Moen PureTouch Classic 7030 Series User manual

Model Numbers
7025, 7030, 7034, 7037
87025, 87030, 87034 Series
U.S. Patent Pending
Other Foreign and Domestic Patents Pending
INS215A
OWNER’S MANUAL
Exclusively from

INS215A
1HELPLINE: 1-877-DRINK-H2O
1-877-(374-6542)
PRODUCT FEATURES
Newly styled handle
and spout receptor Filtered
water
button
Filtered
water outlet
Easy to replace
water filter
➤
➤
➤
Electronic
filter life
indicator
Deck plate models
Deck ring model

INS215A 2
HELPLINE: 1-877-DRINK-H2O
1-877-(374-6542)
WELCOME TO MOEN®
Congratulations! You’ve purchased the revolutionary
PureTouch®Classic Filtering Faucet System. This faucet is
designed to provide great tasting, cleaner water with just one
touch. To get the most enjoyment from your Moen PureTouch
Filtering System, please read all installation and operating
instructions carefully. With simple care and maintenance, the
PureTouch Filtering Faucet System will provide many years of
reliable performance. If you should have any questions, please
call us toll-free at 1-877-DRINK-H2O (1-877-374-6542).
TABLE OF CONTENTS
Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Water Filtration Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . .3
Parts Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Filter Replacement Instructions . . . . . . . . . . . . . . . . . . . . . . .8
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
California Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Performance Data Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

WATER FILTRATION SAFEGUARDS
Your PureTouch® Classic Filtering Faucet System integrates carbon block
filtration technology designed by Culligan®International into a faucet
spout. This technology is fast and effective at reducing contaminants
commonly found in water and is certified by NSF®International. The
PureTouch Filtering Faucet System and installation must comply with
State and Local laws and regulations. To ensure optimal operation of
your new Moen faucet, please read the following safeguards carefully.
MicroTech™ Filter Cartridges
• MicroTech filter cartridges will reduce :
Chlorine, Taste and Odor (MicroTech 400, 600)
Lead (MicroTech 400, 600)
Cysts (Cryptosporidium, Giardia)(MicroTech 600)*
* The contaminants removed or reduced by this filter are not necessarily in your water.
• Do not use with water that is microbiologically unsafe or of unknown
quality without adequate disinfection before or after the system.
Systems certified for cyst reduction may be used on disinfected waters
that may contain filterable cysts.
• MicroTech filter cartridges are designed for replacement after
dispensing 200 gallons of filtered water. Water conditions and usage
may affect filter life and water taste.
• The electronic indicator will signal when filter replacement is necessary
(see page 9).
• Use only MicroTech 400 or 600 filter cartridges with the PureTouch
Classic Filtering Faucet System.
• Filter flow rate = .4-.6 gpm at rated pressure (20psi min. - 125psi max.).
Water Temperature
• Minimum/Maximum faucet operating temperature = 40° - 150°F.
•CAUTION: Do not filter water above 100° F.
MicroTech Filter Flushing Instructions
• New MicroTech Filter Cartridge: After installing a new filter into the
faucet, allow cold water to run through the filtered water outlet for 5
minutes to flush out any loose carbon particles. The filter life
indicator will alternately flash amber and green for the first five
minutes after the indicator is manually reset (see page 9) as an aid
in timing the filter flushing period.
• Daily Use: Allow cold water to run through the filter for 10-15
seconds prior to first use. If the filter has not been used for several
days, run cold water through the filter for 60 seconds prior to use.
Questions
• If you have any questions please call our toll-free helpline,
1-877-DRINK-H2O. Monday through Friday 8:00 a.m. to 8:00 p.m.
1-877-(374-6542) Saturday 8:00 a.m. to 6:30 p.m.
3HELPLINE: 1-877-DRINK-H2O
1-877-(374-6542) INS215A

INS215A 4
HELPLINE: 1-877-DRINK-H2O
1-877-(374-6542)
PARTS DESCRIPTION
1
4
5
6
7
8
9
10
30
17
16
18
19
20
15
24
28
25
26
27
13
14
3
2
12
11
31
31
21
22
23
DESCRIPTION
1
Solid Handle Body
2
Set Screw
3
PlugButton
4
Dome & Pivot
RetainerAssembly
5
Cartridge Screw
6
Handle Adapter &
Connector Assembly
7
PivotStop
8
Spout Retaining Nut
9
Bearing Washer
10
"D"Washer
11
RetainerClip
12
1225 Cartridge
13
FilterCartridge
14
Filltering Appliance
15
Lower Spout Assembly
16
Threaded Shank
17
Supply Tubes (2)
18
Bottom Bearing Washer
19
1/2" Threaded Fitting
20
Deck Ring with Gasket
21
DeckPlate
22
MountingBracket
23
Mounting Nut
24
Side Spray
(SprayModels)
25
Hose Guide with Gasket
(Side Spray Models)
26
SprayHose
27
ExtendedLocknut
(Side Spray Models)
28
Swivel Nut (Spray Models)
29
MountingTool
30
DeckPlate
(Spray in Deck Models)
31
Support Plate with Gasket
29

5HELPLINE: 1-877-DRINK-H2O
1-877-(374-6542)
INSTALLATION INSTRUCTIONS
CAUTION: Always turn water supplies OFF before removing existing
faucet. Turn faucet on to relieve water pressure and to ensure water is
completely off.
OLD FAUCET REMOVAL: Your old faucet may attach in a number of different
ways depending on the brand. To remove, reverse steps in installation
instruction sheet of old faucet, follow instructions in a DIY type of book or
follow instructions listed below.
After years of use, you may need to use a penetrating oil spray on the faucet
mounting hardware to help loosen corrosion and assist in removing the faucet
connections.
Disconnect water supply lines from faucet supply lines. Remove mounting
hardware using a basin wrench or channel lock pliers. Lift out faucet.
Thoroughly clean and dry the mounting surface after removal of old faucet.
INSTALLING THE PURETOUCH® Classic FILTERING FAUCET SYSTEM
Helpful Tools: Phillips screwdriver, two adjustable wrenches
CAUTION: Do not use with portable washing devices, i.e.
dishwashers, washing machines.
NOTE: Do not bend supply tubes until instructed in step 4.
HINTS: When using flexible supplies, we recommend threaded fittings be installed
onto supply lines before placing faucet through sink holes (see step 6). For
installations on tile countertops, remove rubber gasket from underneath support
plate (31) or deck ring (20) and apply a bead of putty in its place. Roll the putty into
the diameter of a pencil. When applied in the groove, the putty should protrude a
minimum of 1/16".
Side Spray Installation (side spray models only)
1. Locate foam gasket on hose guide (25) by sliding gasket onto shank and tucking
outer edge of gasket under the hose guide (25). Do not drive the center of the
gasket up into the hose guide. Install hose guide (25) through furthest left or
right hole in sink. From under sink, thread extended locknut (27) (either side
up) on shank of hose guide and tighten by hand. Feed spray hose (26) down
through the hose guide (25) (do not connect spray hose to faucet until step 6 ).
INS215A
25
25
27
26

2a. WARNING: Do not straighten bent supply tubes until
step 4.
DECK PLATE MODELS: Install faucet through deck holes
(threaded shank (16) to back). Center faucet on sink with
support plate (31) oriented in sink holes.
DECK RING MODELS: Place deck ring (20) over supply
tubes (17) and threaded shank (16) against bottom of
faucet body. Install faucet through deck hole (threaded
shank (16) to back).
FOR ALL MODELS: Position spout to side to keep faucet
from tilting forward. Refer to step 2b for installation of
mounting bracket (22).
2b. IMPORTANT: DECK THICKNESS (countertop)
Your deck thickness determines whether the mounting
bracket (22) is installed open side up or down. For spray
models, a groove on the threaded shank (16) indicates the
minimum amount of thread length which must be exposed for proper
attachment of nuts (23) and (28). For models without spray, a minimum of 1/2"
of threaded shank (16) must be exposed for proper attachment of nut (23).
Position mounting bracket onto threaded shank (16) and around supply tubes
(17). Do NOT kink tubing. Install mounting nut (23) and tighten by hand.
3. Be sure faucet is positioned evenly on sink. Make final tightening of mounting
nut (23) with mounting tool (29).
4. Carefully straighten each supply tube using two
hands. At this time, affix the Caution Hang Tag onto
either supply tube over the 1/2” threaded fitting (19).
If using flexible supply lines with compression fittings,
thread supply line nuts on finger tight, then holding
one threaded fitting with a wrench, tighten nut with
another wrench, rotating one half turn. Do not
overtighten. Connect the existing hot and cold water
supply lines to the two (2) 1/2” threaded fittings. The
hot supply tube is always to the left when threaded
shank (16) is positioned to rear.
INS215A HELPLINE: 1-877-DRINK-H2O
1-877-(374-6542) 6
➤
SINK
GROOVE
GROOVE
Back View of
Faucet Installation
SINK
For deck thickness over
1-1/8" deep, install
mounting bracket (22)
OPEN SIDE DOWN.
DECK RING
SINK
For deck thickness up to
1-1/8" deep, install
mounting bracket (22)
OPEN SIDE UP.
➤
GROOVE
CAUTION:
Severe bends of the supply
lines may cause crimping
and restricted water flow
could result.
22
SINK
Deck ring

5. FOR MODELS WITH SPRAY IN DECK PLATE (30),
install spray hose (26) and spray head (24)
through deck plate hole.
6. TO CONNECT SPRAY HOSE FOR ALL SPRAY
MODELS:
Connect spray hose swivel nut (28) to the
threaded shank (16). Tighten swivel nut by hand
plus 1/4 turn with pliers or channel locks being
careful not to twist the spray hose (26). DO NOT
OVERTIGHTEN.
Flushing is required. See flushing instructions
below.
INS215A
7HELPLINE: 1-877-DRINK-H2O
1-877-(374-6542)
26
24
LINE FLUSHING INSTRUCTIONS
IMPORTANT: Pipe chips, sand, stones and other solids found in new and
renovated plumbing can damage the sealing surfaces of the filter cartridge and
cause a leak. To avoid damage, DO NOT TURN ON SUPPLY VALVES until
instructed below.
Before you insert the filter and filtering appliance:
1. Turn faucet on in the full cold position (handle
pointing to the right) and allow cold water to flow
for 15 seconds
2. Without turning the faucet off, turn the handle to the full hot position (handle
pointing to the left) and allow hot water to flow for 15 seconds.
3. If side spray is installed, without turning the faucet off, turn the handle to the
mid/mix position (handle pointing toward you) and turn on the spray for 15
seconds.
4. Shut off faucet.
5. You are now ready to insert the filter and filtering appliance.
Sink

1. Install a new filter by wetting the outlet ports with
water and then inserting into the round filter ports
on the faucet head and pushing the filter and head
together. Both outlet ports must be
fully inserted into the filter ports.
2. Install the filter and faucet head
assembly on to the spout by wetting the
faucet head o-ring seal and rubber spacer and
then carefully sliding the free end of the filter
into the spout. The head will need to be initially
turned approximately 1/2 turn counter clockwise from
its normal position to slip past the safety catch. Lock the
head into place by simultaneously pushing and twisting the
head clockwise. When properly installed the head will feel
secure, and will be correctly oriented on the spout.
3. Reset the filter life indicator by pushing the filter
button 3 times. Wait 10 seconds. You should not be
running water while resetting the filter life indicator
because the filter button will remain depressed with the
first push as it switches to filter mode. The filter life indicator
has been correctly reset if a short series of rapidly flashing green
light occurs, indicating that the new filter flushing
period has begun.
4. Flush the filter (see page 3) for 5 minutes before
initial use.
Your new Moen faucet is now ready for normal use.
To replace or install filter -
1. Turn off the faucet. Remove the faucet head by
twisting it approximately 1/4 turn counter clockwise to
unlock it. Gently pull the faucet head away from the
spout and twist it approximately another 1/4 turn to get
the faucet head past the safety catch. The faucet head and
depleted filter (if one is installed) can now be pulled
completely out of the spout.
2. The filter is held to the faucet head by two outlet
ports, which connect into the head. Remove the old
filter by simply pulling it straight off. Discard the old filter
and install a new MicroTech 400 or 600 filter.
Note: The faucet will function correctly in unfiltered stream mode
with or without a filter installed. The faucet will not function correctly in
filter mode without a filter. If a filter is not installed and the filter button is
depressed, unfiltered water will flow from both the filtered water outlet and the
stream outlet aerator, and the filter button will not automatically stay depressed.
Use only Microtech 400 or 600 filter cartridges with the PureTouch
Classic
Filtering Faucet system. The Microtech filters are high performance carbon block
filters developed specifically for the PureTouch system.
Outlet Ports
Filtering Appliance
Faucet head o-ring seal
Filter
Spacer
MICROTECH™FILTER INSTALLATION/REPLACEMENT
INS215A 8
HELPLINE: 1-877-DRINK-H2O
1-877-(374-6542)

INS215A
9HELPLINE: 1-877-DRINK-H2O
1-877-(374-6542)
OPERATING INSTRUCTIONS
Controlling The Water
The PureTouch system has two options for water delivery; unfiltered stream and
filtered water.
STREAM MODE:Unfiltered water in regular stream flow.
When the water is turned on at the faucet, the spout will always begin
operating in the regular stream mode.
FILTERED WATER MODE: Filtered water dispensed through the separate
filtered water outlet.
Pressing the front filtered water button will divert water through the filter and
dispense filtered water from a separate outlet. To exit the filter mode, shut off
the faucet.
CAUTION: Only filter cold water. Do not filter water above 100° F.
Electronic Indicator
The flashing light on the electronic filter life indicator provides information
regarding the performance of the filter. The indicator provides you with
information throughout the life of the filter to help communicate the level at
which it is performing. Only reset the indicator when installing a new filter.
Resetting the indicator at any other time will cause incorrect filter life indication.
*If fast red doesn’t change to slow amber/green after memory has been reset,
reset was not complete and needs to be redone. Follow step 3 on page 8.
The electronic indicator is powered by a replaceable, standard 3V lithium watch
battery (2032) designed to last several years.
Battery Replacement
Follow filter replacement instructions to remove filter
appliance. Locate battery compartment drawer, pull out
and replace battery, positive side up. Keep the battery
and battery compartment dry. The electronic indicator
will retain the correct filter life information when the
battery is removed and replaced.
Indicator Color Performance
Amber & Green A new filter must be flushed with cold
water for 5 minutes after it is installed.
This procedure helps clean the filter of
loose carbon particles
Green Filter performing with optimum
efficiency
Amber Caution: Filter is ready for replacement
(approximately 16 gallons left).
Red Warning: Filter is ready for replacement
(approximately 8 gallons left).
Red (fast) Filter life is depleted, discard old filter
and replace with a new MicroTech 400
or 600 filter.
