FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
CRITICAL DIMENSIONS
(DO NOT SCALE)
Specifications
CHATEAU®POSI-TEMP®
Single-Handle Tub/Shower Trim Kit
Models: TL183, TL183BC
(Bulk Packed 12 per carton)
DESCRIPTION
•Metal construction with a chrome plated or brushed
chrome finish.
•
Includes non-metalic showerhead, arm flange and
non-metalic diverter tub spout
OPERATION
•Handle operates counterclockwise through a 270°
arc with off at 6 o’clock and maximum hot at the 9
o’clock position. Shut off in clockwise direction
•Adjustable temperature limit stop to control
maximum hot water temperature
•Pressure balancing mechanism maintains selected
discharge temperature to ± 3°
FLOW
•Showerhead is limited to 2.5 gpm (9.5 L/min) Max
CARTRIDGE
•1222 cartridge design
•Accommodates back to back installations
•Nonmetallic/nonferrous and stainless steel material
STANDARDS
•Third party certified to meet CSA B-125, ASSE 1016,
ASME A112.18.1M, ANSI A117.1 and all applicable
requirements referenced therein
WARRANTY
•Lifetime limited warranty against leaks, drips and
finish defects to the original consumer purchaser
•5 year warranty if used in commercial installations
THIN WALL APPLICATION
THICK WALL APPLICATION
ADA
FINISHED WALL LINE
FACE OF STUD
DIRECTION
OF HANDLE
ROTATION
7" (178mm)
ESC. DIAM.
4-1/2"
(114mm)
2"CC (51mm)
1 7/8" IPS (48mm)
MAX WALL
C
L
2 1/2" MAX. (63mm)
1/2" MIN. CC (13mm)
5/8" MIN. IPS (16mm)
1 3/8" (35mm) 1 3/8"
(35mm)
3/16"(typ) (5mm)
L
C
1 1/2" MAX.
(38mm)
PLASTER GROUND
3-1/2" (89mm) MAX.
2-1/4" (57mm) MIN.
DIAMETER
WALL
OPENING
PLASTIC
TUB/SHOWER
SURROUND
FLOOR LINE
SHOWER
45" (1143mm)/
48" (1219mm)
32" (813mm)
TUB/SHOWER
AND TUB ONLY
6'-6"
(1981mm)
NOMINAL
FLOOR LINE
6"- 11"
(152mm- 279mm)
Rev. 8/05
