
B (mm)
Flare tool for R32/R410A
Clutch type
ø6.35 (1/4″)0 - 0.5
ø9.52 (3/8″)0 - 0.5
ø12.7 (1/2″)0 - 0.5
ø15.88 (5/8″)0 - 0.5
Fig. 4-3
Fig. 4-1
Fig. 4-2
90° ± 0.5°
R0.4 - R0.8
EDie
FCopper pipe

EN
EN-6
5. Drainage piping work
6. Electrical work
BC
A
AC
F
D
B
E
C
D
B
E
ABC D
EF
D
H
I
G
i
• For let side tubing, be sure to insert the rubber plug into the right drain port. (Fig. 5-1)
• Use VP-20 (O.D. ø26 (1”) PVC TUBE) or drain piping and provide 1/100 or more
downward slope.
• Ater completion owork, check that correct drain is available rom the outfow port
of the drain tubing.
ADrain pan
BPlug
CInsert the driver etc.in the plug deeply.
Installing procedures (Fig. 5-2)
1. Attach the joint socket 5supplied with the unit to the drain port on the unit with a
vinyl chloride adhesive.
2. Fasten the socket cover 6supplied with the unit to the joint socket 5.
3. Attach the eld drain tubing (VP-20) to the joint socket 5with a vinyl chloride
adhesive.
4. Wrap the drain tubing cover 7supplied with the unit. (Seam taping)
ADrain pan
BDrain tubing
CSocket cover 6
DJoint socket 5
EDrain tubing cover 7
FInsertion length 37 mm
5. Check or correct drainage. (Fig. 5-3)
* Fill the drain pan with water of about 1 L from the air outlet.
6.1. Electric wiring (Fig. 6-1)
Wiring procedures
1. Remove the tapping screw Cthen remove the beam.
2. Remove the (2) tapping screws Bthen remove the electric part cover A.
3. Connect the electric wires securely to the corresponding terminals.
4. Replace the removed parts.
5. Tie the electric wires with the local wiring clamp located in the right side of the
junction box.
ACover HGrounding cable connector
BSet screws (2 pcs) ITerminal block for Remote controller
CSet screws (Beam) iSecure with the wiring clamp.
DWiring clamp
EControl board
FWire service entrance
GTerminal block for indoor and outdoor units connection
Fig. 5-1
Fig. 5-2
Fig. 5-3
Fig. 6-1

EN
EN-7
6.1.1. Indoor unit power supplied rom outdoor unit
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.1 System
S1
S2
L
N
1
2
S1
S2
S3
S3
AB C
D
E
F
G
S1
S2
L
N
1
2
S1
S2
S3
1
2
S1
S2
S3
S3
1
2
S1
S2
S3
1
2
S1
S2
S3
D
E
F
G G G G
AB C
HH H
* Ax label A that is included with the manuals near each wiring diagram or the indoor and outdoor units.
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
* Ax label A that is included with the manuals near each wiring diagram or the indoor and outdoor units.
Indoor unit model PCA
Wiring
Wire No. × size
(mm²)
Indoor unit-Outdoor unit *1 3 × 1.5 (polar)
Indoor unit-Outdoor unit earth *1 1 × Min.1.5
Indoor unit earth 1 × Min.1.5
Remote controller-Indoor unit *2 2 × 0.3 (Non-polar)
Circuit rating
Indoor unit (Heater) L-N *3 -
Indoor unit-Outdoor unit S1-S2 *3 230 V AC
Indoor unit-Outdoor unit S2-S3 *3 24 V DC
Remote controller-Indoor unit *3 12 V DC
*1. <For 50-140 outdoor unit application>
Max. 45 m
If 2.5 mm2used, Max. 50 m
If 2.5 mm2used and S3 separated, Max. 80 m
<For 200/250 outdoor unit application>
Max. 18 m
If 2.5 mm2used, Max. 30 m
If 4 mm2used and S3 separated, Max. 50 m
If 6 mm2used and S3 separated, Max. 80 m
*2. Max. 500 m
(When using 2 remote controllers, the maximum wiring length or the remote controller cables is 200 m.)
*3. The gures are NOT always against the ground.
S3 terminal has 24 V DC against S2 terminal. However between S3 and S1, these terminals are not electrically insulated by the transormer or other device.
Notes: 1. Wiring size must comply with the applicable local and national code.
2.
Power supply cords and indoor unit/outdoor unit connecting cords shall not be lighter than polychloroprene sheathed fexible cord.
(Design 60245 IEC 57)
3. Install an earth longer than other cables.
4. Indoor and outdoor connecting wires have polarities. Make sure to match the terminal number (S1, S2, S3) or correct wirings.
5. Wiring or remote controller cable shall be apart (5 cm or more) rom power source wiring so that it is not infuenced by electric noise
from power source wiring.
Simultaneous twin/triple/quadruple system
1:1 System
6.1.2. Separate indoor unit/outdoor unit power supplies (For PUZ/PUHZ application only)
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.
1:1 System
6. Electrical work
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Indoor unit earth
S1
S2
L
N
1
2
L
N
S1
S2
S3
S3
D
E
F
G
H
AB C B C
J
* The indoor power supply terminal kit is required. A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Option
J Indoor unit power supply
* Ax label B that is included with the manuals near each wiring diagram or the indoor and outdoor units.

EN
EN-8
6. Electrical work
Simultaneous twin/triple/quadruple system
S1
S2
L
N
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
S3
D
E
F
H
G G G G
KKK
HHH
AB C B C
J
ON
OFF 1 2 (SW8)
3
S1
S2
S3
L
N
CN01
CN01
S1
S2
S3
L
N
CN01
CN01
* Ax label B that is included with the manuals near each wiring diagram or the indoor and outdoor units.
If the indoor and outdoor units have separate power supplies, refer to the table below.
If the indoor power supply terminal kit is used, change the indoor unit electrical box
wiring reering to the gure in the right and the DIP switch settings othe outdoor
unit control board.
Indoor unit specications
Indoor power supply terminal kit (option) Required
Indoor unit electrical box connector connec-
tion change
Required
Label axed near each wiring diagram or the
indoor and outdoor units
Required
Outdoor unit DIP switch settings (when us-
ing separate indoor unit/outdoor unit power
supplies only)
* There are 3 types olabels (labels A, B and C). Ax the appropriate labels to the
units according to the wiring method.
Indoor unit model PCA
*1. A breaker with at least 3.0 mm contact separation in each pole shall be pro-
vided. Use earth leakage breaker (NV).
The breaker shall be provided to ensure disconnection of all active phase
conductors of the supply.
*2. Max. 120 m
*3. Max. 500 m
(When using 2 remote controllers, the maximum wiring length for the remote
controller cables is 200 m.)
*4. The gures are NOT always against the ground.
Indoor unit power supply ~/N (single), 50 Hz, 230 V
Indoor unit input capacity
Main switch (Breaker) *1 16 A
Wiring
Wire No. ×
size (mm²)
Indoor unit power supply & earth 3 × Min. 1.5
Indoor unit-Outdoor unit *2 2 × Min. 0.3
Indoor unit-Outdoor unit earth –
Remote controller-Indoor unit *3 2 × 0.3 (Non-polar)
Circuit
rating
Indoor unit L-N *4 230 V AC
Indoor unit-Outdoor unit S1-S2 *4 –
Indoor unit-Outdoor unit S2-S3 *4 24 V DC
Remote controller-Indoor unit *4 12 V DC
Notes: 1. Wiring size must comply with the applicable local and national code.
2.
Power supply cords and indoor unit/outdoor unit connecting cords shall not be lighter than polychloroprene sheathed fexible cord. (Design 60245 IEC 57)
3. Install an earth longer than other cables.
4. Wiring or remote controller cable shall be apart (5 cm or more) rom power source wiring so that it is not infuenced by electric noise rom power
source wiring.
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Option
J Indoor unit power supply
K Indoor unit earth
Never splice the power cable or the indoor-outdoor connection cable, otherwise it may result in a smoke, a re or communication ailure.
Warning:
* The indoor power supply terminal kits are required.
Set the SW8-3 to ON.
BLUE
YELLOW
BLUE
YELLOW
BLACK
YELLOW
BLUE
BLUE
YELLOW
BLACK
Option
Option
Indoor unit power supplied from outdoor unit
(initial setting)
Separate indoor unit/outdoor unit power supplies
Connectors (connections of initial setting
are for indoor unit power supplied from
outdoor unit)
If the indoor and
outdoor units have
separate power
supplies, change the
connections of the
connectors as shown
in the following
gure.
Connectors
Indoor unit
control board
Indoor unit
control board

EN
EN-9
6. Electrical work
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
MODEL SELECT
A
3
2
14
B
1
C
A
2
D
ON/OFF TEMP
RESETSET CLOCK
MODEL SELECT
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
24
3
A
6.2. Remote controller
6.2.1. For wired remote controller
1) 2 remote controllers setting
If 2 remote controllers are connected, set one to “Main” and the other to “Sub”. For
setting procedures, refer to “Function selection of remote controller” in the operation
manual for the indoor unit.
6.2.2. For wireless remote controller
1) Installation area
• Area in which the remote controller is not exposed to direct sunshine.
• Area in which there is no nearby heating source.
• Area in which the remote controller is not exposed to cold (or hot) winds.
• Area in which the remote controller can be operated easily.
• Area in which the remote controller is beyond the reach ochildren.
2) Installation method (Fig. 6-2)
1Attach the remote controller holder to the desired location using 2 tapping screws.
2Place the lower end of the controller into the holder.
ARemote controller BWall CDisplay panel DReceiver
• The signal can travel up to approximately 7 meters (in a straight line) within 45
degrees to both right and left of the center line of the receiver.
3) Setting (Fig. 6-3)
1Insert batteries.
2Press the SET button with something sharp at the end.
MODEL SELECT
blinks and Model No. is lit.
3Press the temp buttons to set the Model No.
If you mistook the operation, press the ON/OFF button and operate again from
procedure 3.
4Press the SET button with something sharp at the end.
MODEL SELECT
and Model No. are lit for 3 seconds, then turned off.
Indoor Outdoor AModel No.
PCA PUZ/PUHZ, SUZ 001
4) Assigning a remote controller to each unit (Fig. 6-4)
Each unit can be operated only by the assigned remote controller.
Make sure each pair of an indoor unit PC board and a remote controller is assigned
to the same pair No.
5) Wireless remote controller pair number setting operation
1Press the SET button with something sharp at the end.
Start this operation from the status of remote controller display turned off.
MODEL SELECT
blinks and Model No. is lit.
2Press the min button twice continuously. Pair No. “0” blinks.
3Press the temp buttons to set the pair number you want to set.
If you mistook the operation, press the ON/OFF button and operate again from
procedure 2.
4Press the SET button with something sharp at the end.
Set pair number is lit for 3 seconds then turned off.
APair No. of wireless remote controller Indoor PC board
0 Initial setting
1 Cut J41
2 Cut J42
3-9 Cut J41, J42
Fig. 6-2 Fig. 6-3
Fig. 6-4

EN
EN-10
6. Electrical work
6.3. Function settings
6.3.1. Function setting on the unit (Selecting the unit unctions)
1) For wired remote controller
1(Fig. 6-5)
•Select “Service” from the Main menu, and press the [SELECT] button.
• Select “Function settings” with the [F1] or [F2] button, and press the [SELECT]
button.
2(Fig. 6-6)
• Set the indoor unit rerigerant addresses and unit numbers with the [F1] through
[F4] buttons, and then press the [SELECT] button to conrm the current setting.
<Checking the Indoor unit No.>
When the [SELECT] button is pressed, the target indoor unit will start fan operation.
If the unit is common or when running all units, all indoor units for the selected
refrigerant address will start fan operation.
3(Fig. 6-7)
• When data collection rom the indoor units is completed, the current settings
appears highlighted. Non-highlighted items indicate that no function settings are
made. Screen appearance varies depending on the “Unit No.” setting.
4 (Fig. 6-8)
• Use the [F1] or [F2] button to move the cursor to select the mode number, and
change the setting number with the [F3] or [F4] button.
5(Fig. 6-9)
• When the settings are completed, press the [SELECT] button to send the setting
data from the remote controller to the indoor units.
• When the transmission is successully completed, the screen will return to the
Function setting screen.
F1 F2 F3 F4
Service menu
Cursor
Main menu:
Test run
Input maintenance info.
Function setting
Check
Self check
F1 F2 F3 F4
Function setting
Cursor Address
Monitor:
Ref. address
Unit No. Grp./1/2/3/4/All
Fig. 6-5 Fig. 6-6
F1 F2 F3 F4
Function setting
Cursor Cursor
Request:
Ref. address
Mode 1
Mode 2
Mode 3
Mode 4
Grp.
F1 F2 F3 F4
Function setting
Cursor Cursor
Request:
Ref. address
Mode 7
Mode 8
Mode 9
Mode10
Unit # 1
Fig. 6-7 Fig. 6-8
F1 F2 F3 F4
Function setting
Ref. address
Sending data
Grp.
Fig. 6-9

EN
EN-11
2) For wireless remote controller (Fig. 6-10)
Changing the power voltage setting
• Be sure to change the power voltage setting depending on the voltage used.
1Going to the function select mode
Press the CHECK button Ftwice continuously.
(Start this operation rom the status oremote controller display turned o.)
CHECK
is lit and “00” blinks.
Press the temp button Conce to set “50”. Direct the wireless remote controller
toward the receiver of the indoor unit and press the hbutton A.
2Setting the unit number
Press the temp buttons Cand Dto set the unit number “00”. Direct the
wireless remote controller toward the receiver of the indoor unit and press the
min button B.
3Selecting a mode
Enter 04 to change the power voltage setting using the temp buttons Cand
D. Direct the wireless remote controller toward the receiver of the indoor unit and
press the hbutton A.
Current setting number: 1 = 1 beep (1 second)
2 = 2 beeps (1 second each)
3 = 3 beeps (1 second each)
4Selecting the setting number
Use the temp buttons Cand Dto change the power voltage setting to 01
(240 V). Direct the wireless remote controller toward the sensor othe indoor unit
and press the hbutton A.
5To select multiple functions continuously
Repeat steps 3and 4to change multiple function settings continuously.
6Complete function selection
Direct the wireless remote controller toward the sensor of the indoor unit and press
the button E.
Note:
Whenever changes are made to the unction settings ater installation or main-
tenance, be sure to record the changes with a mark in the “Setting” column o
the Function table.
6. Electrical work
6.3.2. Function setting on the remote controller
Refer to the indoor unit operation manual.
Function table
Select unit number 00
Mode Settings Mode no. Setting no. Initial setting setting
Power failure automatic recovery Not available 01 1
Available w2Ο
Indoor temperature detecting Indoor unit operating average
02
1Ο
Set by indoor unit’s remote controller 2
Remote controller’s internal sensor 3
LOSSNAY connectivity Not Supported
03
1Ο
Supported (indoor unit is not equipped with outdoor-air intake)
2
Supported (indoor unit is equipped with outdoor-air intake) 3
Power voltage 240 V 04 1
220 V, 230 V 2Ο
Select unit numbers 01 to 03 or all units (AL [wired remote controller]/07 [wireless remote controller])
Mode Settings Mode no. Setting no. Initial setting setting
Filter sign 100 Hr
07
1
2500 Hr 2Ο
No lter sign indicator 3
Fan speed Silent
08
1
Standard 2Ο
High ceiling 3
Installed options (high eciency lter) Not supported 10 1Ο
Supported 2
Up/down vane setting No vanes
11
1
Equipped with vanes (vanes angle setup 1)2Ο
Equipped with vanes (vanes angle setup 2)3
Fan speed during the cooling thermostat is OFF Setting fan speed
27
1
Stop 2
Extra low 3 Ο
wWhen the power supply returns, the air conditioner will start 3 minutes later.
CHECK CHECK
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
CHECK
CHECKCHECK
1 2
3 4
B
A
CD
E
F
Fig. 6-10

EN
EN-12
7. Test run
7.2. Test run
7.2.1. Using wired remote controller.
■Make sure to read operation manual beore test run. (Especially items to secure saety)
Step 1 Turn on the power.
●Remote controller: The system will go into startup mode, and the remote controller power lamp (green) and “PLEASE WAIT” will blink. While the lamp and message are
blinking, the remote controller cannot be operated. Wait until “PLEASE WAIT” is not displayed before operating the remote controller. After the power is turned on, “PLEASE
WAIT” will be displayed for approximately 2 minutes.
●Indoor controller board: LED 1 will be lit up, LED 2 will be lit up (ithe address is 0) or o (ithe address is not 0), and LED 3 will blink.
●Outdoor controller board: LED 1 (green) and LED 2 (red) will be lit up. (Ater the startup mode othe system nishes, LED 2 will be turned o.) Ithe outdoor controller
board uses a digital display, [- ] and [ -] will be displayed alternately every second.
If the operations do not function correctly after the procedures in step 2 and thereafter are performed, the following causes should be considered and eliminated if they
are found.
(The symptoms below occur during the test run mode. “Startup” in the table means the LED display written above.)
Symptoms in test run mode
Cause
Remote Controller Display OUTDOOR BOARD LED Display
< > indicates digital display.
Remote controller displays “PLEASE WAIT”,
and cannot be operated.
After “startup” is displayed, only green lights up.
<00>
• Ater power is turned on, “PLEASE WAIT” is displayed or 2 minutes
during system startup. (Normal)
After power is turned on, “PLEASE WAIT” is
displayed for 3 minutes, then error code is
displayed.
Ater “startup” is displayed, green (once) and red
(once) blink alternately. <F1>
• Incorrect connection ooutdoor terminal block (R, S, T and S1, S2,
S3.)
Ater “startup” is displayed, green (once) and red
(twice) blink alternately. <F3, F5, F9> • Outdoor unit’s protection devise connector is open.
No display appears even when remote control-
ler operation switch is turned on. (Operation
lamp does not light up.)
Ater “startup” is displayed, green (twice) and red
(once) blink alternately. <EA. Eb>
• Incorrect wiring between the indoor and outdoor unit (Polarity is
wrong or S1, S2, S3.)
• Remote controller transmission wire short.
After “startup” is displayed, only green lights up.
<00>
• There is no outdoor unit oaddress 0. (Address is other than 0.)
• Remote controller transmission wire open.
Display appears but soon disappears even
when remote controller is operated.
After “startup” is displayed, only green lights up.
<00>
• Ater canceling unction selection, operation is not possible or about
30 seconds. (Normal)
Step 2 Switch the remote controller to “Test run”.
1
Select “Test run” rom the Service menu, and press the [SELECT] button. (Fig. 7-1)
2 Select “Test run” rom the Test run menu, and press the [SELECT] button. (Fig. 7-2)
3The test run operation starts, and the Test run operation screen is displayed.
F1 F2 F3 F4
unemecivreS
rosruC
:unemniaM
Test run
Input maintenance info.
Function setting
Check
Self check
Fig. 7-1
F1 F2 F3 F4
Test run menu
Cursor
Service menu:
Test run
Drain pump test run
Fig. 7-2
F1 F2 F3 F4
Cool
Pipe
Auto
Switch disp.
Mode Fan
RemainTest run
Fig. 7-3
F1 F2 F3 F4
Remain
Vane
Fig. 7-4
Step 3 Perorm the test run and check the airfow temperature and auto vane.
1Press the [F1] button to change the operation mode. (Fig. 7-3)
Cooling mode: Check that cool air blows from the unit.
Heating mode: Check that warm air blows from the unit.
2Press the [SELECT] button to display the Vane operation screen, and then press
the [F1] and [F2] buttons to check the auto vane. (Fig. 7-4)
Press the [RETURN] button to return to the Test run operation screen.
Step 4 Conrm the operation othe outdoor unit an.
The speed of the outdoor unit fan is controlled in order to control the performance of the unit. Depending on the ambient air, the fan will rotate at a slow speed and will keep
rotating at that speed unless the perormance is insucient. Thereore, the outdoor wind may cause the an to stop rotating or to rotate in the opposite direction, but this is
not a problem.
►Do not carry out this test on the control wiring (low voltage circuit) terminals.
Warning:
Do not use the air conditioner if the insulation resistance is less than 1 M .
7.1. Beore test run
►Ater completing installation and the wiring and piping othe indoor and
outdoor units, check or rerigerant leakage, looseness in the power supply
or control wiring, wrong polarity, and no disconnection of one phase in the
supply.
►Use a 500-volt megohmmeter to check that the resistance between the power
supply terminals and ground is at least 1 M .

EN
EN-13
7. Test run
Step 5 Stop the test run.
1Press the [ON/OFF] button to stop the test run. (The Test run menu will appear.)
Note: If an error is displayed on the remote controller, see the table below.
LCD Description of malfunction LCD Description of malfunction LCD Description of malfunction
P1 Intake sensor error P9 Pipe sensor error (dual-wall pipe)
E0 ~ E5
Communication error between the
remote controller and the indoor
unit
P2 Pipe sensor error (liquid pipe) PA Leakage error (rerigerant system)
P4 Drain foat switch connector
disconnected (CN4F)
Pb Indoor unit fan motor error
PL Refrigerant circuit abnormal
P5 Drain overfow protection operation FB Indoor controller board error
E6 ~ EF Communication error between the
indoor unit and the outdoor unit
P6 Freezing/overheating protection
operation
U*, F*
(* indicates an
alphanumeric
character
excluding FB.)
Outdoor unit malfunction
Refer to the wiring diagram for the
outdoor unit.
P8 Pipe temperature error
See the table below or the details othe LED display (LED 1, 2, and 3) on the indoor controller board.
LED 1 (microcomputer power supply) Indicates whether control power is supplied. Make sure that this LED is always lit.
LED 2 (remote controller power supply) Indicates whether power is supplied to the wired remote controller. The LED is lit only for the indoor unit that is connected
to the outdoor unit that has an address of 0.
LED 3 (indoor/outdoor unit communication) Indicates whether the indoor and outdoor units are communicating. Make sure that this LED is always blinking.
7.2.2. Using wireless remote controller (Fig. 7-5)
1Turn on the power to the unit at least 12 hours before the test run.
2Press the
TEST RUN
button twice continuously.
(Start this operation rom the status oremote controller display turned o.)
A
TEST RUN
and current operation mode are displayed.
3Press the
MODE
button to activate mode, then check whether
cool air is blown out from the unit.
4Press the
MODE
button to activate mode, then check whether
warm air is blown out from the unit.
5Press the
FAN
button and check whether fan speed changes.
6Press the VANEbutton and check whether the auto vane operates properly.
7Press the ON/OFF button to stop the test run.
Note:
• Point the remote controller towards the indoor unit receiver while ollowing
steps 2to 7.
• It is not possible to run the TEST RUN in FAN, DRY or AUTO mode.
7.2.3. Using SW4 in outdoor unit
Refer to the outdoor unit installation manual.
7.3. Sel-check
7.3.1. Wired remote controller
■Reer to the installation manual that comes with each remote controller or details.
1Press the [CHECK] button twice.
2Set refrigerant address with [TEMP] button if system control is used.
3Press the [ON/OFF] button to stop the self-check.
ACHECK button
BRefrigerant address
CTEMP. button
DIC: Indoor unit
OC: Outdoor unit
ECheck code
FUnit address
7.3.2. Wireless remote controller (Fig. 7-6)
1Turn on the power.
2Press the CHECK button twice.
(Start this operation rom the status oremote controller display turned o.)
Abegins to light.
B“00” begins to blink.
3While pointing the remote controller toward the unit’s receiver, press the
h
button. The check code will be indicated by the number of times that the buzzer
sounds from the receiver section and the number of blinks of the operation lamp.
4Press the ON/OFF button to stop the self-check.
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
CHECK
B
A
2
3
1
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
TEST RUN
A
7
34
2
6
5
Fig. 7-5
Fig. 7-6

EN
EN-14
7. Test run
• Reer to the ollowing tables or details on the check codes. (Wireless remote controller)
[Output pattern A]
[Output pattern A] Errors detected by indoor unit
Wireless remote controller Wired remote
controller
Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp blinks
(Number otimes)
Check code
1 P1 Intake sensor error
2P2 Pipe (TH2) sensor error
P9 Pipe (TH5) sensor error
3 E6, E7 Indoor/outdoor unit communication error
4 P4 Float switch connector open
5P5 Drain pump error
PA Forced compressor stop (due to water leakage abnormality)
6 P6 Freezing/Overheating protection operation
7 EE Communication error between indoor and outdoor units
8 P8 Pipe temperature error
9 E4 Remote controller signal receiving error
10 — —
11 Pb Indoor unit fan motor error
12 Fb Indoor unit control system error (memory error, etc.)
14 PL Refrigerant circuit abnormal
No sound E0, E3 Remote controller transmission error
No sound E1, E2 Remote controller control board error
No sound – – – – No corresponding
OPERATION
INDICATOR
lamp blinking
pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx. 2.5 sec.
On
Approx. 3 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
Off
Approx. 2.5 sec.
On
Approx. 3 sec.
On
0.5 sec.
On
0.5 sec.
· · · Repeated
Number of blinks/beeps in pattern indicates the check
code in the ollowing table (i.e., n=5 or “U2”)
Number of blinks/beeps in pattern
indicates the check code in the
following table
nth
1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds
[Output pattern B]
OPERATION
INDICATOR
lamp blinking
pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx. 2.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
Off
Approx. 2.5 sec.
On
0.5 sec.
On
0.5 sec.
· · · Repeated
Number of blinks/beeps in pattern indicates the check
code in the ollowing table (i.e., n=5 or “P5”)
Number of blinks/beeps in pattern indicates
the check code in the following table
nth
1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds

EN
EN-15
7. Test run
[Output pattern B] Errors detected by unit other than indoor unit (outdoor unit, etc.)
Wireless remote controller Wired remote
controller
Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp blinks
(Number otimes)
Check code
1 E9 Indoor/outdoor unit communication error (Transmitting error) (Outdoor unit)
For details, check the LED
display of the outdoor controller
board.
2 UP Compressor overcurrent interruption
3 U3, U4 Open/short of outdoor unit thermistors
4 UF Compressor overcurrent interruption (When compressor locked)
5 U2 Abnormal high discharging temperature/49C worked/insucient rerigerant
6 U1, Ud Abnormal high pressure (63H worked)/Overheating protection operation
7 U5 Abnormal temperature of heat sink
8 U8 Outdoor unit fan protection stop
9 U6 Compressor overcurrent interruption/Abnormal of power module
10 U7 Abnormality of super heat due to low discharge temperature
11 U9, UH Abnormality such as overvoltage or voltage shortage and abnormal
synchronous signal to main circuit/Current sensor error
12 — —
13 — —
14 Others Other errors (Reer to the technical manual or the outdoor unit.)
*1. Ithe beeper does not sound again ater the initial 2 beeps to conrm the sel-check start signal was received and the OPERATION INDICATOR lamp does
not come on, there are no error records.
*2. Ithe beeper sounds 3 times continuously “beep, beep, beep (0.4 + 0.4 + 0.4 sec.)” ater the initial 2 beeps to conrm the sel-check start signal was received,
the specied rerigerant address is incorrect.
• On wireless remote controller
The continuous buzzer sounds from receiving section of indoor unit.
Blink of operation lamp
• On wired remote controller
Check code displayed in the LCD.
• Ithe unit cannot be operated properly ater test run, reer to the ollowing table to nd the cause.
Symptom Cause
Wired remote controller LED 1, 2 (PCB in outdoor unit)
PLEASE WAIT For about 2 minutes
after power-on
After LED 1, 2 are lit, LED 2 is turned off,
then only LED 1 is lit. (Correct operation)
•For about 2 minutes ater power-on, operation othe remote
controller is not possible due to system start-up. (Correct
operation)
PLEASE WAIT →Error code
Subsequent to about
2 minutes after
power-on
Only LED 1 is lit. →LED 1, 2 blink.
•Connector or the outdoor unit’s protection device is not con-
nected.
Reverse or open phase wiring for the outdoor unit’s power
terminal block (L1, L2, L3)
Display messages do not appear
even when operation switch is
turned ON
(operation lamp does not light up).
Only LED 1 is lit. →LED 1 blinks twice,
LED 2 blinks once.
•Incorrect wiring between indoor and outdoor units (incorrect
polarity oS1, S2, S3)
•Remote controller wire short
On the wireless remote controller with condition above, following phenomena take place.
• No signals rom the remote controller are accepted.
• Operation lamp is blinking.
• The buzzer makes a short ping sound.
Note:
Operation is not possible or about 30 seconds ater cancellation o unction selection. (Correct operation)
For description oeach LED (LED 1, 2, 3) provided on the indoor controller, reer to the ollowing table.
LED 1 (power or microcomputer) Indicates whether control power is supplied. Make sure that this LED is always lit.
LED 2 (power or remote controller) Indicates whether power is supplied to the remote controller. This LED lights only in the case of
the indoor unit which is connected to the outdoor unit refrigerant address “0”.
LED 3 (communication between indoor and outdoor units) Indicates state of communication between the indoor and outdoor units. Make sure that this LED
is always blinking.

EN
EN-16
8. Easy maintenance unction
Maintenance data, such as the indoor/outdoor unit’s heat exchanger temperature and compressor operation current can be displayed with “Smooth maintenance”.
* This cannot be executed during test operation.
* Depending on the combination with the outdoor unit, this may not be supported by some models.
F1 F2 F3 F4
Check menu
Cursor
Service menu:
Error history
Refrigerant volume check
Refrigerant leak check
Smooth maintenance
Request code
Smooth maintenance
Begin:
Smooth maintenance
Exit:
Ref.address
Stable mode
Cursor
Ref.address
Stable mode
Stabilization→Collecting
Cool / Heat/ Normal
Cool / Heat/ Normal
Address
Smooth maintenance
Return:
Smooth maintenance
Return:
Smooth maintenance
Return:
Page
Page
Page
COMP. current
COMP. run time
COMP. On / Off
COMP. frequency
A
Hz
Hr
times
Hr
Ref. address
Cool
Ref.address
Cool
Ref.address
Cool
Sub cool
OU TH4 temp.
OU TH6 temp.
OU TH7 temp.
IU air temp.
IU HEX temp.
IU filter time
1
2
3
• Select “Service” rom the Main menu, and press the [SELECT] button.
• Select “Check” with the [F1] or [F2] button, and press the [SELECT] button.
• Select “Smooth maintenance” with the [F1] or [F2] button, and press the [SELECT]
button.
Select each item.
• Select the item to be changed with the [F1] or [F2] button.
• Select the required setting with the [F3] or [F4] button.
“Ref. address” setting ………. “0” - “15”
“Stable mode” setting……….. “Cool” / “Heat” / “Normal”
• Press the [SELECT] button, xed operation will start.
* Stable mode will take approx. 20 minutes.
The operation data will appear.
The Compressor-Accumulated operating (COMP. run) time is 10-hour unit, and the
Compressor-Number ooperation times (COMP. On/O) is a 100-time unit (ractions
discarded)
Navigating through the screens
• To go back to the Main menu....................[MENU] button
• To return to the previous screen .......... [RETURN] button

RG79F168W02
Importer:
Mitsubishi Electric Europe B.V.
Capronilaan 46, 1119 NS, Schiphol Rijk, The Netherlands
French Branch
25, Boulevard des Bouvets, 92741 Nanterre Cedex, France
German Branch
Mitsubishi-Electric-Platz 1, 40882 Ratingen, Germany
Belgian Branch
Autobaan 2, 8210 Loppem, Belgium
Irish Branch
Westgate Business Park, Ballymount, Dublin 24, Ireland
Italian Branch
Centro Direzionale Colleoni, Palazzo Sirio-Ingresso 1 Viale Colleoni 7, 20864 Agrate Brianza
(MB), Italy
Norwegian Branch
Gneisveien 2D, 1914 Ytre Enebakk, Norway
Portuguese Branch
Avda. do Forte, 10, 2799-514, Carnaxide, Lisbon, Portugal
Spanish Branch
Carretera de Rubi 76-80 - Apdo. 420 08173 Sant Cugat del Valles (Barcelona), Spain
Scandinavian Branch
Hammarbacken 14, P.O. Box 750 SE-19127, Sollentuna, Sweden
UK Branch
Travellers Lane, Hatfeld, Herts., AL10 8XB, England, U.K.
Polish Branch
Krakowska 50, PL-32-083 Balice, Poland
MITSUBISHI ELECTRIC TURKEY ELEKTRİK ÜRÜNLERI A.Ş.
Şeriali Mah. Kale Sok. No: 41 34775 Ümraniye, İstanbul / Turkey
Please be sure to put the contact address/telephone number on
this manual beore handing it to the customer.
This product is designed and intended or use in the residential,
commercial and light-industrial environment.
Printed in Japan
HEAD OFFICE: TOKYO BUILDING, 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN
