Modern Forms F-WC-WT User manual

INSTALLATION INSTRUCTIONS
SMART
F-WC-WT
COMPATIBLE WITH
works with the
Google Assistant
SAFETY RULES
For operation, maintenance, and troubleshooting information,
visit modernforms.com/help.
1. To reduce the risk of electric shock, ensure electricity has
been turned o at the circuit breaker before beginning.
2. All wiring must be in accordance with the National
Electrical Code “ANSI/NFPA 70” and local electrical
codes. Electrical installation should be performed
by a licensed electrician.
CAUTION: If you feel you do not have enough wiring
knowledge or experience, have your RF wall control installed
by a licensed electrician.
NOTE: A maximum of 2 fans can operate on a circuit through
the supplied wall control.
NOTE: A maximum of 12 fans can operate on a circuit through
an on/o switch or a breaker when utilizing the Modern Forms
app for the fan control (without the wall control in the circuit).
INSTALLING THE WALL CONTROL
CAUTION: To prevent electrical shock, ensure electricity has
been turned o at the circuit breaker before beginning.
NOTE: Fan(s) are required to be installed within 30 feet of
the wall control to ensure reliable communication.
NOTE: Wall control is intended for indoor installation only.
NOTE: You can control your fan with up to 4 wall controls or
remotes (including the pre-paired control).
WALL CONTROL TO WALL OUTLET BOX ELECTRICAL
CONNECTIONS (FIG.1):
1. Connect the green wire marked “GROUND” from the wall
control to the copper wire from the wall outlet box that
feeds back to the circuit breaker – important for proper
fan function.
2. Connect the black wire marked “LINE IN” from the wall
control to the black LINE VOLTAGE wire from the wall
outlet box that feeds back to the circuit breaker.
3. Connect the red wire from the wall control to the black
wire from the wall outlet box that feeds up to the fan.
1
Remember to disconnect the power at the circuit breaker.
1. Carefully tuck the wire connections inside the outlet
box. Secure the wall control with the two (2) wall
control screws provided (FIG. 2).
2. Attach the wall mounting plate over the wall switch
and secure with the two (2) wall mounting plate
screws provided (FIG. 2).
3. Fasten the wall plate to the wall mounting plate.
White White
Red
Black
Green (Ground)
Black (to fan)
Copper
Ground
White
(Neutral)
Black (from breaker)
Wall control
Wall outlet box
4. Connect the white wire from the wall control to the
white (neutral) wire from the wall outlet box.
WALL CONTROL OPERATION
Restore power to ceiling fan and test wall control as below for
proper operation.
PARING THE WALL CONTROL TO YOUR FAN
Your fan is pre-paired at the factory. No pairing is necessary.
NOTE: For pairing instructions please skip to section 3.
WALL CONTROL BUTTON FUNCTIONS
button: Turns the light ON or OFF.
Press or hold to increase the light level.
Press or hold to decrease the light level.
button: Turns the fan ON or OFF.
Press or hold the button to increase fan speed.
Press or hold the button to decrease fan speed.
ON-OFF Switch: Pull tab to power o in
case of emergency. Not necessary for normal
fan operation.
NOTE: Your fan features 6 speeds. An audible tone will indicate
when the speed is increased or decreased. When the fan has
reached the minimum/maximum speed level the audible
indication will stop.
button: Switch between Summer and Winter Mode.
SUMMER MODE (Counter-Clockwise):
A downward airow creates a cooling
eect (FIG. 4). This allows you to set
your air conditioner on a warmer
setting without aecting your comfort.
WINTER MODE (Clockwise):
An upward airow moves
warm air o the ceiling area and
re-distributes the warm air that hovers
around the ceiling to the living space.
This should allow for savings on
heating costs (FIG. 5).
NOTE: To operate the reverse button on your fan,
press the button while the fan is running
2
ON-OFF Switch

PAIRING
If you need to re-pair your fan or you want to pair a second
wall control:
1. Power cycle your fan by turning o the power at the
circuit breaker.
2. Press and hold and buttons on wall control
for 10-15 seconds.
3. The LED will blink green then remain solid green.
4. The green LED along with audible beeps will indicate
that pairing is successful.
5. Test wall control for functionality.
UNPAIRING
NOTE: Purging must be completed within 3 minutes
of turning the power on to the fan receiver.
1. When you re-engage power to the fans you
want to purge, press and hold the and
buttons for 4 seconds.
2. The LED will alternate red/green, blink green,
and the receiver will beep to indicate that purging
is successful.
4
5
MULTI LOCATION WIRING
1. Install the wall control using the wiring diagram in section 1.
2. Individually pair each of the wall controls with the fan
receiver using the pairing instructions in section 3.
NOTE: Pairing must be completed within 3 minutes of turning
the power on to the fan/receiver.
FAN WI-FI RESET
NOTE: This function only resets the Wi-Fi credentials.
1. Press and hold the
and buttons for 6 sec.
2. The LED will light red blink green
and return to solid red, and the
receiver will beep to indicate that
Wi-Fi reset is successful.
3. After the Wi-Fi resets, the fan will
broadcast its service set indicator
(SSID).
NOTE: If you are updating your router
the fan will still appear in the Modern
Forms app but will need to be re-paired.
You can change the name of
your fan on the Modern Forms app
upon re-pairing.
6
FACTORY RESET
NOTE: This will remove wall control and app connections.
Wall Control Factory Reset:
1. Press and hold the , and buttons
for 10 seconds
2. The LED will blink red and return to solid red,
and the receiver will beep to indicate that the
factory reset is successful.
RECEIVER BUTTON FACTORY RESET
1. Press the reset button on the receiver until
the receiver beeps
NOTE: This will remove wall control and Modern Forms
app connections.
8
7
Modern Forms App
3
