TECHNICAL MANUAL
Collection data
Manual No. '07•PAC-T-115D
PACKAGED AIR-CONDITIONER
(Spilit system, Air to air heat pump type)
MULTI-TYPE (V-MULTI)
PACKAGED AIR-CONDITIONER
CEILING RECESSED COMPACT TYPE
FDTCVA402HESP2R FDTCVA602HEST2R
CEILING SUSPENDED TYPE
FDENVA402HES2R
502HES2R
602HES2R
FDENVA402HESP2R
502HESP2R
602HESP2R
FDENVA602HEST2R
SATELLITE DUCTED TYPE
FDUMVA402HES2R
502HES2R
602HES2R
FDUMVA402HESP2R
502HESP2R
602HESP2R
FDUMVA602HEST2R
CEILING RECESSED TYPE
FDTVA402HES2R
502HES2R
602HES2R
FDTVA402HESP2R
502HESP2R
602HESP2R
FDTVA602HEST2R
WALL MOUNTED TYPE
FDKNVA402HESP2R
502HESP2R
FDKNVA602HEST2R
(OUTDOOR UNIT)
FDCVA402HESAR
502HESAR
602HESAR
(INDOOR UNIT)
FDTCA201R FDTA201R
251R
301R
FDUMA202R
252R
302R
FDEN201R
251R
301R
FDKNA201R
251R
DRAFT

-
1
-
TABLE OF CONTENTS
1. PACKAGED AIR-CONDITIONER ........................................................................ 1
2. MULTI-TYPE (V MULTI) PACKAGED AIR-CONDITIONER .............................. 36
2. MULTI-TYPE (V MULTI)
PACKAGED AIR-CONDITIONER
CONTENTS
1.1 GENERAL INFORMATION............................................................................... 2
1.1.1 Specific features .......................................................................................... 2
1.1.2 How to read the model name....................................................................... 2
1.2 SELECTION DATA ........................................................................................... 3
1.2.1 Specifications ............................................................................................... 3
(1) Ceiling recessed compact type (FDTC) ........................................................ 3
(2) Ceiling recessed type (FDT) ......................................................................... 5
(3) Ceiling suspended type (FDEN) ................................................................. 12
(4) Satellite ducted type (FDUM)...................................................................... 19
(5) Wall mounted type (FDKN) ......................................................................... 26
1.3 ELECTRICAL DATA ....................................................................................... 29
1.3.1 Electrical wiring .......................................................................................... 29
(1) Indoor unit ................................................................................................... 29
(2) Outdoor unit ................................................................................................ 35

-
2
-
1.1 GENERAL INFORMATION
1.1.1 Specific features
(1) A new refrigerant, R410A, which causes no damage to the earth’s ozone layer, is used. R410A is a pseudoazeotropic refrigerant, so
there is little formation of separate vapor and liquid layers, and it is possible to add refrigerant on-site.
(2) Less refrigerant charge amount due to use of double phase refrigerant flow system. The total refrigerant charge amount has been
reduced by more than 50%.
(3) The microcomputer chip is installed in the indoor unit and outdoor unit. There is no need for the unit to communicate between the
outdoor and indoor units so the unit is more resistant to electromagnetic noise thus the incidence of microcomputer malfunction
has been reduced. The compressor in the outdoor unit has its own self protection function, that reacts according to anomalous high
pressure and excessive high temperature.
(4) There are only three power lines between the outdoor and indoor unit. One cabtyre cable with 3 wires encased in one sheath is
enough for conducting the wiring work between the outdoor unit and the indoor unit. This contributes to simpler wiring work in the
field.
(5) All air supply ports have auto swing louvers. (Only case of FDTC, FDT, FDEN and FDKN models). The indoor fan motor has
three speeds of high, medium and low.
(6) All models have service valves protruding from the outdoor unit for faster flare cannection work in the field.
(7) Compared to the previous models, a single fan is used in the FDCVA402 ~ 602 outdoor unit models, resulting in markedly reduced
weight and greater compactness. In addition, use of an inverter makes these units much more economical compared to the previous
fixed speed units.
Example: FDT V A 40 2 H ES P 2 R
1.1.2 How to read the model name
RoHS specification
: Single type
Applicable power source ... See the specifications
Heat pump type
Series No.
Product capacity
R410A models
V : Inverter specification
Model name
FDTC :
FDT :
FDEN :
FDUM :
FDKN :
FDC :
Celing recessed compact type unit
with wired remote controller
Celing recessed type unit with wired
remote controller
Celing suspended type unit with wire-
less remote controller
Satellite ducted type unit with wired
remote controller
Wall mounted type unit with wireless
remote controller
Outdoor unit
P: Twin type
T: Triple type
(blank)

-
3
-
Item
Model
FDTCA201R FDCVA402HESAR
Nominal cooling capacity(1) kW 10.0 [6.1~11.2]
Nominal heating capacity(1) kW 11.2 [5.6~12.5]
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 2.84/2.84
Running current (Cooling) A 4.2/4.4
Power factor (Cooling) % 98/98
Heating power consumption kW 3.08/3.08
Running current (Heating) A 4.5/4.8
Power factor (Heating) % 99/97
Inrush current (L.R.A) A 5
Noise level dB(A)
35 52
Exterior dimensions mm Unit 248 ×570 ×570 845 ×970 ×370
Height ×Width ×Depth Panel 35 ×700 ×700
Net weight kg 19.5 (Unit:16 Panel:3.5) 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Turbo fan ×1 Propeller fan ×1
Motor W 50 ×1 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Available –
Air filter, Q’ty Long life filter ×1(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control Wired remote control switch (Optional : RC-E1R)
Operation switch Wireless kit (Optional:RCND-KIT-HER) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data Liquid line mm Indoor branch pipe, Outdoor main pipe: φ9.52 (3/8″)
Refrigerant piping size Gas line (in) Indoor branch pipe: φ12.7 (1/2″), Outdoor main pipe: φ15.88 (5/8″)
Connecting method Flare piping
Drain hose Connectable with VP25 (I.D.25mm, O.D.32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts Decorative Panel
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
(5) Indoor unit specifications show the specifications for one unit. Capacity and running characteristics values are shown for the case where two indoor units
are combined and run together.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDTCVA402HESP2R
Powerful mode Hi:46 Me:42 Lo:38
Mild mode Hi:42 Me:38 Lo:35
Powerful mode Hi:13.5 Me:11.5 Lo:10
Mild mode Hi:11.5 Me:10 Lo:8
50
1.2 SELECTION DATA
1.2.1 Specifications
(1) Ceiling recessed compact type (FDTC)
(a) Twin type
Model FDTCVA402HESP2R (Indoor unit: 2 units, Outdoor unit: 1 unit)

-
4
-
Item
Model
FDTCA201R FDCVA602HESAR
Nominal cooling capacity(1) kW 14.0 [6.7~14.8]
Nominal heating capacity(1) kW 16.0 [6.3~16.8]
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 4.64/4.64
Running current (Cooling) A 6.8/7.1
Power factor (Cooling) % 98/99
Heating power consumption kW 4.52/4.52
Running current (Heating) A 6.6/7.0
Power factor (Heating) % 99/98
Inrush current (L.R.A) A 5
Noise level dB(A)
552
Exterior dimensions mm Unit 248 ×570 ×570 845 ×970 ×370
Height ×Width ×Depth Panel 35 ×700 ×700
Net weight kg 19.5 (Unit:16 Panel:3.5) 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Turbo fan ×1 Propeller fan ×1
Motor W 50 ×1 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Available –
Air filter, Q’ty Long life filter ×1(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control Wired remote control switch (Optional : RC-E1R)
Operation switch Wireless kit (Optional:RCND-KIT-HER) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data Liquid line mm Indoor branch pipe, Outdoor main pipe: φ9.52 (3/8″)
Refrigerant piping size Gas line (in) Indoor branch pipe: φ12.7 (1/2″), Outdoor main pipe: φ15.88 (5/8″)
Connecting method Flare piping
Drain hose Connectable with VP25 (I.D.25mm, O.D.32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts Decorative Panel
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
(5) Indoor unit specifications show the specifications for one unit. Capacity and running characteristics values are shown for the case where three indoor units
are combined and run together.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDTCVA602HEST2R
(b) Triple type
Model FDTCVA602HEST2R (Indoor unit: 3 units, Outdoor unit: 1 unit)
Powerful mode Hi:46 Me:42 Lo:38
Mild mode Hi:42 Me:38 Lo:39
Powerful mode Hi:13.5 Me:11.5 Lo:10
Mild mode Hi:11.5 Me:10 Lo:8
53

-
5
-
Item
Model
FDTA401R FDCVA402HESAR
Nominal cooling capacity(1) kW 10.0 [6.1~11.2]
Nominal heating capacity(1) kW 11.2 [5.6~12.5]
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 2.97
Running current (Cooling) A 4.7
Power factor (Cooling) % 9.1
Heating power consumption kW 2.92
Running current (Heating) A 4.6
Power factor (Heating) % 92
Inrush current (L.R.A) A 5
Noise level dB(A)
35 52
Exterior dimensions mm Unit 248 ×840 ×840 845 ×970 ×370
Height ×Width ×Depth Panel 35 ×950 ×950
Net weight kg 19.5 (Unit:16 Panel:3.5) 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Turbo fan ×1 Propeller fan ×1
Motor W 40 ×1 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Available –
Air filter, Q’ty Long life filter ×1(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control Wired remote control switch (Optional : RC-E1R)
Operation switch Wireless kit (Optional:RCN-T-35W-ER) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Liquid line: φ9.52 (3/8″) Gas line: φ15.88 (5/8″)
Refrigerant piping size (in)
Connecting method Flare piping
Drain hose Connectable with VP25 (I.D.25mm, O.D.32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts Decorative Panel
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDTVA402HES2R
Powerful mode Hi:46 Me:43 Lo:41
Mild mode Hi:43 Me:41 Lo:38
Powerful mode Hi:25 Me:22 Lo:20
Mild mode Hi:22 Me:20 Lo:18
50
(2) Ceiling recessed type (FDT)
(a) Single type
Model FDTVA402HES2R

-
6
-
Item
Model
FDTA501R FDCVA502HESAR
Nominal cooling capacity(1) kW 12.5 [6.5~14.0]
Nominal heating capacity(1) kW 14.0 [6.2~16.0]
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 4.05/4.05
Running current (Cooling) A 5.9/6.3
Power factor (Cooling) % 99/98
Heating power consumption kW 3.97/3.97
Running current (Heating) A 5.8/6.3
Power factor (Heating) % 99/96
Inrush current (L.R.A) A 5
Noise level dB(A)
552
Exterior dimensions mm Unit 365 ×840 ×840 845 ×970 ×370
Height ×Width ×Depth Panel 35 ×950 ×950
Net weight kg 38 (Unit:31 Panel:7) 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Turbo fan ×1 Propeller fan ×1
Motor W 120 ×1 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Available –
Air filter, Q’ty Long life filter ×1(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control Wired remote control switch (Optional : RC-E1R)
Operation switch Wireless kit (Optional : RCN-T-35W-ER) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Liquid line: φ9.52 (3/8″) Gas line: φ15.88 (5/8″)
Refrigerant piping size (in)
Connecting method Flare piping
Drain hose Connectable with VP25 (I.D.25mm, O.D.32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts Decorative Panel
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDTVA502HES2R
Model FDTAV502HES2R
Powerful mode Hi:48 Me:45 Lo:43
Mild mode Hi:45 Me:43 Lo:40
Powerful mode Hi:32 Me:29 Lo:26
Mild mode Hi:29 Me:26 Lo:23
52

-
7
-
Item
Model
FDTA601R FDCVA602HESAR
Nominal cooling capacity(1) kW 14.0 [6.7~14.5]
Nominal heating capacity(1) kW 16.0 [6.3~16.5]
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 4.65/4.65
Running current (Cooling) A 6.8/7.3
Power factor (Cooling) % 99/97
Heating power consumption kW 4.54/4.54
Running current (Heating) A 6.7/7.4
Power factor (Heating) % 98/93
Inrush current (L.R.A) A 5
Noise level dB(A)
Exterior dimensions mm Unit 360 ×840 ×840 845 ×970 ×370
Height ×Width ×Depth Panel 35 ×950 ×950
Net weight kg 38 (Unit:31, Panel:7) 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Turbo fan ×4 Propeller fan ×1
Motor W 120 ×1 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Available –
Air filter, Q’ty Long life filter ×1(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control
Wireless remote control switch (Optional: RCN-E1R)
Operation switch Wireless kit (Optional : RCN-T-35W-ER) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Liquid line: φ9.52 (3/8″) Gas line: φ15.88 (5/8″)
Refrigerant piping size (in)
Connecting method Flare piping
Drain hose Connectable with VP25 (I.D.25mm, O.D.32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts –
Model FDTVA602HES2R
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDTVA601HES2R
53
Powerful mode Hi:48 Me:45 Lo:43
Mild mode Hi:45 Me:43 Lo:40
Powerful mode Hi:34 Me:30 Lo:26
Mild mode Hi:30 Me:26 Lo:23

-
8
-
Item
Model
FDTA201R FDCVA402HESAR
Nominal cooling capacity(1) kW
Nominal heating capacity(1) kW
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 2.90/2.96
Running current (Cooling) A 5.1/5.5
Power factor (Cooling) % 86/75
Heating power consumption kW 2.54/2.60
Running current (Heating) A 4.6/4.8
Power factor (Heating) % 84/75
Inrush current (L.R.A) A 45
Noise level dB(A) 3
552
Exterior dimensions mm Unit 270 ×840 ×840 845 ×970 ×370
Height ×Width ×Depth Panel 35 ×950 ×950
Net weight kg 31 (Unit:24 Panel:7) 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Turbo fan ×1 Propeller fan ×1
Motor W 14 ⳯1 120 ⳯1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Available –
Air filter, Q’ty Long life filter ×1(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control Wired remote control switch (Optional : RC-E1R)
Operation switch Wireless kit (Optional : RCN-T-35W-ER) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Indoor branch pipe, Outdoor main pipe: φ9.52 (3/8″)
Refrigerant piping size (in) Indoor branch pipe: φ12.7 (1/2″), Outdoor main pipe: φ15.88 (5/8″)
Connecting method Flare piping
Drain hose Connectable with VP25 (I.D.25mm, O.D.32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts Decorative Panel
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
(5) Indoor unit specifications show the specifications for one unit. Capacity and running characteristics values are shown for the case where two indoor units
are combined and run together.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDTVA402HESP2R
(b) Twin type
Model FDTVA402HESP2R (Indoor unit: 2 units, Outdoor unit: 1 unit)
10.0 [6.1~11.2]
11.2 [5.6~12.5]
2.94/2.96
4.3/4.6
99/98
3.09/3.09
4.5/4.8
99/98
5
50
Powerful mode Hi:18 Me:15 Lo:14
Mild mode Hi:15 Me:14 Lo:13
Powerful mode Hi:36 Me:33 Lo:32
Mild mode Hi:33 Me:32 Lo:31
Liquid line
Gas line

-
9
-
Model FDTVA502HESP2R (Indoor unit: 2 units, Outdoor unit: 1 unit)
Item
Model
FDTA251R FDCVA502HESAR
Nominal cooling capacity(1) kW
Nominal heating capacity(1) kW
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 2.90/2.96
Running current (Cooling) A 5.15.5
Power factor (Cooling) % 86/
Heating power consumption kW 2.54/2.60
Running current (Heating) A 4.6/4.8
Power factor (Heating) % 84/
Inrush current (L.R.A) A
Noise level dB(A)
552
Exterior dimensions mm Unit 270 ×840 ×840 845 ×970 ×370
Height ×Width ×Depth Panel 35 ×950 ×950
Net weight kg 31 (Unit:24 Panel:7) 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Turbo fan ×1 Propeller fan ×1
Motor W 20 ×1 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Available –
Air filter, Q’ty Long life filter ×1(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control Wired remote control switch (Optional : RC-E1R)
Operation switch Wireless kit (Optional : RCN-T-35W-ER) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Indoor branch pipe, Outdoor main pipe: φ9.52 (3/8″)
Refrigerant piping size (in) Indoor branch pipe, Outdoor main pipe: φ15.88 (5/8″)
Connecting method Flare piping
Drain hose Connectable with VP25 (I.D.25mm, O.D.32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts Decorative Panel
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
(5) Indoor unit specifications show the specifications for one unit. Capacity and running characteristics values are shown for the case where two indoor units
are combined and run together.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDTVA502HESP2R
12.5 [6.5~14.0]
14.0 [6.2~16.0]
4.29/4.31
6.3/6.7
98/98
4.13/4.15
6.1/6.4
98/99
5
52
Powerful mode Hi:38 Me:35 Lo:33
Mild mode Hi:35 Me:33 Lo:31
Powerful mode Hi:20 Me:17 Lo:15
Mild mode Hi:17 Me:15 Lo:13
Liquid line
Gas line

-
10
-
Item
Model
FDTA301R FDCVA602HESAR
Nominal cooling capacity(1) kW 14.0 [7.0~14.5]
Nominal heating capacity(1) kW 16.0 [6.3~16.5]
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 4.69/4.71
Running current (Cooling) A 6.9/7.2
Power factor (Cooling) % 98/99
Heating power consumption kW 4.58/4.60
Running current (Heating) A 6.7/7.1
Power factor (Heating) % 99/98
Inrush current (L.R.A) A 5
Noise level dB(A)
35 52
Exterior dimensions mm Unit 270 ×840 ×840 845 ×970 ×370
Height ×Width ×Depth Panel 30 ×950 ×950
Net weight kg 31 (Unit:24 Panel:7) 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Turbo fan ×1 Propeller fan ×1
Motor W 20 ×1 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Available –
Air filter, Q’ty Long life filter ×1(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control Wired remote control switch (Optional : RC-E1R)
Operation switch Wireless kit (Optional : RCN-T-35W-ER) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Indoor branch pipe, Outdoor main pipe: φ9.52 (3/8″)
Refrigerant piping size (in) Indoor branch pipe, Outdoor main pipe: φ15.88 (5/8″)
Connecting method Flare piping
Drain hose Connectable with VP25 (I.D.25mm, O.D.32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts Decorative Panel
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
(5) Indoor unit specifications show the specifications for one unit. Capacity and running characteristics values are shown for the case where two indoor units
are combined and run together.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDTVA602HESP2R
Model FDTVA602HESP2R (Indoor unit: 2 units, Outdoor unit: 1 unit)
Powerful mode Hi:38 Me:35 Lo:33
Mild mode Hi:35 Me:33 Lo:31
Powerful mode Hi:20 Me:17 Lo:15
Mild mode Hi:17 Me:15 Lo:13
53
Liquid line
Gas line

-
11
-
Item
Model
FDTA201R FDCVA602HESAR
Nominal cooling capacity(1) kW
Nominal heating capacity(1) kW
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 2.90/2.96
Running current (Cooling) A 5.1/5.5
Power factor (Cooling) % 86/75
Heating power consumption kW 2.54/2.60
Running current (Heating) A 4.6/4.8
Power factor (Heating) % 84/75
Inrush current (L.R.A) A 45
Noise level dB(A) 3
552
Exterior dimensions mm Unit 270 ×840 ×840 845 ×970 ×370
Height ×Width ×Depth Panel 35 ×950 ×950
Net weight kg 31 (Unit:24 Panel:7) 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Turbo fan ×1 Propeller fan ×1
Motor W 14 ⳯1 120 ⳯1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Available –
Air filter, Q’ty Long life filter ×1(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control Wired remote control switch (Optional : RC-E1R)
Operation switch Wireless kit (Optional : RCN-T-35W-ER) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Indoor branch pipe, Outdoor main pipe: φ9.52 (3/8″)
Refrigerant piping size (in) Indoor branch pipe: φ12.7 (1/2″), Outdoor main pipe: φ15.88 (5/8″)
Connecting method Flare piping
Drain hose Connectable with VP25 (I.D.25mm, O.D.32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts Decorative Panel
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
(5) Indoor unit specifications show the specifications for one unit. Capacity and running characteristics values are shown for the case where three indoor units
are combined and run together.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDTVA602HEST2R
(c) Triple type
Model FDTVA602HEST2R (Indoor unit: 3 units, Outdoor unit: 1 unit)
14.0 [7.0~14.5]
16.0 [6.3~16.5]
4.74/4.77
6.9/7.4
99/98
4.63/4.63
6.8/7.1
98/99
5
53
Powerful mode Hi:18 Me:15 Lo:14
Mild mode Hi:15 Me:14 Lo:13
Powerful mode Hi:36 Me:33 Lo:32
Mild mode Hi:33 Me:32 Lo:31
Liquid line
Gas line

-
12
-
Item
Model
FDENA401R FDCVA402HESAR
Nominal cooling capacity(1) kW 10.0 [6.1~11.2]
Nominal heating capacity(1) kW 11.2 [5.9~12.5]
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 2.85/2.85
Running current (Cooling) A 4.2/4.4
Power factor (Cooling) % 98/98
Heating power consumption kW 2.97/2.97
Running current (Heating) A 4.3/4.6
Power factor (Heating) % 99/98
Inrush current (L.R.A) A 5
Noise level dB(A)
Exterior dimensions mm 250 ×1620 ×690 845 ×970 ×370
Height ×Width ×Depth
Net weight kg 46 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Centrifugal fan ×4 Propeller fan ×1
Motor W 40 ×2 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Unavailable –
Air filter, Q’ty Polypropylene net ×2(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control
Wireless remote control switch (Optional: RCN-E1R)
Operation switch Wired remote control switch (Optional: RC-E1R) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Liquid line: φ9.52 (3/8″) Gas line: φ15.88 (5/8″)
Refrigerant piping size (in)
Connecting method Flare piping
Drain hose Connectable with VP20 (I.D.20mm, O.D.26mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts –
(3) Ceiling suspended type (FDEN)
(a) Single type
Model FDENVA402HES2R
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDENVA402HES2R
50
Powerful mode Hi:46 Me:44 Lo:41
Mild mode Hi:44 Me:41 Lo:39
Powerful mode Hi:29 Me:26 Lo:23
Mild mode Hi:26 Me:23 Lo:21

-
13
-
Item
Model
FDENA501R FDCVA502HESAR
Nominal cooling capacity(1) kW 12.5 [6.5~14.0]
Nominal heating capacity(1) kW 14.0 [6.2~16.0]
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 4.35/4.35
Running current (Cooling) A 6.4/6.7
Power factor (Cooling) % 98/99
Heating power consumption kW 3.95/3.95
Running current (Heating) A 5.8/6.1
Power factor (Heating) % 98/98
Inrush current (L.R.A) A 5
Noise level dB(A)
Exterior dimensions mm 250 ×1620 ×690 845 ×970 ×370
Height ×Width ×Depth
Net weight kg 46 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Centrifugal fan ×4 Propeller fan ×1
Motor W 45 ×2 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Unavailable –
Air filter, Q’ty Polypropylene net ×2(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control
Wireless remote control switch (Optional: RCN-E1R)
Operation switch Wired remote control switch (Optional: RC-E1R) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Liquid line: φ9.52 (3/8″) Gas line: φ15.88 (5/8″)
Refrigerant piping size (in)
Connecting method Flare piping
Drain hose Connectable with VP20 (I.D.20mm, O.D.26mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts –
Model FDENVA502HES2R
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDENVA502HES2R
52
Powerful mode Hi:48 Me:46 Lo:44
Mild mode Hi:46 Me:44 Lo:43
Powerful mode Hi:31 Me:29 Lo:26
Mild mode Hi:29 Me:26 Lo:23

-
14
-
Item
Model
FDENA601R FDCVA602HESRR
Nominal cooling capacity(1) kW 14.0 [6.7~14.5]
Nominal heating capacity(1) kW 16.0 [6.3~16.5]
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 4.95/4.95
Running current (Cooling) A 7.2/7.6
Power factor (Cooling) % 99/99
Heating power consumption kW 4.69/4.69
Running current (Heating) A 6.8/7.2
Power factor (Heating) % 99/99
Inrush current (L.R.A) A 5
Noise level dB(A)
Exterior dimensions mm 250 ×1620 ×690 845 ×970 ×370
Height ×Width ×Depth
Net weight kg 46 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Centrifugal fan ×4 Propeller fan ×1
Motor W 45 ×2 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Unavailable –
Air filter, Q’ty Polypropylene net ×2(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control
Wireless remote control switch (Optional: RCN-E1R)
Operation switch Wired remote control switch (Optional: RC-E1R) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Liquid line: φ9.52 (3/8″) Gas line: φ15.88 (5/8″)
Refrigerant piping size (in)
Connecting method Flare piping
Drain hose Connectable with VP20 (I.D.20mm, O.D.26mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts –
Model FDENVA602HES2R
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDENVA602HES2R
53
Powerful mode Hi:48 Me:46 Lo:44
Mild mode Hi:46 Me:44 Lo:43
Powerful mode Hi:31 Me:29 Lo:26
Mild mode Hi:29 Me:26 Lo:23

-
15
-
Item
Model
FDENA201R FDCVA402HESAR
Nominal cooling capacity(1) kW
Nominal heating capacity(1) kW
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW
Running current (Cooling) A
Power factor (Cooling) %
Heating power consumption kW
Running current (Heating) A
Power factor (Heating) %
Inrush current (L.R.A) A
Noise level dB(A)
Exterior dimensions mm 210 ×1070 ×690 845 ×970 ×370
Height ×Width ×Depth
Net weight kg 30 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Centrifugal fan ×2 Propeller fan ×1
Motor W 30 ×1 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Unavailable –
Air filter, Q’ty Polypropylene net ×2(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control
Wireless remote control switch (Optional: RCN-E1R)
Operation switch Wired remote control switch (Optional: RC-E1R) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Indoor branch pipe, Outdoor main pipe: φ9.52 (3/8″)
Refrigerant piping size (in) Indoor branch pipe: φ12.7 (1/2″), Outdoor main pipe: φ15.88 (5/8″)
Connecting method Flare piping
Drain hose Connectable with VP20 (I.D.20mm, O.D.26mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts –
(b) Twin type
Model FDENVA402HESP2R (Indoor unit: 2 units, Outdoor unit: 1 unit)
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
(5) Indoor unit specifications show the specifications for one unit. Capacity and running characteristics values are shown for the case where two indoor units
are combined and run together.
(6) If wireless specifications are used, use 1 wireless indoor unit in combination with wired indoor units.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDENVA402HESP2R
50
10.0 [6.1~11.2]
11.2 [5.9~12.5]
2.78/2.78
4.1/4.3
98/98
2.94/2.94
4.3/4.5
99/99
5
Powerful mode Hi:42 Me:39 Lo:38
Mild mode Hi:39 Me:38 Lo:37
Powerful mode Hi:12 Me:11 Lo:9
Mild mode Hi:11 Me:9 Lo:7
Liquid line
Gas line

-
16
-
Item
Model
FDENA251R FDCVA502HESAR
Nominal cooling capacity(1) kW
Nominal heating capacity(1) kW
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW
Running current (Cooling) A
Power factor (Cooling) %
Heating power consumption kW
Running current (Heating) A
Power factor (Heating) %
Inrush current (L.R.A) A
Noise level dB(A)
Exterior dimensions mm 210 ×1320 ×690 845 ×970 ×370
Height ×Width ×Depth
Net weight kg 36 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Centrifugal fan ×4 Propeller fan ×1
Motor W 20 ×2 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Unavailable –
Air filter, Q’ty Polypropylene net ×2(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control
Wireless remote control switch (Optional: RCN-E1R)
Operation switch Wired remote control switch (Optional: RC-E1R) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Indoor branch pipe, Outdoor main pipe: φ9.52 (3/8″)
Refrigerant piping size (in) Indoor branch pipe, Outdoor main pipe: φ15.88 (5/8″)
Connecting method Flare piping
Drain hose Connectable with VP20 (I.D.20mm, O.D.26mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts –
Model FDENVA502HESP2R (Indoor unit: 2 units, Outdoor unit: 1 unit)
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
(5) Indoor unit specifications show the specifications for one unit. Capacity and running characteristics values are shown for the case where two indoor units
are combined and run together.
(6) If wireless specifications are used, use 1 wireless indoor unit in combination with wired indoor units.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDENVA502HESP2R
52
12.5 [6.5~14.0]
14.0 [6.2~16.0]
4.23/4.23
6.2/6.5
98/99
3.83/3.83
5.6/9.9
99/99
5
Powerful mode Hi:44 Me:41 Lo:39
Mild mode Hi:41 Me:39 Lo:38
Powerful mode Hi:20 Me:18 Lo:14
Mild mode Hi:18 Me:14 Lo:12
Liquid line
Gas line

-
17
-
Item
Model
FDENA301R FDCVA602HESAR
Nominal cooling capacity(1) kW 14.0 [6.7~14.5]
Nominal heating capacity(1) kW 16.0 [6.3~16.5]
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 4.84/4.84
Running current (Cooling) A 7.1/7.4
Power factor (Cooling) % 98/99
Heating power consumption kW 4.59/4.59
Running current (Heating) A 6.7/7.1
Power factor (Heating) % 99/98
Inrush current (L.R.A) A 5
Noise level dB(A)
Exterior dimensions mm 210 ×1320 ×690 845 ×970 ×370
Height ×Width ×Depth
Net weight kg 36 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Centrifugal fan ×4 Propeller fan ×1
Motor W 20 ×2 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Unavailable –
Air filter, Q’ty Polypropylene net ×2(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control
Wireless remote control switch (Optional: RCN-E1R)
Operation switch Wired remote control switch (Optional: RC-E1R) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Indoor branch pipe, Outdoor main pipe: φ9.52 (3/8″)
Refrigerant piping size (in) Indoor branch pipe, Outdoor main pipe: φ15.88 (5/8″)
Connecting method Flare piping
Drain hose Connectable with VP20 (I.D.20mm, O.D.26mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts –
Model FDENVA602HESP2R (Indoor unit: 2 units, Outdoor unit: 1 unit)
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
(5) Indoor unit specifications show the specifications for one unit. Capacity and running characteristics values are shown for the case where two indoor units
are combined and run together.
(6) If wireless specifications are used, use 1 wireless indoor unit in combination with wired indoor units.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDENVA602HESP2R-P1RSB
53
Powerful mode Hi:44 Me:41 Lo:39
Mild mode Hi:41 Me:39 Lo:38
Powerful mode Hi:20 Me:18 Lo:14
Mild mode Hi:18 Me:14 Lo:12
Liquid line
Gas line

-
18
-
Item
Model
FDENA201R FDCVA602HESAR
Nominal cooling capacity(1) kW
Nominal heating capacity(1) kW
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW
Running current (Cooling) A
Power factor (Cooling) %
Heating power consumption kW
Running current (Heating) A
Power factor (Heating) %
Inrush current (L.R.A) A
Noise level dB(A)
Exterior dimensions mm 210 ×1070 ×690 845 ×970 ×370
Height ×Width ×Depth
Net weight kg 30 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Centrifugal fan ×2 Propeller fan ×1
Motor W 30 ×1 120 ×1
Starting method Direct line start Direct line start
Air flow CMM Cooling: 75, Heating: 73
Outside air intake Unavailable –
Air filter, Q’ty Polypropylene net ×2(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control
Wireless remote control switch (Optional: RCN-E1R)
Operation switch Wired remote control switch (Optional: RC-E1R) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Indoor branch pipe, Outdoor main pipe: φ9.52 (3/8″)
Refrigerant piping size (in) Indoor branch pipe: φ12.7 (1/2″), Outdoor main pipe: φ15.88 (5/8″)
Connecting method Flare piping
Drain hose Connectable with VP20 (I.D.20mm, O.D.26mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts –
(c) Triple type
Model FDENVA602HEST2R (Indoor unit: 3 units, Outdoor unit: 1 unit)
Operation data
(3)
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard. ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
(5) Indoor unit specifications show the specifications for one unit. Capacity and running characteristics values are shown for the case where three indoor units
are combined and run together.
(6) If wireless specifications are used, use 1 wireless indoor unit in combination with wired indoor units.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
FDENVA602HEST2R
53
14.0 [6.7~14.5]
16.0 [6.3~16.5]
4.85/4.85
7.1/7.5
99/98
4.58/4.58
6.7/7.0
99/99
5
Powerful mode Hi:42 Me:39 Lo:38
Mild mode Hi:39 Me:38 Lo:37
Powerful mode Hi:12 Me:11 Lo:9
Mild mode Hi:11 Me:9 Lo:7
Liquid line
Gas line

-
19
-
(4) Satellite ducted type (FDUM)
(a) Single type
Item
Model
FDUMA402R FDCVA402HESAR
Nominal cooling capacity(1) kW 10.0 [6.1~11.2]
Nominal heating capacity(1) kW 11.2 [6.0~12.5]
Power source 3 Phase, 380-415V 50Hz/380V 60Hz
Cooling power consumption kW 2.80/2.80
Running current (Cooling) A 4.2/4.4
Power factor (Cooling) % 96/97
Heating power consumption kW 2.77/2.80
Running current (Heating) A 4.1/4.3
Power factor (Heating) % 98/99
Inrush current (L.R.A) A 5
Noise level dB(A) Hi:37 Me:35 Lo:32
Exterior dimensions mm 350 ×1370 ×635 845 ×970 ×370
Height ×Width ×Depth
Net weight kg 59 74
Refrigerant equipment –RM-B5125MDE31
Compressor type & Q’ty
Starting method – Direct line start
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control – Electronic expansion valve
Refrigerant R410A
Quantity kg – 3.8 [Pre-charged up to the piping length of 30m]
Refrigerant oil r–0.7 (M-MA68)
Defrost control Microcomputer controlled de-icer
Air handling equipment
Fan type & Q’ty Centrifugal fan ×3 Propeller fan ×1
Motor W 45 ×1, 90 ×1 120 ×1
Starting method Direct line start Direct line start
Air flow (Standard) CMM Hi: 28 Me: 25 Lo: 22 Cooling type: 75, Heating type: 73
Available static pressure Pa Standard: 60, Max 90 –
Outside air intake – –
Air filter, Q’ty – –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 20 (Crank case heater)
Operation control Wired remote control switch (Optional: RC-E1R)
Operation switch Wireless kit (Optional: RCND-KIT-HER) – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor. Internal
thermostat for fan motor. Frost protection thermostat. Anomalous discharge temperature protection.
Installation data mm Liquid line: φ9.52 (3/8″) Gas line: φ15.88 (5/8″)
Refrigerant piping size (in)
Connecting method Flare piping
Drain hose Connectable with VP25 (I.D.25mm, O.D.32mm) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Drain hose
Optional parts Filter kit (UM-FL3E)
Operation data
(3)
Model FDUMVA402HES2R
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard.
ISO-T1 “UNITARY AIR-CONDITIONERS”
(3) The operation data indicate when the air-conditioner is operated at 400V 50Hz or 380V 60Hz.
(4) Values in [ ~ ] show the minimum to maximum range.
Notes (1) The data are measured at the following conditions.
FDUMVA402HES2R
50
