Modbus IOG700AM-0xCR1 User manual


ModbusCellularGateway
IOG700AM‐0xCR1

UserManual

ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
2

Chapter1Introduction...................................................................................................................................6
1.1Introduction........................................................................................................................................6
1.2ContentsList.......................................................................................................................................7
1.2.1PackageContents..................................................................................................................7
1.3HardwareConfiguration.................................................................................................................8
1.4LEDIndication.................................................................................................................................11
1.5InstallationRequirement..............................................................................................................12
1.5.1WARNING...........................................................................................................................12
1.5.2SYSTEMREQUIREMENTS..............................................................................................12
1.6HardwareInstallation....................................................................................................................13
1.6.1MounttheUnit...................................................................................................................13
1.6.2InserttheSIMCard...........................................................................................................13
1.6.3ConnectingPower.............................................................................................................14
1.6.4ConnectingDI/DODevices............................................................................................15
1.6.5ConnectingSerialDevices...............................................................................................16
1.6.6ConnectingtotheNetworkoraHost..........................................................................16
Chapter2GettingStarted...........................................................................................................................17
2.1Wizard..............................................................................................................................................17
NetworkSetupWizard................................................................................................................17
VPNSetupWizard........................................................................................................................26
2.3Status................................................................................................................................................32
2.3.3NetworkStatus..................................................................................................................32
2.3.7ClientList.............................................................................................................................40
2.3.9FirewallStatus....................................................................................................................41
2.3.bVPNStatus..........................................................................................................................45
2.3.dSystemMgmt.Status........................................................................................................48
Chapter3BasicNetwork............................................................................................................................50
3.1WAN..................................................................................................................................................50
3.1.1PhysicalInterface...............................................................................................................51
3.1.3InternetSetup.....................................................................................................................63

ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
3

3.3LAN&VLAN...................................................................................................................................73
3.3.1EthernetLAN.......................................................................................................................73
3.3.3VLAN.....................................................................................................................................73
3.7IPv6...................................................................................................................................................89
3.7.1IPv6Configuration.............................................................................................................93
3.9NAT/Bridge................................................................................................................................100
3.9.1NATConfiguration..........................................................................................................100
3.9.3VirtualServer&VirtualComputer...............................................................................104
3.9.5SpecialAP&ALG.............................................................................................................
112
3.9.7DMZ&PassThrough......................................................................................................119
3.bRouting...........................................................................................................................................122
3.b.1StaticRouting....................................................................................................................122
3.b.3DynamicRouting..............................................................................................................127
3.b.5RoutingInformation........................................................................................................139
3.dClient&Server&Proxy.............................................................................................................140
3.d.1DNS&DDNS....................................................................................................................140
3.d.3DHCPServer.....................................................................................................................145
Chapter5AdvancedNetwork..................................................................................................................150
5.1Firewall...........................................................................................................................................150
5.1.1FirewallConfiguration....................................................................................................150
5.1.3PacketFilters....................................................................................................................151
5.1.5URLBlocking.....................................................................................................................158
5.1.9WebContentFilters........................................................................................................164
5.1.bMACControl.....................................................................................................................169
5.1.dApplicationFilters............................................................................................................174
5.1.fIPS.........................................................................................................................................178
5.1.hOptions...............................................................................................................................183
5.3QoS&BWM.................................................................................................................................188
5.3.1Configuration....................................................................................................................188
5.3.3Rule‐basedQoS................................................................................................................191

ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
4

5.5VPN..................................................................................................................................................205
5.5.1Configuration....................................................................................................................205
5.5.3IPSec...................................................................................................................................207
5.5.5PPTP....................................................................................................................................227
5.5.7L2TP....................................................................................................................................239
5.5.9GRE......................................................................................................................................252
5.5.dOpenVPN...........................................................................................................................260
5.7Redundancy...................................................................................................................................276
5.7.1VRRP...................................................................................................................................276
5.9SystemManagement..................................................................................................................280
5.9.1TR‐069................................................................................................................................280
5.9.3SNMP..................................................................................................................................284
5.9.5TelnetwithCLI.................................................................................................................295
5.9.7UPnP...................................................................................................................................298
5.bCertificate.......................................................................................................................................301
5.b.1Configuration....................................................................................................................301
5.b.3MyCertificates.................................................................................................................303
5.b.5TrustedCertificates.........................................................................................................310
5.b.7IssueCertificates..............................................................................................................316
5.dCommunicationBus....................................................................................................................321
5.d.1PortConfiguration...........................................................................................................321
5.d.3VirtualCOM......................................................................................................................323
5.d.5Modbus..............................................................................................................................334
5.d.9DataLogging.....................................................................................................................349
Chapter7Applications................................................................................................................................351
7.1MobileApplication.......................................................................................................................351
7.1.1SMS.....................................................................................................................................351
7.1.3USSD...................................................................................................................................355
7.1.5NetworkScan...................................................................................................................359
7.1.7SMSManagement...........................................................................................................361

ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
5

7.5CaptivePortal...............................................................................................................................370
7.5.1Configuration....................................................................................................................370
Chapter9System........................................................................................................................................376
9.1SystemRelated.............................................................................................................................376
9.1.1SystemRelated.................................................................................................................376
9.1.3PacketAnalyzer................................................................................................................384
9.3Scheduling.....................................................................................................................................387
9.7Grouping........................................................................................................................................389
9.9ExternalServers...........................................................................................................................392
9.bMMI.................................................................................................................................................395


ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
6

Chapter1Introduction
1.1Introduction
Congratulations on your purchase of this outstanding product: Modbus Cellular Gateway. For
M2M (Machine-to-Machine) applications, AMIT Modbus Cellular Gateway is absolutely the
right choice. With built-in world-class 3G HSPA+ or 4G LTE module, you just need to insert
SIM card from local mobile carrier to get to Internet. The redundant SIM design provides a
more reliable WAN connection for critical applications. By VPN tunneling technology, remote
sites easily become a part of Intranet, and all data are transmitted in a secure (256-bit AES
encryption) link. To meet a variety of M2M application requirements, AMIT Modbus Cellular
Gateway products are based on modular design. A new functional module can replace current
one to support new application in short time, such as for NFC or GPS applications.

This IOG700AM series product is loaded with luxuriant security features including VPN, firewall,
NAT, port forwarding, DHCP server and many other powerful features for complex and
demanding business and M2M (Machine-to-Machine) applications. The redundancy design in
fallback 9-48 VDC power terminal, dual SIM cards and VRRP function makes the device as a
back-up in power, network connection and data transmission without lost.

MainFeatures:
Provide3G/LTEWANconnection.
SupportdualSIMsfortheredundantwirelessWANconnection.
ProvideoneEthernetportforcomprehensiveLANconnection.
FeaturewithVPNandNATfirewalltohavepowerfulsecurity.
Supporttherobustremoteorlocalmanagementtomonitornetwork.
Designedbysolidandeasy‐to‐mountmetalbodyforbusinessandM2Menvironmenttowork
withavarietyM2M(Machine‐to‐Machine)applications.

Beforeyouinstallandusethisproduct,pleasereadthismanualindetailforfullyexploitingthe
functionsofthisproduct.


ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
7

1.2ContentsList
1.2.1PackageContents
#StandardPackage

ItemsDescriptionContentsQuantity
1IOG700AM‐0TCR1
ModbusCellularGateway1pcs
2 Cellular Antenna 2pcs
3 Power Adapter
(DC 12V/1A)
(*1)
1pcs
4 RJ45 Cable 1pcs
5 Console Cable
1pcs
6 CD
(Manual) 1pcs
7 Mounting Bracket
2pcs
8 DIN‐RailBracket

1pcs



1ThemaximumpowerconsumptionofIOG700‐0TCR1is7W.

ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
8

1.3HardwareConfiguration
FrontView













※ResetButton
TheRESETbuttonprovidesuserwithaquickandeasywaytoresortthedefaultsetting.PresstheRESET
buttoncontinuouslyfor6seconds,andthenreleaseit.Thedevicewillrestoretofactorydefault
settings.








A
utoMDI/MDIXRJ45 Ports
1xFELANtoconnectlocaldevices
Reset
Button
LED
Indicators
3G/LTE
Antenna

ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
9

BottomView





LeftView 










SIMA
Slot
SIMB
Slot
3G/LTE(Aux)
Antenna
3G/LTE(Main)
Antenna
PowerTerminal
Block

ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
10

 RightView 















Serial
Port
SD
Card
DI/DO
TerminalBlock

ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
11

1.4LEDIndication


LEDIconIndicationLEDColorDescription
PowerSource1GreenSteadyON:Deviceispoweredonbypowersource1

PowerSource2
(*2)GreenSteadyON:Deviceispoweredonbypowersource2

SIMA
(*3)GreenSteadyON:SIMcardAischosenforconnection
SIMBGreenSteadyON:SIMcardBischosenforconnection
HighCellularSignalGreenSteadyON:ThesignalstrengthofCellularisstrong
LowCellularSignalGreenSteadyON:ThesignalstrengthofCellularisweak
LANGreen
SteadyON:EthernetconnectionofLANWANis
established
Flash:Datapacketsaretransferred
SerialPortGreenSteadyON:Ifserialdeviceisattached

2Ifbothofpowersource1andpowersource2areconnected,thedevicewillchoosepowersource1first.The
LEDofpowersource2willremainOFFatthiscondition.
3TheSIMLEDindicateswhichSIMsocketwillbechosenforconnectionbysystemsetting,nomatterSIMcardis
insertedornot.

ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
12

1.5InstallationRequirement
1.5.1WARNING




1.5.2SYSTEMREQUIREMENTS
NetworkRequirements
AnEthernetRJ45cableorDSLmodem
3Gcellularservicesubscription
IEEE802.11nor802.11b/gwirelessclients
10/100EthernetadapteronPC
Web‐basedConfigurationUtility
Requirements
Computerwiththefollowing:
Windows®,Macintosh,orLinux‐basedoperating
system
AninstalledEthernetadapter
BrowserRequirements:
InternetExplorer6.0orhigher
Chrome2.0orhigher
Firefox3.0orhigher
Safari3.0orhigher






Do not use the product in high humidity or high
temperatures.
Only use the power adapter that comes with the
package. Using a different voltage rating power
adaptor is dangerous and may damage the product.
Do not open or repair the case yourself. If the
product is too hot, turn off the power immediately
and have it repaired at a qualified service center.
 Pl
ace
t
h
e
p
r
oduct
o
n
a
stab
l
e
su
rf
ace
a
n
d
a
v
o
i
d

Attention


ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
13

1.6HardwareInstallation
Thischapterdescribeshowtoinstallandconfigurethehardware

1.6.1MounttheUnit
The IOG700AM series can be placed on a desktop, mounted on the wall or mounted on a DIN-
rail. The DIN-rail bracket is not screwed on the product when out of factory. Please screw the
DIN-rail bracket on the product first if necessary.
1.6.2InserttheSIMCard
WARNNING:BEFOREINSERTINGORCHANGINGTHESIMCARD,PLEASEMAKESURETHATPOWEROF
THEDEVICEISSWITCHEDOFF.
TheSIMcardslotsarelocatedatthebottomsideofIOG700 serieshousinginordertoprotecttheSIM
card.YouneedtounscrewandremovetheouterSIMcardcoverbeforeinstallingorremovingtheSIM
card.PleasefollowtheinstructionstoinsertaSIMcard.AfterSIMcardiswellplaced,screwbackthe
outerSIMcardcover.







  







Step1:
Followredarrowto
unlockSIMsocket

Step2:
LiftupSIMholder,
andinsertSIMcard

Step3:
PutbackSIMholder,and
followredarrowtolock
SIMsocket

ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
14

1.6.3ConnectingPower
The IOG700AM series can be powered by connecting one or two power sources to the
terminal block. It supports dual 9 to 48VDC power inputs4. Following picture is the power
terminal block pin assignments and it is located at the right side of device. Please check
carefully and connect to the right power requirements and polarity.



ThereareaDCconverterandaDC12V/1Apoweradapter5inthepackageforyoutoeasilyconnectDC
poweradaptertothisterminalblock.


WARNNING:Thiscommercial‐gradepoweradapterismainlyforeaseofpoweringupthepurchased
devicewhileinitialconfiguration.It’snotforoperatingatwidetemperaturerangeenvironment.
PLEASEPREPAREORPURCHASEOTHERINDUSTRIAL‐GRADEPOWERSUPPLYFORPOWERINGUPTHE
DEVICE.

 

4Ifbothofpowersource1andpowersource2areconnected,thedevicewillchoosepowersource1first.If
poweroutageoccurredfrompowersource1,thisdevicewillswitchtopowersource2automaticallyand
seamlessly.
5ThemaximumpowerconsumptionofIOG700‐0TCR1is15.5W.

ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
15

1.6.4ConnectingDI/DODevices
ThereareaDIandaDOportstogetherwithpowerterminalblock.Pleaserefertofollowing
specificationtoconnectDIandDOdevices.

ModeSpecification
DigitalInputTriggerVoltage(high)Logiclevel1:5V~30V
NormalVoltage(low)Logiclevel0:0V~2.0V
DigitalOutput
Voltage
(RelayMode)
Dependsonexternaldevice
maximumvoltageis30V
MaximumCurrent1A

ExampleofConnectionDiagram





ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
16

1.6.5ConnectingSerialDevices
The IOG700AM provides one standard serial port RJ12 female connector and one RJ12 to
DB9 conversion cable. Connect the serial device to the unit DB9 male port with the right pin
assignments of RS-232/485 are shown as below.

Pin1Pin2Pin3Pin4Pin5Pin6Pin7Pin8Pin9
RS‐232DCDRXDTXDDTRGNDDSRRTSCTSRI
RS‐485  DATA+DATA‐ GND

1.6.6ConnectingtotheNetworkoraHost
The IOG700AM series provides one RJ45 port to connect 10/100Mbps Ethernet. It can auto
detect the transmission speed on the network and configure itself automatically. Connect one
Ethernet cable to the RJ45 port (LAN) of the device on the front panel and plug another end of
the Ethernet cable into your computer’s network port. In this way, you can use the RJ45
Ethernet cable to connect the IOG700AM series to the host PC’s Ethernet port for configuring
or troubleshooting the device.



ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
17

Chapter2GettingStarted
2.1Wizard

NetworkSetupWizard

WiredRouterNetworkSetupWizardwillguideyouthroughabasicconfigurationprocedurestep
bystep.

Step‐2istochangeyourloginpassword.
GotoWizard>NetworkSetupWizard>Step‐2


Item ValuesettingDescription
OldPassword1.Stringformat:anytextIfyouwanttochangepassword,Enterthecurrentpasswordinthisitem.
NewPassword1.Stringformat:anytextEnterthenewpassword.
NewPassword
Confirmation
Theboxisuncheckedby
defaultEnterthenewpasswordtore‐confirm.
ExitNAClicktheExitbuttontocancelSetupWizard.
BackNAClicktheBackbuttontogotothepreviousstep.
NextNAClicktheNextbuttontogotothenextstep.



ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
18

Step‐3istochangethetimezone.
GotoWizard>NetworkSetupWizard>Step‐3


Item ValuesettingDescription
Timezonelist1.AMustfilledsettingSelectthetimezoneforthesystemclock.
DetectAgainNAClicktheDetectAgainbuttontodetectthetimezonefromnetwork.
ExitNAClicktheExitbuttontocancelSetupWizard.
BackNAClicktheBackbuttontogotothepreviousstep.
NextNAClicktheNextbuttontogotothenextstep.

Item ValuesettingDescription
RuleName
1.Stringformat:anytext
2.AMustfilledsetting
3.BydefaultAlwaysisselected.
4.Theboxisuncheckedbydefault.
5.NA



ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
19

Step4.InternetConnection(WANInterfaceSetting)
InthisstepoftheWizardyouwillbespecifyinghowyourrouterconnectstotheInternetbyselecting
theappropriatePhysicalInterfaceandWANType.Fordetailsettings,refertothefollowingpagesfor
yourrequiredsettings.

GotoWizard>NetworkSetupWizard>Step4.WANinterface



Step4.WANinterfaceSetting
Item ValuesettingDescription
PhysicalInterfaceAMustfilledsetting
HereyouspecifythePhysicalInterfacethatconnectsyourroutertotheInternet.
ThetypeofavailableInterfaceswilldependontheroutermodel.Theyarenormally
theEthernetportandthe3G/4Gwirelessinterface.
WANTypeAMustfilledsettingChoosetheWANtypefortheselectedPhysicalInterfaceabove.
BackN/AClickBackbuttontogotopreviousstep
NextN/AClickNextbuttontogotonextsub‐steps


ModbusCellularGateway
Indexskippingisusedtoreserveslotsfornewfunctioninsertion,whenrequired.
20

PhysicalInterface:Ethernet
WANType:DynamicIPAddress


DynamicIPSettings
Item ValuesettingDescription
HostNameAnoptionalsettingEnterthehostnameprovidedbyyourServiceProvider.
ISPRegisteredMAC
AddressAnOptionalsetting
EntertheMACaddressthatyouhaveregisteredwithyourserviceprovider.OrClick
theClonebuttontocloneyourPC’sMACtothisfield.
UsuallythisisthePC’sMACaddressassignedtoallowyoutoconnecttoInternet.
BackN/AClickBackbuttontogotopreviousstep
NextN/AClickNextbuttontogotonextstep
