MJM E118-3TW-FF-SQ-PAIL User manual

IDENTIFY COMPONENTS TO START ASSEMBLY
SEAT SECTION WITH ARMS, COMMODE, FOLDING FOOTREST
PVC BACKREST WITH MESH SLING.
BOX WITH CASTERS AND SCREWS
o4 CASTERS WITH BRAKES.
STEP 1 –CASTERS
INSERT CASTER LEG STEMS INTO BASE SECTION
STEP 2 CASTERS.
DRILL THROUGH LEG
PIPES USING 1/8 DRILL
BIT AND PILOT HOLES
AS REFERENCE.
SECURE USING 1/2’’
RETAINING SCREWS
AND PILOT HOLES AS
REFERENCE.
STEP 3 BACKREST & MESH SLING
INSERT PVC BACKREST INTO T-FITTING LOCATED ON
ARM SECTIONS.
E118-3-FF-SQ-PAIL
Assembly Instructions
NOTE: A PHILLIPS SCREWDRIVER OR A CORDLESS HAND DRILL IS REQUIRED TO TIGHTEN / SECURE ALL SCREWS.
MJM INTERNATIONAL CORPORATION
E118-3TW-FF-SQ-PAIL
ASSEMBLY INSTRUCTIONS

STEP 4 BACKREST & MESH SLING
SECURE USING 1/2’’ RETAINING SCREWS AND
PILOT HOLES AS REFERENCE.
STEP 5 FOLDING FOOTREST
SECURE WITH VINYL STRAP.
Direct Supply® Direct Choice™
DCE1187 MJM INTERNATIONAL CORPORATION
-FF-SQ-PAIL DCE118-3-17-FF-
BB-18-SQ-PAIL DCE118-3-17-FF-
LSB-18-SQ-PAIL
Assembly Instructions
NOTE: CASTERS, PVC BACKREST MUST BE CHECKED AND SECURED PRIOR TO USING SHOWER CHAIR.
WARNING NOT SECURING ALL THE ABOVE CAN CREATE A SERIOUS SAFETY HAZARD.
2
Rev: 1.3
STEP 6 PRODUCTS COMPLETLY ASSEMBLED
E118-3-FF-SQ-PAIL
E118-3-FF-BB-18-SQ-PAIL
E118-3-FF-LSB-18-SQ-PAIL
