MOEBE Shelving System User manual

Strandlodsvej 42a,1 / 2300 Copenhagen S, Denmark / [e-mail] / [phone]
Assembly Instructions: Shelving System
Shelving System
2
PLAN AHEAD
Carefully plan the placement of the
shelves before starting to build your
system.
Each shelf is designed for a load
capacity of up to 20 kg.
12
4
3
SHELVES CAN ONLY BE ASSEMBLED
ONE WAY
The shelves have to be turned the right
way when assembling - the indicator
dot should always face downwards.
1
2
3
4
5
6
7
8
9
10
Water level
Ruler
Hammer
Drill
REQUIRED:
BEGIN WITH THE LEGS
Insert an end cap into the bottom of
each leg. Use a hammer if needed.
ASSEMBLING A SHELF
Place the rst shelf on the ground and make sure
that it is turned the right way. Insert one leg at a
time through the holes and lift the shelf to a desired
height.
Use the wedges to x the shelf, tap them a few times
with a hammer to secure, repeat this for all four legs.
Watch out not to leave any marks.
When the rst shelf is in place, the assembling gets
easier.

Strandlodsvej 42a,1 / 2300 Copenhagen S, Denmark / [e-mail] / [phone]
Assembly Instructions: Shelving System
2
Done!
5 6
8
7
Shelving System
ASSEMBLING A BACK PLATE
Slide down the backplate between the
two legs on either of the long sides.
Push it down until it sits on the shelf
underneath.
CONNECTING A SAFETY CLIP
Remember to secure the shelving
system to the wall, preventing it from
falling over. Slide down the safety clip
on the top of the legs that meet the
wall, mark where to drill. Use adequate
wall plugs suited for your wall type.
Fasten the clip with the screw.
EXTENDING THE LEGS
Screw the connector screws as far
into the legs as possible.
Add the leg extension by screwing it
tight against the lower part of the leg.
LEVEL THE SHELVES
Make sure the shelfves are leveled by using a water
level or a ruler.

Strandlodsvej 42a,1 / 2300 Copenhagen S, Denmark / [e-mail] / [phone]
Congratulations on your new Shelving
System!
The MOEBE Shelving System gives you full freedom to
build your own piece of furniture. Build as tall as you like,
build as wide as you like, build around corners, or even
span dierent levels. Use as a room divider or simply place
against a wall.
As a modular system, Shelving System is built entirely
from individual parts. It can be customised and adapted
again and again.
All shelves are held in place by 4 wedges in either corner.
The combination of the wedges and the smooth legs al-
lows the shelves to be positioned wherever desiered, with-
out any limitations.
Assembly Instructions: Shelving System

Strandlodsvej 42a,1 / 2300 Copenhagen S, Denmark / [e-mail] / [phone]
Security
We do not recommend to use the Shelving System with-
out securing it to the wall. If doing so please be aware that
it is your responsibility to make sure, that it is constructed
so it will not fall over.
Please also note, that we do not recommend to place
more than 20 kg on each shelf.
Care instructions
When unwrapped it might take 2-3 days for the protective
oil to completely dry. Be careful to protect clothing and
other materials that can soak up oil during this time.
If any time the wood displays lighter dry patches, we rec-
ommend you to apply a thin coat of oil to the furniture with
a dean lint-free cloth to nourish the wood. Small cans of
pigment-free furniture oil are available from most DIY hard-
ware stores. Do not use oils sold for cooking or eating.
Any spills must be removed immediately using a cloth.
Dust can be removed with clamp cloth. Light strains may
be removed by gently rubbing in the direction of the grain
with 400 grit (very ne) sandpaper and re-oiling afterwards.
Heat and sunlight
Avoid exposing your furniture to excessive heat e.g. by
placing it in front of a radiator as this can cause cracking. A
minimum of 30cm clearance from heat sources is advised.
Direct sunlight will cause the colour of real wood to change,
even if it is stained or lacquered. This will be particularly ap-
parent if the furniture is placed under eg. a window. Oak will
tend to darken in this situation.
Never place hot items directly on to wooden surfaces. Pro-
longue use of hot electrical equipment, such as a televi-
sion, on top of furniture, may also cause scorching.
Assembly Instructions: Shelving System

Strandlodsvej 42a,1 / 2300 Copenhagen S, Denmark / [e-mail] / [phone]
Assembly Instructions: Cabinet
Cabinet
2
1 2
4
3
x2
x2
x4
x2
x1
x1
x1
x12
Start by placing the bottom shelf at a desired
height, fasten it with the wedges. Use a water
level and a hammer to make sure it is leveled
and secured.
Insert the dowels into the holes of the
back and side panels. Attach them to
the bottom shelf.
Slide down the top shelf until it sits on the dowels
of the side panels. Fasten it with the wedges.
Use a hammer to make sure it is secured.
Insert the door stoppers by screwing them
into the holes of the top shelf.

Strandlodsvej 42a,1 / 2300 Copenhagen S, Denmark / [e-mail] / [phone]
Assembly Instructions: Cabinet
Cabinet
2
5 6
8
7
Place the hinges in the large holes
of the doors.
Attach by folding over the metal plate
until it clicks into place.
Mount the doors onto the side panels
of the cabinet.
Slide the hinge over the metal plate.

Strandlodsvej 42a,1 / 2300 Copenhagen S, Denmark / [e-mail] / [phone]
Assembly Instructions: Cabinet
Cabinet
2
9
Done!
Door
Adjustment
Click it into place.
To adjust the placement of the doors,
tighten/loosen these three screws.

Strandlodsvej 42a,1 / 2300 Copenhagen S, Denmark / [e-mail] / [phone]
Assembly Instructions: Cabinet
Congratulations on your Cabinet!
With the cabinet add-on you have the possibility to hide
the things you don’t want to show - we all have them.
The cabinet can be placed at any height within the system,
and still allows for shelves to be placed at either side. The
add-on for your Shelving System comes at packed and
consists of two custom shelves, two side panels, a back
plate, doors and an optional inner shelf.

Strandlodsvej 42a,1 / 2300 Copenhagen S, Denmark / [e-mail] / [phone]
Clothes Bar
2
1 2
4
3
x1
x2
x2
Assembly Instructions: Clothes Bar
The Clothes bar is attached
to each end of a shelf.
Mount the grabbing piece by pressing
it onto one end of a shelf.
Place the bar against the hole and fas-
ten it by screwing on the end piece.
Repeat step two on the
other side of the shelf. Done!

Strandlodsvej 42a,1 / 2300 Copenhagen S, Denmark / [e-mail] / [phone]
Assembly Instructions: Clothes Bar
Congratulations on your new Clothes
Bar!
With the Clothes Bar add-on you can design your own
wardrobe to t perfectly in your bedroom or hallway.
The Clothes Bar is simply attached to each end of a shelf,
which means you can always keep adding as many as you
have shelves.
