Moffat MTE18 Operating instructions

Safety Instructions ............ . 2, 3
Operating Instructions
Control Settings ...................... . 4
Storage Drawers...................... . 4
Ice Service............................. . 5
Care and Cleaning ................. .6, 7
Installation Instructions
Advanced Planning................... 8
Refrigerator Features................. . 9
Reversing the Door Swing ........ 10-13
Troubleshooting Tips
Normal Operating Sounds ........... 14
Problem Solver................... 15, 16
Consumer Support
Product Registration ................ 17
Warranty .......................... 19
Consumer Support .................. 20
moffatappliances.ca
Refrigerator
Top Freezer
29-5942-1 04/16 MCC
Write the model and serial
numbers here:
Model # ____________________
Serial # ____________________
You can find them on a label inside
the refrigerator.
MTE18
Owner’s Manual and
Installation Instructions

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
2
IMPORTANT SAFETY INFORMATION READ ALL INSTRUCTIONS BEFORE USING
Moffat Appliances website
For more information on your refrigerator’s operation, visit www.moffatappliances.ca or
call 800.561.3344
nThis refrigerator must be properly installed and located in
accordance with the Installation Instructions before it is
used.
nDo not allow children to climb, stand or hang on the shelves
in the refrigerator. They could damage the refrigerator and
seriously injure themselves.
nDo not touch the cold surfaces in the freezer compartment,
particularly when hands are damp or wet. Skin may stick to
these extremely cold surfaces.
nDo not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
nIn refrigerators with automatic ice makers, avoid contact
with the moving parts of the ejector mechanism, or with
the heating element that releases the cubes. Do not place
fingers or hands on the automatic ice making mechanism
while the refrigerator is plugged in.
nKeep fingers out of the “pinch point” areas; clearances
between the doors and between the doors and cabinet are
necessarily small. Be careful closing doors when children are
in the area.
nUnplug the refrigerator before cleaning and making repairs.
NOTE: We strongly recommend that any servicing be
performed by a qualified individual.
nTurning the control to the COLD position does not remove
power to the light circuit.
nDo not refreeze frozen foods which have thawed
completely.
nBefore replacing a burned-out light bulb, the refrigerator
should be unplugged in order to avoid contact with a live
wire filament. (A burned-out light bulb may break when
being replaced.)
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety
messages will follow the safety alert symbol and the word “DANGER”, “WARNING”, or “CAUTION”. These words are defined as:
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, explosion, electric shock, or injury when using your
refrigerator follow these basic safety precautions:
REFRIGERATOR SAFETY INFORMATION
WARNING
WARNING
DANGER
CAUTION

3
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING. moffatappliances.ca
WARNING Explosion Hazard.
Keep flammable materials and vapors, such as gasoline, away from refrigerator. Failure to do so can
result in fire, explosion, or death.
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped with a 3-prong
(grounding) plug which mates with a standard 3-prong
(grounding) wall outlet to minimize the possibility of electric
shock hazard from this appliance.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Where a standard 2-prong wall outlet is encountered, it is
your personal responsibility and obligation to have it replaced
with a properly grounded 3-prong wall outlet. Do not use an
adapter.
The refrigerator should always be plugged into its own
individual electrical outlet which has a voltage rating that
matches the rating plate.
This provides the best performance and also prevents
overloading house wiring circuits which could cause a fire
hazard from overheated wires.
Never unplug your refrigerator by pulling on the power cord.
Always grip plug firmly and pull straight out from the outlet.
Repair or replace immediately all power cords that have
become frayed or otherwise damaged. Do not use a cord
that shows cracks or abrasion damage along its length or at
either end.
When moving the refrigerator away from the wall, be careful
not to roll over or damage the power cord.
CONNECTING ELECTRICITY
WARNING Electrical Shock Hazard.
Plug into a grounded 3-prong outlet
Do not remove the ground prong
Do not use an adapter
Failure to follow these instructions can result in death, fire, or electrical shock.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
WARNING Suffocation and child entrapment hazard.
Remove fresh-food and freezer doors from the refrigerator, prior to disposal. Failure to do so can result
in child entrapment which can lead to death or brain damage.
Child entrapment and suffocation are not problems of
the past. Junked or abandoned refrigerators are still
dangerous even if they will sit for “just a few days.” If you
are getting rid of your old refrigerator, please follow the
instructions below to help prevent accidents.
Before You Throw Away Your Old Refrigerator or
Freezer:
nTake off the fresh food and freezer doors.
nLeave the shelves in place so that children may not
easily climb inside.
Refrigerants
All refrigeration products contain refrigerants, which
under federal law must be removed prior to product
disposal. If you are getting rid of an old refrigeration
product, check with the company handling the disposal
about what to do.
PROPER DISPOSAL OF YOUR OLD REFRIGERATOR
IMPORTANT:

About the control on the refrigerator.
Control Settings
Refrigerator Control
When first powered all lights are illuminated for 3 seconds .The
factory setting 3 is displayed after 3 seconds.
Change setting by pressing SET key, each time you press it will
advance by 1. Press until the desired setting is achieved. Adjust
controls one increment at a time to determine your preferred
setting. Allow 12 hours after each adjustment for the refrigerator
reach the temperature you have set. Setting 1 is the warmest
5 is the coldest.
Standby Mode
When the refrigerator is in ON, Press SET for 3 seconds the
refrigerator will go into standby mode, the standby indicator
light will be on.
Standby setting will stop cooling in both the refrigerator and
freezer compartments but does not shut off electrical power to
the refrigerator.
Revert to normal operation by pressing the SET button ,the
standby light will go off, it will go back to the last setting.
After each adjustment, check both the freezer and the fresh
food compartments. Changing the fresh food control will affect
the temperature of the freezer compartment. Likewise, changing
the freezer control can affect the temperature of the fresh food
compartment.
Control settings will vary based on personal preferences, usage
and operating conditions and may require more than one
adjustment. Factors that affect temperature include the amount
of food in the fresh food and freezer compartments, frequency
of door opening, and temperature of food when placed in either
compartment.
There is a temperature control in the fresh food compartment as well as the freezer
compartment. Initially set the control to the recommended normal settings in the fresh food
and freezer compartments. Allow 24 hours for the temperature to stabilize.
4
Fruit and Vegetable Drawers
These storage drawers provide space to store
fruits, vegetables and meats.
To remove and replace the drawers and the
cover above them, the door must be fully
opened. In some installations, the refrigerator
may have to be moved away from the wall for
the door to be fully opened.
About the storage drawers.
Freezer Temp Control
Fresh Food Temp Control
1 is cold
5 is coldest
Min is Cold
Middle is Normal
Max is Coldest

5
Ice Trays
To make ice, fill the ice tray with water and set
it on a level surface in the freezer compartment.
Ice cubes will form in a few hours.
To release ice cubes, turn the tray upside down,
hold it over a container and twist both ends.
For only one or two ice cubes, leave the tray
right-side up, twist both ends slightly and
remove as many cubes as you want.
Wash ice trays in lukewarm water only—
do not put them in an automatic dishwasher.
About ice service. moffatappliances.ca

6
Care and cleaning of the refrigerator.
Cleaning the Outside
Keep the outside clean. Wipe with a clean
cloth lightly dampened with mild liquid dish
detergent. Dry with a clean, soft cloth.
Do not wipe the stainless steel door with
a soiled dishcloth or wet towel. These may
leave a residue that can erode the finish. Do
not use scouring pads, powdered cleaners,
bleach or cleaners containing bleach
because these products can scratch and
weaken the finish. Use only a liquid cleanser
free of grit and rub in the direction of the
brush lines.
The stainless steel door and door handle
can be cleaned with a commercially
available stainless steel cleaner. Cleaners
with oxalic acid (e.g. Bar Keepers Friend
Soft Cleanser) will remove rust, lime, and
other tarnish. Do not use appliance wax or
polish on the stainless steel.
Protect the paint finish. The finish on the
outside of the refrigerator is a high quality,
baked-on paint finish. With proper care, it
will stay new-looking and rust free for years.
Apply a coat of kitchen/appliance wax when
the refrigerator is new, and then at least
twice a year.
Cleaning the Inside
To help prevent odors, leave an open box
of baking soda in the fresh food and freezer
compartments.
Unplug the refrigerator before cleaning.
If this is not practical, wring excess moisture
out of sponge or cloth when cleaning around
switches, lights or controls.
Use warm water and baking soda solution—
about a tablespoon (15 ml) of baking soda to
a quart (1 liter) of water. This both cleans and
neutralizes odors. Rinse and wipe dry.
Other parts of the refrigerator—including door
gaskets, fruit and vegetable drawers, and all
plastic parts—can be cleaned the same way.
After cleaning the door gaskets, apply a thin
layer of petroleum jelly to the door gaskets
at the hinge side. This helps keep the gaskets
from sticking and bending out of shape. Do
not use cleansing powders or other abrasive
cleaners.
Do not wash any plastic refrigerator parts
in the dishwasher.
Avoid cleaning cold glass shelves (on some
models) with hot water because the extreme
temperature difference may cause them to
break. Handle glass shelves carefully. Bumping
tempered glass can cause it to shatter.

Preparing for Vacation
For long vacations or absences, remove food
and unplug the refrigerator. Clean the interior
with a baking soda solution of one tablespoon
(15 ml) of baking soda to one quart (1 liter) of
water. Leave the doors open.
Preparing to Move
Remove food and unplug the refrigerator.
Secure all loose items such as shelves and
drawers by taping them securely in place to
prevent damage.
Be sure the refrigerator stays in an upright
position during moving.
7
moffatappliances.ca
Replacing the Light Bulb
! WARNING: Light bulb may be hot.
Before replacing a burned-out light bulb, the
refrigerator should be unplugged in order to
avoid contact with a live wire filament (A burned-
out light bulb may break when being replaced.)
Turning the control to the OFF position does not
remove power to the light circuit .
Maximum bulb wattage: 40W
Unplug the refrigerator
The bulb is located at the top of the
refrigerator compartment.
Unfasten screw to remove light cover.
Replace bulb with a new one of the same
or lower wattage
Reattach light cover using screw
Plug the refrigerator back in
CAUTION
Using a bulb rated higher than 40W may
damage the control housing and light lens.

Installation Refrigerator
Instructions Models MTS18
LEVELING LEGS
Adjustable legs at the front corners of the refrigerator
should be set so the refrigerator is firmly positioned
on the floor, and the front is raised just enough that
the door closes easily when opened about halfway.
To adjust the leveling legs, turn the legs clockwise
to raise the refrigerator, counterclockwise to lower it.
If you have questions, call 1.800.561.3344 or Visit our Website at:
www.moffatappliances.ca
To raise the refrigerator
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•IMPORTANT – Save these instructions for local
inspector’s use.
•IMPORTANT – Observe all governing codes
and ordinances.
• Note to Installer – Be sure to leave these instructions
with the Consumer.
• Note to Consumer – Keep these instructions
for future reference.
• Skill level – Installation of this appliance requires basic
mechanical skills.
• Completion time – Refrigerator Installation
15 minutes
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not covered
under the Warranty.
LOCATION REQUIREMENTS
• Do not install the refrigerator where the temperature will go
below 55°F (13°C) because it will not run often enough to
maintain proper temperatures.
• Install it on a floor strong enough to support it fully loaded.
CLEARANCES
• Free-standing installation only.
• If the refrigerator is being installed next to a wall, leave
sufficient space on the hinge side to allow the door
to swing open enough to access the clear bins in the
refrigerator compartment.
• Do not install within 5” (13 cm) of the range.
• Minimum Clearances:
Back 2” from wall
Sides 3/4”
Top 3/4”
UNPACKING YOUR REFRIGERATOR
• Remove tape and any labels (except for the rating label)
from your refrigerator. Tape or glue residue can also be
removed by rubbing a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm
water and dry.
• Do not use sharp instruments, rubbing alcohol,
flammable fluids, or abrasive cleaners to remove tape
or glue. These products can damage the surface of your
refrigerator.
• When moving the refrigerator, do not tilt the refrigerator
beyond 45° from upright position.
POWER CORD
• Plug the refrigerator power cord into its own properly
grounded wall outlet with a voltage rating matching that
on the refrigerator rating plate.
• Do not use an extension cord.
• Read all safety precautions on pages 2 and 3.
8
1” = 2.5 cm; 1’ = 0.3 m

9
Installation Instructions
Control Dial
Levelling Legs
Dairy Bin
Adjustable Shelves
Temperature Control Panel
Crisper Cover
Fruit and Vegetable Crispers
Door Shelf
Door Shelf
Door Shelf
REFRIGERATOR FEATURES (appearance and features may vary)
* All images in this instruction manual are for indication only; please refer to your individual unit for details.

When reversing the door swing:
•Read the instructions all the way through before
starting.
•Handle parts carefully to avoid scratching paint.
•Set screws down by their related parts to avoid using
them in the wrong places.
•Provide a non-scratching work surface for the doors.
IMPORTANT: Once you begin, do not move the cabinet
until door-swing reversal is completed.
These instructions are for changing the hinges from the
right side to the left side—if you ever want to change
the hinges back to the right side, follow these same
instructions and reverse all references to left and right.
Unplug the refrigerator from its electrical outlet.
NOTE: Do not let either door drop to the floor. To do
so could damage the door stop.
CAUTION
Lifting Hazard
The Fresh Food and Freezer doors are heavy Use
both hands to secure the doors before lifting.
IMPORTANT NOTES
Installation Instructions
REVERSING THE DOOR SWING
REMOVE FREEZER DOOR (CONT.)
1
5. Remove the tape and tilt the door away from the
cabinet. Lift it off the center hinge pin.
6. Transfer plastic bushing from right side of top of
freezer door to the left side.
Top Hinge
7Remove the hole covers with a putty knife on the
opposite side of the three hinges.
Hole Cover Center Hinge
Hole Covers
Bottom Hinge
Hole Covers
5/16″socket and ratchet
TOOLS YOU WILL NEED
Phillips screwdriver
Masking tape Allen wrench (Stainless Steel
Handle Models)
1” = 2.5 cm; 1’ = 0.3 m
1. Remove all food from the inner door liner..
2. Tape the door shut with masking tape.
3. Remove the hinge cover on top of the freezer door
with a thin-blade screwdriver..
10
REMOVE FREEZER DOOR
1
4. Remove the three screws with a 5/16″ socket and
ratchet, then lift the hinge straight up to free the hinge
pin from the socket in the top of the door.
8. Set the door on a non-scratching surface with the
inside up.

REMOVE REFRIGERATOR DOOR
2
1. Remove all food from the inner door liner.
2. Tape the door shut with masking tape.
3. Remove the center hinge by removing two hinge
screws with a 5/16″socket and ratchet. Save the
center hinge and screws.
4. Remove the tape and tilt the door away from the
cabinet. Lift the door straight up to free its bottom
socket from the pin in the bottom hinge bracket.
5. Transfer plastic bushing from right side of top of
refrigerator door to the left side.
6. Set the door on a non-scratching surface with the
inside up.
7. Install the 2 hole plugs from the opposite side of
the cabinet to the screw holes vacated by the
center hinge removal.
TRANSFER BOTTOM HINGE TO THE
LEFT
1. Using a 5/16 Socket
and ratchet, remove
the 2 screws from the
bottom hinge.
2. Move the bottom
hinge pin from the
right to the left side
with a thin-blade
screwdriver until the
shoulder of the hinge
pin is touching the
hinge.
3. Move the bottom
hinge from the right
to the left side and
tighten the 2 screws.
4. Install the 2 hole
plugs from the
opposite side of the
cabinet to the screw
holes vacated by
the bottom hinge
removal.
TRANSFER DOOR STOP TO THE LEFT
1. On both the refrigerator and freezer doors,
remove the screws from the door stop on the
right with a Phillips screwdriver.
2. Install the door stop on the left of each door.
3
4
Installation Instructions
REVERSING THE DOOR SWING (CONT.)
1” = 2.5 cm; 1’ = 0.3 m
11

Installation Instructions
REVERSING DOOR HANDLES –
TRANSFER FREEZER DOOR HANDLE
TO THE LEFT SIDE
1. Loosen the set screws on the handle with 1/8”
wrench and remove handle.
2. Remove the fasteners from the surface of the freezer
door, and cover the new vacant holes..
3. Remove the plug buttons from the surface of the right
side of the refrigerator door and insert the fasteners
with a Phillips screwdriver.
5REVERSING DOOR HANDLES –
TRANSFER REFRIGERATOR DOOR
HANDLE TO THE LEFT SIDE
1. Loosen set screws on handle with 1/8” wrench
and remove handle.
2. Remove the fastener from the surface of the
refrigerator door, and cover the new vacant hole
with the plug from the opposite side.
3. Insert the fastener into the surface of the right side
of the freezer door with a Phillips screwdriver.
6
12
1” = 2.5 cm; 1’ = 0.3 m
4. Attach handle to freezer door with screws at the top
of the handle. Use 1/8” allen wrench to tighten the set
screws.
NOTE: Do not over-tighten.
4. Attach the handle to the freezer door with set screws.
Use 1/8” allen wrench to tighten the set screws.
NOTE: Do not over-tighten.
REVERSING THE DOOR SWING (CONT.)

13
Installation Instructions
REVERSING THE DOOR SWING (CONT.)
REHANG THE REFRIGERATOR DOOR
1. Lower the refrigerator door onto the bottom
hinge pin.
7
2. While holding the door securely, use the new
left-hand middle hinge from the accessory kit
insert hinge pin into socket in door. Attach the
center hinge with two screws with a 5/16″socket
and ratchet.
REHANG THE FREEZER DOOR
1. Lower the freezer door onto the center hinge pin.
2. Place the left top hinge so the pin fits into the door
socket. (Left top hinge and cover can be found inside
of the product. Call your Moffat Service provider
at 800.561.3344 if parts are missing. Support the
door on the handle side and make sure the door
is straight and the gap between the doors is even
across the front. While holding the door in place,
tighten the top hinge screws. Do not overtighten
these screws. Tighten them until they are just snug,
and then turn them another one-half turn.
3. Snap the left top hinge cover over the hinge.
8
1” = 2.5 cm; 1’ = 0.3 m

HUMMM...
WHOOSH...
n The new high efficiency compressor may run faster and
longer than your old refrigerator and you may hear a
high-pitched hum or pulsating sound while
it is operating.
n You may hear a whooshing sound when the doors close.
This is due to pressure equalizing within the refrigerator.
Newer refrigerators sound different from older refrigerators. Modern refrigerators
have more features and use newer technology.
n You may hear the fans spinning at high speeds.
This happens when the refrigerator is first plugged in,
when the doors are opened frequently or when a large
amount of food is added to the refrigerator or freezer
compartments. The fans are helping to maintain the
correct temperatures.
CLICKS, POPS,
CRACKS and CHIRPS
n You may hear cracking or popping sounds when
the refrigerator is first plugged in. This happens as
the refrigerator cools to the correct temperature.
n The compressor may cause a clicking or chirping
sound when attempting to restart (this could take
up to 5 minutes).
n Expansion and contraction of cooling coils during and
after defrost can cause a cracking or popping sound.
n On models with an ice maker, after an ice making
cycle, you may hear the ice cubes dropping into the ice
bucket.
WATERSOUNDS
n The flow of refrigerant through the freezer cooling coils
may make a gurgling noise like boiling water.
n Water dropping on the defrost heater can cause a
sizzling, popping or buzzing sound during the defrost
cycle.
n A water dripping noise may occur during the defrost
cycle as ice melts from the evaporator and flows into
the drain pan.
n Closing the door may cause a gurgling sound due
to pressure equalization.
Do you hear what I hear? These sounds are normal.
Normal operating sounds.
14

15
Problem Possible Causes What To Do
Refrigerator does not
operate Refrigerator in defrost cycle. Wait about 30 minutes for defrost cycle to end.
Refrigerator is unplugged. Push the plug completely into the outlet.
The fuse is blown/circuit breaker is
tripped. Replace fuse or reset the breaker.
Vibration or rattling
(slight vibration is
normal)
Front leveling legs need adjusting. See Leveling Legs.
Motor operates for long
periods or cycles on and
off frequently. (Modern
refrigerators with more
storage space and a
larger freezer require
more operating time.
They start and stop
often to maintain even
temperatures.)
Normal when refrigerator is first plugged
in. Wait 24 hours for the refrigerator to completely cool down.
Often occurs when large amounts of
food are placed in refrigerator. This is normal.
Door left open. Check to see if a package is holding door open.
Hot weather or frequent door openings. This is normal.
Temperature control set at the coldest
setting. See About the control.
Fresh food or freezer
compartment too warm Temperature control not set cold enough. See About the control.
Warm weather or frequent door
openings. Set the temperature control one step colder. See About the control.
Door left open. Check to see if a package is holding door open.
Frost or ice crystals on
frozen food (frost within
package is normal)
Door left open. Check to see if a package is holding door open.
Too frequent or too long door openings.
Ice cubes have odor/
taste Food transmitting odor/taste to ice cubes. Wrap foods well.
Interior of refrigerator needs cleaning. See Care and cleaning.
Slow ice cube freezing Door left open. Check to see if package is holding door open.
Temperature control not set cold
enough. See About the control.
Refrigerator has odor Foods transmitting odor to refrigerator. Foods with strong odors should be tightly wrapped.
Keep an open box of baking soda in the refrigerator;
replace every three months.
Interior needs cleaning. See Care and cleaning.
Moisture forms on
outside of refrigerator Not unusual during periods of high humidity. Wipe surface dry.
Moisture collects inside
(in humid weather, air
carries moisture into
refrigerator when doors
are opened)
Too frequent or too long door openings.
Before you call for service… moffatappliances.ca
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.

16
Problem Possible Causes What To Do
Interior light does
not work No power at outlet. Replace fuse or reset the breaker.
Light bulb burned out. See Replacing the light bulb.
Food is freezing in the
refrigerator Food too close to the air vent at the back of the refrigerator. Move the food away from the air vent.
Refrigerator control is set too cold. Move the refrigerator control to a warmer
temperature setting one increment at a time. See
About the controls.
Rust, tarnish, or grime on
stainless steel doors Moist environment or salt air. Clean stainless steel with cleaners containing oxalic acid (e.g. Bar Keepers Friend Soft
Cleanser) will remove rust, lime,and other
tarnish. Do not wipe the refrigerator with a
soiled dish cloth or wet towel. Do not use
scouring pads, powdered cleaners, bleach or
cleaners containing bleach because these
products can scratch and ruin the brush nish
of the stainless steel.
Before you call for service…
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.

17
OWNERSHIP REGISTRATION
P.O. BOX 1780
MISSISSAUGA, ONTARIO
L4Y 4G1
(FOR CANADIAN CONSUMERS ONLY)
Please place in envelope and mail to:
Veuillez mettre dans une enveloppe et envoyez à :

18
RAC NRUTER DNA ENIL SIHT GNOLA TUC D SKNAHT—
For Canadian
Customers
Pour les
Consommateurs
Canadiens
OWNERSHIP REGISTRATION CERTIFICATE – FICHE D’INSCRIPTION DU PROPRIÉTAIRE
Please register your product to enable us to contact you in
the remote event a safety notice is issued for this product
and to allow for efficient communication under the terms of
your warranty, should the need arise.
Veuillez enregistrer votre produit afin de nous permettre de
communiquer avec vous si jamais un avis de sécurité concernant
ce produit était émis et de communiquer facilement avec vous en
vertu de votre garantie, si le besoin s’en fait sentir.
REGISTER ON-LINE:
www.geappliances.ca
ENREGISTREMENT SUR INTERNET À :
www.electromenagersge.ca
MAIL TO: P.O. BOX 1780, MISSISSAUGA
POSTER À : ONTARIO, L4Y 4G1
MR. / M MRS. / MME.
MISS/MLLE. MS.
FIRST NAME / PRÉNOM LAST NAME / NOM
STREET NO / N
O
RUE STREET NAME / RUE APT.NO/APP./RR#
CITY / VILLE
PROVINCE POSTAL CODE POSTAL
AREA CODE/
IND. RÉG.
TELEPHONE E-MAIL
DID YOU PURCHASE A SERVICE CONTRACT FOR THIS APPLIANCE?
AVEZ-VOUS ACHETÉ UN CONTRAT DE SERVICE POUR CET APPAREIL ? YES/OUI
NO/NON
IF YES/SI OUI : EXPIRATION
Y/A M D/J
NAME OF SELLING DEALER / NOM DU MARCHAND
INSTALLATION DATE / DATE D’INSTALLATION
Y/A M D/J CORRESPONDENCE
ENGLISH
CORRESPONDANCE
FRANÇAIS
I do not wish to receive any promotional offers regarding this product.
Je ne désire pas recevoir d’offres promotionnelles concernant ce produit
.
MODEL / MODÈLE
SERIAL / SÉRIE

19
Refrigerator Warranty.
All warranty service provided by our Factory Service Centers, or
an authorized Customer Care®technician. To schedule service
call 1-800-561-3344.
Please have serial number and model number available when
calling for service.
■Service trips to your home to teach you how to use the product.
■Improper installation, delivery or maintenance.
■Failure of the product if it is abused, misused, or used for other
than the intended purpose or used commercially.
■Loss of food due to spoilage.
■Replacement of house fuses or resetting of circuit breakers.
■Damage caused after delivery.
■Replacement of the water filter cartridge, if included, due to water
pressure that is outside the specified operating range or due to
excessive sediment in the water supply.
■Replacement of the light bulbs, if included, or water filter
cartridge, if included, other than as noted above.
■Damage to the product caused by accident, fire, floods or acts
of God.
■Incidental or consequential damage caused by possible defects
with this appliance.
■Product not accessible to provide required service.
What MC Commercial Inc. Will Not Cover:
This warranty is extended to the original purchaser and any succeeding owner for products purchased in
Canada for home use within Canada.
In-home warrant service will be provided in areas where it is available and deemed reasonable by
MC Commercial Inc. to provide.
Warrantor: MC Commercial Inc., Burlington, ON L7R 5B6
EXCLUSION OF IMPLIED WARRANTES-Your sole and exclusive remedy is product repair as provided in this
Limited Warranty. Any implied warranties, including the implied warranties of merchantability or fitness
for a particular purpose, are limited to one year or the shortest period allowed by law.
For The Period Of: MC Commercial Inc. Will Replace
One Year
From the date of the
original purchase
Any part of the refrigerator which fails due to a defect in materials or workmanship.
During this limited one-year warranty, MC Commercial Inc. will also provide, free of charge, all labor and
related service to replace the defective part.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain
service under the warranty.

Consumer Support.
Schedule Service
Expert repair service is only one step away from your door.
Call 1.800.561.3344 during normal business hours.
Real Life Design Studio
We support Universal Design concept-products, services and environments that can be used by people of all
ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental abilities and
impairments. For details of our Universal Design applications, including kitchen design ideas for people with disabilities,
check out our Website today.
Write to us: Director, Customer Relations, MC Commercial Inc.
Bureau 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
Extended Warranties
Please consult your local listings for extended warranty suppliers.
Parts and Accessories
Consult the yellow pages for the nearest authorized parts distributor, or call 1.800.661.1616.
Instructions contained in this manual cover procedures to be performed by any user.
Other servicing generally should be referred to qualified service personnel. Caution must be exercised, since
improper servicing may cause unsafe operation.
Contact Us
If you are not satisfied with the service you receive, contact us on our Website with all the details including your phone
number, or write to:
Director, Customer Relations, MC Commercial Inc.
Bureau 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
Register Your Appliance moffatappliances.ca
Register your new appliance on-line-at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise.
You may also mail in the pre-printed registration card included in the packing material.
20
