Mitsubishi 2016 OUTLANDER User manual

Table of contents
1
2
3
4
5
6
7
8
9
10
11
12
Overview
Quick index
General information
Seat and restraint systems
Features and controls
Driving safety
Comfort controls
For emergencies
Vehicle care and maintenance
Customer assistance/Reporting Safety Defects
Specifications
Alphabetical index
BK0223400US.book 1 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
Information Provided by:

Instruments and controls
1-1
1
Overview
N00100202658
Instruments and controls
Combination headlights and dimmer
switch P.5-177
Turn signal lever P.5-183
Front fog light switch (if so equipped) P.5-184
Steering wheel audio remote control switches P.7-27
[For DISPLAY AUDIO and MMCS, refer to the separate
owner’s manuals.]
Active stability control (ASC) OFF
switch P.5-95 Supplemental restraint system
(SRS) - airbag (for driver’s
seat) P.4-33, 4-40
Horn switch P.5-191
Instrument cluster
P.5-126
Windshield wiper and washer
switch P.5-185
Rear window wiper and
washer switch P.5-189
Cruise control switch P.5-96
Steering wheel height and reach adjustment
lever P.5-54
Engine switch (if so
equipped) P.5-18
Bluetooth®2.0 interface (if so equipped)
P.5-192
Driver’s vents
P.7-2
Sportronic steering wheel paddle shifter
(if so equipped) P.5-68, 5-76
Driver’s vents
P.7-2
Multi information display
switch (if so equipped)
P.5-129
Headlight leveling switch
(if so equipped) P.5-182
Driver’s side power liftgate switch (if so equipped) P.5-40
Fuse box P.9-25
Lane departure warning (LDW) switch
(if so equipped) P.5-117
Forward collision mitigation
system (FCM) ON/OFF
switch (if so equipped)
P.5-114
Supplemental restraint system (SRS) - front knee airbag
(for driver’s seat) P.4-40
Ignition switch (if so equipped)
P.5-60
BK0223400US.book 1 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
Information Provided by:

Instruments and controls
Overview 1-2
1
Audio (if so equipped) P.7-15
Mitsubishi Multi-Communication System (MMCS) (if so equipped)
[For DISPLAY AUDIO and MMCS, refer to the separate owner’s manuals.]
Hazard warning flasher switch
P.5-184
Electric rear window defogger switch P.5-190
Wiper deicer switch (if so equipped) P.5-190
Fuel tank filler door release lever
P.3-3
Drive mode-selector (if so equipped) P.5-79
S-AWC drive mode-selector (if so equipped) P.5-83 Selector lever P.5-64, 5-72
Parking brake lever P.5-53
Supplemental restraint system (SRS) - air bag
(for front passenger’s seat)
P.4-33, 4-40
Air conditioner P.7-5
Hood release lever
P.9-3
Floor console box P.5-229
Arm rest
12 V power outlet P.5-219
USB input terminal
(if so equipped) P.5-215
Heated seat switch (if so equipped)
P.4-8
Cup holder P.5-232
12 V power outlet P.5-219
Power liftgate main switch (if so equipped)
P.5-39
Key slot (if so equipped)
P.5-26
Glove compartment P.5-229
Card holder P.5-229
Passenger’s vents
P.7- 2
Passenger’s airbag off indicator P.4-38
Front passenger seat belt warning light
P.4-22
BK0223400US.book 2 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
Information Provided by:

Interior
1-3 Overview
1
N00100302372
Interior
Sun visors P.5-218
Vanity mirror P.5-218
Card holder P.5-218
Supplemental restraint system (SRS) - side airbag
(for front seats) P.4-44
Sunglasses holder (if so equipped)
P.5-231
Adjustable seat belt shoulder anchor P.4-23
Seat belts P.4-17
Cargo room light
P.5-227, 9-32
Electric remote-controlled outside rearview mirrors switch P.5-58
Lock switch P.5-50
Power door lock
switch P.5-35
Power window switch
P.5-49
Second row seat P.4-8
Third row seat (7 persons)
P.4-10
Dome light (rear) P.5-226
Inside rearview mirror P.5-55
HomeLink®Wireless Control System (if so
equipped) P.5-220
Front seat P.4-4
BK0223400US.book 3 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
Information Provided by:

Interior
Overview 1-4
1
Assist grips P.5-235
Coat hook P.5-235
Bottle holder P.5-233 Sunroof switch
(if so equipped) P.5-51
Head restraints P.4-10
Arm rest P.4-9
Cup holder P.5-232
Cargo area cover (if so equipped)
P.5-233
Supplemental restraint system (SRS) - curtain
airbags P.4-45
Dome light (front)/Reading
lights P.5-226, 5-226
Downlight
P.5-177
Hands-free microphone
(if so equipped) P.5-193
BK0223400US.book 4 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
Information Provided by:

Luggage area
1-5 Overview
1
N00100501511
Luggage area
Jack P. 8-5
Tools P.8-5
Luggage hooks P.5-236
Luggage floor box P.5-230
Tether anchorages for child restraint system P.4-29
BK0223400US.book 5 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
Information Provided by:

Outside (Front)
Overview 1-6
1
N00100602564
Outside (Front)
Sunroof (if so equipped) P.5-51
Windshield wipers P.5-185
Engine hood P.9-3
Front fog lights (if so equipped) P.5-184, 9-30, 9-35
Outside rearview mirrors P.5-57
Side turn-signal lights (if so equipped)
P.5-183, 9-30, 9-35
Fuel tank filler P.3-3
Power window P.5-49
Front turn-signal lights
P.5-183, 9-30, 9-34
Front turn signal lights
P.5-183, 9-30, 9-34
Headlights, low beam
P.5-177, 9-30, 9-33
Parking lights P.5-177, 9-30, 9-34
Daytime running lights (if so equipped)
P.5-177, 9-30, 9-34
Headlights, low beam
P.5-177, 9-30, 9-32
Parking lights P.5-177, 9-30, 9-34
Daytime running lights (if so equipped)
P.5-177, 9-30, 9-34
Headlights, high beam
P.5-177, 9-30, 9-33
Headlights, high beam
P.5-177, 9-30, 9-33
Halogen headlights type LED headlights type
Front side-marker lights
P.5-177, 9-30, 9-33 Front side-marker lights
P.5-177, 9-30, 9-33
BK0223400US.book 6 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
Information Provided by:

Outside (Rear)
1-7 Overview
1
N00100602577
Outside (Rear)
Keyless entry system (if so equipped) P.5-7, 5-29
F.A.S.T.-key (Free-hand Advanced Security Transmitter) (if so equipped)
P.5-12
Locking and unlocking P.5-33
Tire P.9-15
Tire pressure monitoring system
P.5- 11 9
Tire inflation pressures P.9-18
Changing tires P.8-6
Tire rotation P.9-20
Tire chains P.9-21
Size of tires and wheels P.11-7
Stop lights P.5-177, 9-30, 9-35
Rear turn signal lights P.5-183, 9-30, 9-35
Spare tire P.8-7 Back-up lights P.9-30, 9-36
License plate lights
P.5-177, 9-30, 9-37
Rear-view camera (if so equipped)
P.5-124
Rear window wiper
P.5-189
High-mounted stop light P.9-30
Antenna P.7-51
Liftgate (if so equipped) P.5-36
Power liftgate (if so equipped)
P.5-38
Rear side-marker lights P.5-177, 9-30
Tail lights P.5-177, 9-30, 9-35
BK0223400US.book 7 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
Information Provided by:

2-1
2
If this warning light comes on or flashes while you’re driving...
Quick index
N00200702234
If this warning light comes on or flashes while you’re driving...
NOTE
For information regarding warning displays in the multi-information display (Color liquid crystal display type), refer to “Multi-information display” on
page 5-128.
These warning lights will come on for a few seconds for a bulb check when the ignition switch is first turned to “ON” or the operation mode is put in ON.
Warning lights Do this Ref. Page
Charging system warning light
Park your vehicle in a safe place and stop the engine.
Contact your Mitsubishi Motors dealer or a repair facility of your choice for assis-
tance.
P. 5-174
Oil pressure warning light
(Vehicles equipped with mono-color
liquid crystal display)
Park your vehicle in a safe place and stop the engine, then check the engine oil
level.
If the light comes on while the engine oil level is normal, have the system checked
at an authorized Mitsubishi Motors dealer or a repair facility of your choice as soon
as possible.
P. 5-174
or
Brake warning light
If this light comes on while driving, check to see that the parking brake is fully
released.
If this light stays on after releasing the parking brake, immediately stop and check
the brake fluid level.
If the brake fluid level is correct, there may be a system malfunction. Avoid hard
braking and high speed, and contact an authorized Mitsubishi Motors dealer or a
repair facility of your choice for assistance.
P. 5-173
BK0223400US.book 1 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
Information Provided by:

If this warning light comes on or flashes while you’re driving...
2-2 Quick index
2
Selector lever position indicator in the
instrument cluster flashes rapidly
(once per second)
(Vehicles equipped with mono-color
liquid crystal display)
Park your vehicle in a safe place.
Idle the engine until the selector lever position indicator stops flashing.
If the indicator does not go off, have the system checked at an authorized Mitsubi-
shi Motors dealer or a repair facility of your choice as soon as possible.
P. 5-66,
5-74
or
Engine malfunction indicator
(“SERVICE ENGINE SOON” or
“Check engine light”)
Although your vehicle will usually be drivable and not need towing, have the
engine system checked at an authorized Mitsubishi Motors dealer or a repair facility
of your choice as soon as possible. If the vehicle is not drivable, contact emergency
roadside assistance at 1-888-648-7820 (for vehicles sold in U.S.A.) or 1-888-576-
4878 (for vehicles sold in Canada), an authorized Mitsubishi Motors dealer, or local
towing company for assistance.
P. 5-173
Electric power steering system (EPS)
warning light
(Vehicles equipped with mono-color
liquid crystal display)
If this light comes on while the engine is running, it may become harder to turn the
steering wheel. Have your vehicle inspected at an authorized Mitsubishi Motors
dealer or a repair facility of your choice as soon as possible.
P. 5-93
Warning lights Do this Ref. Page
BK0223400US.book 2 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
