INSTALLATION MANUAL
For safe and correct use, read this manual and the outdoor unit installation manual thoroughly before installing
the air-conditioner unit.
MANUEL D’INSTALLATION
Avant d’installer le climatiseur, lire attentivement ce manuel, ainsi que le manuel d’installation de l’appareil
extérieur pour une utilisation sûre et correct.
FOR INSTALLER
POUR L’INSTALLATEUR
SPLIT-SYSTEM HEAT PUMP
TPKA0A.1LA Series
English
Français
MANUAL DE INSTALACIÓN
Para un uso seguro y correcto, lea detalladamente este manual de instalación antes de montar la unidad de
aire acondicionado.
PARA EL INSTALADOR
Español
VG79Y564H01_IM.indb 1 30-Nov-22 11:00:00
1
en
1. Safety precautions
Note:
In this installation manual, the term “Wired remote controller” refers only to the TAR-41MAA and the term “Wireless remote controller” refers only to the
PAR-SL101A-E. If you need any information for other remote controllers, refer to the installation manual that is included with the grilled, which includes a
remote controller, or the initial setting manual that is included with the optional remote controller.
►Beforeinstallingtheunit,makesureyoureadallthe“SafetyPrecautions”.
►The“SafetyPrecautions”provideveryimportantpointsregardingsafety.Makesureyoufollowthem.
►Pleasereporttoyoursupplyauthorityorobtaintheirconsentbeforeconnectingthisequipmenttothepowersupplysystem.
Symbolsusedinthetext
Warning:
Describesprecautionsthatshouldbeobservedtopreventdangerofinjuryor
death to the user.
Caution:
Describesprecautionsthatshouldbeobservedtopreventdamagetothe
unit.
Symbolsusedintheillustrations
: Indicates a part which must be grounded.
: Be sure not to do.
After installation work has been completed, explain the “Safety Precautions,” use,
and maintenance of the unit to the customer according to the information in the
Operation Manual and perform the test run to ensure normal operation. Both the
Installation Manual and Operation Manual must be given to the user for keeping.
These manuals must be passed on to subsequent users.
Warning:
• Carefullyreadthelabelsaffixedtothemainunit.
• Askadealeroranauthorizedtechniciantoinstall,relocateandrepairthe
unit.
• Theusershouldneverattempttorepairtheunitortransferittoanother
location.
• Forinstallationandrelocationwork,followtheinstructionsintheInstallation
Manual and use tools and pipe components specifically made for use with
refrigerant specified in the outdoor unit installation manual.
• Theunitmustbeinstalledaccordingtotheinstructionsinorderto
minimizetheriskofdamagefromearthquakes,typhoons,orstrongwinds.
Anincorrectlyinstalledunitmayfalldownandcausedamageorinjuries.
• Donotaltertheunit.Itmaycausefire,electricshock,injuryorwater
leakage.
• Theunitmustbesecurelyinstalledonastructurethatcansustainits
weight.
• Theapplianceshallbestoredinawell-ventilatedareawheretheroomsize
corresponds to the room area as specified for operation.
• If the air conditioner is installed in a small room or closed room, measures
mustbetakentopreventtherefrigerantconcentrationintheroomfrom
exceedingthesafetylimitintheeventofrefrigerantleakage.Shouldthe
refrigerantleakandcausetheconcentrationlimittobeexceeded,hazards
duetolackofoxygenintheroommayresult.
• Keepgas-burningappliances,electricheaters,andotherfiresources
(ignition sources) away from the location where installation, repair, and
otherairconditionerworkwillbeperformed.
Ifrefrigerantcomesintocontactwithaflame,poisonousgaseswillbe
released.
• Ventilatetheroomifrefrigerantleaksduringoperation.Ifrefrigerantcomes
intocontactwithaflame,poisonousgaseswillbereleased.
• Allelectricworkmustbeperformedbyaqualifiedtechnicianaccordingto
localregulationsandtheinstructionsgiveninthismanual.
• Do not use intermediate connection of the electric wires.
• Useonlyspecifiedcablesforwiring.Thewiringconnectionsmustbemade
securelywithnotensionappliedontheterminalconnections.Also,never
splicethecablesforwiring(unlessotherwiseindicatedinthisdocument).
Failuretoobservetheseinstructionsmayresultinoverheatingorafire.
• Wheninstallingorrelocating,orservicingtheairconditioner,useonlythe
specified refrigerant written on outdoor unit to charge the refrigerant lines.
Donotmixitwithanyotherrefrigerantanddonotallowairtoremaininthe
lines.
Ifairismixedwiththerefrigerant,thenitcanbethecauseofabnormalhigh
pressureintherefrigerantline,andmayresultinanexplosionandother
hazards.
The use of any refrigerant other than that specified for the system will
causemechanicalfailureorsystemmalfunctionorunitbreakdown.Inthe
worst case, this could lead to a serious impediment to securing product
safety.
• Theapplianceshallbeinstalledinaccordancewithnationalwiring
regulations.
• Thisapplianceisnotintendedforusebypersons(includingchildren)with
reducedphysical,sensoryormentalcapabilities,orlackofexperience
andknowledge,unlesstheyhavebeengivensupervisionorinstruction
concerninguseoftheappliancebyapersonresponsiblefortheirsafety.
• Childrenshouldbesupervisedtoensurethattheydonotplaywiththe
appliance.
• Theterminalblockcoverpaneloftheunitmustbefirmlyattached.
• Ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,its
serviceagentorsimilarlyqualifiedpersonsinordertoavoidahazard.
• UseonlyauthorizedaccessoriesbyMitsubishiElectricandaskadealeror
anauthorizedtechniciantoinstallthem.
Ifaccessoriesareincorrectlyinstalled,waterleakage,electricshock,orfire
may result.
• Afterinstallationhasbeencompleted,checkforrefrigerantleaks.If
refrigerantleaksintotheroomandcomesintocontactwiththeflameofa
heaterorportablecookingrange,poisonousgaseswillbereleased.
• Do not use means to accelerate the defrosting process or to clean, other
thanthoserecommendedbythemanufacturer.
• Theapplianceshallbestoredinaroomwithoutcontinuouslyoperating
ignitionsources(forexample:openflames,anoperatinggasapplianceor
an operating electric heater).
• Donotpierceorburn.
• Beawarethatrefrigerantsmaynotcontainanodour.
• Pipe-workshallbeprotectedfromphysicaldamage.
• Theinstallationofpipe-workshallbekepttoaminimum.
• Compliancewithnationalgasregulationsshallbeobserved.
• Keepanyrequiredventilationopeningsclearofobstruction.
• Donotuselowtemperaturesolderalloyincaseofbrazingtherefrigerant
pipes.
• Whenperformingbrazingwork,besuretoventilatetheroomsufficiently.
Makesurethattherearenohazardousorflammablematerialsnearby.
Whenperformingtheworkinaclosedroom,smallroom,orsimilar
location,makesurethattherearenorefrigerantleaksbeforeperforming
thework.
Ifrefrigerantleaksandaccumulates,itmayigniteorpoisonousgasesmay
bereleased.
• Exercisecautionwhenusinganyauxiliaryheatsourceandfollowallthird
party manufacturer instructions and safety guidelines for installation and
usage.
AnyauxiliaryheatsourceconnectedtothisunitviatheCN24connection
musthaveanindependenttemperaturecontrolmechanism.Failureto
installandmaintainsuchtemperaturecontrolmechanismmayvoidthe
warranty for this unit.
MitsubishiElectricshallnotbearanywarrantyobligationorotherliability
foranydamageorlossinconnectionwithsuchthirdpartyauxiliary
heaters.
Contents
1. Safety precautions.............................................................................................1
2. Installation location............................................................................................2
3. Installing the indoor unit ....................................................................................3
4. Installing the refrigerant piping ..........................................................................6
5. Drainage piping work.........................................................................................7
6. Electrical work ...................................................................................................9
7. Test run............................................................................................................14
8. Easy maintenance function .............................................................................18
VG79Y564H01_IM.indb 1 30-Nov-22 11:00:01
2
en
Fig.2-1
2. Installationlocation
A
B
L
W
H
H
E
J
M
I
D
C
D
K
F
G
1.2. Beforeinstallation or relocation
Caution:
• Beextremelycarefulwhentransportingtheunits.Twoormorepersonsare
neededtohandletheunit,asitweighs20kg,44lbsormore.Donotgrasp
thepackagingbands.Wearprotectiveglovesasyoucaninjureyourhands
on the fins or other parts.
• Besuretosafelydisposeofthepackagingmaterials.Packagingmaterials,
suchasnailsandothermetalorwoodenpartsmaycausestabsorother
injuries.
• Thermalinsulationoftherefrigerantpipeisnecessarytoprevent
condensation. If the refrigerant pipe is not properly insulated, condensation
willbeformed.
1.1. Before installation(Environment)
Caution:
• Donotusetheunitinanunusualenvironment.Iftheairconditioneris
installedinareasexposedtosteam,volatileoil(includingmachineoil),or
sulfuricgas,areasexposedtohighsaltcontentsuchastheseaside,the
performancecanbesignificantlyreducedandtheinternalpartscanbe
damaged.
• Donotinstalltheunitwherecombustiblegasesmayleak,beproduced,
flow,oraccumulate.Ifcombustiblegasaccumulatesaroundtheunit,fireor
explosionmayresult.
• Donotkeepfood,plants,cagedpets,artwork,orprecisioninstrumentsin
the direct airflow of the indoor unit or too close to the unit, as these items
canbedamagedbytemperaturechangesordrippingwater.
• Whentheroomhumidityexceeds80%orwhenthedrainpipeisclogged,
water may drip from the indoor unit. Do not install the indoor unit where
such dripping can cause damage.
• Wheninstallingtheunitinahospitalorcommunicationsoffice,be
preparedfornoiseandelectronicinterference.Inverters,homeappliances,
high-frequencymedicalequipment,andradiocommunicationsequipment
cancausetheairconditionertomalfunctionorbreakdown.Theair
conditionermayalsoaffectmedicalequipment,disturbingmedicalcare,
andcommunicationsequipment,harmingthescreendisplayquality.
• Placethermalinsulationonthepipestopreventcondensation.Ifthe
drainpipeisinstalledincorrectly,waterleakageanddamagetotheceiling,
floor, furniture, or other possessions may result.
• Donotcleantheairconditionerunitwithwater.Electricshockmayresult.
• Tightenallflarenutstospecificationusingatorquewrench.Iftightened
toomuch,theflarenutcanbreakafteranextendedperiod.
• Iftheunitisrunforlonghourswhentheairabovetheceilingisathigh
temperature/highhumidity(dewpointabove26ºC,79ºF),dewcondensation
maybeproducedintheindoorunitortheceilingmaterials.Whenoperatingthe
unitsinthiscondition,addinsulationmaterial(10-20mm,25/64-25/32inch)to
theentiresurfaceoftheunitandceilingmaterialstoavoiddewcondensation.
1.3. Beforeelectricwork
Caution:
• Besuretoinstallcircuitbreakers.Ifnotinstalled,electricshockmayresult.
• Forthepowerlines,usestandardcablesofsufficientcapacity.Otherwise,a
shortcircuit,overheating,orfiremayresult.
• Wheninstallingthepowerlines,donotapplytensiontothecables.
• Besuretogroundtheunit.Iftheunitisnotproperlygrounded,electric
shockmayresult.
• Usecircuitbreakers(groundfaultinterrupter,isolatingswitch(+Bfuse),
andmoldedcasecircuitbreaker)withthespecifiedcapacity.Ifthecircuit
breakercapacityislargerthanthespecifiedcapacity,breakdownorfire
may result.
1.4. Beforestartingthetestrun
Caution:
• Turnonthemainpowerswitchmorethan12hoursbeforestarting
operation.Startingoperationjustafterturningonthepowerswitchcan
severelydamagetheinternalparts.
• Beforestartingoperation,checkthatallpanels,guardsandother
protectivepartsarecorrectlyinstalled.Rotating,hot,orhighvoltageparts
cancauseinjuries.
• Do not operate the air conditioner without the air filter set in place. If the air
filterisnotinstalled,dustmayaccumulateandbreakdownmayresult.
• Donottouchanyswitchwithwethands.Electricshockmayresult.
• Donottouchtherefrigerantpipeswithbarehandsduringoperation.
• Afterstoppingoperation,besuretowaitatleastfiveminutesbeforeturning
offthemainpowerswitch.Otherwise,waterleakageorbreakdownmay
result.
1. Safety precautions
2.1. Outlinedimensions(Indoorunit)(Fig.2-1,2-2)
Select a proper position allowing the following clearances for installation and
maintenance.
(mm, inch)
DWHABCDE
237
9-11/32 898
35-23/64 299
11-25/32
Min. 150
Min.
5-29/32
Min. 50
Min.
1-31/32
Min. 50
Min.
1-31/32
Min. 250
Min.
9-27/32
Min. 260
Min.
10-1/4
F Air outlet: Do not place an obstacle within 1500 mm, 59-1/16 inch of the air outlet.
G Floor surface
H Furnishings
I When the projection dimension of a curtain rail or the like from the wall exceeds 60 mm,
2-23/64 inch, extra distance should be taken because the fan air current may create a
short cycle.
J 1800 mm, 70-55/64 inch or greater from the floor surface (for high location mounting)
K 75 mm, 2-61/64 inch, or greater with left, rear left, or lower left piping, and optional drain
pump installation. (Use the hook positioned on the lower part of the mount board when the
dimension is 55 mm, 2-11/64 inch or greater and less than 75 mm, 2-61/64 inch (Less than
55 mm, 2-11/64 inch: NG). Refer to 3.5. for details.)
L 350 mm, 13-25/32 inch or greater with optional drain pump installation
M Refer to Fig. 2-2
Fig.2-2
(mm, inch)
I
With Optional DRAIN PUMP
60 or less
2-23/64 or less
More than 60
More than 2-23/64
MMin. 7
Min. 9/32
Min. 60
Min. 2-23/64
Min. 250
Min. 9-27/32
* Please keep space to make vane to act.
M
I
VG79Y564H01_IM.indb 2 30-Nov-22 11:00:01
3
en
3. Installingtheindoorunit
Fig.3-2
Fig.3-1
15 (19/32)
0
125 (4-59/64)
165 (6-1/2)
231.7 (9-1/8)
274.2 (10-51/64)
321.2 (12-41/64)
350.2 (13-25/32)
364 (14-21/64)
15 (19/32)
125 (4-59/64)
165 (6-1/2)
231.7 (9-1/8)
285.2 (11-15/64)
321.2 (12-41/64)
350.2 (13-25/32)
364 (14-21/64)
7.2 (9/32)
0
16 (5/8)
32.2 (1-17/64)
76 (2-63/64)
107.2 (4-7/32)
132.2
(5-13/64)
157.2 (6-3/16)
244.7
(9-41/64)
257.2 (10-1/8)
44.7 (1-49/64)
119.7
(4-23/32)
287.2
(11-1/4)
0
391.5 (15-13/32)
449
(17-43/64)
128.8
(5-5/64)
141.8 (5-37/64)
282.5
(11-1/8)
392.5 (15-29/64)
449
(17-43/64)
230 (9-1/16)
0
274 (10-25/32)
25 (63/64)
69.7 (2-3/4)
123.5
(4-55/64)
177.2
(6-31/32)
57.2 (2-1/4)
82.2 (3-15/64)
189.7
(7-15/32)
23.5 (59/64)
25 (63/64)
212
(8-11/32)
238 (9-3/8)
G
H
C
FD
E
B
A
mm (inch)
Fig.3-3
A
C
DE
B
A Sleeve
B Hole
C (Indoors)
D Wall
E (Outdoors)
3.1. Checktheindoorunitaccessories(Fig.3-1)
The indoor unit should be supplied with the following accessories.
PART NUMBER ACCESSORY QUANTITY
LOCATION OF SETTING
1Mount board 1
Fix at the back of the unit
2Tapping screw 4 × 25 12
3Felt tape 3
4Band 4
5Clamp 1
3.2. Installingthewallmountingfixture
3.2.1. Settingthewallmountingfixtureandpipingpositions
►Usingthewallmountingfixture,determinetheunit’sinstallationposition
andthelocationsofthepipingholestobedrilled.
Warning:
Beforedrillingaholeinthewall,youmustconsultthebuildingcontractor.
[Fig.3-2]
A Mount board 1
B Indoor unit
C Bottom left rear pipe hole (ø75 mm, 2-61/64 inch)
D Bottom right rear pipe hole (ø75 mm, 2-61/64 inch)
E Bottom right rear condit cable hole (ø75 mm, 2-61/64 inch)
F Knockout hole for left rear hole (105 × 300 mm, 3-15/16 × 11-13/16 inch)
G Bolt hole (4-ø9 mm, 23/64 inch hole)
H Tapping hole (6-ø4.3 mm, 11/64 inch hole)
I Hole centre
J Align the scale with the line.
K Insert scale.
3.2.2. Drillingthepipinghole(Fig.3-3)
►Useacoredrilltomakeaholeof75-80mm,2-61/64-3-5/32inchdiameter
in the wall in the piping direction, at the position shown in the diagram to
the left.
►The hole should incline so that the outside opening is lower than the
inside opening.
►Insertasleeve(witha75mm,2-61/64inchdiameterandpurchased
locally) through the hole.
Note:
The purpose of the hole’s inclination is to promote drain flow.
1 2
3 4
5
J I
K
H
100
(3-15/16)
210
(8-17/64)
Hole centre
side
VG79Y564H01_IM.indb 3 30-Nov-22 11:00:01
4
en
3. Installingtheindoorunit
Fig.3-6
B
A
C
E
D
3.2.3. Installingthewallmountingfixture
►Sincetheindoorunitweighsnear13kg,29lbs,selectionofthemounting
locationrequiresthoroughconsideration.Ifthewalldoesnotseemtobe
strongenough,reinforceitwithboardsorbeamsbeforeinstallation.
►Themountingfixturemustbesecuredatbothendsandatthecentre,if
possible.Neverfixitatasinglespotorinanynonsymetricalway.
(Ifpossible,securethefixtureatallthepositionsmarkedwithabold
arrow.)
Warning:
Ifpossible,securethefixtureatallpositionsindicatedwithaboldarrow.
Caution:
• Theunitbodymustbemountedhorizontally.
• Fastenattheholesasshownbythearrows.
(Fig.3-4)
A Min. 119 mm, 4-11/16 inch (669 mm, 26-11/32 inch or greater with optional drain pump
installation)
B Min. 224 mm, 8-13/16 inch
C Min. 75 mm, 2-61/64 inch (Use the hook positioned on the lower part of the mount board
when the dimension is less than 100 mm, 3-15/16 inch with left, rear left, or lower left
piping, and optional drain pump installation. Refer to 3.5. for details.)
D Fixing screws (4 × 25) 2
E Level
F Mount board 1
3.3. Whenembeddingpipesintothewall(Fig.3-5)
• The pipes are on the bottom left.
• When the cooling pipe, drain pipes internal/external connection lines etc are to
be embedded into the wall in advance, the extruding pipes etc, may have to be
bent and have their length modified to suit the unit.
• Use marking on the mount board as a reference when adjusting the length of the
embedded cooling pipe.
• During construction, give the length of the extruding pipes etc some leeway.
A Mount board 1
B Reference marking for flare connection
C Through hole
D On-site piping
3.4. Preparingtheindoorunit
* Check beforehand because the preparatory work will differ depending on the
exiting direction of the piping.
* When bending the piping, bend gradually while maintaining the base of the
piping exiting portion. (Abrupt bending will cause misshaping of the piping.)
* Cut off outlet of the pipe depending on the exiting direction of the piping.
Extractionandprocessingofthepipingandwiring(Fig.3-6)
1.Connectionofindoor/outdoorwiring→Seepage9.
2. Wrap the felt tape 3in the range of the refrigerant piping and drain hose which
will be housed within the piping space of the indoor unit.
• Wrap the felt tape 3securely from the base for each of the refrigerant piping
and the drain hose.
• Overlap the felt tape 3at one-half of the tape width.
• Fasten the end portion of the wrapping with vinyl tape.
A Liquid pipe
B Gas pipe
C Indoor/outdoor connection cable
D Drain hose
E Felt tape 3
3. Be careful that the drain hose is not raised, and that contact is not made with the
indoor unit box body.
Do not pull the drain hose forcefully because it might come out.
Rear,rightandlowerpiping(Fig.3-7)
1) Be careful that the drain hose is not raised, and that contact is not made with
the indoor unit box body.
Arrange the drain hose at the underside of the piping and wrap it with felt
tape 3.
2) Securely wrap the felt tape 3starting from the base. (Overlap the felt tape at
one-half of the tape width.)
A Cut off for right piping.
B Cut off for lower piping.
A
B
C
DD
D
F
E
D
D
Fig.3-5
B
A
C
D
Fig.3-7
B
A
1)2)
Fig.3-4
: Points to be fastened (5 points)
: Points to be fastened only when
using the lower hook (2 points)
VG79Y564H01_IM.indb 4 30-Nov-22 11:00:02
5
en
3. Installingtheindoorunit
Leftandleftrearpiping(Fig.3-8)
4.Drainhosereplacement→See5.Drainagepipingwork.
Be sure to replace the drain hose and the drain cap for the left and rear left
piping. Dripping may occur if you forget to install or fail to replace these parts.
CDrain cap
1) Be careful that the drain hose is not raised, and that contact is not made with
the indoor unit box body.
2) Securely wrap the felt tape 3starting from the base. (Overlap the felt tape at
one-half of the tape width.)
3) Fasten the end portion of the felt tape 3with vinyl tape.
D Cut off for left piping.
Fig.3-8
C
D
1)
3)
2)
Fig.3-9
Fig.3-10
Fig.3-11
BA
C
D
A
C
B
C
A
B
3.5. Mountingtheindoorunit
1. Affix the mount board 1to the wall.
2. Hang the indoor unit on the hook positioned on the upper part of the mount
board.
Rear,rightandlowerpiping(Fig.3-9)
3. While inserting the refrigerant piping and drain hose into the wall penetration
hole (penetration sleeve), hang the top of the indoor unit to the mount board 1.
4. Move the indoor unit to the left and right, and verify that the indoor unit is hung
securely.
5. Fasten by pushing the bottom part of the indoor unit onto the mount board 1.
(Fig. 3-10)
* Check that the knobs on the bottom of the indoor unit are securely hooked into
the mount board 1.
6. After installation, be sure to check that the indoor unit is installed level.
A Mount board 1
B Indoor unit
C Hook
D Square hole
Leftandleftrearpiping(Fig.3-11)
3. While inserting the drain hose into the wall penetration hole (penetration sleeve),
hang the top of the indoor unit to the mount board 1.
Cut part of the shipping box and wrap into a cylindrical form as illustrated in the
diagram. Hook this to the rear surface rib as a spacer, and raise the indoor unit.
4. Connect the refrigerant piping with the site-side refrigerant piping.
5. Fasten by pushing the bottom part of the indoor unit onto the mount board 1.
* Check that the knobs on the bottom of the indoor unit are securely hooked into
the mount board 1.
6. After installation, be sure to check that the indoor unit is installed level.
AIndoor unit
BShipping box
CSpacer (Cut out a piece of card board from shipping box.)
Note:
• Whentheindoorunitcannotbehangedandliftedupwiththeregularhook
(thedimensionof2.1.K(theclearancebetweentheceilingandtheunit)
is75mm,2-61/64inchorless),hangtheunitonthelowerhookforleft
piping.(Fig.3-12)
• Thelowerhookisatemporaryhookonlyforinstallation.Whenthe
installationisdone,besuretohangtheindoorunitontheregularhook.
Theindoorunitcannotbeoperatedwhileitishangedonthelowerhook.
(Fig.3-12)
ARegular hook
BLower hook for left piping
CSpacer
DFixing screw 2
* When using the lower hook, be sure to screw on the base of the lower hook with
a fixing screw 2, otherwise the indoor unit will fall.
C
A
B
D
Fig.3-12
VG79Y564H01_IM.indb 5 30-Nov-22 11:00:03
6
en
4. Installing the refrigerant piping
4.3. Positioningrefrigerantanddrainpiping(Fig.4-3)
A Gas pipe * Indicates the condition with accessories mounted.
B Liquid pipe
C Drain hose (Effective length: 500 mm, 19-11/16 inch)
D Left-side piping knockout hole
E Right-side piping knockout hole
F Lower piping knockout hole
GMount board 1
5 (13/64)237 (9-11/32)
199 (7-53/64)650 (25-19/32)
299 (11-25/32)
898 (35-23/64)
160 (6-19/64)
178 (7-1/64)
533 (20-63/64) (B)
450 (17-23/32) (A)
192 (7-9/16)
49 (1-15/16)
D
EE
F
C
Fig.4-3
A Flare cutting dimensions
Copper pipe O.D. (mm, inch) Flare dimensions øA
dimensions (mm, inch)
ø6.35, 1/4” 8.7 - 9.1, 11/32 - 23/64
ø12.7, 1/2” 16.2 - 16.6, 41/64 - 21/32
Fig. 4-1
4.1. Precautions
FordevicesthatuseR410Arefrigerant
• Usealkylbenzeneoil(smallamount)astherefrigerationoilappliedtothe
flared sections.
•
UseC1220copperphosphorusforcopperandcopperalloyseamlesspipes,to
connecttherefrigerantpipes.Userefrigerantpipeswiththethicknessesspecified
inthetablebelow.Makesuretheinsidesofthepipesarecleananddonotcontain
anyharmfulcontaminantssuchassulfuriccompounds,oxidants,debris,ordust.
Warning:
Wheninstallingorrelocating,orservicingtheairconditioner,useonlythe
specified refrigerant written on outdoor unit to charge the refrigerant lines. Do
notmixitwithanyotherrefrigerantanddonotallowairtoremaininthelines.
Ifairismixedwiththerefrigerant,thenitcanbethecauseofabnormalhigh
pressureintherefrigerantline,andmayresultinanexplosionandotherhazards.
The use of any refrigerant other than that specified for the system will cause
mechanicalfailureorsystemmalfunctionorunitbreakdown.Intheworst
case, this could lead to a serious impediment to securing product safety.
ø6.35 mm, 1/4 inch thickness
0.8 mm, 1/32 inch
ø9.52 mm, 3/8 inch thickness
0.8 mm, 1/32 inch
ø12.7 mm, 1/2 inch thickness
0.8 mm, 1/32 inch
ø15.88 mm, 5/8 inch thickness
1.0 mm, 3/64 inch
• Donotusepipesthinnerthanthosespecifiedabove.
4.2. Connectingpipes(Fig.4-1)
• When commercially available copper pipes are used, wrap liquid and gas pipes
with commercially available insulation materials (heat-resistant to 100 °C, 212 °F
or more, thickness of 12 mm, 1/2 inch or more).
• The indoor parts of the drain pipe should be wrapped with polyethylene foam
insulation materials (specific gravity of 0.03, thickness of 9 mm, 23/64 inch or more).
• Flare the ends of the refrigerant pipes. A
• Apply refrigerating machine oil over the entire flare seat surface. B
• Use the flare nuts as follows. C
•
For connection, first align the center, then tighten the first 3 to 4 turns of flare nut by hand.
• Use 2 wrenches to tighten piping connections. D
• Use refrigerant piping insulation provided to insulate indoor unit connections.
Insulate carefully.
• After connecting the refrigerant piping to the indoor unit, be sure to test the pipe
connections for gas leakage with nitrogen gas. (Check that there is no refrigerant
leakage from the refrigerant piping to the indoor unit.)
• Use flared nut installed to this indoor unit.
• In case of reconnecting the refrigerant pipes after detaching, make the flared part
of pipe re-fabricated.
D Flare nut tightening torque
Copper pipe O.D.
(mm, inch)
Flare nut O.D.
(mm, inch)
Tightening torque
(N·m, ft·lbs)
ø6.35, 1/4 17, 43/64 14 - 18, 10 - 13
ø12.7, 1/2 28, 1-7/64 49 - 61, 35 - 44
Warning:
• Becarefulofyingarenut!(Internallypressurized)
Removethearenutasfollows:
1. Loosen the nut until you hear a hissing noise.
2. Donotremovethenutuntilthegashasbeencompletelyreleased(i.e.,
hissing noise stops).
3. Checkthatthegashasbeencompletelyreleased,andthenremovethenut.
• Wheninstallingtheunit,securelyconnecttherefrigerantpipesbeforestarting
the compressor.
Fig.4-2
E
F
B
Copper pipe O.D. (mm, inch)
B (mm, inch)
Flare tool for R410A
Clutch type
ø6.35, 1/4” 0 - 0.5, 0 - 1/64
ø12.7, 1/2” 0 - 0.5, 0 - 1/64
EDie
FCopper pipe
LEFT FRONT
FRONT (OPEN THE GRILLE)
BOTTOM
RIGHT
mm (inch)
øA
D
45°±2°
Union joint
Male side Female side
Tighten the flare nut
with a torque wrench.
Lock the union joint
with a wrench.
Flare nut
90°±0.5°
R0.4 to R0.8
(R1/64 to R1/32)
VG79Y564H01_IM.indb 6 30-Nov-22 11:00:04
7
en
4. Installing the refrigerant piping
Fig.4-5
A
B
D
C
4.4. Refrigerant piping (Fig. 4-4)
Indoor unit
1. Remove the flare nut and cap of the indoor unit.
2. Make a flare for the liquid pipe and gas pipe and apply refrigerating machine oil
(available from your local supplier) to the flare sheet surface.
3. Quickly connect the on site cooling pipes to the unit.
4. Wrap the pipe cover that is attached to the gas pipe and make sure that the
connection join is not visible.
5. Wrap the pipe cover of the unit’s liquid pipe and make sure that it covers the
insulation material of the on site liquid pipe.
6. The portion where the insulation material is joined is sealed by taping.
A Site-side refrigerant piping
B Unit side refrigerant piping
4.4.1. Storinginthepipingspaceoftheunit(Fig.4-5)
1. Wrap the supplied felt tape in the range of the refrigerant piping which will be
housed within the piping space of the unit to prevent dripping.
2. Overlap the felt tape at one-half of the tape width.
3. Fasten the end portion of the wrapping with vinyl tape, etc.
A Gas pipe
BLiquid pipe
CIndoor/outdoor connection cable
DFelt tape 3
Fig. 4-4
B
A
Fig.5-1
5. Drainagepipingwork
J
K
5.1. Drainagepipingwork(Fig.5-1)
• Drain pipes should have an inclination of 1/100 or more.
• For extension of the drain pipe, use a soft hose (inner dia. 15 mm, 19/32
inch) available on the market or hard vinyl chloride pipe (VP-16/O.D. ø22 mm,
55/64 inch PVC TUBE). Make sure that there is no water leakage from the
connections.
• Do not put the drain piping directly in a drainage ditch where sulphuric gas may
be generated.
• When piping has been completed, check that water flows from the end of the
drain pipe.
Caution:
ThedrainpipeshouldbeinstalledaccordingtothisInstallationManualto
ensure correct drainage. Thermal insulation of the drain pipes is necessary
topreventcondensation.Ifthedrainpipesarenotproperlyinstalledand
insulated, condensation may drip on the ceiling, floor or other possessions.
A Inclined downwards
B Must be lower than outlet point
C Water leakage
D Trapped drainage
E Air
F Wavy
G The end of drain pipe is under water.
H Drainage ditch
I5 cm, 1-31/32 inch or less between the end of drain pipe and the ground.
J Drain hose
K Soft PVC hose (Inside diameter 15 mm, 19/32 inch)
or
Hard PVC pipe (VP-16)
* Bond with PVC type adhesive
Preparingleftandleftrearpiping(Fig.5-2)
1 Remove the drain cap.
• Remove the drain cap by holding the bit that sticks out at the end of the pipe and
pulling.
A Drain cap
2 Remove the drain hose.
• Remove the drain hose by holding on to the base of the hose a(shown by
arrow) and pulling towards yourself b.
3 Insert the drain cap.
• Insert a screwdriver etc into the hole at the end of the pipe and be sure to push
to the base of the drain cap.
4 Insert the drain hose.
• Push the drain hose until it is at the base of the drain box connection outlet.
• Please make sure the drain hose hook is fastened properly over the extruding
drain box connection outlet.
B Hooks
A
A
1
3
Fig.5-2
a
b
A
B
2
4
Correct Incorrect
AB
C
E
D
C
F
Incorrect
Incorrect Incorrect
C
G
H
I
VG79Y564H01_IM.indb 7 30-Nov-22 11:00:05
8
en
5. Drainagepipingwork
♦ Storinginthepipingspaceoftheindoorunit(Fig.5-3)
* When the drain hose will be routed indoors, be sure to wrap it with commercially
available insulation.
* Gather the drain hose and the refrigerant piping together and wrap them with the
supplied felt tape 3.
* Overlap the felt tape 3at one-half of the tape width.
* Fasten the end portion of the wrapping with vinyl tape, etc.
A Gas pipe
B Liquid pipe
C Drain hose
D Indoor/outdoor connection wiring
E Felt tape 3
♦ Checkofdrainage(Fig.5-4)
1. Open the front grille and remove the filter.
2. Facing the fins of the heat exchanger, slowly fill with water.
3. After the drainage check, attach the filter and close the grille.
Fig.5-3
Fig.5-4
A
B
D
E
C
VG79Y564H01_IM.indb 8 30-Nov-22 11:00:05
9
en
6. Electricalwork
6.1. Electricwiring
[Fig.6-1]
Connection can be made without removing the front panel.
1. Open the front grille, remove the screw (2 pieces), and remove the electrical box
cover.
* Electrical work can be conducted more effectively with the panel removed.
When attaching the panel, check that the hooks Kat three locations on the air
outlet side are connected securely.
2. Securely connect each wire to the terminal block.
* In consideration of servicing, provide extra length for each of the wires.
* Take care when using strand wires, because beards may cause the wiring to
short out.
3. Install the parts that were removed back to their original condition.
4. When going through the right side of the indoor unit, cut out the removable
section of the Corner box E.
AFront grille
BFixing screw
CElectrical box cover
DFixing screw
ECorner box
FConduit plate
GConduit cover
HFixing screw
IFixing screw
JRemote control cable
KIndoor-outdoor connection cable
LGround wire
MLock nut
NConduit joint
OConduit pipe
PGround wire connection portion
QMA remote control terminal block: (1, 2) do not have polarity
RTerminal block for indoor and outdoor units connection: S1, S2 and S3, have polarity
SHook
Caution:
Wiringforremotecontrollercableshallbeapart(5cm,1-31/32inchormore)
frompowersourcewiringsothatitisnotinfluencedbyelectricnoisefrom
power source wiring.
J
K
L
KJ
Q
R
J
L K
P
S
Fig.6-1
55 mm, 2-11/64 inch
12 mm, 15/32 inch
• If the cables have the same diameter,
insert them into the cut outs on both
sides.
• If the cables have different diameters,
insert them on one side into separate
spaces with one cable positioned above
the other.
<When wiring two indoor-outdoor connection cables>
WARNING
• Connecting two wires on one side is
prohibited.
• Connecting three wires or more to the
same terminal is prohibited.
• Connecting wires with different diameters
is prohibited.
When using a single cable, a round crimped terminal or other
terminal work is prohibited.
Cut outs
Fig.6-2 Fig.6-3
E
When going through the right side
N
F
I
O
H
G
M
JKL
A
B
C
FGH
E
D
VG79Y564H01_IM.indb 9 30-Nov-22 11:00:07
10
en
6.1.1. Indoorunitpowersuppliedfromoutdoorunit
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.1
6. Electricalwork
Indoor unit model TPKA0A.1LA10A Series
Minimum circuit ampacity 1 A
Maximum rating of overcurrent protective device 15 A
Wiring
Wire No.
× size
Indoor unit-Outdoor unit *1 3 × AWG14 (Polar)
Indoor unit earth 1 × Min. AWG14
Wired remote controller-Indoor unit *2 2 × Min. AWG22 (Non-polar, unshielded)
Circuit
rating
Indoor unit-Outdoor unit S1-S2 *3 208/230 V AC
Indoor unit-Outdoor unit S2-S3 *3 *4 24 V DC / 28 V DC
Wired remote controller-Indoor unit *3 12 V DC
*1. <For 12-36 outdoor unit application>
Max. 45 m, 148 ft
If AWG13 (2.5 mm2) used, Max. 50 m, 165 ft
If AWG13 (2.5 mm2) used and S3 separated, Max. 80 m, 263 ft
*2. Max. 500 m, 1640 ft
(When using 2 remote controllers, the maximum wiring length for the remote controller cables is 200 m, 656 ft.)
*3. The figures are NOT always against the ground.
S3 terminal has 24 V DC / 28 V DC against S2 terminal. However, between S3 and S1, these terminals are not electrically insulated by the transformer or other device.
*4. It depends on the outdoor unit.
Notes: 1. Wiringsizemustcomplywiththeapplicablelocalandnationalcode.
2. Powersupplycordsandindoorunit/outdoorunitconnectingcordsshallnotbelighterthanpolychloroprenesheathedflexiblecord.
(Design60245IEC57)
3. Usecoppersupplywires.
4. UseULwiresrated300Vormoreforthepowersupplycordsandtheindoorunit/outdoorunitconnectingcords.
5. Installanearthlongerthanothercords.
6. Indoorandoutdoorconnectingwireshavepolarities.Makesuretomatchtheterminalnumber(S1,S2,S3)forcorrectwirings.
7. Wiringforremotecontrollercableshallbeapart(5cm,2inchormore)frompowersourcewiringsothatitisnotinfluencedbyelectricnoisefrom
power source wiring.
8. Thisapplianceincorporatesanearthconnectionforfunctionalpurposeonly.
Warning:
Neversplicethepowercableortheindoor-outdoorconnectioncable,otherwiseitmayresultinasmoke,areorcommunicationfailure.
Simultaneous twin system
* Affix a label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.
Applied earth type depends on outdoor unit.
Please refer to connected outdoor unit Installation Manual.
S1
S2
L1
L2
GR
1
2
S1
S2
S3
S3
AB
C
D
E
F
G
CN105
(RED)
H
I
AOutdoor unit power supply
BWiring circuit breaker or isolating switch
COutdoor unit
DIndoor unit/outdoor unit connecting cords
EWired remote controller
FIndoor unit
G Indoor unit earth
HIndoor controller board
IRadio frequency interface for RF thermostat
Only for 1:1 System
S1
S2
L1
L2
GR
1
2
S1
S2
S3
1
2
S1
S2
S3
S3
A
C
E
F F
B
GG
D
* Affix a label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.
AOutdoor unit power supply
BWiring circuit breaker or isolating switch
COutdoor unit
DIndoor unit/outdoor unit connecting cords
EWired remote controller
FIndoor unit
GIndoor unit earth
■Only for wired remote controller.
1:1 System
S1
S2
L1
L2
1
2
S1
S2
S3
S3
AB C
D
E
F
G
GR
AOutdoor unit power supply
BEarth leakage breaker
CWiring circuit breaker or isolating switch
DOutdoor unit
EIndoor unit/outdoor unit connecting cables
FRemote controller
GIndoor unit
VG79Y564H01_IM.indb 10 30-Nov-22 11:00:07
11
en
6. Electricalwork
6.2. Functionsettings
6.2.1. Bywiredremotecontroller
1(Fig. 6-4)
• Select “Service” from the Main menu, and press the [SELECT/HOLD] button.
• Select “Settings” from the Service menu, and press the [SELECT/HOLD]
button.
2(Fig. 6-5)
• Select “Function settings” with the [SELECT/HOLD] button.
3(Fig. 6-6)
• Set the indoor unit refrigerant addresses and unit numbers with the [F1]
through [F4] buttons, and then press the [SELECT/HOLD] button to confirm
the current setting.
<CheckingtheIndoorunitNo.>
When the [SELECT/HOLD] button is pressed, the target indoor unit will start fan
operation. If the unit is common or when running all units, all indoor units for the
selected refrigerant address will start fan operation.
4(Fig. 6-7)
• When data collection from the indoor units is completed, the current settings
appears highlighted. Non-highlighted items indicate that no function settings
are made. Screen appearance varies depending on the “Unit No.” setting.
5 (Fig. 6-8)
• Use the [F1] or [F2] button to move the cursor to select the mode number, and
change the setting number with the [F3] or [F4] button.
6 (Fig. 6-9)
• When the settings are completed, press the [SELECT/HOLD] button to send
the setting data from the remote controller to the indoor units.
• When the transmission is successfully completed, the screen will return to the
Function setting screen.
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Settings menu
Service menu: MENU
Function setting
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Service menu
Cursor
Main menu: RETURN
Test run
Input maintenance info.
Settings
Check
Others
MENU
ON
OFF
RETURN SELECT
HOLD
F1 F2 F3 F4
Function setting
Cursor Address
Monitor: SELECT
Ref. address
Unit No.
Grp./1/2/3/4/All
Fig.6-5Fig.6-4
Fig.6-6
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Function setting
Cursor Cursor
Ref. address
Mode 1
Mode 2
Mode 3
Mode 4
Grp.
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Function setting
Cursor Cursor
Request: SELECT
Ref. address
Mode 1
Mode 2
Mode 3
Mode 4
Grp.
Fig.6-7
Fig.6-8
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Function setting
Ref. address
Sending data
Grp.
Fig.6-9
Functiontable
Select unit number “Grp.”
Mode Settings Mode no. Setting no. Initial setting Setting
Power failure automatic recovery Not available 01 1
Available *1 2*2
Indoor temperature detecting Indoor unit operating average
02
1
Set by indoor unit’s remote controller 2
Remote controller’s internal sensor 3
LOSSNAY connectivity Not Supported
03
1
Supported (indoor unit is not equipped with outdoor-air intake) 2
Supported (indoor unit is equipped with outdoor-air intake) 3
Power voltage 230 V 04 1
208 V 2
Select unit numbers 1 to 4 or “All”
Mode Settings Mode no. Setting no. Initial setting Setting
Filter sign 100 Hr
07
1
2500 Hr 2
No filter sign indicator 3
Fan speed Silent
08
1
Standard 2
High ceiling 3
Fan speed during the cooling
thermostat is OFF
Setting fan speed
27
1
Stop 2
Extra low 3
*1 When the power supply returns, the air conditioner will start 3 minutes later.
*2 Power failure automatic recovery initial setting depends on the connecting outdoor unit.
VG79Y564H01_IM.indb 11 30-Nov-22 11:00:07
12
en
6. Electricalwork
6.3. CN24settings(Masssavesettings)
• Heat Pump auto ON/OFF setting depend on Outdoor temperature
• Heater via CN24 auto ON/OFF setting depend on Outdoor temperature or
difference between setting temp. and indoor ambient temperature.
1(Fig.6-10)
• Select “Service” from the Main menu, and press the [SELECT/HOLD] button.
• Select “Settings” with the [F1] or [F2] button, and press the [SELECT/HOLD]
button.
2(Fig.6-11)
• Select “CN24 settings” with the [F1] or [F2] button, and press the [SELECT/
HOLD] button.
3(Fig.6-12)
• Set the indoor unit refrigerant address with the [F1] or [F2] button, then press the
[SELECT/HOLD] button.
4(Fig.6-13, 6-14)
• Select “Limit settings” or “CN24 ON condition” with the [F1] or [F2] button and
press the [SELECT/HOLD] button.
5(Fig.6-16, 6-18)
• Set T(difference between ambient temp. and setting temp.) with [F3] or [F4]
button and press the [SELECT/HOLD] button.
6(Fig.6-15, 6-17)
• Set UB, UA, LB, LA with [F3] or [F4] button and press the [SELECT/HOLD]
button.
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Settings
Service menu: MENU
Function setting
Rotation settings
CN24 settings
Cursor
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Service menu
Cursor
Service menu: RETURN
Test run
Input maintenance info.
Settings
Check
Others
MENU
ON
OFF
RETURN SELECT
HOLD
F1 F2 F3 F4
CN24 settings
Monitor: SELECT
Address
Address
Fig.6-11Fig.6-10
Fig.6-12
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
CN24 settings
Cursor
Limit settings
CN24 disabled(UB) 50 °F
CN24 enabled(UA) 47 °F
H/P enabled(LB) 15 °F
H/P disabled(LA) 5 °F
Setting display: SELECT
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
CN24 settings
Cursor
Setting display: SELECT
CN24 enabled condition
∆T 5 °F
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
CN24 enabled condition
Select : SELECT
∆T 5°F
Temp.
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
CN24 enabled condition
∆T 4 °F
Changes saved
Service menu : MENU
Fig.6-13
Fig.6-14
Fig.6-16
Fig.6-18
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Limit settings
Cursor
Select: SELECT
Temp.
CN24 disabled(UB) 50 °F
CN24 enabled(UA) 47 °F
H/P enabled(LB) 15 °F
H/P disabled(LA) 5 °F
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Limit settings
Service menu : MENU
CN24 disabled(UB) 50 °F
CN24 enabled(UA) 48 °F
H/P enabled(LB) 15 °F
H/P disabled(LA) 5 °F
Changes saved
Fig.6-15
Fig.6-17
Connected outdoor unit UB UA LB LA
Setting range Default Setting range Default Setting range Default Setting range Default
TRUZA** 32°F ~ 70°F 47°F 23°F ~ 61°F 38°F -27°F ~ 52°F - -36°F ~ 43°F -
TRUZH** 32°F ~ 70°F 47°F 23°F ~ 61°F 38°F -27°F ~ 52°F - -36°F ~ 43°F -
NTXSKS09/12/15/18/24/30/36A112BA
32°F ~ 70°F 47°F 23°F ~ 61°F 38°F 14°F ~ 52°F - 5°F ~ 43°F -
NTXSKH09/12/15/18/24/30/36A112AA
32°F ~ 70°F 47°F 23°F ~ 61°F 38°F 14°F ~ 52°F - 5°F ~ 43°F -
NTXMMX/NTXMPH 32°F ~ 70°F 47°F 23°F ~ 61°F 38°F 14°F ~ 52°F - 5°F ~ 43°F -
*If outdoor unit not listed above table, please refer to outdoor IM for details.
VG79Y564H01_IM.indb 12 30-Nov-22 11:00:08
13
en
6.4. Rotationsetting
You can set these functions by wired remote controller. (Maintenance monitor)
Rotation setting
Select : SELECT
Rotation
TempDifTrigger
− Content +
Backup only
+4°C
Cur.
F1 F2 F3 F4
Reset
4Set the rotation function.
• Select “Rotation” with the [F1] button.
• Select the switching period or “Backup only” with the [F2] or [F3] button.
■“Rotation” setup options
None, 1 day, 3 days, 5 days, 7 days, 14 days, 28 days, Backup only
5Set the support function.
• Select “TempDifTrigger” with the [F1] button.
• Select the difference between the suction temperature and the set temperature with the [F2] or [F3]
button.
1Select “Service” from the Main menu, and press the [SELECT/HOLD] button.
2Select “Settings” with the [F1] or [F2] button, and press the [SELECT/HOLD] button.
3Select “Rotation setting” with the [F1] or [F2] button, and press the [SELECT/HOLD] button.
Rotation setting
Select : SELECT
Rotation
TempDifTrigger
− Content +
Backup only
+4°C
Cur.
F1 F2 F3 F4
Reset
Notes:
• When 1 to 28 days are selected from the setup options, the backup function is also enabled.
• When “Backup only”is selected, the rotation function will be disabled. The systems with refrigerant
addresses of 00 or 01 (00 system/ 01 system) will be operated as a main system while the 02 system
is the standby mode as backup.
6Press the [SELECT/HOLD] button to update the setting.
■“TempDifTrigger” setup options
None, +4ºC, +6ºC, +8ºC
Notes:
• The support function is available only in the COOL mode. (Not available in the HEAT, DRY and AUTO
mode.)
• The support function is enabled when any option other than “None” is selected from the “Rotation”
setup options.
Reset method
• Press the [F4] button in step 4 or 5 to reset the operation time of the rotation function. Once it is reset, operation will start from the systems with
refrigerant addresses of 00 or 01.
Note: When the system with refrigerant address of 02 is in the backup operation, the 00 or 01 systems will be operated again.
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Settings menu
Service menu: MENU
Function setting
Rotation setting
Cursor
6. Electricalwork
VG79Y564H01_IM.indb 13 30-Nov-22 11:00:08
14
en
7. Testrun
7.1. Beforetestrun
►Aftercompletinginstallationandthewiringandpipingoftheindoorandoutdoor
units, check for refrigerant leakage, looseness in the power supply or control
wiring, wrong polarity, and no disconnection of one phase in the supply.
►Usea500-voltmegohmmetertocheckthattheresistancebetweenthepower
supplyterminalsandgroundisatleast1.0MΩ.
►Donotcarryoutthistestonthecontrolwiring(lowvoltagecircuit)terminals.
Warning:
Donotusetheairconditioneriftheinsulationresistanceislessthan1.0MΩ.
7.2. Testrun
7.2.1. Usingwiredremotecontroller
■ Makesuretoreadoperationmanualbeforetestrun.(Especiallyitemstosecuresafety)
Step 1 Turn on the power.
● Remotecontroller:Thesystemwillgointostartupmode,andtheremotecontrollerpowerlamp(green)and“PleaseWait”willblink.Whilethelampandmessageare
blinking, the remote controller cannot be operated. Wait until “Please Wait” is not displayed before operating the remote controller. After the power is turned on, “Please
Wait” will be displayed for approximately 3 minutes.
● Indoorcontrollerboard:LED1willbelitup,LED2willbelitup(iftheaddressis0)oroff(iftheaddressisnot0),andLED3willblink.
● Outdoorcontrollerboard:LED1(green)andLED2(red)willbelitup.(Afterthestartupmodeofthesystemfinishes,LED2willbeturnedoff.)Iftheoutdoorcontroller
board uses a digital display, [- ] and [ -] will be displayed alternately every second.
If the operations do not function correctly after the procedures in step 2 and thereafter are performed, the following causes should be considered and eliminated if they
are found.
(The symptoms below occur during the test run mode. “Startup” in the table means the LED display written above.)
Symptoms in test run mode
Cause
Remote Controller Display OUTDOORBOARDLEDDisplay
< > indicates digital display.
Remote controller displays “Please Wait”, and
cannot be operated. After “startup” is displayed, only green lights up.
<00> • After power is turned on, “Please Wait” is displayed for 3
minutes during system startup. (Normal)
After power is turned on, “Please Wait” is
displayed for 3 minutes, then error code is dis-
played.
After “startup” is displayed, green (once) and red
(once) blink alternately. <F1> • Incorrect connection of outdoor terminal block (L1, L2, GR and
S1, S2, S3.)
After “startup” is displayed, green (once) and red
(twice) blink alternately. <F3, F5, F9> • Outdoor unit’s protection devise connector is open.
No display appears even when remote control-
ler operation switch is turned on. (Operation
lamp does not light up.)
After “startup” is displayed, green (twice) and
red (once) blink alternately. <EA. Eb>
• Incorrect wiring between the indoor and outdoor unit (Polarity
is wrong for S1, S2, S3.)
• Remote controller transmission wire short.
After “startup” is displayed, only green lights up.
<00>
• There is no outdoor unit of address 0. (Address is other than
0.)
• Remote controller transmission wire open.
Display appears but soon disappears even
when remote controller is operated. After “startup” is displayed, only green lights up.
<00> • After canceling function selection, operation is not possible for
about 30 seconds. (Normal)
Step2 Switch the remote controller to “Test run”.
1Select “Test run” from the Service menu, and press the [SELECT/HOLD] button.
(Fig. 7-1)
2Select “Test run” from the Test run menu, and press the [SELECT/HOLD] button.
(Fig. 7-2)
3The test run operation starts, and the Test run operation screen is displayed.
Step3 Performthetestrunandchecktheairowtemperatureandautovane.
1Press the [F1] button to change the operation mode. (Fig. 7-3)
Cooling mode: Check that cool air blows from the unit.
Heating mode: Check that warm air blows from the unit.
2Press the [SELECT/HOLD] button to display the Vane operation screen, and
then press the [F1] and [F2] buttons to check the auto vane. (Fig. 7-4)
Press the [RETURN] button to return to the Test run operation screen.
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Cool
Pipe
Auto
Switch disp.
Mode Fan
RemainTest run
F
SELECT
Fig.7-3
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
unemecivreS
rosruC
: RETURNunemniaM
Test run
Input maintenance info.
Settings
Check
Others
Fig.7-1
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Test run menu
Cursor
Service menu: MENU
Test run
Drain pump test run
Fig.7-2
F1 F2 F3 F4
MENU
ON
OFF
RETURN SELECT
HOLD
Remain
Vane
Fig.7-4
VG79Y564H01_IM.indb 14 30-Nov-22 11:00:08
15
en
7. Testrun
Step4 Conrmtheoperationoftheoutdoorunitfan.
The speed of the outdoor unit fan is controlled in order to control the performance of the unit. Depending on the ambient air, the fan will rotate at a slow speed and will keep
rotatingatthatspeedunlesstheperformanceisinsucient.Therefore,theoutdoorwindmaycausethefantostoprotatingortorotateintheoppositedirection,butthisis
not a problem.
Step5 Stopthetestrun.
1Press the [ON/OFF] button to stop the test run. (The Test run menu will appear.)
Note: If an error is displayed on the remote controller, see the table below.
LCD Description of malfunction LCD Description of malfunction LCD Description of malfunction
P1 Intake sensor error P9 Pipe sensor error (dual-wall pipe)
E0 – E5 Communication error between the
remote controller and the indoor unit
P2 Pipe sensor error (liquid pipe) PA Leakage error (refrigerant system)
P4 Drainoatswitchconnectordisconnected
(CN4F)
Pb Indoor unit fan motor error
PL Refrigerant circuit abnormal
P5 Drainoverowprotectionoperation FB Indoor controller board error
E6 – EF Communication error between the
indoor unit and the outdoor unit
P6 Freezing/overheating protection
operation
U*, F*
(* indicates an
alphanumeric
character
excluding FB.)
Outdoor unit malfunction
Refer to the wiring diagram for the
outdoor unit.
P8 Pipe temperature error
See the table below for the details of the LED display (LED 1, 2, and 3) on the indoor controller board.
LED 1 (microcomputer power supply) Indicates whether control power is supplied. Make sure that this LED is always lit.
LED 2 (remote controller power supply) Indicates whether power is supplied to the wired remote controller. The LED is lit only for the indoor unit that is con-
nected to the outdoor unit that has an address of 0.
LED 3 (indoor/outdoor unit communication) Indicates whether the indoor and outdoor units are communicating. Make sure that this LED is always blinking.
■ Testrun(Fig.7-5)
1. Press the button 1to stop the air conditioner.
• If the weekly timer is enabled ( is on), press the button 3to
disable it ( is off).
2. Press the button 2for 5 seconds.
• comes on and the unit enters the service mode.
3. Press the button 2.
• Bcomes on and the unit enters the test run mode.
4. Press the following buttons to start the test run.
: Switch the operation mode between cooling and heating and start the
test run.
: Switch the fan speed and start the test run.
: Switch the airflow direction and start the test run.
: Switch the louver and start the test run.
: Start the test run.
5. Stop the test run.
• Press the button 1to stop the test run.
• After 2 hours, the stop signal is transmitted.
Fig.7-5
Fig.7-6
1
A
B
2
3
5
B
1
A
4
2
3
■ Self-check(Fig.7-6)
1. Press the button 1to stop the air conditioner.
•If the weekly timer is enabled ( is on), press the button 3to
disable it ( is off).
2. Press the button 2for 5 seconds.
• Acomes on and the unit enters the self-check mode.
3. Press the button 5to select the refrigerant address (M-NET address) Bof the
indoor unit for which you want to perform the self-check.
4. Press the button 4.
• If an error is detected, the check code is indicated by the number of beeps
from the indoor unit and the number of blinks of the OPERATION INDICA-
TOR lamp.
5. Press the button 1.
• Aand the refrigerant address (M-NET address) Bgo off and the self-
check is completed.
7.2.2. Usingwirelessremotecontroller
VG79Y564H01_IM.indb 15 30-Nov-22 11:00:09
16
en
7. Testrun
OPERATION
INDICATOR
lamp blinking
pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx. 2.5 sec.
On
Approx. 3 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
Off
Approx. 2.5 sec.
On
Approx. 3 sec.
On
0.5 sec.
On
0.5 sec.
· · · Repeated
Number of blinks/beeps in pattern indicates the check
code in the following table (i.e., n=5 for “U2”)
Number of blinks/beeps in pattern indicates
the check code in the following table
nth
1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds
[Output pattern B]
OPERATION
INDICATOR
lamp blinking
pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx. 2.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec. On
0.5 sec.
Off
Approx. 2.5 sec.
On
0.5 sec.
On
0.5 sec.
· · · Repeated
Number of blinks/beeps in pattern indicates the check
code in the following table (i.e., n=5 for “P5”)
Number of blinks/beeps in pattern indicates
the check code in the following table
nth
1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds
• Refer to the following tables for details on the check codes. (Wireless remote controller)
[Output pattern A]
7.3. Self-check
■ Refertotheinstallationmanualthatcomeswitheachremotecontrollerfordetails.
[Output pattern A] Errors detected by indoor unit
Wireless remote controller Wired remote
controller
Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp blinks
(Number of times)
Check code
1 P1 Intake sensor error
2P2 Pipe (TH2) sensor error
P9 Pipe (TH5) sensor error
3 E6, E7 Indoor/outdoor unit communication error
4 P4 Drain sensor error/Float switch connector open
5P5 Drain pump error
PA Forced compressor error
6 P6 Freezing/Overheating protection operation
7 EE Communication error between indoor and outdoor units
8 P8 Pipe temperature error
9 E4 Remote controller signal receiving error
10 — —
11 Pb Indoor unit fan motor error
12 Fb Indoor unit control system error (memory error, etc.)
14 PL Refrigerant circuit abnormal
No sound E0, E3 Remote controller transmission error
No sound E1, E2 Remote controller control board error
No sound – – – – No corresponding
*1 If the beeper does not sound again after the initial 2 beeps to confirm the self-check start signal was received and the OPERATION INDICATOR lamp does not come
on, there are no error records.
*2 If the beeper sounds 3 times continuously “beep, beep, beep (0.4 + 0.4 + 0.4 sec.)” after the initial 2 beeps to confirm the self-check start signal was received, the
specified refrigerant address is incorrect.
• On wireless remote controller
The continuous buzzer sounds from receiving section of indoor unit.
Blink of operation lamp
• On wired remote controller
Check code displayed in the LCD.
VG79Y564H01_IM.indb 16 30-Nov-22 11:00:09
17
en
7. Testrun
[Output pattern B] Errors detected by unit other than indoor unit (outdoor unit, etc.)
Wireless remote controller Wired remote
controller
Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp blinks
(Number of times)
Check code
1 E9 Indoor/outdoor unit communication error (Transmitting error) (Outdoor unit)
For details, check the LED
display of the outdoor controller
board.
2 UP Compressor overcurrent interruption
3 U3, U4 Open/short of outdoor unit thermistors
4 UF Compressor overcurrent interruption (When compressor locked)
5 U2 Abnormalhighdischargingtemperature/49Cworked/insucientrefrigerant
6 U1, Ud Abnormal high pressure (63H worked)/Overheating protection operation
7 U5 Abnormal temperature of heat sink
8 U8 Outdoor unit fan protection stop
9 U6 Compressor overcurrent interruption/Abnormal of power module
10 U7 Abnormality of super heat due to low discharge temperature
11 U9, UH Abnormality such as overvoltage or voltage shortage and abnormal synchro-
nous signal to main circuit/Current sensor error
12 — —
13 — —
14 Others Other errors (Refer to the technical manual for the outdoor unit.)
*1 If the beeper does not sound again after the initial 2 beeps to confirm the self-check start signal was received and the OPERATION INDICATOR lamp does not come
on, there are no error records.
*2 If the beeper sounds 3 times continuously “beep, beep, beep (0.4 + 0.4 + 0.4 sec.)” after the initial 2 beeps to confirm the self-check start signal was received, the
specified refrigerant address is incorrect.
• On wireless remote controller
The continuous buzzer sounds from receiving section of indoor unit.
Blink of operation lamp
• On wired remote controller
Check code displayed in the LCD.
• If the unit cannot be operated properly after test run, refer to the following table to find the cause.
Symptom Cause
Wired remote controller LED 1, 2 (PCB in outdoor unit)
Please Wait For about 3 minutes
after power-on
After LED 1, 2 are lighted, LED 2 is turned
o,thenonlyLED1islighted.(Correct
operation)
•For about 3 minutes after power-on, operation of the remote
controller is not possible due to system start-up. (Correct
operation)
Please Wait →Error code
Subsequent to
about 3 minutes
after power-on
Only LED 1 is lighted. →LED 1, 2 blink.
•Connector for the outdoor unit’s protection device is not con-
nected.
Reverse or open phase wiring for the outdoor unit’s power
terminal block (L1, L2, GR)
Display messages do not appear
even when operation switch is
turned ON (operation lamp does
not light up).
Only LED 1 is lighted. →LED 1 blinks
twice, LED 2 blinks once.
•Incorrect wiring between indoor and outdoor units (incorrect
polarity of S1, S2, S3)
•Remote controller wire short
On the wireless remote controller with condition above, following phenomena take place.
• No signals from the remote controller are accepted.
• Operation lamp is blinking.
• The buzzer makes a short ping sound.
Note:
Operationisnotpossibleforabout30secondsaftercancellationoffunctionselection.(Correctoperation)
For description of each LED (LED 1, 2, 3) provided on the indoor controller, refer to page 15.
VG79Y564H01_IM.indb 17 30-Nov-22 11:00:10
18
en
8. Easymaintenancefunction
Maintenance data, such as the indoor/outdoor unit’s heat exchanger temperature and compressor operation current can be displayed with “Smooth maintenance”.
* Thiscannotbeexecutedduringtestoperation.
* Dependingonthecombinationwiththeoutdoorunit,thismaynotbesupportedbysomemodels.
• Select “Service” from the Main menu, and press the [SELECT/HOLD] button.
• Select “Check” with the [F1] or [F2] button, and press the [SELECT/HOLD]
button.
• Select “Smooth maintenance” with the [F1] or [F2] button, and press the
[SELECT/HOLD] button.
Select each item.
• Select the item to be changed with the [F1] or [F2] button.
• Select the required setting with the [F3] or [F4] button.
“Ref. address” setting ………. “0” - “15”
“Stable mode” setting……….. “Cool” / “Heat” / “Normal”
• Press the [SELECT/HOLD] button, fixed operation will start.
* Stable mode will take approx. 20 minutes.
The operation data will appear.
The Compressor-Accumulated operating (COMP. run) time is 10-hour unit, and the
Compressor-Numberofoperationtimes(COMP.On/O)isa100-timeunit(fractions
discarded)
Navigatingthroughthescreens
• To go back to the Service menu................[MENU] button
• To return to the previous screen .......... [RETURN] button
F1 F2 F3 F4
ON
OFF
MENU
RETURN SELECT
HOLD
Check menu
Cursor
Service menu: MENU
Error history
Diagnosis
Smooth maintenance
Request code
Smooth maintenance
Begin: SELECT
Smooth maintenance
Exit: ON/OFF
Ref.address
Stable mode
Cursor
Ref.address
Stable mode
Stabilization→Collecting
Cool / Heat/Normal
Address
Cool / Heat/Normal
Smooth maintenance
Return: RETURN
Smooth maintenance
Return: RETURN
Smooth maintenance
Return: RETURN
Page
Page
Page
COMP. current
COMP. run time
COMP. On / Off
COMP. frequency
A
Hz
Hr
times
Hr
Ref. address
Cool
Ref.address
Cool
Ref.address
Cool
Sub cool
OU TH4 temp.
OU TH6 temp.
OU TH7 temp.
5
IU air temp.
IU HEX temp.
IU filter time
7
5
F
F
5
F
F
F
F
1
2
3
Smooth maintenance
Return: RETURN
Smooth maintenance
Return: RETURN
Smooth maintenance
Return: RETURN
Page
Page
Page
COMP. current
COMP. run time
COMP. On / Off
COMP. frequency
Ref. address
Cool
Ref.address
Cool
Ref.address
Cool
Sub cool
OU TH4 temp.
OU TH6 temp.
OU TH7 temp.
IU air temp.
IU HEX temp.
IU filter time
A
Hr
times
Hr
Hz
F
37
F
4
F
F
86
F
83
F
5
VG79Y564H01_IM.indb 18 30-Nov-22 11:00:10
fr
1. Consignes de sécurité.......................................................................................1
2. Emplacement pour l’installation.........................................................................2
3. Installation de l’appareil intérieur.......................................................................3
4. Installation de la tuyauterie du réfrigérant .........................................................6
5. Mise en place du tuyau d’écoulement...............................................................7
6. Installations électriques .....................................................................................9
7. Marche d’essai ................................................................................................14
8. Fonction d’entretien aisé .................................................................................18
Remarque:
Dansleprésentmanueld’installation,l’expression“télécommandefilaire”faitréférenceuniquementaumodèleTAR-41MAAetleterme“télécommandesansfil”
uniquementaumodèlePAR-SL101A-E.Pourtouteinformationrelativeàunautremodèledetélécommande,reportez-vousaumanueld’installationfourniaveclagrille,
quicomprendunetélécommande,ouaumanuelderéglageinitialfourniaveclatélécommandeenoption.
1. Consignes de sécurité
►Avantd’installerleclimatiseur,lireattentivementtoutesles“Consignesdesécurité”.
►Les“Consignesdesécurité”reprennentdespointstrèsimportantsconcernantlasécurité.Veillezbienàlessuivre.
►Ilestnécessairedeconsulteroud’obtenirl’autorisationdelacompagnied’électricitéconcernéeavantdeconnecterlesystème.
Symbolesutilisésdansletexte
Avertissement:
Précautionsàsuivrepourévitertoutdangerdeblessureoudedécèsde
l’utilisateur.
Précaution :
Décritlesprécautionsquidoiventêtreprisespouréviterd’endommager
l’appareil.
Symbolesutilisésdanslesillustrations
: Indique un élément qui doit être mis à la terre.
: À éviter absolument.
Une fois l’installation terminée, expliquer les “Consignes de sécurité”, l’utilisation et
l’entretien de l’appareil au client conformément aux informations du mode d’emploi et
effectuer l’essai de fonctionnement en continu pour garantir un fonctionnement normal.
Le manuel d’installation et le mode d’emploi doivent être fournis à l’utilisateur qui doit les
conserver. Ces manuels doivent également être transmis aux nouveaux utilisateurs.
Avertissement:
• Prendresoindelirelesétiquettessetrouvantsurl’appareilprincipal.
• Contacterunrevendeurouuntechnicienagréépourinstaller,déplaceret
réparer l’appareil.
• N’essayezjamaisderépareroudedéplacervous-mêmel’appareil.
• Pourl’installationetledéplacement,suivrelesinstructionsfourniesdans
le manuel d’installation et utiliser des outils et des éléments de tuyauterie
spécifiquementconçuspourl’utilisationavecleréfrigérantindiquédansle
manueld’installationdel’appareilextérieur.
• L’appareildoitêtreinstalléconformémentauxinstructionspourréduireles
risquesdedommagesliésàdestremblementsdeterre,destyphonsou
desventsviolents.Uneinstallationincorrectepeutentraînerlachutede
l’appareiletprovoquerdesdommagesoudesblessures.
• Nepasmodifierl’appareil.Celapourraitprovoquerunrisqued’incendie,
d’électrocution,deblessureoudefuited’eau.
•
L’appareildoitêtresolidementinstallésurunestructurepouvantsupporterson
poids
.
• L’appareilserastockédansunezonebienventiléeoùlatailledespièces
correspondàlasurfacedespiècesspécifiéepourlefonctionnement.
•
Sileclimatiseurestinstallédansunepetitepièceoudansunlocalfermé,certaines
mesuresdoiventêtreprisespouréviterquelaconcentrationderéfrigérantne
dépasse le seuil de sécurité en cas de fuite de réfrigérant. En cas de fuite de
réfrigérantetdedépassementduseuildeconcentration,desrisquesliésau
manqued’oxygènedanslapiècepeuventsurvenir.
• Tenirlesappareilsàgaz,lesradiateursélectriquesetautressources
d’incendie(sourcesd’inflammation)àl’écartdeslieuxoùl’installation,les
réparationsetautrestravauxsurleclimatiseurseronteffectués.
Toutcontactduréfrigérantavecuneflammelibèredesgaztoxiques.
•
Aérerlapièceencasdefuitederéfrigérantlorsdel’utilisation.Lecontactdu
réfrigérantavecuneflammepeutprovoquerdesémanationsdegaztoxiques.
• Touttcavailsurlesinstallationsélectriquesdoitêtreeffectuéparun
technicienqualifiéconformémentauxréglementationslocalesetaux
instructions fournies dans ce manuel.
• Nepasutiliserderaccordementintermédiairedesfilsélectriques.
• N’utiliserquelescâblesspécifiéspourlesraccordements.Les
raccordementsdoiventêtreréaliséscorrectementsanstensionsur
lesbornes.Nejamaiseffectuerdejonctionsurlescâbles(saufencas
d’indicationscontraires).Lenonrespectdecetteconsignepeutentraîner
une surchauffe ou un incendie.
•
Lors de l’installation, du déplacement ou de l’entretien du climatiseur,
n’utilisezqueleréfrigérantindiquésurl’appareilextérieurpourremplirles
tuyauxderéfrigérant.Nepaslemélangeravecunautreréfrigérantetfairele
vided’airdanslestuyaux.
Siduréfrigérantestmélangéavecdel’air,celapeutprovoquerdespointesde
pressiondanslestuyauxderéfrigérantetentraîneruneexplosionetd’autres
risques
.
L’utilisation d’un réfrigérant différent de celui spécifié pour le climatiseur
peutentraînerdesdéfaillancesmécaniques,desdysfonctionnements
dusystèmeouunepannedel’appareil.Danslepiredescas,celapeut
entraînerunobstacleàlamiseensécuritéduproduit.
• L’appareildoitêtreinstalléconformémentauxréglementationsnationales
relativesaucâblage.
• Cetappareiln’estpasconçupourêtreutilisépardespersonnes(ycompris
desenfants)présentantdescapacitésphysiques,sensoriellesoumentales
réduites,oumanquantd’expérienceetdeconnaissances,àmoinsqu’elles
nesoientsuperviséesouaientreçudesinstructionsrelativesàl’utilisation
del’appareilparunepersonneresponsabledeleursécurité.
• Lesenfantsdoiventêtresurveilléspours’assurerqu’ilsnejouentpasavec
l’appareil.
• Lecouvercledublocdesortiedel’appareildoitêtresolidementfixé.
•
Silecordond’alimentationestendommagé,ildoitêtreremplacéparle
fabricant,sesrevendeursouuntechnicienqualifiépourévitertoutdangerde
chocélectrique
.
• UtilisezuniquementdesaccessoiresautorisésparMitsubishiElectricet
demandezàunrevendeurouàuntechnicienagréédelesinstaller.
Si les accessoires ne sont pas correctement installés, une fuite d’eau, un
chocélectriqueouunincendiepeutseproduire.
• Unefoisl’installationterminée,vérifierleséventuellesfuitesderéfrigérant.
Sileréfrigérantfuitdanslapièceetentreencontactaveclaflammed’un
chauffageoud’unecuisinière,desgaztoxiquespeuventsedégager.
• Nefaitesusaged’aucunmoyenvisantàaccélérerleprocessusde
dégivrageouànettoyerautrequeceuxrecommandésparlefabricant.
•
L’appareildoitêtrerangédansunepiècenecontenantaucunesource
d’allumagecontinue(exemple:flammesnues,appareilàgazouchauffage
électrique)
.
• Nepercezpasetnebrûlezpasl’appareil.
• Sachezquelesréfrigérantspeuventêtreinodores.
• Latuyauteriedoitêtreprotégéecontretoutdommagephysique.
• L’installationdetuyauteriedoitêtrelimitéeaustrictminimum.
• Lesréglementationsnationalessurlesgazdoiventêtrerespectées.
• Gardezlesouverturesdeventilationlibresd’obstruction.
• Nepasutiliserd’alliagedesoudureàbassetempératurepourlebrasage
destuyauxderéfrigérant.
•
Lorsdetravauxdesoudure,veilleràassureruneventilationsuffisantedela
pièce
.
Veilleràcequ’aucunmatériaudangereuxouinflammablenesetrouveà
proximité
.
Siletravailesteffectuédansunepiècefermée,depetitetailleouunendroit
similaire,vérifierl’absencedetoutefuitederéfrigérantavantdecommencerle
travail
.
Sileréfrigérantfuitets’accumule,ilrisquedes’enflammeretdesgaz
toxiquespeuventsedégager.
• Faitesattentionquandvousutilisezunesourcedechaleurauxiliaireet
suiveztouteslesinstructionsdufabricanttiersainsiquelesdirectivesde
sécurité pour l’installation et l’utilisation.
Toutesourcedechaleurauxiliaireconnectéeàcetteunitéparlaconnexion
CN24doitêtredotéed’unmécanismedecontrôledelatempérature
indépendant.Toutmanquementaumontageetàl’entretiendece
mécanismedecontrôledelatempératurepeutannulerlagarantiedecette
unité.
MitsubishiElectricn’accepteraaucuneobligationdegarantieniaucune
autreresponsabilitéencasdedommageoudeperteenconnexionavec
ceschauffagesauxiliairestiers.
Tabledesmatières
1
VG79Y564H01_IM.indb 1 30-Nov-22 11:00:10
Table of contents
Languages:
Other Mitsubishi Electric Heat Pump manuals
Mitsubishi Electric
Mitsubishi Electric PUHZ-W50VHA2R1 User manual
Mitsubishi Electric
Mitsubishi Electric SUZ-SWM VA Series User manual
Mitsubishi Electric
Mitsubishi Electric PUHZ-W HA series User manual
Mitsubishi Electric
Mitsubishi Electric Mr.SLIM PKA-A HA6 Series User manual
Mitsubishi Electric
Mitsubishi Electric EHST20 Series User manual
Mitsubishi Electric
Mitsubishi Electric PUHZ-SW HA Series User manual
Mitsubishi Electric
Mitsubishi Electric PUHZ-SW50VHA User manual
Mitsubishi Electric
Mitsubishi Electric PUHZ-HW HA series User manual
Mitsubishi Electric
Mitsubishi Electric CRHV-P600YA-HPB How to use
Mitsubishi Electric
Mitsubishi Electric PKA-A24KA6 User manual
Mitsubishi Electric
Mitsubishi Electric TRANE TPKA0A.1HA70 Series User manual
Mitsubishi Electric
Mitsubishi Electric MR. SLIM PCA Series User manual
Mitsubishi Electric
Mitsubishi Electric ECODAN EHST20C-VM2C User manual
Mitsubishi Electric
Mitsubishi Electric SLZ-KF09 User manual
Mitsubishi Electric
Mitsubishi Electric SUHZ-SW VA Series User manual
Mitsubishi Electric
Mitsubishi Electric PUZ-ZM100YKA User manual
Mitsubishi Electric
Mitsubishi Electric City Multi PUHY-P192TSKMU-A Owner's manual
Mitsubishi Electric
Mitsubishi Electric QAHV-N136TAU-HPB Product guide
Mitsubishi Electric
Mitsubishi Electric TRANE TPKA0A0121HA70A User manual
Mitsubishi Electric
Mitsubishi Electric SLZ-KF09 User manual
Mitsubishi Electric
Mitsubishi Electric Mr. Slim MSZ-GE06NA-8 Installation and operation manual
Mitsubishi Electric
Mitsubishi Electric PUH-P200MYA Operating manual
Mitsubishi Electric
Mitsubishi Electric PUZ-WM AA Series User manual
Mitsubishi Electric
Mitsubishi Electric PWFY-P-NMU-E-AU Installation and operation manual
Popular Heat Pump manuals by other brands
Arctic Heat Pumps
Arctic Heat Pumps V4 Installation instructions manual
Ecoer
Ecoer 36K installation manual
DeDietrich
DeDietrich Alezio V220 Evolution user guide
CTC Union
CTC Union EcoAir 500M Installation and maintenance manual
Glen Dimplex
Glen Dimplex System M Comfort 9/12 kW Installation and operating instruction
Innova
Innova Ephoca HPAC 2.0 installation manual
Toshiba
Toshiba ESTIA HWS-802H-E installation manual
York
York GEYSIR VARIO RANGE user manual
Trane
Trane Thermo King SPECTRUM T-90 Series installation manual
Payne
Payne PH3Z Series installation instructions
Daikin
Daikin 4MXL36TVJU Service Manual Removal Procedure
Haier
Haier GE NS17HSA installation instructions
