MMP LIFTEM MARK IV User manual

MILLENNIUM MEDICAL PRODUCTS, INC.
PATIENT LIFT AND TRANSFER SYSTEM
LIFTEM®OPERATIONS MANUAL
MODEL MARK IV
March 2006

MILLENNIUM MEDICAL PRODUCTS, INC.
i
LIFTEM®OPERATIONS MANUAL
Table of Contents
CHAPTER 1.................................................................................................................................. 1
A. WHAT IS LIFTEM......................................................................................................... 1
1. Description........................................................................................................................ 1
2. Why use LIFTEM............................................................................................................. 1
B. CAPABILITIES OF LIFTEM ........................................................................................ 2
1. Maximum Lift and Transfer Capacity .............................................................................. 2
2. Lift and Transfer Capabilities ........................................................................................... 2
C. SAFETY PRECAUTIONS ............................................................................................. 3
1. When LIFTEM Can be Used ............................................................................................ 3
2. When LIFTEM Can Not be Used ..................................................................................... 3
3. Things to Remember when Operating LIFTEM............................................................... 4
CHAPTER 2.................................................................................................................................. 5
STEP BY STEP OPERATION............................................................................................. 5
1. General.............................................................................................................................. 5
2. Lift and Transfer Patient From Bed.................................................................................. 6
3. Lift and Transfer Back to Bed ........................................................................................ 10
CHAPTER 3................................................................................................................................ 14
USEFUL TIPS .................................................................................................................... 14
1. Battery Operation............................................................................................................ 14
2. Operation by 115 Volt AC Power using Wall Socket .................................................... 14
3. Operation in Case of a Dead Battery or Loss of AC Electric Power.............................. 14
4. Charging a Dead Battery................................................................................................. 15
5. Moving LIFTEM ............................................................................................................ 15
6. Assembly & Disassembly of LIFTEM ........................................................................... 15
7. Limited Warranty............................................................................................................ 16
CHAPTER 4................................................................................................................................ 17
TROUBLESHOOTING GUIDE ........................................................................................ 17
1. General............................................................................................................................ 17
2. Methods of Determining “Possible Cause” of LIFTEM Malfunction............................ 19
CHAPTER 5................................................................................................................................ 21
SLING MANUAL .............................................................................................................. 21
Sling Model 3624................................................................................................................ 22
Laundering Procedures for Sling Model 3624.................................................................... 22
Warranty for Sling Model 3624.......................................................................................... 24
Application Instructions for Sling Model 3624 .................................................................. 24
Attaching Sling Model 3624 to the LIFTING BAR ........................................................... 26
Stretcher Sling Model 700 .................................................................................................. 27

MILLENNIUM MEDICAL PRODUCTS, INC.
ii
Laundering Procedures For Stretcher Sling Model 700 ..................................................... 27
Warranty for Sling Model 700............................................................................................ 28
Application Instructions for Stretcher Sling Model 700..................................................... 28
General................................................................................................................................ 28
Sling Inspection Data Sheet................................................................................................ 32
CHAPTER 6................................................................................................................................ 33
SCALE INSTALLATION AND OPERATION ................................................................ 33
A - Introduction................................................................................................................... 33
B - Installation of the Scale................................................................................................. 33
C - Operate the Scale and Weigh the Patient...................................................................... 34
D - Important Points............................................................................................................ 34
E - Maintenance and Recalibration..................................................................................... 35
F - Warranty........................................................................................................................ 35
CHAPTER 7................................................................................................................................ 36
MAINTENANCE PROCEDURES .................................................................................... 36
Weekly Service and Maintenance....................................................................................... 36
Monthly Service and Maintenance ..................................................................................... 36
Periodic Retest Data Sheet.................................................................................................. 40
Triennial Service and Maintenance .................................................................................... 41
Quadrennial Service and Maintenance ............................................................................... 41
LIFTEM FIGURES .................................................................................................................... 42
FIGURE 1 ........................................................................................................................... 43
FIGURE 2 ........................................................................................................................... 44
FIGURE 3 ........................................................................................................................... 44
FIGURE 4 ........................................................................................................................... 44
FIGURE 5 ........................................................................................................................... 45
FIGURE 6 ........................................................................................................................... 46
FIGURE 7 ........................................................................................................................... 47
FIGURE 8 .......................................................................................................................... 49

MILLENNIUM MEDICAL PRODUCTS, INC.
1
CHAPTER 1
A. WHAT IS LIFTEM
1. Description
LIFTEM is an automated patient lift and transfer system. It has been designed to lift and
transfer patients weighing up to 700 lbs. from a bed to a chair, wheelchair and bedside
commode, gurney, and back WITHOUT MOVING THE LIFT. One person safely and
efficiently completes the lift and transfer. This is accomplished as the lift mechanism
rotates the patient from the bed to the desired receptacle with the touch of a remote
control button.
2. Why use LIFTEM
LIFTEM allows a single caregiver to safely and mechanically lift and transfer a patient
that might ordinarily require two or more caregivers. The only contact required between
patient and caregiver is the application and removal of the lifting sling. As a result,
LIFTEM reduces the instances of patient and caregiver injury and, because it is
unnecessary to move LIFTEM during the transfer procedure, the potential to tip over is
eliminated. Basic reasons for using LIFTEM include:
•Safely lifts and transfers a patient using just one caregiver
•Lifts and transfers a patient too heavy for manual transfer by caregivers
•Prevents injury to patients that could result during manual patient transfers caused
by unintended rough handling or accidents
•Prevents caregiver injuries, such as back strain, that can occur during the
lift/transfer
•Increases the efficient use of caregiver resources

MILLENNIUM MEDICAL PRODUCTS, INC.
2
B. CAPABILITIES OF LIFTEM
1. Maximum Lift and Transfer Capacity
The maximum lift and transfer capacity of LIFTEM is 700 lbs. This capacity is based on
the provision that the LIFTEM legs are fully OPEN AND EXTENDED. In addition,
LIFTEM must be setup properly with respect to its position around the bed, the patient,
and the patient receptacle. This aspect will be covered in detail in the later sections of
this manual. (See chapter 2)
2. Lift and Transfer Capabilities
LIFTEM can be setup to transfer a patient from a bed to a receptacle, such as a
wheelchair, and then back again without moving LIFTEM. LIFTEM is designed so the
lift mechanism is rotated electrically while the patient is suspended from the
MAST/BOOM. This requires that the receptacle which the patient is being transferred to,
be positioned properly with respect to LIFTEM. This procedure is described in detail
later in this manual. (See chapter 2)
LIFTEM can be used for the following, with the provision that the system is positioned
appropriately and that the legs of LIFTEM ARE COMPLETELY OPENED AND
EXTENDED.
•To lift and transfer a patient from a bed to a gurney and back
•To lift and transfer a patient from a bed to a wheelchair and back
•To lift and transfer a patient from a bed to a bedside commode and back
•To lift and transfer a patient from a wheelchair to a commode and back
•To lift a patient from any device to perform other caregiver functions such as
changing bed linen and weighing the patient using a scale attachment.

MILLENNIUM MEDICAL PRODUCTS, INC.
3
C. SAFETY PRECAUTIONS
READ OPERATING MANUAL AND VIEW THE TRAINING AND APPLICATION VIDEO BEFORE
ATTEMPTING TO USE LIFTEM TO LIFT AND TRANSFER A PATIENT!ONLY TRAINED CAREGIVERS
SHOULD USE LIFTEM. ALL CAREGIVERS MUST BE TRAINED ON THE USE OF THE SYSTEM BY A
KNOWLEDGEABLE PERSON.THIS IS MANDATORY.
FAILURE TO OBSERVE THE SETUP AND OPERATING INSTRUCTIONS CAN RESULT IN SERIOUS
INJURY TO THE PATIENT AND /OR THE CAREGIVER
1. When LIFTEM Can be Used
9Use LIFTEM only after proper training has been administered to the caregiver.
9Use LIFTEM to lift and transfer a person weighing less than 700 pounds.
9Use LIFTEM only after it is properly positioned and the REAR WHEEL CASTERS
ARE LOCKED and the LEGS FULLY OPEN AND EXTENDED.
9Use LIFTEM only to lift and transfer a person, NOT AS A TRANSPORTATION
DEVICE OR TREATMENT PLATFORM/STATION. (Never move LIFTEM,
attempt to apply CPR, or use an electronic defibrillator while a patient is suspended
from the MAST/BOOM in a lifting sling or on a stretcher.)
9Use LIFTEM only after the lifting sling has been properly fitted to the patient and
secured to the LIFTING BAR.
9Use LIFTEM only after explaining to the patient, the sequence of operations to be
performed and insuring his/her cooperation.
9Use LIFTEM always with the caregiver facing the patient, HOLDING AND
STEADYING THE SLING and holding the HANDSET.
9When moving the patient from left to right or reverse with a patient suspended from
the lift point always jog (rapidly press and release) the HANDSET.
2. When LIFTEM CANNOT be Used
LIFTEM should N Ne ev ve er rbe used under the following situations:
∅N Ne ev ve er ruse LIFTEM without a trained caregiver.
∅N Ne ev ve er ruse LIFTEM to lift and transfer a patient weighing over 700 pounds.
∅N Ne ev ve er ruse LIFTEM while the legs are CLOSED AND RETRACTED AND/OR THE
REAR WHEEL CASTERS ARE UNLOCKED.
! WARNING !

MILLENNIUM MEDICAL PRODUCTS, INC.
4
∅N Ne ev ve er r a at tt te em mp pt t t to o u us se e LIFTEM w wi it th h a a p pa at ti ie en nt t w wh ho o i is s a ag gi it ta at te ed d a an nd d/ /o or r u un nc co oo op pe er ra at ti iv ve e. .
∅N Ne ev ve er rmove LIFTEM with a patient suspended from the MAST/BOOM.
∅N Ne ev ve er r
p pu us sh h o or r p pu ul ll l o on n t th he e s sl li in ng g w wi it th h a a p pa at ti ie en nt t s su us sp pe en nd de ed d f fr ro om m t th he e M MA AS ST T/ /B BO OO OM M. .
∅N Ne ev ve er rmove LIFTEM with the legs OPEN or EXTENDED.
∅N Ne ev ve er rlift a patient without a caregiver positioned near him/her and having one hand
on the sling to steady the patient.
3. Things to Remember when Operating LIFTEM
Keep the following things in mind when you operate LIFTEM:
!Do not rush. - Used properly, LIFTEM will save time and help reduce
injury.
!Always follow operating instructions.
!Always make sure caregiver using LIFTEM is trained.
!Always stay within the operating limits of LIFTEM.
!Always use the system as a lift and transfer device and N NE EV VE ER RAS A
TRANSPORTATION DEVICE OR TREATMENT STATION.
!When moving LIFTEM, remember to CENTER the MAST/BOOM, always
RETRACT the legs, LOWER the BOOM, and SECURE the LIFTING
BAR.
!Always recharge the BATTERY after each use.
!Only operate on level surfaces.
!Always make sure the LIFTING BAR is attached to the proper LIFT
POINT for the weight of the patient being lifted (Figure 7).
!When rotating the BOOM from left to right, or reverse, with a patient
suspended from the LIFT POINT always JOG (rapidly press and release)
the HANDSET.
!The LIFTEM CONTROLLER has a 10% Duty Cycle. It should be allowed
to cool for at least 2 minutes after 18 minutes of continuous ACTUATOR
operation.

MILLENNIUM MEDICAL PRODUCTS, INC.
5
CHAPTER 2
STEP BY STEP OPERATION
1. General
This chapter will provide operating instructions for the use of LIFTEM
MARK IV to safely and efficiently lift and transfer a patient from one
location to another. LIFTEM is illustrated in Figures 1, 2 and 3 which
identify the main parts of the system (Figure 1), and the positions of the
LEGS for a safe lift and transfer (Figures 2 and 3).
Figure 2 shows LIFTEM with the LEGS closed and retracted. This
configuration can be used to move the system from location to location
but must not be used to lift and transfer a patient because it can be
unstable.
Figure 3 shows the LEG deployment that MUST be used for a safe lift and transfer of a
patient. Note: Unless the LEGS are FULLY OPEN AND EXTENDED, YOU WILL
NOT BE ABLE TO POSITION THE LIFTING ARM OVER THE PATIENT. In
this configuration the appropriate SLING is fitted to the patient. The BOOM and
LIFTING BAR are positioned over the patient to allow the SLING to be attached to the
ends of the LIFTING BAR. There is sufficient latitude in the motion of the BOOM (up
& down) and the MAST (rotate left and right) to allow a lift from a bed or from the floor.
LIFTEM must be located appropriately with respect to the position of the patient to be
lifted and the receptacle to which the patient is transferred. (See Figure 5).
Prior to using LIFTEM remember that LIFTEM is normally operated from a BATTERY
source. It is important to make sure the BATTERY is fully charged. In an emergency,
LIFTEM can be operated from a 115 Volt AC wall outlet by plugging the POWER
CORD into a standard power receptacle. If the CONTROLLER emits a Beep sound, it is
an indication that the BATTERY is low on charge. Use should be discontinued, the
POWER CORD should be connected and the BATTERY should be charged. 115 Volt
AC power is not to be used for normal operation. AC power should ONLY be used
in emergencies.

MILLENNIUM MEDICAL PRODUCTS, INC.
6
Some LIFTEM unit CONTROLLERS are equipped with an EMERGENCY STOP switch,
found on the upward facing end of the CONTROLLER (see photograph below). This
switch is to be pushed in the event of an unexpected occurrence during lift operation.
When pushed, the switch interrupts all power to the LIFTEM actuators and causes the
system to come to a complete stop. The CONTROLLER can be reset by turning the
switch knob in the clockwise direction.
Safety Precautions:
1) Prior to resetting the CONTROLLER verify that the patient is calm and is not caught
in any part of the Wheelchair/Bed, etc.
2) Verify that the LEGS are fully spread and extended.
3) Verify that the patient and any personnel assisting in the procedure being performed
with LIFTEM are clear of any moving parts around the BASE.
2. Lift and Transfer Patient From Bed
a) Preparing the Patient
•Explain the lift and transfer procedure to the patient prior to
starting.
•Select the proper sling and place it along the patient’s side.
•Roll the patient toward you and then position the sling flat next
to the patient. (See Chapter 5, Sling Manual.)
•Then allow the patient to roll back onto the sling.

MILLENNIUM MEDICAL PRODUCTS, INC.
7
b) Positioning LIFTEM
•Move the receiving device (chair, commode, and wheelchair) into
place at the side of the bed.
•Move LIFTEM, in the fully retracted position, into the room.
Position LIFTEM in the appropriate location around the bed. The
MAST/BOOM should be in the center position and with the
LIFTING BAR attached to the BOOM.
•Raise the BOOM to the horizontal position by pressing the BOOM -
UP button.
•Move LIFTEM so that one of the legs is inside the wheel or leg of
the bed. (Figure 5)
•Ensure the LIFTING BAR is secured to the proper LIFTING
POINT on the BOOM and ELEVATED, so that it does not interfere
with the patient.
•LOCK THE REAR WHEELS by pressing down on the caster lock
tabs.
•Locate the receiving device next to the bed and position it so that the
LIFTEM LEGS can be OPEN AND EXTENDED.
•SPREAD the LEGS to the maximum angle as shown in Figure 3.
This is accomplished by pressing the LEG SPREAD - OPEN button
(Figure 4). Both LEGS will rotate to the open position.
•After the LEGS are fully spread, EXTEND them by pressing the
LEG EXTEND - OUT button (Figure 4). Both LEGS will extend at
the same time. Continue to keep the button pressed until the LEGS
are fully extended (Figure 3).
•Activate the BOOM ROTATE SWITCHES (Right/Left) and
determine that the available swing will provide easy movement from
one position to another (Figure 5). Note: The BOOM will only
rotate within the distance between each EXTENDED LEG.
•Make the final adjustment of the receiver so that the lift and transfer
is within the range of motion of the MAST/BOOM assembly.
Safety Precautions:
1) LEGS must be fully spread and extended to prevent LIFTEM from tipping to
front or back or to either side.
2) BOOM will not rotate unless LEGS are fully spread and extended.
3) Keep hands free of BASE while extending and expanding LEGS.

MILLENNIUM MEDICAL PRODUCTS, INC.
8
c) Lifting the Patient
•Adjust the BOOM height using the BOOM LIFT - UP/DOWN buttons on the
HANDSET to position the LIFTING BAR and attach the sling straps onto the
hooks of the LIFTING BAR
•Position yourself to guide the patient during the lift and
transfer. This is done best by assuming a position inside
the open and extended legs of the lift and adjacent to the
bed and receiver.
•Raise the patient from the departure surface by pressing
the BOOM LIFT - UP button. Lift the patient high
enough so the transfer to the receiver can be made with
no restrictions.
•The patient will feel more secure if the caregiver is holding onto the sling straps
as the individual is lifted.
Safety Precautions:
1) Insure that LIFTING BAR remains clear of patient while lowering and
attaching sling.
2) Insure that patient is free of bed linens and limbs are free of bed frame prior
to lifting.
3) Insure that all sling straps are evenly (same color loop on right and left side)
and fully engaged on LIFTING BAR.
4) Insure that LIFTEM is clear and remains clear of any catheters or cables
connected to the patient.
5) Do not attempt to lift patient unless LIFTEM LEGS are fully spread and
extended.
6) Do not attempt to close or retract LIFTEM LEGS with patient suspended.
7) Never move the LIFTEM with patient suspended from BOOM.
8) Insure that the LIFTING BAR is secured to the proper LIFTING POINT on
the BOOM.

MILLENNIUM MEDICAL PRODUCTS, INC.
9
d) Transferring the Patient
•With one hand on the patient or sling as a guide, rotate
the patient to the receiver by rapidly pressing and
releasing the BOOM ROTATE – RIGHT or LEFT
button (Figure 4).
•The LEFT button will rotate the patient to the left and
the RIGHT button to the right as viewing the BOOM
from in front of LIFTEM away from the legs.
•Once positioned over the receiver, lower the patient onto the receiving surface by
pressing the BOOM LIFT - DOWN button.
Safety Precautions:
1) Steady patient while rotating BOOM to minimize patient discomfort and to
prevent LIFTEM unbalance due to swaying as boom rotates.
2) Insure that patient is clear and remains clear of receiving surface frame while
lowering.
3) Insure that any catheters or cables attached to patient do not become
entangled in the LIFTEM or the receiving device.
4) Do not attempt to move LIFTEM with patient suspended from BOOM.
5) Insure that LIFTING BAR remains clear of patient while lowering.
6) When rotating the BOOM from left to right, or reverse, with a patient
suspended from the LIFT POINT always jog (rapidly press and release) the
HANDSET to reduce tendency for patient to sway during rotation.
e) Completed Patient Transfer
•After the Patient has been successfully transferred, the SLING can remain in
place if the patient is to be transferred back to the bed or to another receiver in a
short time period. If this is the case, remove the sling straps from the LIFTING
BAR and leave the sling in place.
•To remove the SLING:
When the patient is in a wheelchair or on a commode,
uncross the lower sling straps, and remove the straps from
under the patients’ legs. Lean the patient forward and
gently pull the sling from under the patient.
•Be sure you are clear of the patient and then raise the BOOM by pressing the
BOOM LIFT - UP button high enough so the BOOM can be rotated out of the
way of the patient.

MILLENNIUM MEDICAL PRODUCTS, INC.
10
•Rotate the MAST/BOOM to the center position by pressing
the BOOM ROTATE button. As viewed from the front of the
lift, if the BOOM is to the left side press the RIGHT button
and if it is to the right side press the LEFT button. The BOOM
will automatically stop at the center position.
•Retract both LEGS by pressing the LEG EXTEND - IN
button.
•Close both LEGS by pressing the LEG SPREAD - CLOSE button.
•If the RECEIVER is in the way, unlock the rear wheel casters by
releasing the lock tabs on both casters and move the lift away from
the RECEIVER. Do so by pressing on the unlocking tab on the wheel brake using
your foot.
•Move LIFTEM out of the way of the gurney or wheelchair.
•With LIFTEM away from the patient, return the BOOM to its lowest position by
pressing the BOOM LIFT - DOWN button and return LIFTEM to its designated
storage area.
•Charge the BATTERY by plugging the 115 Volt AC Power cord into a wall
socket.
Safety Precautions:
1) Insure that LIFTING BAR remains clear of patient while lowering.
2) Keep hands free of BASE while closing and retracting LEGS.
3. Lift and Transfer Back to Bed
a) Positioning Patient and LIFTEM
The procedure to return the patient to the bed from the device in which the patient
resides is the opposite from section 2 (Lift and Transfer from Bed). The first step is
to position the patient by the bed such as follows:
•Place the wheelchair or commode by the bed.
•Retrieve LIFTEM from the storage area and position by
the bed and patient. Prior to properly setting up
LIFTEM, position the appropriate sling under the
patient.
FRONT
Wheelchair

MILLENNIUM MEDICAL PRODUCTS, INC.
11
•For a wheelchair or commode sling, lean the patient forward and place sling along
the rear of the patient. Gently pull lower part of sling under the patient’s legs.
Cross the sling straps in the center and attach to the LIFTING BAR. In certain
cases it may be practical to keep the sling on the patient while in the wheelchair or
on the commode.
•Using the LIFTEM HANDSET under battery power, setup LIFTEM as follows.
Position yourself by the patient when performing this function and hold the
HANDSET in one hand leaving the other hand free to maneuver.
•With the BOOM in the center position, elevate the BOOM above the height of the
patient with the LIFTING BAR attached to the proper LIFTING POINT on the
BOOM by pressing the BOOM LIFT - UP button.
•SPREAD the LEGS fully by pressing the LEG SPREAD - OPEN button.
•EXTEND the LEGS fully by pressing the LEG EXTEND - OUT button. The
BOOM can now be moved left or right, away from the patient, if necessary.
•Position LIFTEM so one of the LEGS is between the wheels of the receiver and
the other LEG under the bed. Figure 5 shows possible positions for LIFTEM
before the RECEIVER is in place.
•LOCK the REAR WHEEL CASTERS by pressing down on the caster lock tabs.
•Rotate the MAST/BOOM from over the bed to above the patient. Depending on
which side of the caregiver the bed is, use the appropriate BOOM ROTATE -
RIGHT or LEFT button.
•Make this movement with the BOOM at its highest position to assure it will not
interfere with the patient and the caregiver.
•When the BOOM is positioned above the patient, position the LIFTING BAR on
the BOOM and allow it to hang down making sure it does not interfere with the
patient and the caregiver.
•Lower the BOOM toward the patient by pressing the BOOM LIFT - DOWN
button.
•Attach the sling straps to the LIFTING BAR attachment.
•Now the patient is ready to be lifted and transferred to the bed.

MILLENNIUM MEDICAL PRODUCTS, INC.
12
Safety Precautions:
1) Insure that all sling straps are evenly (same color loop on right and left side)
and fully engaged on LIFTING BAR.
2) Insure that LIFTING BAR remains clear of patient while raising and
lowering boom and attaching sling.
3) Insure patient’s limbs remain clear of gurney or commode during lifting.
4) Insure that any catheters or cables attached to patient do not become
entangled in the LIFTEM or the receiving device.
5) Keep hands free of BASE while extending and expanding LEGS.
6) Do not attempt to lift patient unless LIFTEM LEGS are fully SPREAD and
EXTENDED.
7) Do not attempt to close or retract LIFTEM LEGS with patient suspended.
8) Do not attempt to move LIFTEM with patient suspended from BOOM.
9) Insure that the LIFTING BAR is secured to the proper LIFTING POINT on
the BOOM.
10) When rotating the BOOM from left to right, or reverse, with a patient
suspended from the lift point always jog (rapidly press and release) the
HANDSET to reduce tendency for patient to sway during rotation.
b) Patient Lift from Wheelchair or Commode
•Lift the patient from the gurney, wheelchair or commode by pressing
the BOOM LIFT - UP button.
•The caregiver should maintain the free hand on the patient to provide
added security and maneuverability.
•Lift the patient high enough so they will clear the bed.
•Rotate the patient over the bed by pressing the appropriate BOOM
ROTATE - RIGHT or LEFT button. If the patient is positioned to the
left of the bed the RIGHT button must be pressed.
•Steady patient while rotating boom to minimize discomfort and prevent lift
unbalance due to swaying as boom rotates.
•Now that the patient is positioned over the bed the transfer can be completed.

MILLENNIUM MEDICAL PRODUCTS, INC.
13
c) Transferring to Bed
•Lower the patient to the bed by pressing the BOOM LIFT - DOWN button on the
HANDSET.
•Once positioned on the bed remove the SLING from the LIFTING BAR
ATTACHMENT POINTS.
•Lift the BOOM to its highest position, by pressing the BOOM/MAST - UP
button.
•Remove the SLING.
•For a regular SLING roll the patient to one side and remove the SLING from
underneath the patient.
Safety Precautions:
1) While lowering insure that patient’s limbs remain clear of bed frame.
2) Insure that LIFTING BAR remains clear of patient while removing SLING.
3) Insure that any catheters or cables attached to patient do not become
entangled in the LIFTEM or the receiving device.
4) When rotating the BOOM from left to right, or reverse, with a patient
suspended from the LIFT POINT always jog (rapidly press and release) the
HANDSET to reduce tendency for patient to sway during rotation.
d) After Patient Transfer Completed
•Move the MAST/BOOM to the center position by pressing the
appropriate BOOM ROTATE - RIGHT or LEFT button.
•Retract the LEGS of LIFTEM by pressing the LEG EXTEND
- IN button. Close the LEGS by pressing the LEG SPREAD -
CLOSE button.
Note: Unless the BOOM is in the center position, it is not possible to retract
or close the LEGS.
•Unlock REAR WHEEL CASTERS by depressing the rear wheel caster lock tabs.
•Move LIFTEM away from the bed.
•Move the MAST/BOOM to its lowest position by pressing the BOOM DOWN
button.
•Remove LIFTEM to its storage area and charge the BATTERY.
Safety Precautions:
1) Insure that LIFTING BAR remains clear of patient while rotating BOOM.
2) Keep hands free of BASE while closing and retracting LEGS.

MILLENNIUM MEDICAL PRODUCTS, INC.
14
CHAPTER 3
USEFUL TIPS
1. Battery Operation
A BATTERY located on the BASE, powers LIFTEM. Through testing it has been
established that a fully charged BATTERY will allow the following is the approximate
number of patient lift and transfers to be completed before recharging:
•Patient weight - 150 pounds 70 lift and transfers
•Patient weight - 300 pounds 40 lift and transfers
•Patient weight - 700 pounds 30 lift and transfers
NOTE: A lift and transfer cycle is described as lifting a patient from the initial position to
the new position to which they will be transferred.
If CONTROLLER emits a Beep sound, it is an indication that BATTERY is low on
charge. Use should be discontinued, the POWER CORD should be connected to AC
Power and the BATTERY should be charged.
2. Operation by 115 Volt AC Power using Wall Socket
LIFTEM can also be operated using 115 Volt AC Power. Plug the POWER CORD into a
115 Volt AC wall socket and the system will operate as though it is on BATTERY
power. THIS METHOD OF POWERING LIFTEM SHOULD ONLY BE USED IN
EMERGENCIES.
3. Operation in Case of a Dead Battery or Loss of AC Electric Power
a) Dead Battery
In the event a patient is in the middle of a lift and transfer and the BATTERY looses
power, plug the POWER CORD into an 115 Volt AC outlet and LIFTEM can then be
operated.. AC POWER IS NOT TO BE USED FOR DURING NORMAL
OPERATION.
b) Loss of AC Power and a Dead Battery
LIFTEM cannot be operated if the BATTERY is dead and the AC Power is not
available. However, if loss of power occurs during a lift and transfer and a patient is
suspended, the patient can be lowered using a RED RELEASE BUTTON located on
the body of the LIFT ACTUATOR. Simply pull the RED RELEASE BUTTON
upward. It will move about one inch. Hold it in that position as the patient is slowly
lowered to a receiver. Once the patient is safely secured release the button. LIFTEM
cannot be used again until the BATTERY is recharged or until the 115 Volt AC
Power is restored.

MILLENNIUM MEDICAL PRODUCTS, INC.
15
4. Charging a Dead Battery
A 115 Volt AC Power source is required to recharge a dead or partially
discharged BATTERY. To recharge a dead BATTERY the AC
POWER CORD must be plugged into a 115 Volt AC wall socket. It will
take about 8 hours to fully recharge a dead BATTERY. It is
recommended that the power cord be plugged in to recharge the
BATTERY while LIFTEM is in storage. This will assure the user of a
fully charged system ready at all times.
5. Moving LIFTEM
LIFTEM is easily transportable. However it is highly recommended
that the following configuration be used when moving LIFTEM from
one location to another:
•The LEGS must be completely CLOSED
•The LEGS must be completely RETRACTED
•The BOOM must be in its lowest position
•The MAST/BOOM must be centered between the closed legs
In this configuration, LIFTEM can be pushed or pulled easily using the handles located
on the MAST. IN NO CASE SHOULD A PATIENT BE ON THE LIFT IN THIS
CONFIGURATION.
6. Assembly & Disassembly of LIFTEM
LIFTEM has been designed for ease of shipping and mobility where elevators are not
available and space is restricted. To accomplish this, LIFTEM can be easily
disassembled into subassemblies. Refer to the Assembly Instruction manual that has
been provided with this device.

MILLENNIUM MEDICAL PRODUCTS, INC.
16
7. Limited Warranty
Millennium Medical Products, Inc. (MMP) guarantees LIFTEM® to be free from defects
in materials and workmanship under normal use and service, for a period of one (1) year
from the date of purchase by the original purchaser, excluding the batteries, which are
warranted for six (6) months. This warranty is voided upon transfer of ownership of this
product. MMP agrees to repair or replace this product, at our discretion and at no charge,
within the warranty period provided the product is delivered to MMP in its original
packaging or the equivalent thereof; is fully insured with all shipping charges prepaid;
and that MMP consents the unit is defective. The repaired or replaced unit shall be
warranted for a period equal to the balance of the defective unit’s warranty period. A
handling charge of $35.00 will be applied to any returned product proven not to be
defective. For warranty service, please contact the dealer from whom you leased or
purchased your MMP LIFTEM®. NOTE: You must never return the product to your
dealer or to MMP at any time without the written consent of either party. To ensure the
best service to our customers, MMP requires the following information to be included
with a returned unit:
1. Serial Number and Model Number on the packaging.
2. An RGA form, obtained either from your dealer or directly from MMP.
3. A detailed description of the problem and its symptoms.
This warranty shall not apply to any product which has been repaired or altered in any
way so as, in our judgment, to affect its functionality and durability, nor to any products
subject to abuse, misuse, negligence or accident, improper maintenance, improper
installation, nor to any product used with other parts, components and/or accessories with
quality and/or specifications not compatible with this product. This warranty does not
cover products that have been impaired by occurrences considered Acts of God over
which MMP has no control. This warranty shall also be voided if any required periodic
maintenance, if applicable, has not been properly performed on this product.
This warranty and the aforementioned remedies offered are exclusive and in lieu of all
other express or implied warranties. No other representations or claims shall be binding
or obligate MMP in any way. Any warranty applicable to this product is limited to the
aforementioned period indicated. In no event shall MMP be liable for any special,
incidental, or consequential damages; loss of revenue; or cost of replacement goods;
resulting from the use or malfunction of this product to the associated equipment on or
with which it is used. This limited warranty statement gives the customer specific legal
rights. The customer/user may also have other rights, which may vary from state to state
in the United States, from province to province in Canada, and from country to country
elsewhere in the world.

MILLENNIUM MEDICAL PRODUCTS, INC.
17
CHAPTER 4
TROUBLESHOOTING GUIDE
1. General
This guide covers most of the normal electrical and control functional
problems that may occur during the operation of LIFTEM. The
location of the devices mentioned in this guide is shown on Figures No.
1 through 6 that are included in the “Operations Manual”.
When the system is delivered all of the cables, with the exception of the
LIFT ACTUATOR CABLE and the BATTERY CABLE, have been
connected to the CONTROLLER. As part of the “Assembly Instructions”
that are provided with LIFTEM, the LIFT ACTUATOR and the
BATTERY connections to the CONTROLLER are explained. If there is a
problem with the LIFT ACTUATOR not working, then repeat this
procedure.
NOTE: In order to protect the CONTROLLER circuitry, insure that the POWER CORD is
disconnected from the 115 Volt AC MAINS and that the BATTERY is unplugged from the
CONTROLLER prior to plugging in or unplugging and ACTUATOR cable.
It is very important that all of the input connections to the
CONTROLLER be made properly and that they are fully
seated into their terminals. These connectors are very
tight, as they have an “O-Ring” seal to prevent moisture
from entering the connector. To ease the installation of
these connectors, if they have been removed, it is
suggested that a small amount of lubricant, such as mineral
oil/liquid soap, etc., be applied around the “O-Ring”.
For any technical questions or support e-mail: [email protected]
