Mitsubishi Electric HC7000 User manual

MITSUBISHI HOME THEATER PROJECTOR
Vertical direction Dimensions
Horizontal direction
Screen
25%
Maximum shift
Maximum shift
Left shift
Screen width (W)
Right shift
5% 5%
25%
50%
50%
Screen height (H)
Specifications
Projection system
Panel size
Number of pixels
Drive system
Array
Zoom / focus operation
Lens shift
Throw ratio
Projection lens
Light source lamp
Optical system
Iris
Brightness (lm)
Contrast ratio
Resolution
Video
PC
Video
Serial / RS-232C standard
Trigger terminal
Digital keystone
Fan noise
Power source voltage
Power consumption (W)
Weight (kg / lbs)
Main unit dimensions
Supplied accessories
PC input
Horizontal (kHz)
Vertical (Hz)
Panel specs
Optical specs
Projection screen size (inches)
Images
HC7000
Transmissive liquid crystal system
0.74type x3 Aspect ratio 16:9 with micro lens
1920x1080 (total 2,073,600 pixels)
3 primary color liquid-crystal shutter system
Stripe pattern
1.6-power zoom / motorized
Motorized up-down 75% / right-left 5%
1.42-2.26
f=23.5-37.6mm / 0.9”-1.5” F2.5-3.1
160W
Mirror color separation / prism synthesis system
Auto-iris
50-300: (Diagonal)
1000
72000:1 (Auto-Iris) typ.
VGA*640x480 - UXGA*1600x1200
15-100kHz
24, 50Hz-120Hz
NTSC, NTSC4.43, PAL (including PAL-M and N), SECAM, PAL-60,
Video input: 480i/p, 576i/p, 1080i 60/50, 1080p 60/50/24, 720p 60/50
PC/AT compatibles, Mac
1 terminal
2 terminals
1 terminal
1 terminal
1 terminal (component can also be input to Mini D-Sub 15 pin)
1 terminal (D-Sub 9 pin)
1 terminal
Vertical ±15steps
17dBA (at low mode)
AC100V 50/60Hz
250 (at stand by 7W)
7.5 / 16.5
427x440x159mm / 16.8”x17.3”x6.3” (excluding height adjustment)
Power source cord (2.9m), Remote control, AA batteries (x2), RGB signal cable, RS-232C cable, Lens cap, Lamp replacement tray
2-years parts and labor, 1-year or 500 hours on lamp (whichever comes first)
Model name
*: SVGA,XGA,WXGA,SXGA,UXGA are registered trademarks of IBM Corporation of the United States
Input signal
system
Input
Output
Mini D-Sub 15 pin
HDMI terminal
RCA terminal
S-Video terminal
RCA terminal
PC input
HDMI input
Composites
S
Components
Functions
Other
Warranty
WxDxH
Projection distance
50
60
70
80
90
100
110
120
130
140
150
200
250
300
127
152
178
203
229
254
279
305
330
356
381
508
635
762
40.2
48.0
55.9
64.2
72.0
79.9
88.2
96.1
104
112
120
160
200
240
29.9
35.8
42.1
48.0
53.9
59.8
66.1
72.0
77.9
83.9
90.2
120
150
180
55
67
79
91
102
114
122
134
146
158
169
228
284
343
91
106
126
148
161
181
201
217
236
256
272
366
457
547
0
0
0
0
0
0
0
0
0
0
0
0
0
0
16.9
20.0
23.6
27.2
30.3
33.9
37.0
40.6
43.7
47.2
50.8
67.3
84.3
101
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1.9
2.4
2.8
3.1
3.5
3.9
4.3
4.7
5.1
5.5
5.9
7.9
9.8
12
1.9
2.4
2.8
3.1
3.5
3.9
4.3
4.7
5.1
5.5
5.9
7.9
9.8
12
inch inch inch inch inch inch inch inch inch inch inch inch inch
Diagonal
Diagonal
Screen size (4:3) Projection image size (16:9)
Projection distance Up-down lens shift Right-Left lens shift
W
(width)
H
(height)
Max
Zoom
Min
Zoom Down Up Left Right
cm
46.1
55.1
64.2
73.6
82.7
91.7
101
110
119
128
138
183
230
275
40.2
48.0
55.9
64.2
72.0
79.9
88.2
96.1
104
112
120
160
200
240
22.4
27.2
31.5
35.8
40.6
44.9
49.6
53.9
58.7
62.9
67.3
90.2
113
135
W
(width)
H
(height) Black
zone
3.9
4.3
5.1
5.9
6.7
7.5
8.3
9.1
9.8
10.6
11.4
14.9
18.9
22.4
127
152
178
203
229
254
279
305
330
356
381
508
635
762
43.7
52.4
61.0
69.7
78.3
87.0
96.1
104.7
113.4
122.0
130.7
174.4
217.7
261.4
24.4
29.5
34.3
39.4
44.1
49.2
53.9
58.7
63.8
68.5
73.6
98.0
122.4
147.2
59
71
87
98
110
122
134
150
161
173
185
248
311
374
98
118
138
158
177
197
217
236
256
276
299
398
496
598
0
0
0
0
0
0
0
0
0
0
0
0
0
0
19
22
26
30
33
37
41
44
48
52
55
74
92
110
19
22
26
30
33
37
41
44
48
52
55
74
92
110
0
0
0
0
0
0
0
0
0
0
0
0
0
0
2.4
2.8
3.1
3.5
3.9
4.3
4.7
5.1
5.5
5.9
6.7
8.7
11
13
2.4
2.8
3.1
3.5
3.9
4.3
4.7
5.1
5.5
5.9
6.7
8.7
11
13
inch cm inch inch inch inch inch inch inch inch
Diagonal
Screen size (16:9) Projection distance Up-down lens shift Right-Left lens shift
W
(width)
H
(height)
Max
Zoom
Min
Zoom Down Up Left Right
50
60
70
80
90
100
110
120
130
140
150
200
250
300
16.9
20.0
23.6
27.2
30.3
33.9
37.0
40.6
43.7
47.2
50.8
67.3
84.3
101
Scan frequency
08-08 - LITHC7000 New publication, effective Aug. 2008
Specifications subject to change without notice.
MITSUBISHI DIGITAL ELECTRONICS
AMERICA, INC.
Presentation Products Division
Phone: [phone]
Email: [email protected]
www.mitsubishi-presentations.com
MITSUBISHI ELECTRIC SALES
CANADA, INC.
Information Technologies Group
Phone: [phone]
www.mitsubishielectric.ca
Illumination.
Definition.
Diamond.
0.63” 0.36”
6.26”
2.31”
3.33”
2.24”
5.88”
6” 6”
8.9” 4”
3.9”
17.34”
2.3”
16.8”
* The above figures are approximate and may be slightly different from the actual measurements.

Evolutionary in design and functionality,
its alluring presence expresses sheer pleasure in every way and form.
Embodied with cutting-edge full high-definition technologies,
including advanced black color reproduction techniques,
the HC7000 is setting standards for the industry.
Dynamic and intriguing, exciting the senses…
Just wait until you turn it on!
The beauty is the performance
NEW HC7000

w/ aperturew/o aperture
Extra-low Dispersion (ED)
glass lens
Conventional projectors commonly have problems related to loss of light intensity; not so with the HC7000. Degraded
polarization results from the offset position of the liquid crystal elements. An optical compensation panel has been newly
developed and installed between the liquid crystal panel and polarization filter. This panel corrects the optical projection angle
and prevents light leakage, thereby preserving the intensity and realizing new heights in the level of contrast. Together with our
high-speed Diamond Black Iris, a high contrast of 72000:1 is achieved for the HC7000.
New Optics Panel Delivers Precise Light Focusing and an
Amazing Level of High-contrast
Superior image reproduction is provided using a 17-piece/14 cluster
optical system equipped with extra-low dispersion (ED) lenses.
Far exceeding the performance of conventional glass lenses,
chromatic aberration is virtually eliminated and resolution across
the entire screen, including the peripheral edges, is improved.
Equipped with a fixed aperture, reproduction of every shade,
from grays to the deepest of blacks, is ensured.
Extra-low Dispersion Glass Lens for Superior High-definition Resolution
Conventional sirocco fan
Cooling structure adopted to
realize silent operation
HC7000 sirocco fan
Optical path
Ver t i ca l
airflow
Cooling
fan
Cooling
fan
New cooling structure
Output polarizing
plate group Incident
polarizing
plate group
Liquid crystal panel
Optical path
Cooling
fan
Conventional cooling structure
A new cooling system is introduced for the liquid crystal panel. It includes a new cooling duct design for the new
chassis, a smaller fan motor and a large (low-noise) sirocco fan. As a result, a larger air-intake area is secured and
the fan operates at a slower speed, providing improved cooling efficiency owing to the hermetic performance of
the new chassis. The end result is industry-leading quiet operation of 17dBA (at low mode). Mitsubishi always aims
to produce the quietest projectors in the market.
Innovative Liquid crystal Panel Cooling System Design
Realizes Industry-leading Quiet Operation - 17dBA (at low mode)
The ultimate in black color reproduction. Experiencing is Believing.
Newly Developed Diamond Black Iris with 1/60-second Iris Control
Evolutionary advancements in the HC7000 include the adoption of Mitsubishi’s original Diamond Black Iris technology. The iris
section takes on a “diamond-cut” shape that prevents light refraction and realizes an enhanced level of contrast. True blacks are
clearly depicted even during sequences of continual bright-dark scene intervals, ensuring the reproduction of every detail with
vivid clarity. Combined together with Mitsubishi’s innovative contrast control, a perfect balance between blacks, the brightest
whites and the full color spectrum in between is achieved.
Previous Auto-Iris (HC5000)
New Auto-Iris (HC7000)
*as of July 2008, for projectors under 7.5kg (in-house study)
Conventional optical system
New optical compensation panel
Reproduction of
jet-black
Polarization filter Lens Screen
Linear polarization
Linear polarization
Elliptical polarization Light leakage
Linear polarization
Polarization filter Liquid crystal panel
Polarization filter
Polarization filter Lens Screen
Liquid crystal panel +
polarization filter

Lens shift right-left motor drive Lens shift up-down motor drive
Focus motor
Zoom motor
An inorganic liquid-crystal panel is incorporated, creating deep rich blacks and eliminating the need for the rubbing
process. This realizes the reproduction of vivid high-definition images with no vertical lines. The rate panel service life
is approximately tenfold that of organic film panels, translating into years of high picture quality viewing enjoyment.
Full High-definition Liquid crystal Panel (1920x1080)
“Deep Color” Compatible HDMI 1.3 Input Terminals
The HC7000 has two HDMI input terminals, and is capable
of processing high-contrast images from 10- and 12-bit
video signals in addition to the conventional 8-bit signal.
Amazingly Easy to Use Anytime, Anywhere
1.6X Power Zoom/Focus DramaticallyImproves
High-definition Resolution and Set-up Ease
Using the 100-type size (16:9) enables not only the adjustment of projection
distance from 10.1ft to 16.4ft, but also brilliant crystal-clear images in tight spots
where sufficient distance to the screen cannot be kept. With a vertical lens shift
range of 75% and horizontal range of 5%, installation is simple and easy. Two-stage
adjustment, quick and fine, has been added to the power drive to enhance usability.
The anamorphic lens compatibility of the HC7000 widens the projection range of cinema-scope images. Mode 1 provides extended
projection, and Mode 2 is for images other than cinema-scope, which mirror the original with the anamorphic lens attached.
Anamorphic Lens Compatibility - Choose Setting Based on Media Played
Reon-VX: Next-generation high-performance video processor
Successor to the REALTA IC manufactured by Silicon Optics Inc., renowned for its IC solutions that deliver Hollywood Quality
Video (HQV), this high-quality chip is the key to improved image reproduction.
High-precision I/P conversion for all signal sources
Precise and accurate rendering is what you get with Mitsubishi’s 10-bit interlace/progressive (I/P) conversion image processing
technology. Be it broadcast satellite movies, mixed video sources or even commercially packaged media, the end result is always
the progressive reproduction of high picture quality.
High-performance video scaler
This ultra-precise image scaling function guarantees superior pixel conversion processing when converting resolution up from
720x480p to 1920x1080p. A unique filtering technique enables adaptive switching to a total of
1024 filter tabs each horizontally and vertically, further contributing to the high-definition picture
quality of the images. Our Fixed Film/Video Mode greatly improves conversion precision.
14-bit Digital Gamma Correction
Mitsubishi’s original 14-bit gamma correction processing function expands gradation expression
power 16-fold over the conventional 10-bit technology. This dramatically raises
the projector’s ability to reproduce the subtleties in dark images.
Full 10-bit 4:4:4 Signal Processing
HQV noise-reduction (TRNR, MNR/BAR) reduces buzzing and block noise.
Chromatic up-sampling errors reduced
Precision Enhanced with the Addition of Fixed Film/Video Mode to
the “Reon-VX” IC from Silicon Optics Inc.
2-3 Pulldown
When processing
24 frames/sec images at
60 frames/sec, smooth
motion becomes distorted
because the signals in the
2- and 3-frame sequences
cause overflow into the
third B-frame.
24P Direct Output
With a signal processing
speed of 24 frames/sec
increased to 48 frames/sec,
the sequence created
aligns the signal, providing
a smoothness and
textured detail that
mirror the original.
The HC7000 is compatible with Blu-ray 24P direct output. Thanks to an output of up to 48P (96Hz liquid crystal panel driver), twice the speed of
conventional movie signals (24 frames/sec), unbelievably life-like images are reproduced with a smoothness and texture detail that mirror the original.
24P Blu-ray Direct Input Compatibility – Reproduction of Original Image Motion
A B C D
1 frame 1 frame 1 frame 1 frame
A A B B B C C D D D
24 frames/sec
film signal
2-3 pulldown
converts to
30 frames/sec
1 frame 1 frame 1 frame 1 frame
A B C D
A A B B C C D D
24 frames/sec
film signal
24P
(played at 48Hz)
The HC7000 is equipped with
a projector power switch/screen
extension/retraction trigger
combination, creating a convenient
one-touch operation function
for cinema viewing. The
anamorphic modes can also
be controlled.
Trigger Terminal
The projection lamp has a long 5000-hour
estimated service life for months of uninterrupted
viewing pleasure. When its time to clean or replace
the lamp, a side-loading installation design makes
it so the projector does not need to be moved.
So regardless of installation–whether suspended
from the ceiling or sitting on a shelf–lamp
maintenance and replacement is simple and easy.
Long-life Lamp (up to 5000 hours)
The button on the remote controller
illuminate automatically, promising easy,
trouble-free operation even in the darkest
of rooms. Convenience is also improved
with a function that enables the screen
to be adjusted directly from the remote
controller.
Illuminated Remote Controller
The HC7000 comes with an air
filter that has a three-dimensional
honeycomb structure, a
microscopic filtering surface
and a special electrostatic film
for enhanced filtering efficiency.
It attaches to the side of the projector
and works as an air purification
system to prevent dirt and other
air-borne particulates from entering
the chassis.
3D Micro-surface Air Filter
Anamorphic Mode 1
Anamorphic Mode 2
neercsepocs-ameniC1edoMcihpromanAegamIlanigirO
2edoMcihpromanAegamIdednapxenA)9:61(egamIlan
igirO
1080 1080
1080
True-to-life Images will Amaze You. Flexibile and Versatile Home Theater.
