Mobilita M303 User manual

www.mobilita.in
TollFree : 1800 121 8485
Deluxe Heavy Duty
Drop-Arm Commode
code : M303
www.mobilita.in
TollFree : 1800 121 8485

Commode assembly
instructions and precautions
01. Remove all parts from box -
1 drop arm commode with seat and lid,
1 bucket with lid,
1 splash guard,
1 backrest, and 4 leg extensions.
02. To adjust the legs and seat height, place the seat
face down and depress the silver push button on one of
the legs of the commode and slide a leg extension over
it. Lengthen or shorten the leg extension to the desired
position. Once the desired position is found, ensure
that the silver push button protrudes from the adjust-
ment hole of the leg extension and is fully engaged so
that it does not move. Adjust the other three legs to the
same length, and make sure that the commode sits
level.
03. Lay the front end of the commode face down and
Insert the backrest into the tube slots under the seat.
Depress the silver push buttons on each side of the
backrest until they protrude from the adjustment hole
and are fully engaged into the user’s desired setting.
Ensure the silver push buttons are fully engaged by
pulling on the back.
04. Lift the seat and place the bucket in the center of
the commode in between the bucket hangers. When
using the commode over a toilet, replace the bucket
with the splash guard.
01. Lowering the drop arms: On the side of the arms,
push in the RED spring loaded release button and
push down on the drop arm.
Raising the drop arms: Pull up on the arms until the
RED spring loaded release button completely pops
out and is locked.
HOW TO USE YOUR
Drop Arm Commode
Weight Capacity : 136 Kg
Bucket & Lid
Back Rest Leg Extensions
Splash Guard
02. The commode should be low enough to ensure
that your feet touch the floor when sitting on it, but
high enough to enable easier sitting and standing.
03. After use, remove the bucket, discard waste and
sanitize.

01. Lowering the drop arms: On the side of the arms,
push in the RED spring loaded release button and
push down on the drop arm.
Raising the drop arms: Pull up on the arms until the
RED spring loaded release button completely pops
out and is locked.
Warranty
Your Mobilita branded product is warrantied to be free
of defects in materials and workmanship for the
product of the original consumer purchaser.
This device was built to exacting standards and
carefully inspected prior to shipment. This Warranty is
an expression of our confidence in the materials and
workmanship of our products and our assurance to the
consumer of years of dependable service.
This warranty does not cover device failure due to
owner misuse or negligence, or normal wear and tear.
The warranty does not extend to non-durable compo-
nents, such as rubber accessories, casters, and grips,
which are subject to normal wear and need periodic
replacement.
If you have a question about your Mobilita device or this
warranty, please contact an authorized Mobilita dealer.
© 2017 Eternity Distribution Pvt. Ltd. All rights reserved
Mobilita is a trademark of
Eternity Distribution Pvt. Ltd.
Chennai, Tamil Nadu, India | Made in China for Mobilita
[email protected] | TollFree 1800 121 8485
02. The commode should be low enough to ensure
that your feet touch the floor when sitting on it, but
high enough to enable easier sitting and standing.
03. After use, remove the bucket, discard waste and
sanitize.
