1. General Information
About this Manual
Intended Use of this Manual
This manual describes the common use and maintenance procedures of the
Dansensor® MAP Check 3 Vacuum device.
It is intended for the daily users and should be kept with the equipment for reference at all
times.
Reservations
This manual was written and illustrated using the best possible information available at the
time of publication.
Any differences between this manual and the equipment reflect improvements introduced
after the publication of the manual.
Changes, technical inaccuracies and typographic errors will be corrected in subsequent
editions.
As a part of our policy of continuous improvement, we reserve the right to alter design and
specifications without further notice.
Important!
Safety and Use
Prior to using the equipment it is assumed that it has been properly installed and
configured as described in this manual.
The manufacturer cannot be held responsible for any damage caused by incorrect use of
this equipment.

8 User Guide EN Dansensor®MAP Check 3 Vacuum
P/N 320598-G
11/2019
Notes, cautions, warnings and tips!
Throughout the manual notes, cautions, and warnings are indicated with various icons and
written in bold like the example below:
CAUTION! Never use hard tools or abrasive materials when cleaning any part of the
device.
Explanation
NOTE! The operator should observe and/or act according to the information in
order to obtain the best possible function of the equipment.
CAUTION! The operator must observe and/or act according to the information in
order to avoid any mechanical or electrical damage to the equipment.
WARNING! The operator must observe and/or act according to the information in
order to avoid any personnel injury.
Tips and recommendations
Tips, recommendations and “best practise” advises are indicated as shown in the example
below:
TIP! If grille does not come off easily, you can use a screwdriver or the like to release it. 

Dansensor®MAP Check 3 Vacuum EN User Guide 9
P/N 320598-G
11/2019
Safety Instructions
Personnel operating and maintaining the device must be familiar with all aspects of its
operation and be proficient in maintenance.
Such personnel should review the following precautions to promote safety awareness.
General
Always refer to the manual before operating or maintaining the equipment.
Observe all WARNINGS, CAUTIONS and NOTES.
Do not open the device. In case of technical problems please contact your service provider.
Do not cover the machine with a cloth or piece of plastic to protect it from dust, as this
prevents free air circulation around the machine and might lead to overheating and errors
in the sensor read-out.
Do not expose the equipment to heavy moisture or heat and keep it away from direct
sunlight.
Never short circuit or remove safety devices.
Installation
To ensure the best installation with the least technical problems, please install equipment
as described in this manual.
Never install the equipment in explosive environments.
Always use correct fittings when connecting gas from the gas bottle.
Provide adequate space around the equipment for proper ventilation.
The units are Class 1 appliances and must be connected to an earthed mains connection.
It is the responsibility of the owner and operator(s) of the equipment, that the installation is
made in accordance with local rules and regulations.
When installing the equipment it is necessary to ensure proper ventilation in the room of
the installation in accordance with requirements from manufacturer.
The manufacturer cannot be held responsible for any damage caused by incorrect
installation of this equipment.
Operation and Maintenance
Be sure to disconnect electrical power and unplug the unit before performing any cleaning
or maintenance.
All panels and protective guards must be in place before operating the equipment.
When operating or maintaining the equipment always obey the relevant rules and
regulations for workers safety.
Repair or replace damaged power cords immediately.
Never block gas outlets.

10 User Guide EN Dansensor®MAP Check 3 Vacuum
P/N 320598-G
11/2019

Dansensor®MAP Check 3 Vacuum EN User Guide 11
P/N 320598-G
11/2019
2. Introduction
Dansensor® MAP Check 3 Vacuum
The Dansensor® MAP Check 3 Vacuum Vacuum is a gas analyser designed for measurement
of O2or O2/CO2concentrations on packaging machines that flushes gas in cycles controlled
by the packaging machine. This can either be a tray sealer or thermo former that uses vacuum
or a packaging machine that flushes gas over the product in a cycle, where the device is
connected to an external vacuum to enable measuring.
The device has no built-in pump and depends on external vacuum.
Depending on the version, the analyser measures oxygen (O2) and carbon dioxide (CO2)
simultaneously or only oxygen (O2).
For additional system quality control, all versions are available with built-in buffer tank
measurement capability to ensure proper mixture and pressure in the tank before start of
packaging. These models connect directly with a sample hose to the buffer tank and are
independent of tank pressure within the specified working range.
The device measures the O2or O2/CO2concentrations of gas in the die of the packaging
machine, immediately before it is sealed. This measuring method is, therefore, non-
destructive. The concentration of gas is measured for each packaging machine cycle.
The device will ensure the user a quality control of oxygen and carbon dioxide in the
packaging process, by observing critical points in the machine; gas concentration at die and if
used also quality of the buffer tank contents before start.
The device has a Diagnostics view that will facilitate running-in of the packaging machine for
new production. It gives a view to critical parameters of importance to the measuring cycle.
This reduces the number of laboratory tests required to make machine ready for production.
The device takes out the measuring gas from the product vacuum directly on the machine
vacuum die (or from the gas flushed in to a chamber if there is no vacuum in the packaging
machine). The results of this type of measurements are typically different from what is actually
measured in spot tests on packaged products. This is due to the fact that sample is taken
directly in the stream of gas in vacuum outlet of die.
Results from the device should be used as a process status indicator rather than exact
measurement of package contents. Combined with the buffer tank measuring capability this
increases the level of certainty that packages will be packed with correct gas concentrations.
Observation of changes in packaging machine can be made using the product warning and
alarm settings to alert user or machine that something is out of range.
The device is prepared to communicate with the packaging machine and is, therefore
typically a fully integrated part of the machine. Communication can be either RS232 or LAN
(Ethernet) using PSIP and Modbus TCP protocols.

12 User Guide EN Dansensor®MAP Check 3 Vacuum
P/N 320598-G
11/2019
“Stand-Alone” or “Black-Box”
The “Stand-Alone” devices features a 5” colour touch screen from which device settings are
made and measuring results are continuously displayed.
The “Black-Box” version without user interface is especially designed for cost effective
automated machine control. The “Black-Box”version can only be controlled from the
packaging machine or a connected PC.
Fig. 1. Dansensor® MAP Check 3 Vacuum “Black-Box” and “Stand-Alone” devices
Sensors
The devices can be fitted with both an O2sensor and a CO2sensor or an O2sensor only.
Mixer control
In combination with the Dansensor® MAP Mix Provectus gas mixer the device can fill a
buffer tank by letting Dansensor® MAP Check 3 Vacuum control the mixer. See "Mixer
Control" on page 30 for details.

Dansensor®MAP Check 3 Vacuum EN User Guide 13
P/N 320598-G
11/2019
Flow System
The figures below show the internal flow system of the various device versions.
Fig. 2 shows a standard version with O2sensor
Fig. 3 shows a standard version with both O2and CO2sensors.
Fig. 4 shows a buffer version with O2sensor. 
Fig. 5 shows a buffer version with both O2and CO2sensors.
Fig. 2.
Fig. 3.
Fig. 4.
Packaging Machine
EVACUATION
VALVE
GASSING
VALVE
VACUUM
GAS
BUFFER
V2
V1
VACUUM
CAL. GAS
INLET
AIR INLET SAMPLE
LOOP
SAMPLE GAS
INLET
O2
sensor
(Zr)
P1
V3
75
ml/min
5 l/min
@
sample
boost
sample
boost
V4
P2
DIE
Packaging Machine
EVACUATION
VALVE
GASSING
VALVE
VACUUM
V2
V1
VACUUM
CAL. GAS
INLET
AIR INLET SAMPLE
LOOP
SAMPLE GAS
INLET
O2
sensor
(Zr)
P1
V3V6
75
ml/min
5 l/min
@
sample
boost
sample
boost
CO2
sensor
(IR)
DIE
GAS
BUFFER
V4
P2
Packaging Machine
EVACUATION
VALVE
GASSING
VALVE
VACUUM
V2
V5
V1
VACUUM
CAL. GAS
INLET
BUFFER GAS
INLET
AIR INLET SAMPLE
LOOP
PROPORTIONAL
VALVE
SAMPLE GAS
INLET
O2
sensor
(Zr)
P1
P3
V3
75
ml/min
5 l/min
@
sample
boost
sample
boost
DIE
GAS
BUFFER
V4
P2

14 User Guide EN Dansensor®MAP Check 3 Vacuum
P/N 320598-G
11/2019
Fig. 5.
“Buffer“ version
The “Buffer “versions can measure the O2and CO2levels in the packaging machines buffer
tank. Doing this before start up ensures that the gas is OK before you start to pack the
product.
A hose is connected from the buffer tank to the "Buffer Gas Inlet" on the device. Please note
that the device will not be able to perform a proper measurement unless the pressure in the
buffer tank is within a certain range - see "7. Technical Information" on page 83 for further
details.
During a buffer measurement the device uses a normal sensor flow (75 ml/min).
The longer hose that is used and the higher pressure the longer it will take to get the correct
gas to the sensors. Therefore make the hose as short as possible. Do a test measurement to
find out how long time it takes for the gas to reach the sensor. Then ensure that the buffer
measure time is long enough.
No vacuum in the packaging machine
The Dansensor® MAP Check 3 Vacuum can be used even if there is no vacuum connected
inside the die of the packaging machine. To use the device in this way connect the evacuation
and gas signals so that the device gets the signals at the same time.
Packaging Machine
EVACUATION
VALVE
GASSING
VALVE
VACUUM
V2
V5
V1
VACUUM
CAL. GAS
INLET
BUFFER GAS
INLET
AIR INLET SAMPLE
LOOP
PROPORTIONAL
VALVE
SAMPLE GAS
INLET
O2
sensor
(Zr)
P1
P3
V3V6
75
ml/min
5 l/min
@
sample
boost
sample
boost
CO2
sensor
(IR)
DIE
GAS
BUFFER
V4
P2

Dansensor®MAP Check 3 Vacuum EN User Guide 15
P/N 320598-G
11/2019
Overview
5" touch panel color display (“Stand-Alone” versions only)
For intuitive operation of the device by use of explanatory icons and easy
understandable text messages and buttons.
USB host 
For connection of a memory stick (“Stand-Alone” versions only)
The connector is fitted with a water-proof cover.
All versions have a USB connector on the backside of the device as well.
ON/Status indicator (“Black-Box” versions only)
When lit power is on.
Colour/light combinations indicate the following:
• Green - steady “Autostart” disabled
• Green - flashing Ready
• Red - flashing (every 2 sec) Heating
• Red - flashing (twice per sec.) Error



.FBU.JYHS
.FBTVSF.FOV1SPEVDU


3FBEZ
#VGGFS

0
$0
CBS
0


$ZDMFT




&2 
%DO
2


..1
'BVMUT
EJTBCMFE
7BDVVN
7BDVVN

16 User Guide EN Dansensor®MAP Check 3 Vacuum
P/N 320598-G
11/2019
”POWER”
Power supply connector
Cooling air inlet grille
With dust filter and a fan inside the device
Cooling air outlet grille
With dust filter
“I/O CONTROL”
Communication port (D-SUB 25) for packaging machine control signals
“COM1”
RS232 port (D-SUB 9) for connection to packaging machine or external data collection
via PC software (SDK-PSIP)
“COM2”
RS232 port (D-SUB 9) for control of MAP Mix Provectus gas mixer and for connection to
terminal server for configuration (“Black-Box”).
LAN/Ethernet port 
Connection to local computer network for
- external data collection (LAN Data dump)
- communication with PC software (SDK-PSIP)
- Modbus TCP communication with packaging machine
The port has 2 built-in status indicator LED’s
USB host 
For connection of a memory stick
“Stand-Alone”versions have a USB connector on the device front as well.





Dansensor®MAP Check 3 Vacuum EN User Guide 17
P/N 320598-G
11/2019
Gas connections
“VACUUM”
Vacuum connector
“SAMPLE GAS INLET”
Connector for sample gas from packaging machine die
“AIR INLET”
For pressure equalisation with atmospheric air or for exhaust of bypass flow when
measuring on the buffer tank and when calibrating
“CAL. GAS INLET”
Only used when calibrating
“BUFFER GAS INLET”
Buffer tank connection (“Buffer” versions only)
  



18 User Guide EN Dansensor®MAP Check 3 Vacuum
P/N 320598-G
