Specifications
Rev. 3/11
Lift
Rod
4-3/4”
(121mm)
3-13/32”
(87mm)
2-15/16”
(74mm)
3-15/32”
(88mm)
8” (203mm) - 16” (406mm)
centers
Spout Escutcheon Dia.
2-9/32” (58mm)
Handle Escutcheon Dia.
2-5/32” (55mm)
1-1/4” (32mm)
Max Deck Thickness
1-1/4”
(32mm)
5-1/4”
(133mm)
QUICK CONNECT
HOSE ASSEMBLY
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
DESCRIPTION
- Metal construction with various finishes identified by suffix
- 1/2" IPS connections will accept standard ball nose connection for 3/8” tubing
- Optional hot and cold temperature indicators available
- Hydrolock™ quick connect installation
- Includes metal pop-up waste assembly
- For use with S948 valve
- Designed to be installed through 3, 1-1/8” dia. holes
OPERATION
- Lever style handles
- Maximum handle rotation angle is 90˚ to full on for either handle
- Rotate hot side handle counterclockwise to open and clockwise to close
- Rotate cold side handle clockwise to open and counterclockwise to close
FLOW
- Flow is limited to 1.5 gpm max (5.7 L/min) at 60 psi, for products made
before October 2008 flow is limited to 2.2 gpm max. (8.3 L/min)
CARTRIDGE
- 1224 cartridge design with nonmetallic/nonferrous
and stainless steel materials
STANDARDS
- Third party certified to WaterSense,® ASME A112.18.1/CSA B125.1
and all applicable requirements referenced therein
- Certified to ANSI/NSF 61/9
- Contains no more than 0.25% weighted average lead content
- Complies with California Proposition 65 and with the Federal Safe
Drinking Water Act
-
ADA
for lever handles
WARRANTY
- Lifetime limited warranty against leaks, drips and finish defects
to the original consumer purchaser
- 5 year warranty if used in commercial installations
DIVINE™
Two-Handle Widespread
Lavatory Faucet Trim
Models: TS458 series
Valve: S948
NOTE: FOR DECK THICKNESS 1-3/8” - 3”, USE SERVICE KIT #115001. VALVES INSTALL THROUGH 1-1/4” DIA. HOLE
CRITICAL DIMENSIONS
(DO NOT SCALE)
M•pact™System
