Moducase MAX Series User manual

MAX Series
MAX70/70plus/150/150plus

Quick overview of aluminum frame
Front Frame
Side frame back bar
Joints uses M5x20mm (3/4”) bolts x 32 and washers x 32

*Note
If you have adjoining displays, please DO NOT insert Rubber slots on the back of the front frame and
Side frame bar before assembly of displays.

Display Frame Contents
•Side frame top/bottom bar with screws (Side frame bar) x 4 units
•Back frame top/bottom bar with screws (Back frame top/bottom bar) x 2 units
•Side frame back bar (side frame back bar) x 2 units

*Orientation of Front frame
Centre screw hole upward
Lips facing outward
*Rubber slot facing up
Insert rubber slot if you are
installing the sidepanel.
*The rubber slot facing inward, opposite of the
front frame lips

Side panel
Side panel

Top panel

Side frame Back Bar
bar
Side frame Back Bar
bar
*Do not tighten the bolts

*Leave at least a 5mm or ¼” gap

*Flip the display 180 degrees
Back panel
