SERVICE MANUAL
MITSUBISHI ELECTRIC CORP. SANDA WORKS
Your company internal use only.
CV-0MW7G21-7
Copyright (C) Mitsubishi Electric Corporation.
SE027709123E Ver.ppt11E
MITSUBISHI MOTORS
POWER AMPLIFIER
◆CONTENTS
● FEATURES and SPECIFICATIONS ......................................... 2
● CONNECTORS .............................................................................. 3
● SYSTEM CONFIGURATION ..................................................... 4
● BLOCK DIAGRAM ......................................................................... 5
● DISASSEMBLING PROCEDURES ............................................6
● PARTS LIST .................................................................................... 7
● ELECTRICAL PARTS LIST ........................................... 8 ～ 12
2009 Dec.
Model : CV-0MW7G21-7
MELCO Code : 34R036
PART No. : 8701A309

2Your company internal use only.
Copyright (C) Mitsubishi Electric Corporation.
CV-0MW7G21-7
◆FEATURES and SPECIFICATIONS
FEATURES
< Power amplifier Part >
●High power 650W output power amplifier.
Woofer mono 150W x 2ch (1Ω) ....... Double voice coil Woofer drive
Front-Lo stereo 75W x 2ch (2Ω) ....... Front-Door Speaker drive
Front-M/H stereo 50W x 2ch (4Ω) ....... Front-Door Mirror Speaker drive
Rear stereo 50W x 2ch (2Ω) ....... Rear-Door Speaker drive
●Differential signal input circuit. (input Front 2ch of H/U)
●DSP circuit.
Auto-Loudness, Bass/Treble/Middle, Volume/Fader/Balance
Surround
Fix-EQ
Test tone
Input/Output limiter
Beep sound
Guide voice control
< Others >
●Diagnostic facility. (DC offset detector, High temperature detector, Out of
supply voltage short, Out of GND short)
SPECIFICATIONS
●Distortion : 0.5% max at 0.5W
●S/N : 55dB min at 0.5W
●Channel Separation : 50dB min at 0.5W
●Residual Output : 0.5mVrms max at Vol. min.
●Offset Voltage : 100mV max
●Backup Current : 1mA max
●Dimensions (W x D x H) : 264mm x 220mm x 60mm
●Weight : 2.0kg

3Your company internal use only.
Copyright (C) Mitsubishi Electric Corporation.
CV-0MW7G21-7
◆CONNECTORS
Power supply ,Speaker and
H/U Communication18P
Connector
PinNo. Signal Name PinNo. Signal Name
1 FL Lo (+) 10 FR Lo (-)
2 FR Lo (+) 11 BATTERY (+)
3 - 12 BATTERY (+)
4 BATTERY (+) 13 DATA
5 GND 14 DATA S-GND
6 - 15GND
7 Woofer 1 (+) 16 GND
8 Woofer 2 (+) 17 Woofer 1 (-)
9 FL Lo (-) 18 Woofer 2 (-)
Power supply ,Speaker and H/U Communication18P Connector Speaker and Voice Input 14P Connector
Speaker and Voice Input
14P Connector PinNo. Signal Name PinNo. Signal Name
1 FL M/H (+) 8 FR M/H (-)
2 FR M/H (+) 9 FL IN (-)
3 FL IN (+) 10 FR IN (-)
4 P-ON 11 FR IN (+)
5 RR (+) 12 FRONT-IN S-GND
6 RL (+) 13 RR (-)
7 FL M/H (-) 14 RL (-)

4Your company internal use only.
Copyright (C) Mitsubishi Electric Corporation.
CV-0MW7G21-7
◆SYSTEM CONFIGURATION

5Your company internal use only.
Copyright (C) Mitsubishi Electric Corporation.
CV-0MW7G21-7
◆BLOCK DIAGRAM

6Your company internal use only.
Copyright (C) Mitsubishi Electric Corporation.
CV-0MW7G21-7
●Disassembling procedures
In reverse of assembling procedures.
●Assembling procedures
1. S5-PCB-AMP is installed in M005.
2. M004 is installed in the set united according to
the procedure of 1.
The screw tightening does from Ⓒ,
and tightens Ⓑ afterwards.
3. M001 and M002 are installed in the set united
according to the procedure of 2.
4. M003 is installed.
◆DISASSEMBLING PROCEDURES
This part is not cut.
Ⓒx 5
Ⓑx 3
Ⓑ
M004 : HEAT-SINK-SUB
M005 : ASSY-CHASSIS
Ⓑx 9
Ⓐ
Ⓐx 2
M002 : CHASSIS-F
M001 : CHASSIS-R
Ⓐx 2
M003 : HEAT-SINK-MAIN
Ⓓx 6 Ⓑ
*At the installation of M002,
Insert it after confirming there is
surely the hook.
(Be careful not to transform.)
S5-PCB-AMP
0.8 +0.2/-0.13X6Ⓓ
0.8 +0.2/-0.13X10Ⓑ
0.8 +0.2/-0.13X6Ⓐ
Ⓒ
No.
0.8 +0.2/-0.13X16
Tighten torque(N・ｍ）Screw

7Your company internal use only.
Copyright (C) Mitsubishi Electric Corporation.
CV-0MW7G21-7
◆PARTS LIST
-SCREW-TAPPING 3X6669L077O2D
-SCREW-S-PAN 3X16653P11052C
-SCREW-S-PAN 3X10653P11048B
-SCREW-S-PAN 3X6653P11046A
P.6ASSY-CHASSIS891J06810M005
P.6HEAT-SINK-SUB635K06610M004
P.6HEAT-SINK-MAIN635J08910M003
P.6CHASSIS-F560J33311M002
P.6CHASSIS-R560J32611M001
PageParts NameParts No.Ref No.

Ref. No. Parts No. Parts Name Note Spec. Base Parts No. Ref. No. Parts No. Parts Name Note Spec. Base Parts No.
C005 141L185O1 C-CERAMIC-CHIP GRM1882C1H471JA01D CH 50V 471J1608 N930L72217 C504 181P376O2 C-ELECTROLYTIC-TAPE USR1H2R2MDD1TP 50V 2R2M N930L72217
C006 141L185O1 C-CERAMIC-CHIP GRM1882C1H471JA01D CH 50V 471J1608 N930L72217 C505 141L185O9 C-CERAMIC-CHIP GRM1882C1E102JA01D CH 25V 102J1608 N930L72217
C007 141L184O3 C-CERAMIC-CHIP GRM1882C1H221JA01D CH 50V 221J1608 N930L72217 C511 181P74826 C-ELECTROLYTIC R3A-16V470MFOP2#-T36 16V470M 6.3X5 N930L72217
C008 141L183O5 C-CERAMIC-CHIP MCH185A101JK CH 50V 101J1608 N930L72217 C512 141L162O1 C-CERAMIC-CHIP GRM188B11H103KA01D B 50V 103K 1608 N930L72217
C009 141L184O3 C-CERAMIC-CHIP GRM1882C1H221JA01D CH 50V 221J1608 N930L72217 C513 172P232O9 C-POLYESTER-TAPE ECQB1H103KF4 50V 103K N930L72217
C010 141L183O5 C-CERAMIC-CHIP MCH185A101JK CH 50V 101J1608 N930L72217 C514 172P232O9 C-POLYESTER-TAPE ECQB1H103KF4 50V 103K N930L72217
C011 141L184O3 C-CERAMIC-CHIP GRM1882C1H221JA01D CH 50V 221J1608 N930L72217 C515 181P74826 C-ELECTROLYTIC R3A-16V470MFOP2#-T36 16V470M 6.3X5 N930L72217
C012 141L184O3 C-CERAMIC-CHIP GRM1882C1H221JA01D CH 50V 221J1608 N930L72217 C521 141L161O3 C-CERAMIC-CHIP GRM188B11H222KA01D B 50V 222K 1608 N930L72217
C013 141L184O3 C-CERAMIC-CHIP GRM1882C1H221JA01D CH 50V 221J1608 N930L72217 C522 141L161O3 C-CERAMIC-CHIP GRM188B11H222KA01D B 50V 222K 1608 N930L72217
C014 141L184O3 C-CERAMIC-CHIP GRM1882C1H221JA01D CH 50V 221J1608 N930L72217 C523 141L161O3 C-CERAMIC-CHIP GRM188B11H222KA01D B 50V 222K 1608 N930L72217
C015 141L183O5 C-CERAMIC-CHIP MCH185A101JK CH 50V 101J1608 N930L72217 C524 141L161O3 C-CERAMIC-CHIP GRM188B11H222KA01D B 50V 222K 1608 N930L72217
C301 141L162O1 C-CERAMIC-CHIP GRM188B11H103KA01D B 50V 103K 1608 N930L72217 C525 141L161O5 C-CERAMIC-CHIP GRM188B11H332KA01D B 50V 332K 1608 N930L72217
C302 141L162O1 C-CERAMIC-CHIP GRM188B11H103KA01D B 50V 103K 1608 N930L72217 C526 141L161O5 C-CERAMIC-CHIP GRM188B11H332KA01D B 50V 332K 1608 N930L72217
C303 141L162O1 C-CERAMIC-CHIP GRM188B11H103KA01D B 50V 103K 1608 N930L72217 C527 141L161O5 C-CERAMIC-CHIP GRM188B11H332KA01D B 50V 332K 1608 N930L72217
C306 141L162O1 C-CERAMIC-CHIP GRM188B11H103KA01D B 50V 103K 1608 N930L72217 C528 141L161O5 C-CERAMIC-CHIP GRM188B11H332KA01D B 50V 332K 1608 N930L72217
C307 181P372O3 C-ELECTROLYTIC-TAPE USR1C100MDD1TP 16V 100M N930L72217 C529 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217
C308 141L162O1 C-CERAMIC-CHIP GRM188B11H103KA01D B 50V 103K 1608 N930L72217 C530 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217
C309 181P372O3 C-ELECTROLYTIC-TAPE USR1C100MDD1TP 16V 100M N930L72217 C531 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217
C310 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 C532 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217
C311 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 C533 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217
C312 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 C534 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217
C313 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 C535 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217
C314 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 C536 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217
C315 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 C537 172P232O9 C-POLYESTER-TAPE ECQB1H103KF4 50V 103K N930L72217
C316 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 C538 172P232O9 C-POLYESTER-TAPE ECQB1H103KF4 50V 103K N930L72217
C317 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 C561 172P171O4 C-STACKED-METAL-CHIP ECHU1C223JB5 16V 223J 3216 N930L72217
C331 141L185O9 C-CERAMIC-CHIP GRM1882C1E102JA01D CH 25V 102J1608 N930L72217 C562 172P171O4 C-STACKED-METAL-CHIP ECHU1C223JB5 16V 223J 3216 N930L72217
C332 141L161O9 C-CERAMIC-CHIP GRM188B11H682KA01D B50V682K1608 N930L72217 C563 181P74849 C-ELECTROLYTIC R3A-35V4R7MDOP2#-T36 35V4R7M 4X5 N930L72217
C333 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C564 181P74849 C-ELECTROLYTIC R3A-35V4R7MDOP2#-T36 35V4R7M 4X5 N930L72217
C334 181P372O3 C-ELECTROLYTIC-TAPE USR1C100MDD1TP 16V 100M N930L72217 C566 181P376O1 C-ELECTROLYTIC-TAPE USR1H010MDD1TP 50V 010M N930L72217
C335 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C567 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217
C336 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C568 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217
C337 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C569 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217
C338 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C570 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217
C339 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C571 181P74826 C-ELECTROLYTIC R3A-16V470MFOP2#-T36 16V470M 6.3X5 N930L72217
C340 141L164O8 C-CERAMIC-CHIP GRM188B11A224KA01D B 10V 224K 1608 N930L72217 C572 141L185O9 C-CERAMIC-CHIP GRM1882C1E102JA01D CH 25V 102J1608 N930L72217
C341 141L164O8 C-CERAMIC-CHIP GRM188B11A224KA01D B 10V 224K 1608 N930L72217 C573 141L185O9 C-CERAMIC-CHIP GRM1882C1E102JA01D CH 25V 102J1608 N930L72217
C351 141L185O9 C-CERAMIC-CHIP GRM1882C1E102JA01D CH 25V 102J1608 N930L72217 C574 141L185O9 C-CERAMIC-CHIP GRM1882C1E102JA01D CH 25V 102J1608 N930L72217
C352 141L161O9 C-CERAMIC-CHIP GRM188B11H682KA01D B50V682K1608 N930L72217 C575 141L185O9 C-CERAMIC-CHIP GRM1882C1E102JA01D CH 25V 102J1608 N930L72217
C353 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C576 172P211O0 C-STACKED-METAL-TAPE ECQV1H474B46 50V 474J N930L72217
C354 181P372O3 C-ELECTROLYTIC-TAPE USR1C100MDD1TP 16V 100M N930L72217 C577 172P233O0 C-POLYESTER-TAPE ECQB1H153KF4 50V 153K N930L72217
C355 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C578 181P75090 C-ELECTROLYTIC RW2-16V332MI6P2#-T4 16V332M 12.5X25 N930L72117
C356 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C579 181P376O1 C-ELECTROLYTIC-TAPE USR1H010MDD1TP 50V 010M N930L72217
C357 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C582 141L161O5 C-CERAMIC-CHIP GRM188B11H332KA01D B 50V 332K 1608 N930L72217
C358 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C583 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217
C359 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C584 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217
C360 141L164O8 C-CERAMIC-CHIP GRM188B11A224KA01D B 10V 224K 1608 N930L72217 C585 141L181O9 C-CERAMIC-CHIP GRM1882C1H220JZ01D CH50V220J 1608 N930L72217
C361 141L164O8 C-CERAMIC-CHIP GRM188B11A224KA01D B 10V 224K 1608 N930L72217 C586 172P232O9 C-POLYESTER-TAPE ECQB1H103KF4 50V 103K N930L72217
C371 181P372O3 C-ELECTROLYTIC-TAPE USR1C100MDD1TP 16V 100M N930L72217 C601 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217
C372 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C602 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217
C373 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C603 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217
C374 181P74823 C-ELECTROLYTIC R3A-16V100MDOP2#-T36 16V100M 4X5 N930L72217 C604 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217
C375 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C605 172P233O0 C-POLYESTER-TAPE ECQB1H153KF4 50V 153K N930L72217
C376 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C606 181P372O6 C-ELECTROLYTIC-TAPE USR1C470MDD1TP 16V 470M N930L72217
C3A1 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217 C609 172P233O0 C-POLYESTER-TAPE ECQB1H153KF4 50V 153K N930L72217
C3A2 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217 C610 181P75090 C-ELECTROLYTIC RW2-16V332MI6P2#-T4 16V332M 12.5X25 N930L72117
C3A3 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217 C623 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217
C3A4 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217 C624 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217
C3C1 141L162O1 C-CERAMIC-CHIP GRM188B11H103KA01D B 50V 103K 1608 N930L72217 C625 172P233O0 C-POLYESTER-TAPE ECQB1H153KF4 50V 153K N930L72217
C3G1 141L181O9 C-CERAMIC-CHIP GRM1882C1H220JZ01D CH50V220J 1608 N930L72217 C626 181P372O6 C-ELECTROLYTIC-TAPE USR1C470MDD1TP 16V 470M N930L72217
C3G2 141L181O9 C-CERAMIC-CHIP GRM1882C1H220JZ01D CH50V220J 1608 N930L72217 C629 172P233O0 C-POLYESTER-TAPE ECQB1H153KF4 50V 153K N930L72217
C501 181P372O5 C-ELECTROLYTIC-TAPE USR1C330MDD1TP 16V 330M N930L72217 C630 181P75090 C-ELECTROLYTIC RW2-16V332MI6P2#-T4 16V332M 12.5X25 N930L72117
C502 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 C641 141L161O3 C-CERAMIC-CHIP GRM188B11H222KA01D B 50V 222K 1608 N930L72217
C503 181P372O4 C-ELECTROLYTIC-TAPE USR1C220MDD1TP 16V 220M N930L72217 C642 141L161O3 C-CERAMIC-CHIP GRM188B11H222KA01D B 50V 222K 1608 N930L72217
8
◆ELECTRICAL PARTS LIST

Ref. No. Parts No. Parts Name Note Spec. Base Parts No. Ref. No. Parts No. Parts Name Note Spec. Base Parts No.
C643 141L161O5 C-CERAMIC-CHIP GRM188B11H332KA01D B 50V 332K 1608 N930L72217 D502 264L060O1 DIODE-CHIP 1SS355 FNTE-17 N930L72217
C644 141L161O5 C-CERAMIC-CHIP GRM188B11H332KA01D B 50V 332K 1608 N930L72217 D503 264L060O1 DIODE-CHIP 1SS355 FNTE-17 N930L72217
C645 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217 D504 264P582O7 DIODE-ZENER-CHIP MA8043-H-TX N930L72217
C646 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217 D881 264L067O4 DIODE-ZENER-CHIP MA8056-M(TX) 5.6V N930L72217
C647 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217 D901 264P607O2 DIODE-CHIP 1SR154-400TE25 N930L72217
C648 141L184O7 C-CERAMIC-CHIP GRM1882C1H331JA01D CH 50V 331J1608 N930L72217 D902 264L067O4 DIODE-ZENER-CHIP MA8056-M(TX) 5.6V N930L72217
C649 141L181O9 C-CERAMIC-CHIP GRM1882C1H220JZ01D CH50V220J 1608 N930L72217 D951 264P607O2 DIODE-CHIP 1SR154-400TE25 N930L72217
C650 141L181O9 C-CERAMIC-CHIP GRM1882C1H220JZ01D CH50V220J 1608 N930L72217 D952 264P585O0 DIODE-ZENER-CHIP MA8091-M-TX N930L72217
C651 172P232O9 C-POLYESTER-TAPE ECQB1H103KF4 50V 103K N930L72217 D953 264L067O4 DIODE-ZENER-CHIP MA8056-M(TX) 5.6V N930L72217
C652 172P232O9 C-POLYESTER-TAPE ECQB1H103KF4 50V 103K N930L72217 H-IC-1 591K55210 HOLDER-IC ｸﾛﾑﾌﾘｰ ECOTRIO T0.8 N930L72117
C681 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 H-TR-1 593L34010 HOLDER-TR ｴｺﾄﾘｵ T0.8 N930L72117
C682 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 H-TR-2 593L34010 HOLDER-TR ｴｺﾄﾘｵ T0.8 N930L72117
C683 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 IC301 266L065O5 IC-TAPE NJM2115V-TE1 ｵﾍﾟｱﾝﾌﾟ N930L72217
C684 181P374O9 C-ELECTROLYTIC-TAPE USR1V4R7MDD1TP 35V 4R7M N930L72217 IC302 266L065O5 IC-TAPE NJM2115V-TE1 ｵﾍﾟｱﾝﾌﾟ N930L72217
C685 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217 IC303 266L065O5 IC-TAPE NJM2115V-TE1 ｵﾍﾟｱﾝﾌﾟ N930L72217
C686 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217 IC331 262P52111 IC-TRAY AK7730AVT DSP N930L72217
C687 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217 IC351 262P52111 IC-TRAY AK7730AVT DSP N930L72217
C688 172P210O8 C-STACKED-METAL-TAPE ECQV1H224B46 50V 224J N930L72217 IC371 262P52710 IC AK4358 N930L72217
C691 181P372O6 C-ELECTROLYTIC-TAPE USR1C470MDD1TP 16V 470M N930L72217 IC511 266L065O6 IC-TAPE NJM4580V ｵﾍﾟｱﾝﾌﾟ N930L72217
C696 172P233O0 C-POLYESTER-TAPE ECQB1H153KF4 50V 153K N930L72217 IC521 266L065O6 IC-TAPE NJM4580V ｵﾍﾟｱﾝﾌﾟ N930L72217
C697 181P75090 C-ELECTROLYTIC RW2-16V332MI6P2#-T4 16V332M 12.5X25 N930L72117 IC522 266L065O6 IC-TAPE NJM4580V ｵﾍﾟｱﾝﾌﾟ N930L72217
C801 181P372O3 C-ELECTROLYTIC-TAPE USR1C100MDD1TP 16V 100M N930L72217 IC561 266P62811 IC-MAG TDA7560 Dﾊﾞｰｼﾞｮﾝ 4CH*45W MOSFET N930L72117
C802 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 IC581 266L065O6 IC-TAPE NJM4580V ｵﾍﾟｱﾝﾌﾟ N930L72217
C803 181P372O3 C-ELECTROLYTIC-TAPE USR1C100MDD1TP 16V 100M N930L72217 IC601 266P65211 IC-MAG TDA7575B 1CH*150W-1OHM N930L72117
C804 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 IC621 266P65211 IC-MAG TDA7575B 1CH*150W-1OHM N930L72117
C805 181P372O3 C-ELECTROLYTIC-TAPE USR1C100MDD1TP 16V 100M N930L72217 IC651 266L065O6 IC-TAPE NJM4580V ｵﾍﾟｱﾝﾌﾟ N930L72217
C806 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 IC652 266L065O6 IC-TAPE NJM4580V ｵﾍﾟｱﾝﾌﾟ N930L72217
C807 141L182O1 C-CERAMIC-CHIP GRM1882C1H270JZ01D CH 50V 270J1608 N930L72217 IC681 266P65211 IC-MAG TDA7575B 1CH*150W-1OHM N930L72117
C808 141L182O1 C-CERAMIC-CHIP GRM1882C1H270JZ01D CH 50V 270J1608 N930L72217 IC801 262P53782 IC M30620MCP-539GP U-COM(MASK) N930L72217
C809 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 IC851 263P02510 IC-TAPE MM1185BFFE SYSTEM RESET N930L72217
C851 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 IC901 266P61410 IC-TAPE LF33ABPT 3.3V REG N930L72217
C853 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 IC903 263P23533 IC-TAPE S-812C33AUA-C2NT2G REGULATOR 3.3V N930L72217
C854 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 IC951 266P61410 IC-TAPE LF33ABPT 3.3V REG N930L72217
C901 181P135O4 C-ELECTROLYTIC-TAPE UVR1V101MED1TA 35V 101M N930L72217 L001 351P11310 COIL-CHOKE ALD-20-8 N930L72117
C902 181P372O3 C-ELECTROLYTIC-TAPE USR1C100MDD1TP 16V 100M N930L72217 L002 351P11310 COIL-CHOKE ALD-20-8 N930L72117
C903 181P370O4 C-ELECTROLYTIC-TAPE USR0J101MDD1TP 6.3V 101M N930L72217 L003 351P11310 COIL-CHOKE ALD-20-8 N930L72117
C904 189L007O3 C-DOUBLE-LAYER-TAPE FM0H473ZFTP 0.047F 5.5V N930L72217 L331 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
C905 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 L333 351P091O3 COIL-CHIP BK1608HS470-T HS470 1608 N930L72217
C906 181P370O4 C-ELECTROLYTIC-TAPE USR0J101MDD1TP 6.3V 101M N930L72217 L334 351P091O3 COIL-CHIP BK1608HS470-T HS470 1608 N930L72217
C907 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 L335 351P091O3 COIL-CHIP BK1608HS470-T HS470 1608 N930L72217
C908 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 L336 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
C909 181P372O5 C-ELECTROLYTIC-TAPE USR1C330MDD1TP 16V 330M N930L72217 L337 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
C913 181P372O5 C-ELECTROLYTIC-TAPE USR1C330MDD1TP 16V 330M N930L72217 L338 351P031O6 COIL-CHIP FSLM2520-2R2J=P2 2R2M 2520 N930L72217
C914 181P372O5 C-ELECTROLYTIC-TAPE USR1C330MDD1TP 16V 330M N930L72217 L339 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
C915 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 L340 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
C951 181P135O4 C-ELECTROLYTIC-TAPE UVR1V101MED1TA 35V 101M N930L72217 L341 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
C953 181P74823 C-ELECTROLYTIC R3A-16V100MDOP2#-T36 16V100M 4X5 N930L72217 L342 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
C954 181P133O0 C-ELECTROLYTIC-TAPE UVR1C471MPDAMFTA 16V 471M N930L72217 L351 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
C955 181P74823 C-ELECTROLYTIC R3A-16V100MDOP2#-T36 16V100M 4X5 N930L72217 L352 351P031O6 COIL-CHIP FSLM2520-2R2J=P2 2R2M 2520 N930L72217
C956 181P74810 C-ELECTROLYTIC R3A-10V101MFOP2#-T36 10V101M 6.3X5 N930L72217 L353 351P091O3 COIL-CHIP BK1608HS470-T HS470 1608 N930L72217
C958 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 L354 351P091O3 COIL-CHIP BK1608HS470-T HS470 1608 N930L72217
C959 141L164O6 C-CERAMIC-CHIP GRM188B11C104KA01D B 16V 104K 1608 N930L72217 L355 351P091O3 COIL-CHIP BK1608HS470-T HS470 1608 N930L72217
C960 181P74898 C-ELECTROLYTIC-TAPE R3A-10V330MEOP2#-T36 10V330M 5X5 N930L72217 L356 351P091O3 COIL-CHIP BK1608HS470-T HS470 1608 N930L72217
D006 264P516O1 DIODE-CHIP S3D6600 N930L72217 L357 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
D007 264P516O1 DIODE-CHIP S3D6600 N930L72217 L358 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
D008 264P588O6 DIODE-ZENER-CHIP MA8270-M-TX N930L72217 L359 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
D009 264L060O1 DIODE-CHIP 1SS355 FNTE-17 N930L72217 L360 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
D010 264P588O6 DIODE-ZENER-CHIP MA8270-M-TX N930L72217 L361 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
D012 264P588O6 DIODE-ZENER-CHIP MA8270-M-TX N930L72217 L362 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
D013 264P588O6 DIODE-ZENER-CHIP MA8270-M-TX N930L72217 L371 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
D014 264P588O6 DIODE-ZENER-CHIP MA8270-M-TX N930L72217 L372 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
D015 264P588O6 DIODE-ZENER-CHIP MA8270-M-TX N930L72217 L373 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
D016 264P584O1 DIODE-ZENER-CHIP MA8068-M-TX N930L72217 L3G1 351P091O3 COIL-CHIP BK1608HS470-T HS470 1608 N930L72217
D501 264L060O1 DIODE-CHIP 1SS355 FNTE-17 N930L72217 L3G2 351P095O4 COIL-CHOKE-CHIP BK1608LM252-T N930L72217
9
◆ELECTRICAL PARTS LIST

Ref. No. Parts No. Parts Name Note Spec. Base Parts No. Ref. No. Parts No. Parts Name Note Spec. Base Parts No.
L3G3 351P091O3 COIL-CHIP BK1608HS470-T HS470 1608 N930L72217 Q954 260L100O1 TRANSISTOR-CHIP 2SD1760-Q N930L72217
L901 351P031O6 COIL-CHIP FSLM2520-2R2J=P2 2R2M 2520 N930L72217 R001 103L192O1 R-CHIP RMC1/10471JATP 1/8W 471J 2125 N930L72217
LC371 409P030O1 LC-MULTIPLE-CHIP NFE61HT102F2A9L EMIﾌｨﾙ N930L72217 R002 103L192O1 R-CHIP RMC1/10471JATP 1/8W 471J 2125 N930L72217
LC372 409P030O1 LC-MULTIPLE-CHIP NFE61HT102F2A9L EMIﾌｨﾙ N930L72217 R003 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
LC373 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R004 103L294O1 R-CHIP RMC1/16223JTP 1/10W 223J 1608 N930L72217
LC374 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R005 103L292O1 R-CHIP RMC1/16471JTP 1/10W 471J 1608 N930L72217
LC375 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R006 103L293O1 R-CHIP RMC1/16332JTP 1/10W 332J 1608 N930L72217
LC376 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R007 103L294O1 R-CHIP RMC1/16223JTP 1/10W 223J 1608 N930L72217
LC377 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R008 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217
LC378 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R009 103L294O1 R-CHIP RMC1/16223JTP 1/10W 223J 1608 N930L72217
LC379 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R010 103L294O1 R-CHIP RMC1/16223JTP 1/10W 223J 1608 N930L72217
LC380 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R011 103L294O9 R-CHIP RMC1/16104JTP 1/10W 104J 1608 N930L72217
LC381 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R012 103L294O9 R-CHIP RMC1/16104JTP 1/10W 104J 1608 N930L72217
LC382 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R013 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
LC383 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R014 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
LC384 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R021 103L301O1 R-CHIP RPC50T680J 1/2W 680J 5025 N930L72217
LC385 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R022 103L301O1 R-CHIP RPC50T680J 1/2W 680J 5025 N930L72217
LC386 409P023O2 LC-MULTIPLE-CHIP NFW31SP106X1E4L N930L72217 R023 103L301O0 R-CHIP RPC50T560J 1/2W 560J 5025 N930L72217
LC901 409P030O1 LC-MULTIPLE-CHIP NFE61HT102F2A9L EMIﾌｨﾙ N930L72217 R024 103L301O0 R-CHIP RPC50T560J 1/2W 560J 5025 N930L72217
P002 452L173O3 CONNECTOR 7322-8380-30 18P SIDE N930L72117 R025 103L301O1 R-CHIP RPC50T680J 1/2W 680J 5025 N930L72217
P003 452L34211 CONNECTOR 9442B-14J-T 14P SIDE N930L72117 R026 103L301O1 R-CHIP RPC50T680J 1/2W 680J 5025 N930L72217
PLATE1 443P01012 TERMINAL SD01123-21 N930L72217 R198 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
PLATE2 443P01012 TERMINAL SD01123-21 N930L72217 R199 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
PLATE3 443P01012 TERMINAL SD01123-21 N930L72217 R301 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
PLATE4 443P01012 TERMINAL SD01123-21 N930L72217 R302 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
PLATE5 443P01012 TERMINAL SD01123-21 N930L72217 R303 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
PLATE6 443P01012 TERMINAL SD01123-21 N930L72217 R304 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q001 260M061O6 TRANSISTOR-CHIP 2SA1037AKT146R N930L72217 R309 103P504O4 R-CHIP RMC1/16393FTP 1/10W 393F 1608 N930L72217
Q002 260M061O5 TRANSISTOR-CHIP 2SC2412K T146 S N930L72217 R310 103P503O3 R-CHIP RMC1/16472FTP 1/10W 472F 1608 N930L72217
Q003 260M061O5 TRANSISTOR-CHIP 2SC2412K T146 S N930L72217 R311 103P504O4 R-CHIP RMC1/16393FTP 1/10W 393F 1608 N930L72217
Q004 260M061O6 TRANSISTOR-CHIP 2SA1037AKT146R N930L72217 R312 103P503O3 R-CHIP RMC1/16472FTP 1/10W 472F 1608 N930L72217
Q005 260M061O5 TRANSISTOR-CHIP 2SC2412K T146 S N930L72217 R313 103P504O4 R-CHIP RMC1/16393FTP 1/10W 393F 1608 N930L72217
Q006 260M061O2 TRANSISTOR-CHIP DTC124EKAT146 N930L72217 R314 103P503O3 R-CHIP RMC1/16472FTP 1/10W 472F 1608 N930L72217
Q501 260M061O2 TRANSISTOR-CHIP DTC124EKAT146 N930L72217 R315 103P504O4 R-CHIP RMC1/16393FTP 1/10W 393F 1608 N930L72217
Q502 260L042O2 TRANSISTOR-CHIP DTA144TKAT146 N930L72217 R316 103P503O3 R-CHIP RMC1/16472FTP 1/10W 472F 1608 N930L72217
Q503 260M061O6 TRANSISTOR-CHIP 2SA1037AKT146R N930L72217 R317 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
Q504 260M061O2 TRANSISTOR-CHIP DTC124EKAT146 N930L72217 R318 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
Q505 260M061O2 TRANSISTOR-CHIP DTC124EKAT146 N930L72217 R331 103L293O4 R-CHIP RMC1/16562JTP 1/10W 562J 1608 N930L72217
Q506 260M061O2 TRANSISTOR-CHIP DTC124EKAT146 N930L72217 R332 103L291O9 R-CHIP RMC1/16331JTP 1/10W 331J 1608 N930L72217
Q561 260L033O1 TRANSISTOR-CHIP DTC323TK T146 N930L72217 R333 103L291O9 R-CHIP RMC1/16331JTP 1/10W 331J 1608 N930L72217
Q562 260L033O1 TRANSISTOR-CHIP DTC323TK T146 N930L72217 R334 103L291O9 R-CHIP RMC1/16331JTP 1/10W 331J 1608 N930L72217
Q563 260L033O1 TRANSISTOR-CHIP DTC323TK T146 N930L72217 R335 103L291O9 R-CHIP RMC1/16331JTP 1/10W 331J 1608 N930L72217
Q564 260L033O1 TRANSISTOR-CHIP DTC323TK T146 N930L72217 R336 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q565 260M061O2 TRANSISTOR-CHIP DTC124EKAT146 N930L72217 R337 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q566 260M061O2 TRANSISTOR-CHIP DTC124EKAT146 N930L72217 R338 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q567 260M061O1 TRANSISTOR-CHIP DTA124EKAT146 N930L72217 R351 103L293O4 R-CHIP RMC1/16562JTP 1/10W 562J 1608 N930L72217
Q568 260M061O2 TRANSISTOR-CHIP DTC124EKAT146 N930L72217 R357 103L294O5 R-CHIP RMC1/16473JTP 1/10W 473J 1608 N930L72217
Q601 260L033O1 TRANSISTOR-CHIP DTC323TK T146 N930L72217 R358 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q602 260L033O1 TRANSISTOR-CHIP DTC323TK T146 N930L72217 R359 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q607 260M061O1 TRANSISTOR-CHIP DTA124EKAT146 N930L72217 R371 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q681 260L033O1 TRANSISTOR-CHIP DTC323TK T146 N930L72217 R372 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q682 260L033O1 TRANSISTOR-CHIP DTC323TK T146 N930L72217 R373 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q683 260L033O1 TRANSISTOR-CHIP DTC323TK T146 N930L72217 R374 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q684 260L033O1 TRANSISTOR-CHIP DTC323TK T146 N930L72217 R375 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q801 260M061O1 TRANSISTOR-CHIP DTA124EKAT146 N930L72217 R3G1 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
Q880 260L042O7 TRANSISTOR-CHIP DTC114TKAT146 N930L72217 R501 103L292O9 R-CHIP RMC1/16222JTP 1/10W 222J 1608 N930L72217
Q901 260M061O1 TRANSISTOR-CHIP DTA124EKAT146 N930L72217 R502 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217
Q902 260M061O8 TRANSISTOR-CHIP DTC144EKAT146 N930L72217 R503 103L295O6 R-CHIP RMC1/16394JTP 1/10W 394J 1608 N930L72217
Q903 260P68210 TRANSISTOR 2SD2375OP 2W 60V 3A N930L72117 R504 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217
Q904 260M061O8 TRANSISTOR-CHIP DTC144EKAT146 N930L72217 R505 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217
Q905 260L047O1 TRANSISTOR-CHIP 2SA1369-T113-1G PB-FREE(SN-2BI) N930L72217 R506 103L293O0 R-CHIP RMC1/16272JTP 1/10W 272J 1608 N930L72217
Q951 260M061O1 TRANSISTOR-CHIP DTA124EKAT146 N930L72217 R507 103L294O1 R-CHIP RMC1/16223JTP 1/10W 223J 1608 N930L72217
Q952 260M061O8 TRANSISTOR-CHIP DTC144EKAT146 N930L72217 R508 103L293O2 R-CHIP RMC1/16392JTP 1/10W 392J 1608 N930L72217
Q953 260P68210 TRANSISTOR 2SD2375OP 2W 60V 3A N930L72117 R509 103L292O9 R-CHIP RMC1/16222JTP 1/10W 222J 1608 N930L72217
10
◆ELECTRICAL PARTS LIST

Ref. No. Parts No. Parts Name Note Spec. Base Parts No. Ref. No. Parts No. Parts Name Note Spec. Base Parts No.
R511 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217 R605 103L291O3 R-CHIP RMC1/16101JTP 1/10W 101J 1608 N930L72217
R512 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217 R606 103L291O3 R-CHIP RMC1/16101JTP 1/10W 101J 1608 N930L72217
R521 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R608 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
R522 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R625 103L291O3 R-CHIP RMC1/16101JTP 1/10W 101J 1608 N930L72217
R523 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R626 103L291O3 R-CHIP RMC1/16101JTP 1/10W 101J 1608 N930L72217
R524 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R628 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
R525 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R641 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217
R526 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R642 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217
R527 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R643 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217
R528 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R644 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217
R529 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R645 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217
R530 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R646 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217
R531 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R647 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217
R532 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R648 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217
R533 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R649 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217
R534 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R650 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217
R535 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R651 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217
R536 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R652 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217
R537 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217 R653 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217
R538 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217 R654 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217
R539 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217 R655 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217
R540 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217 R656 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217
R541 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217 R657 103P503O7 R-CHIP RMC1/16103FTP 1/10W 103F 1608 N930L72217
R542 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217 R658 103P503O7 R-CHIP RMC1/16103FTP 1/10W 103F 1608 N930L72217
R543 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217 R659 103P503O7 R-CHIP RMC1/16103FTP 1/10W 103F 1608 N930L72217
R544 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217 R660 103P503O7 R-CHIP RMC1/16103FTP 1/10W 103F 1608 N930L72217
R545 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217 R681 103L293O5 R-CHIP RMC1/16682JTP 1/10W 682J 1608 N930L72217
R546 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217 R682 103L293O5 R-CHIP RMC1/16682JTP 1/10W 682J 1608 N930L72217
R547 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217 R683 103L293O5 R-CHIP RMC1/16682JTP 1/10W 682J 1608 N930L72217
R548 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217 R684 103L293O5 R-CHIP RMC1/16682JTP 1/10W 682J 1608 N930L72217
R549 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217 R685 103L293O4 R-CHIP RMC1/16562JTP 1/10W 562J 1608 N930L72217
R550 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217 R686 103L293O4 R-CHIP RMC1/16562JTP 1/10W 562J 1608 N930L72217
R551 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217 R687 103L293O4 R-CHIP RMC1/16562JTP 1/10W 562J 1608 N930L72217
R552 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217 R688 103L293O4 R-CHIP RMC1/16562JTP 1/10W 562J 1608 N930L72217
R561 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217 R689 103L291O3 R-CHIP RMC1/16101JTP 1/10W 101J 1608 N930L72217
R562 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217 R690 103L291O3 R-CHIP RMC1/16101JTP 1/10W 101J 1608 N930L72217
R563 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217 R691 103L291O3 R-CHIP RMC1/16101JTP 1/10W 101J 1608 N930L72217
R564 103L292O7 R-CHIP RMC1/16152JTP 1/10W 152J 1608 N930L72217 R692 103L291O3 R-CHIP RMC1/16101JTP 1/10W 101J 1608 N930L72217
R565 103L292O7 R-CHIP RMC1/16152JTP 1/10W 152J 1608 N930L72217 R694 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
R566 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217 R805 103L294O9 R-CHIP RMC1/16104JTP 1/10W 104J 1608 N930L72217
R567 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217 R807 103L294O9 R-CHIP RMC1/16104JTP 1/10W 104J 1608 N930L72217
R568 103L293O9 R-CHIP RMC1/16153JTP 1/10W 153J 1608 N930L72217 R809 103L294O9 R-CHIP RMC1/16104JTP 1/10W 104J 1608 N930L72217
R569 103L293O9 R-CHIP RMC1/16153JTP 1/10W 153J 1608 N930L72217 R811 103L294O9 R-CHIP RMC1/16104JTP 1/10W 104J 1608 N930L72217
R570 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217 R815 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
R571 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217 R816 103L291O7 R-CHIP RMC1/16221JTP 1/10W 221J 1608 N930L72217
R572 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217 R817 103L291O7 R-CHIP RMC1/16221JTP 1/10W 221J 1608 N930L72217
R573 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217 R818 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
R574 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217 R819 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
R575 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217 R820 103L291O7 R-CHIP RMC1/16221JTP 1/10W 221J 1608 N930L72217
R581 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217 R821 103L295O3 R-CHIP RMC1/16224JTP 1/10W 224J 1608 N930L72217
R582 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217 R822 103L294O5 R-CHIP RMC1/16473JTP 1/10W 473J 1608 N930L72217
R583 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R823 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
R584 103P502O9 R-CHIP RMC1/16222FTP 1/10W 222F 1608 N930L72217 R824 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
R585 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217 R825 103L294O5 R-CHIP RMC1/16473JTP 1/10W 473J 1608 N930L72217
R586 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217 R826 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217
R587 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N930L72217 R827 103L291O7 R-CHIP RMC1/16221JTP 1/10W 221J 1608 N930L72217
R588 103P503O2 R-CHIP RMC1/16392FTP 1/10W 392F 1608 N930L72217 R829 103L294O5 R-CHIP RMC1/16473JTP 1/10W 473J 1608 N930L72217
R589 103P503O7 R-CHIP RMC1/16103FTP 1/10W 103F 1608 N930L72217 R830 103L294O5 R-CHIP RMC1/16473JTP 1/10W 473J 1608 N930L72217
R590 103P503O7 R-CHIP RMC1/16103FTP 1/10W 103F 1608 N930L72217 R831 103L294O5 R-CHIP RMC1/16473JTP 1/10W 473J 1608 N930L72217
R5A1 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217 R851 103L295O7 R-CHIP RMC1/16474JTP 1/10W 474J 1608 N930L72217
R601 103L292O7 R-CHIP RMC1/16152JTP 1/10W 152J 1608 N930L72217 R871 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217
R602 103L292O7 R-CHIP RMC1/16152JTP 1/10W 152J 1608 N930L72217 R872 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217
R603 103L293O9 R-CHIP RMC1/16153JTP 1/10W 153J 1608 N930L72217 R883 103L292O9 R-CHIP RMC1/16222JTP 1/10W 222J 1608 N930L72217
R604 103L293O9 R-CHIP RMC1/16153JTP 1/10W 153J 1608 N930L72217 R884 103L294O5 R-CHIP RMC1/16473JTP 1/10W 473J 1608 N930L72217
11
◆ELECTRICAL PARTS LIST

Ref. No. Parts No. Parts Name Note Spec. Base Parts No. Ref. No. Parts No. Parts Name Note Spec. Base Parts No.
R8A1 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
R8A2 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
R8A3 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N930L72217
R8B1 103L294O5 R-CHIP RMC1/16473JTP 1/10W 473J 1608 N930L72217
R8B2 103L294O5 R-CHIP RMC1/16473JTP 1/10W 473J 1608 N930L72217
R8G1 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
R8G2 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
R8G3 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
R8G4 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
R901 103L294O2 R-CHIP RMC1/16273JTP 1/10W 273J 1608 N930L72217
R902 103L292O9 R-CHIP RMC1/16222JTP 1/10W 222J 1608 N930L72217
R903 103L292O9 R-CHIP RMC1/16222JTP 1/10W 222J 1608 N930L72217
R904 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N930L72217
R905 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217
R906 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217
R949 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
R951 103L292O6 R-CHIP RMC1/16122JTP 1/10W 122J 1608 N930L72217
R952 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
R953 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217
R954 103L291O3 R-CHIP RMC1/16101JTP 1/10W 101J 1608 N930L72217
R955 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N930L72217
R997 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
R998 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
R999 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N930L72217
RN371 109P01213 R-NETWORK-CHIP RAC164D103JCTP 1/16W 103J 3216 N930L72217
RN372 109P01213 R-NETWORK-CHIP RAC164D103JCTP 1/16W 103J 3216 N930L72217
RN373 109P01213 R-NETWORK-CHIP RAC164D103JCTP 1/16W 103J 3216 N930L72217
RN802 109P01211 R-NETWORK-CHIP RAC164D221JCTP 1/16W 221J 3216 N930L72217
X3G1 285P11422 CRYSTAL-TAPE SMD-49 22.5792MHZ N930L72217
X801 285L012O7 CRYSTAL-TAPE AT-49 PB-FREE 10MHZ 16PF N930L72217
930L72117 S5-PCB-AMP N903L50717
930L72217 S6-PCB-AMP N930L72117
12
◆ELECTRICAL PARTS LIST
