MOBILUS COSMO HM User manual

MOBILUS MOTOR Spółka z o.o.
ul. Miętowa 37, 61-680 Poznań, PL
tel. [phone], fax [phone]
VAT NO. PL9721078008
www.mobilus.pl
User manual of
COSMO | HM3+
Wersja 1.1ENG, 171020

1. GENERAL INFORMATION
COSMO | HM, COSMO | HM3+ is a 4-channel remote control, designed for remote control
receivers brand MOBILUS (radio remote controls for roller shutters, awnings, blinds / control
modules for motors without radio communication module / ON / OFF modules).
• Support 4 channels.
• Support 4 channel groups..
Remote COSMO | HM3+ - is a remote control with mechanical keyboard.
Please refer to the instruction manual that tells how to safely use the device. You are solely
responsible for any damages resulting from the using the device in a manner inconsistent
with its intended purpose. The manufacturer accepts no responsibility for damage or injury
caused by misuse, improper handling and running.
2. DESCRIPTION OF THE REMOTE CONTROL
2
1
COSMO | HM3+
4
3
1Display - channels / status.
2 Navigation ring.
3 Flap housing.
4 Battery compartment 2 x AAA.
Control button / navigation area LEFT.
Control button / navigation area RIGHT.
Control button / navigation area UP.
Control button / navigation area DOWN.
Control button / navigation area STOP.
2

3. CONTENTS OF THE PACKAGE
The packaging contains the following items:
• Remote COSMO | HM3+ .
• 2 AAA batteries in the remote control protected against discharging with a seal.
• User manual.
4. TECHNICAL PARAMETERS
• Radio protocol:COSMO / COSMO | 2WAY ( the remote does not support bidirectional com-
munication - it does not receive feedback messages, it sends commands to receivers).
• Frequency: 868 [MHz].
• Dynamic code.
• FSK modulation.
• The supply voltage 3,0 V DC .
• Power source: batteries 2 x AAA LR03.
• Working temperature [ oC ]: 0-40oC.
• Display: 3 x LED.
• Range in building: 40 [m]. The range of the radio signal depends on the type of construction,
used materials and placement of units. The transmition of the radio signal in different
conditions is as follows: brick wall 60-90%, reinforced concrete 2,060%, wooden structures
with sheets of plasterboard 80-95%, glass 80-90%, metal walls 0-10%.
• Dimensions of the remote control (without the handle): 49 x 16 x 125 mm.
5. POWER SUPPLY
The device is powered by two batteries AAA
LR03. To change the battery slide the bottom
flap down tight.
+ -
6. THE INITIAL COMMISSIONING
The device is factory protected against battery
wearing. To the deprotecion:
1. Open the battery cover.
2. Remove the seal Z, which protects the
batteries from discharging (marked
in white).
Z
3

7. READING OF REMOTE INTO THE MOTOR’S MEMORY
WARNING! Do not program the remote control when the shutter is in the extreme position
(top or bottom). Each program and changes of motor’s operation directions are confirmed by
two micro-movements of the driver.
Failure to comply with these rules may result in damage the blinds (inhaled by the housing).
Fig. 7.1
1 channel 2 channel 3 channel 4 channel
1. Press the / to select the appropriate channel - Fig. 8.1.
2. nter MOBILUS motor, serie R in the PROGRAMMING MODE OF MASTER REMOTE:
- press for 5 seconds PROGRAMMING BUTTON in the motor - Fig. 7.2a;
-
or double turn off and turn on the power supply od the motor - Fig. 7.2b;
T
he confirmation of properly performed operation will be two micro-movements of the motor driver - ( Fig.
7.2c );.
Fig. 7.2
ON OFFON OFF
2x
a b c
5 s.
WARNING! The first remote control readed into the receiver is a remote control MASTER. It
allows you to operate motor and enter it in the PROGRAM MODE OF OTHER REMOTES.
3. On the MASTER remote control simultaneously press the and - Fig. 7.3a.The LED
of the selected channel will flash - Fig. 7.3b. Hold the buttons until the motor driver will
perform two micro-movements confirming the input of the motor in the PROGRAM
MODE.
Fig. 7.3a Fig. 7.3b
4

8. READING IN OTHER REMOTE
1. On the MASTER remote control simultaneously press the and - rys. 8.1a. The LED
of the selected channel will flash - Fig. 8.1b. Hold the buttons until the motor driver will
perform two micro-movements confirming the input of the motor in the PROGRAM
MODE.
Fig. 8.1a
MASTER MASTER
Fig. 8.1b
MASTER
MASTER
On the second remote control, you
want to program, press the
and - Fig. 8.2c. Hold the buttons
until the motor driver will perform two
micro-movements - Fig. 8.2d. Another
remote was loaded into the motor.
rys. 8.2c
PILOT 02 PILOT 02
rys. 8.2d
a b c
4 s.
Within 20 sec. you can proceed to load the next remote. However, if no action of programming at this
time doesn’t happen, motor automatically returns to the OPERATING MODE. You can expedite return
to the OPERATING MODE manually using the remote control MASTER. In this case, press the button
on the and and hold more than 5 seconds. In both cases, return to the OPERATING MODE will
be confirmed by two micro-movements of the driver.
9. CHANGE OF MOTOR’S OPERATION DIRECTION
a cb
WARNING ! You can change the direction of the work of motor for MOBILUS drives with electronic
limit switches only before setting the upper and lower limit switches. You can change the direction
of work for the MOBILUS motors with mechanical limit switches at any time.
5

CONTINUED 9. CHANGE OF MOTOR’S OPERATION DIRECTION
After loading the remote control to the motor check that the buttons UP and DOWN
correspond to lifting and lowering the blinds. If not, press simultaneously buttons STOP and
DOWN and hold them for about 4 seconds on the remote control any loaded to the motor. The
confirmation of correctly performed operation are two micro-movements of the driver.
10. TRANSMISSION PROTOCOL SWITCHING COSMO - COSMO | 2WAY
Remote control COSMO | HM3+ works in latest version of radio communication
COSMO | 2WAY. COSMO | HM3+ is not a bi-directional remote, ie it is not possible to display
feedback.
f you need to change the mode to an older version (for example, if you purchase a new remote
control for older COSMO radio tubular motors), follow these instructions:
1. Use the / buttons to activate the remote control.
2. Press and hold for 20 seconds and buttons - Fig. 10.
3. When the LEDs at the bottom of the front panel light up, the corresponding communication
standard is activated:
- the latest radio communication COSMO | 2WAY
- previous communication COSMO
Fig. 10
> 20 s.
6

NOTES
7

WARRANTY
The manufacturer guarantees correct device functioning. The manufacturer also agree to repair or
replace device damaged if the damage results from defects in materials and construction.
The warranty is valid for 24 months from the date of purchase under the following conditions:
• Installation was made by a person authorized in accordance with the manufacturer’s instructions.
• Seals haven’t been breached and unauthorized design changes haven’t been made.
• The device was operated as intended by the user manual.
• Damage is not a result of the improperly performed electrical installation or any atmospheric
phenomena.
• The manufacturer is not responsible for damage resulting from misuse or mechanical
damage.
• In case of failure the device should be provided for repair with proof of purchase.
Defects found during the warranty period will be removed free for no longer than 14 working days
from the date of acceptance of device for repair. The manufacturer MOBILUS MOTOR Sp. z o.o.
carries on warranty repairs repairs. If you have any questions, please contact your dealer (please
provide the following information: event description, description of the error, the conditions under
which the accident occurred).
MAINTENANCE
1. For cleaning, use a soft cloth (eg. microfiber), moistened with water. Then wipe dry.
2. Do not use chemicals.
3. Avoid using in soiled and dusty environments.
4. Do not use the device at temperatures higher or lower than the declared range.
5. Do not open the device - otherwise the warranty shall be lost.
6. The device is sensitive to dropping, throwing.
ENVIRONMENTAL PROTECTION
This appliance is marked according to the European Directive on Waste Electrical and
Electronic Equipment (2002/96/EC) and further amendments. By ensuring this product
is disposed of correctly, you will help to prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate wa-
ste handling of this product. The symbol on the product, or the documents accompanying
the product, indicates that this appliance may not be treated as household waste. It shall
be handed over to the applicable collection point for the waste electrical and electronic
equipment for recycling purpose. For more information about recycling of this product,
please contact your local authorities, your household waste disposal service or the shop
where you purchased the product.
