INFORMATION FOR FIRST AND SECOND RESPONDERS
EMERGENCY RESPONSE GUIDE FOR VEHICLE
2018 - 2022 Model year
LI ION
Version:1.1

1
Introduction
This manual provides safety instructions that need to be followed
when rescuing the passengers from the vehicle after an accident
and describes how to handle the damaged vehicle.
Failure to follow these instructions and especially the warnings and
cautions may result in serious injury such as an electrical shock due
to the high voltage battery installed on OUTLANDER PHEV.
Please read and understand this manual carefully for your and
the passengers safety.
Throughout this manual the words WARNING, CAUTION appear.
These serve as reminders to be especially careful. Failure to follow instructions could result in
personal injury or damage to your vehicle.
WARNING
Indicates a strong possibility of severe personal injury or death if instructions are not followed.
CAUTION
Means hazards or unsafe practices that could cause minor personal injury or damage to the vehicle.
NOTE
Gives helpful information.
*: indicates optional equipment.
It may differ according to the sales classification; refer to the sales catalogue.
Mitsubishi Motors reserves the right to make changes in design and specification and/or to make
additions to or improvements in this product without obligation to install them on products
previously manufactured.
・Please note that the contents of this manual may not fit completely with actual vehicle due to the
change of vehicle specification.

2
CONTENTS
0.Rescue sheet(s)
P.3
1.Identification / recognition
P.4
2.Immobilization / stabilization / lifting
P.9
3.Disable direct hazards / safety regulations
P.12
4.Access to the occupants
P.17
5.Stored energy / liquids / gases / solids
P.21
6.In case of fire
P.23
7.In case of submersion
P.27
8.Towing / transportation / storage
P.28
9.Important additional information
P.31
10.Explanation of pictograms used
P.49

3
0.Rescue sheet(s)
OUTLANDER PHEV
Body type: Station wagon
Type: GG3W Model year: 2018–2022
Airbag
Stored
gas inflator
Seat belt
pretensioner
SRS
control unit
Pedestrian
protection
active
system
Automatic
rollover
protection
system
Gas strut /
Preloaded
spring
High
strength
zone
Zone
requiring
special
attention
Battery
low voltage
Ultra
capacitor,
low voltage
Fuel tank
Gas tank
Safety valve
High voltage
battery
pack
Highvoltage
Powercable
component
High voltage
disconnect
Fuse box
disabling
high voltage
system
Ultra
capacitor,
high voltage
ID No.
Version No.
Version Date.
Page
GGW-UNRS-02
01
05/2021
1
Li-ion drive battery
Max:336 voltage
ⒸMITSUBISHI MOTORS CORPORATION. All rights reserved.

4
1.Identification / recognition
1. Features on vehicle exterior
OUTLANDER PHEV shares one vehicle body with petrol engine models. Therefore, their exteriors are very similar.
If you find any of the following features which can identify OUTLANDER PHEV, always wear appropriate Personal
Protective Equipment (PPE).
WARNING:
- Use insulating Personal Protective Equipment (PPE) (Rubber insulating gloves, Rubber soled insulating shoes:
rated to a minimum of 500V voltage resistance), when contact with the vehicle body is possible, until you can
identify whether the vehicle is OUTLANDER PHEV or not.
- Engine noise does not always mean that the vehicle is a model with petrol engine.
(1) Feature list
OUTLANDER PHEV can be identified by the “PLUG-IN HYBRID EV" logo, battery charging lid, chassis number
(model code) and the power drive unit (PDU) cover.
The "PHEV (PLUG-IN HYBRID EV)" logo is installed on the left and right sides of the fender panel and on the liftgate.
(2) Features on exterior
(1) "PLUG-IN HYBRID EV" logo mark on the left and right front fenders
(2) "PHEV" logo mark on the liftgate
<18MY to 19MY is Right side.> <20MY to 22MY is Left Side>
(3) "Battery charging lid" on the right rear panel
NOTE:
There is no Battery charging lid except for PHEV vehicles. The left rear panel is the "Fuel filler lid".
Battery charging lid
(1)
(2)
(3)

5
(1) “Chassis number” shown in the engine compartment
(2)"PLUG-IN HYBRID EV" logo mark on the "PDU cover" in the engine compartment
GG2WJZ******
GG3WMZ******
Chassis number
PDU cover
(2)
(1)
GG2WXD******
GG3WXD******
The first four characters/numbers of the chassis number (in red) “GG2W or GG3W” identify the vehicle as an
OUTLANDER PHEV.

6
2. High voltage wiring harness location
High voltage wiring harness are located as shown in the figure below.
<Vehicle without 120V AC Power supply (1500W)>
<Vehicle with 120V AC Power supply (1500W)>
*: Refer to “10. Explanation of pictogram used”
A/C compressor cable
Charge port
Main drive
front cable (P, N line)
lithium-ion battery
(U, V, W three phse line)
Generator cable
Front motor cable
(U, V, W three phse line)
On board charger/
DC-DC converter cable
(Rear electric motor
Control unit)
rear cable (P)
Main drive
lithium-ion battery
rear cable (N)
Main drive
lithium-ion battery
EV charging cable
(Regular charger)
Rear motor cable
(U, V, W, three phase line)
(Quick charger)
EV charging cable
A/C compressor cable
Charge port
Junction cable
Main drive
front cable (P, N line)
lithium-ion battery
(U, V, W three phse line)
Generator cable
Front motor cable
(U, V, W three phse line)
On board charger/
DC-DC converter cable
(Rear electric motor
Control unit)
rear cable (P)
Main drive
lithium-ion battery
rear cable (N)
Main drive
lithium-ion battery
EV charging cable
(Regular charger)
(Quick charger)
EV charging cable
Electric heater cable
Rear motor cable
(U, V, W, three phase line)
Electric heater cable

7
3. Supplemental Restraint System (SRS) airbag component location
SRS airbags system (location of airbags and related components) are located as shown in the figure below:
*: Refer to “10. Explanation of pictogram used”
SRS
Warning lamp
SRS-ECU
Curtain air bag module
Front impact sensor
Side impact sensor <Front>
Side-airbag module
Knee air bag module
Driver’s
air bag module
Clock spring
Passenger’s
air bag module
pre-tensioner
Seat belt
pre-tensioner
Seat belt
Combination meter
Overhead bezel
Passenger’s air bag OFF indicator light
<For 20MY to 22MY>
Hazard indicator assembly
Passenger’s air bag OFF indicator light
<18MY to 19MY>
Passenger’s
air bag cut off
switch
Occupant classification-ECU
Occupant classification
sensor
Seat slide sensor
Side impact sensor <Rear>

8
4. Vehicle dimensions
Vehicle weight ： 4,178 – 4,244 lbs.*
1,895 – 1,925 kg
*：Differs on the model, the vehicle weight will change.
60.6 in. / 1,540 mm
70.9 in. / 1,800 mm
60.6 in. / 1,540 mm
67.3 in. / 1,710 mm
184.8 in. / 4,695 mm
105.1 in. / 2,670 mm
7.3 in. / 185
