Rev 9/11
CRITICAL DIMENSIONS
(DO NOT SCALE)
ICON™
Two Handle Widespread
Lavatory Faucet
Models: T6520 series
Valve: 9000, 69000
NOTE: THIS FAUCET IS DESIGNED TO BE INSTALLED
THRU 3 HOLES, 1-1/8" MIN. DIA.
Lift
Rod
1-11/32"
(34mm)
QUICK CONNECT
HOSE ASSEMBLY
2-1/4" (57mm)
esct. dia.
8"
(204mm)
3"
(76mm)
4-3/16"
(107mm)
9"
(229mm)
5-13/16"
(148mm)
5-1/8
(130mm)
5-1/4"
(134mm)
1-1/2” (38mm)
MAX. DECK THICKNESS
Specifications
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
FAUCET DESCRIPTION
•Metal construction with various finishes identified by suffix
•1/2" IPS connections
OPERATION
•Lever style handles
•Maximum handle rotation angle is 90˚ to full on for either handle
•Hot side counterclockwise to open (clockwise to close)
•Cold side clockwise to open (counterclockwise to close)
FLOW
•Flow is limited to 1.5 gpm max (5.7L/min) at 60 psi,
for products made before October 2008 flow is limited to
2.2 gpm max (8.3 L/min)
CARTRIDGE
•1224 cartridge design
•Nonmetallic, nonferrous and stainless steel material
STANDARDS
•Third party certified to WaterSense,® CSA B125.1, ASME A112.18.1, ICC
A117.1and all applicable requirements referenced therein
•Certified to ANSI/NSF 61/9
• Complies with California Proposition 65 and with the
Federal Safe Drinking Water Act
•ADA for lever handle
WARRANTY
•Lifetime limited warranty against leaks, drips and finish
defects to the original consumer purchaser
•5 year warranty if used in commercial installations
