Mitsubishi Electric DLP FD730U User manual

MULTIMEDIA DATA/VIDEO PROJECTORS
Vivid color 4100lm* Brightness and 3000:1 High Contrast
Features including impressive 4100lm brightness and a high contrast of
3000:1 allow the FD730U to reproduce clear, sharp images regardless of
venue size, be it a large meeting room or lecture hall. Mitsubishi Electric’s
original color wheel and BrilliantColor™ are incorporated as well, ensur-
ing life-like color reproduction. Whether coming from a computer, video-
cassette player or other source, the reproduction of vivid images full of
color is guaranteed.
3000lm 4100lm
Lens Shift Function (Vertical only)
The problem of offset image often experienced at
the time of installation has been eliminated.
Simply open the top cover on the projector and
use the manual lens shift-adjustment toggle to
correct the image. It’s safe and easy to use, even
when confronted with difficult installation
conditions such as a low ceiling.
+12%
-14%
Shift-adjustment toggle
When you want the best...
FULL HIGH-DEFINITION
Cutting-edge mobile projectors
with clear, sharp, vivid imagery
Models are equipped with selection functions for the lamp, power source and
standby mode, allowing each to be set according to the usage environment.
Lamp Mode: STANDARD / LOW
Standby Mode: STANDARD / LOW
Auto Power Off: OFF / 5min / 10min / 15min / 30min / 60min
Energy-efficient Mode Selection
FD
7
30U
Each mode can be set individually
Modes can be set and changes made to them
by direct input using the operation panel
on the projector or via the remote controller.
High Image Quality High Reliability & User friendly Presentation
Installation flexibility
• Lamp life specification is an estimate based on verification under proper conditions and is not the duration of the
warranty. Lamp will shut-off automatically when usage reaches the specified estimated maximum lamp hours.
Service life may vary widely depending on usage and operating environment and conditions, as well as users’
adherence to the maintenance and cleaning procedures provided in the user’s manual.
A longer service life for the projection lamp has been achieved by
incorporating an optimal design for lamp temperature control. Benefits
include substantial reductions in projector operating cost and the labor
required for changing the lamp.
Estimated 5000-hour lamp life (in Low mode)
Mounted lamp3,000-hour lamp
5,000-hour lamp
3,000 5,000 6,000
Mounted lamp
1st replacement Reduced
operating
cost
*Please refer to “Screen Size and Projection Distance” on the back cover.
Availability area
for lens shift
from default position
4100
LUMENS
1080P
HIGH DEFINITION
VERTICAL
LENS SHIFT 5000HR
EST. LAMP LIFE*
10W AUDIO
SPEAKER

126 7 8 9
4 5
3
Screen Size and Projection Distance
Side view
Specifications
Input and Output Terminals
MOBILE PROJECTOR
Picture Performance Presentation User-friendly
1
2
3
4
5
S-Video / Video
Audio input-1
Monitor output
Audio output
Audio input-2
6
7
8
9
Computer / Component
video input
HDMI
LAN (RJ-45)
Serial RS-232C
FD730U
Other Features
Dimensions
PC compatibility
640 × 480 - 1600 × 1200 True : 1920 × 1080, sync on green available
NTSC / NTSC 4.43 / PAL (including PAL-M, N)/ SECAM / PAL-60
Component video; 480i/p (525i/p), 576i/p (625i/p), 720p (750p),
1080i/p (1125i/p 50/60Hz)
Video compatibility
Standard Mode: 280W (Shut-off Time 3000hrs)
Low Mode: 230W (Shut-off Time 5000hrs)
RGB: mini D-sub 15pin × 2
Audio: stereo mini jack (ø3.5mm) × 2
(one for Computer1, the other for Computer2)
Video: RCA × 1 + S-VIDEO × 1 Digital; HDMI × 1
Video audio: RCA jack (L/R) × 1
RGB: mini D-sub 15pin × 1 Audio: stereo mini jack (ø3.5mm) × 1
10W mono
13.6 × 5.3 × 10.6 inch
9.5lbs
AC 100-240V, 50/60Hz
VLT-XD700LP
3-Years Parts/Labor, 3-Years Express Replacement Assistance,
1-Year or 500 hours lamp warranty (whichever comes first)
FD730U
0.65" 1-chip DMD
1920 × 1080 (total 2,073,600 pixels)
4100lm
3000 : 1
40" - 300"
1.4 ~ 2.1
SERIAL: mini D-sub 9pin × 1 (RS232C)
LAN (RJ-45): × 1 (projector control)
Model
Display technology
Resolution
Brightness*
Contrast ratio
Picture size
Throw ratio
Input terminals
Output terminals
Communication terminals
Audio speaker
Dimensions (W × H × D)
Weight
Power requirements
Optional lamp
Warranty
Screen (16 : 9)
Diagonal size Width (W) Shortest (Wide) Longest (Tele)
H1 H2
Height (H)
inch
20
29
39
49
59
74
98
123
147
Projection Distance (L)Lens shift height
Height
projected
image (Hd)
inch
40
60
80
100
120
150
200
250
300
cm
102
152
203
254
305
381
508
635
762
inch
35
52
70
87
105
131
174
218
261
cm
89
133
177
221
266
332
443
553
664
cm
50
75
100
125
149
187
249
311
374
inch
47
71
96
120
145
182
243
304
365
m
1.2
1.8
2.4
3.1
3.7
4.6
6.2
7.7
9.3
inch
71
107
144
180
216
271
362
–
–
m
1.8
2.7
3.6
4.6
5.5
6.9
9.2
–
–
inch
6.6
10
13
16
20
25
33
41
49
cm
17
25
34
42
50
63
84
105
126
inch
2.8
4
6
7
8
11
14
18
21
cm
7
11
14
18
21
27
36
45
54
inch
2.4
4
5
6
7
9
12
15
18
cm
6
9
12
16
19
23
31
39
47
Screen size chart
FD730U Downside
Upside
Height
Hd
H2 H1
Projection distance (L)
Brilliant
ColorTM
Color
Enhancer
Wall
Screen
Closed
Caption
Low
Fan Noise
Top
Loading
Lamp
LAN
(RJ-45) HDMI
Long-life
Lamp
Direct
Power Off
Password
Lock
Audio
Mix Visual PA
Low
Stand-by
Power
10W
Speaker
User
Logo
Projection
Manual
Lens Shift
Efficient
Mode
*Compliance with ISO21118-2005 • Varies depended on condition. • All brand names and product names are
trademarks, registered trademarks or trade names of their respective holders. • Lamp life specification is an estimate
based on verification under proper conditions and is not the duration of the warranty. Lamp will shut-off automatically
when usage reaches the specified estimated maximum lamp hours. Service life may vary widely depending on usage
and operating environment and conditions, as well as users’ adherence to the maintenance and cleaning procedures
provided in the user manual. • “HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.”
Stand-by Wattage under 0.5W*
Auto Power Off
Unpainted Cabinet (Recyclable)
Excellent Sound Projection (10W Speaker+Audio Mix)
Quiet 28dB Operation
*The trademark of PJLink is trademark applied for registration or registered trademark in Japan,
the United States, and other countries and areas.
Network Connectivity
Projectors are equipped with a RJ-45 LAN terminal for remote operation.
In addition to that, the FD730U is compatible with PJLinkTM.
Using Audio Mix and the built-in 10W speaker, the voice of the presenter and
audio from an external audio source can be delivered simultaneously.
Stand-by (low) mode power consumption is less than 0.5W, offering increased
energy savings and further contributing to environmental preservation.
As an eco-conscious measure to promote recycling, an unpainted projector
cabinet is adopted.
Projection fan noise can be distracting during a presentation or
videoconference. The FD730U operates at a significantly low noise level of
only 28dB (i.e., in “low lamp” mode). As a result, presentations and
conferences can be held without distracting projector noise in the background.
*Time preset by user
*When in stand-by (low) mode. At this time, use of the LAN function is not possible.
Source lamp
Unit:mm
134
64.5
Lens Shift
Upper Side : 1.31mm
Lower Side : 1.27mm
80
9.5
345
270
If no image signal is output for a predetermined period of time*, power is automatically
turned off, realizing energy savings by reducing needless power consumption.
LITFD730U
New publication, effective October 2012.
Specifications subject to change without notice.
