Modbus HD67736-A1 User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 1 of 25
User Manual
Revision 1.000
English
IEC 61850 Server / Modbus TCP Slave -
Converter
(Order Code: HD67736-A1 )
For Website information:
www.adfweb.com? roduct=HD67736
For rice information:
www.adfweb.com? rice=HD67736-A1
Benefits and Main Features
Very easy to configure
Triple Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
For other IEC 61850 server products see also the following link:
Converter IEC 61850 Server to
www.adfweb.com? roduct=HD67733 (Modbus Master)
www.adfweb.com? roduct=HD67734 (Modbus Slave)
www.adfweb.com? roduct=HD67735 (Modbus TCP Master)
www.adfweb.com? roduct=HD67737 (BACnet Master)
www.adfweb.com? roduct=HD67738 (BACnet Slave)
www.adfweb.com? roduct=HD67739 (CAN)
www.adfweb.com? roduct=HD67740 (CANopen)
www.adfweb.com? roduct=HD67741 (DeviceNet Master)
www.adfweb.com? roduct=HD67742 (DeviceNet Slave)
www.adfweb.com? roduct=HD67743 (EtherNet/IP Master)
www.adfweb.com? roduct=HD67744 (EtherNet/IP Slave)
www.adfweb.com? roduct=HD67745 (J1939)
www.adfweb.com? roduct=HD67746 (KNX)
www.adfweb.com? roduct=HD67747 (MQTT)
www.adfweb.com? roduct=HD67748 (NMEA 0183)
www.adfweb.com? roduct=HD67749 (NMEA 2000)
www.adfweb.com? roduct=HD67750 (PROFIBUS Master)
www.adfweb.com? roduct=HD67751 (PROFIBUS Slave)
www.adfweb.com? roduct=HD67B82 (PROFINET Master)
www.adfweb.com? roduct=HD67752 (PROFINET Slave)
www.adfweb.com? roduct=HD67753 (SNMP Manager)
www.adfweb.com? roduct=HD67754 (SNMP Agent)
www.adfweb.com? roduct=HD67755 (Serial)
www.adfweb.com? roduct=HD67756 (Ethernet)
Do you have your customer protocol? Then go to:
www.adfweb.com? roduct=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 2 of 25
INDEX
age
INDEX 2
U DATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAM LE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
OWER SU LY 7
FUNCTION MODES 8
LEDS 9
ETHERNET 10
USE OF COM OSITOR SW67736 11
NEW CONFIGURATION / O EN CONFIGURATION 12
SOFTWARE O TIONS 13
SET COMMUNICATION 15
IEC 61850 ACCESS 17
TLS KNOWN CERTIFICATE 18
U DATE DEVICE 19
MODBUS MA 21
MECHANICAL DIMENSIONS 22
ORDERING INFORMATIONS 23
ACCESSORIES 23
DISCLAIMER 24
OTHER REGULATIONS AND STANDARDS 24
WARRANTIES AND TECHNICAL SU ORT 25
RETURN OLICY 25
UPDATED DOCUMENTATION
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST
WARNING
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS
All trademarks mentioned in this document belong to their respective
owners.
Revision Date Author Chapter Description
1.000 18/09/2020 Ff All First Release

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 3 of 25
SECURITY ALERT
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 4 of 25
EXAMPLE OF CONNECTION

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 5 of 25
CONNECTION SCHEME
Figure 1: Connection scheme for HD67736-A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 6 of 25
CHARACTERISTICS
The HD67736-A1 are IEC 61850 / Modbus TC Slave - Converters.
It allows for the following characteristics:
Isolation between Ethernet - ower Supply;
Two-directional information between IEC 61850 bus and Modbus TC bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION
You need Compositor SW67735 software on your C in order to perform the following:
Define the parameters of IEC 61850 line;
Define the parameters of Modbus TC line;
Define IEC 61850 variables to read and write;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 7 of 25
POWER SUPPLY
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67736-A1 3.5
HD67736-A1
Caution
Do n
ot reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 8 of 25
FUNCTION MODES
The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for uploading the roject and/or Firmware.
For the operations to follow for the updating, see ‘U DATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 9 of 25
LEDS
The device has got six LEDs that are used to give information about the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: ON [supply voltage ]
(green)
ON Device powered
OFF Device not powered
ON Device powered
OFF Device not powered
2: Device State (green) Blinks slowly (~1Hz) Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in progress
3: IEC 61850 communication
(green) It blinks when a IEC 61850 request is received Blinks quickly Boot state Blinks very slowly (~0.5Hz) update in progress
4: Modbus communication
(green) It blinks when a Modbus TC request is received Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in progress
5: Ethernet1 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in progress
6: Ethernet2 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in progress

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 10 of 25
ETHERNET
IEC 61850 and Modbus TC connection and the updating of the converter must be made using Connector3 and/or Connector4 of the
HD67736-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the
T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight
cable, to connect the device to a C/ LC/other is recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 11 of 25
USE OF COMPOSITOR SW67736
To configure the Converter, use the available software that runs with Windows called SW67736. It is downloadable on the site
www.adfweb.com and its operation is described in this document. ( his manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (X , Vista, Seven, 8, 10; 32/64bit).
When launching the SW67736, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main window for SW67736

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 12 of 25
NEW CONFIGURATION / OPEN CONFIGURATION
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “IEC 61850 Server / Modbus TC Slave
- Converter” in order to configure another device in the same manner, it is necessary
to maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 13 of 25
SOFTWARE OPTIONS
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67736 checks automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 14 of 25
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 15 of 25
SET COMMUNICATION
This section define the fundamental communication parameters of two buses, IEC 61850
and Modbus TC .
By ressing the “Set Communication” button from the main window for SW67736 (Fig. 2)
the window “Set Communication” appears (Fig. 3).
The means of the fields for “IEC61850 Server” are:
In the fields “IP Address” the I address for IEC 61850 side of the converter is
defined;
In the fields “SubNet Mask” the SubNet Mask for IEC 61850 side of the converter is
defined;
In the fields “Gateway” the default gateway of the net is defined. This feature can
be enabled or disabled pressing the Check Box field. This feature is used for going
out of the net;
In the field “Port” the port used for IEC 61850 communication is defined;
If the field “Password” the password used for accessing to IEC 61850 variables is
defined.
The means of the fields for “TLS” are:
If the field “Enable TLS” is checked, the TLS protocol for secure connection is
enabled;
In the field “Key” the key for the authentication is defined;
In the field “Key Password” the password for decrypting the key is defined;
In the field “Server Certificate” the certificate for the server is defined;
In the field “Root Certificate” the root of the server is defined;
If the field “Enable Only Known Certificates” is checked, the converter will accept
just connection from known Clients (defined in the section “TLS Known Certificate”).
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 16 of 25
The means of the fields for “Modbus TC Slave” are:
In the fields “IP Address” the I address for Modbus TC side of the converter is defined;
In the fields “SubNet Mask” the SubNet Mask for Modbus TC side of the converter is defined;
In the fields “Gateway” the default gateway of the net is defined. This feature can be enabled or disabled pressing the Check Box
field. This feature is used for going out of the net;
In the field “Port” the port used for Modbus TC communication is defined.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 17 of 25
Figure 4: “IEC 61850 Access” window
IEC 61850 ACCESS
By ressing the “IEC 61850 Access” button from the main window for SW67736 (Fig. 2) the window “Set Variables Access for IEC 61850”
appears (Fig. 4).
This section is used to define the IEC 61850 variables from/to which take/map the data of Modbus TC map.
The means of the fields are:
If the field “Enable” is checked, the IEC 61850 variable is enabled;
In the field “Name” the name of the IEC 61850 variable is defined;
In the field “Type” the data format of the IEC 61850 variable is defined;
If the field “Read Only” is checked, the IEC 61850 variable is just in reading. Otherwise, it is writeable too;
In the field “Position” the starting byte of the internal memory arrays from/to which taking/mapping the data is defined;
In the field “Start Bit” the starting bit of the byte of the field “ osition” is defined;
In the field “Conversion” the conversion of the data is defined. This option is used to convert the data format between Modbus and
IEC 61850;
In the field “Molt. Factor” a multiplicative factor of the value is defined;
If the field “Swap” is checked, the bytes’ order is swapped;
If the field “Swap Word” is checked, the words’ order is swapped;
In the field “Mnemonic” a description of the variable is defined.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 18 of 25
TLS KNOWN CERTIFICATE
By pressing the “TLS Known Certificate” button from the Main Window of SW67736 (Fig. 2) the “Definition the list of Known Certificates”
window appears (Fig. 5).
The data of the columns have the following meanings:
If the field “Enable” is checked, the TLS certificate is allowed;
In the field “Certificate” the certificate of the Client is defined;
In the field “Mnemonic” a description is defined.
Figure
5
: “ LS Known Certificate
” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 19 of 25
UPDATE DEVICE
By pressing the “Update Device” button, it is possible to load the created
Configuration into the device; and also the Firmware, if necessary. This by using the
Ethernet port.
If you don’t know the actual I address of the device you have to use this procedure:
Turn OFF the Device;
ut Dip1 of ‘Dip-Switch A’ in ON position;
Turn ON the device
Connect the Ethernet cable;
Insert the I “192.168.2.205”;
Select which operations you want to do;
ress the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn OFF the Device;
ut Dip1 of ‘Dip-Switch A’ in OFF position;
Turn ON the device.
If you know the actual I address of the device, you have to use this procedure:
Turn ON the Device with the Ethernet cable inserted;
Insert the actual I of the Converter;
Select which operations you want to do;
ress the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically goes at Normal Mode.
At this point the configuration/firmware on the device is correctly updated.
Figure 6: “Update device” windows

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG Revision 1.000 age 20 of 25
Note:
When you receive the device, for the first time, you also have to update the Firmware in the HD67736 device.
Warning:
If Fig. 7 appears when you try to do the Update try these points before seeking
assistance:
Try to repeat the operations for the updating;
Try with another C;
Try to restart the C;
Check the LAN settings;
If you are using the program inside a Virtual Machine, try to use in the main
Operating System;
If you are using Windows Seven, Vista, 8 or 10 make sure that you have the
administrator privileges;
In case you have to program more than one device, using the "UD Update", you
have to cancel the AR table every time you connect a new device on Ethernet. For
do this you have to launch the "Command rompt" and write the command "arp -d".
ay attention that with Windows Vista, Seven, 8, 10 you have to launch the
"Command rompt" with Administrator Rights;
ay attention at Firewall lock.
Warning:
In the case of HD67736 you have to use the software “SW67736”: www.adfweb.com\download\filefold\SW67736.zip.
Figure
7
:
“
Error
” window
