MOLDEX-METRIC 7000 Series User manual

The 7140 combines the 7100 organic vapor cartridge, the
7920 piggyback adapter and the 7940 P100 particulate
filter disk.
The 7640 combines the 7600 multi-gas/vapor Smart®
cartridge, the 7920 piggyback adapter and the 7940 P100
particulate filter disk.
Cost Savings
7140 and 7640 come pre-assembled but, unlike competitive
models, they can be easily disassembled. This feature enables
the user to replace either the filter or the cartridge or both as they
become used up which helps to save money and reduces waste.
With other brands, users are forced to discard the entire unit.
Convenience
Pre-assembled units save time and reduce the chance of error in
selecting or assembling cartridge/filter combinations. Simply
remove from the bag and attach to the respirator.
Applications
The Moldex 7140 and 7640 combo stacked cartridge/filters
are useful in a variety of applications including petrochemical,
construction, transportation, and chemical manufacturing.
• For use with Moldex 7000 half mask respirator and Moldex
9000 full face respirator.
• All product and packaging material is 100% PVC-Free, for a
greener alternative.
Packaging
Part # Description Quantity Case
7140 Organic Vapor 1 pair per Bag 30 pairs
Cartridge/P100
7640 Multi-Gas/Vapor 1 pair per Bag 30 pairs
Smart®Cartridge/P100
COMBO STACKED CARTRIDGE/FILTERS
®
7640
7140

IMPORTANT NOTICE TO USERS
You are responsible to understand and follow all warnings, restrictions and other
information contained in the instruction manual before you enter a contaminated
work area. Failure to do so may result in sickness or death.
APPLICATIONS
USE AGAINST
1. Contaminants specified on NIOSH approval label, matrix, cartridges or filters and
in accordance with all limitations and applicable safety and health regulations,
including OSHA.
2. Contaminants with good warning properties, i.e., smell, taste or irritation.
DO NOT USE AGAINST
1. Concentrations of contaminants which are unknown, or are immediately dangerous
to life or health.
2. Concentrations of contaminants which exceed the maximum use concentration or
10x times the OSHA Permissible Exposure Limit, (PEL), when qualitatively fit tested,
or 50x times the PEL when quantitatively fit tested, or according to applicable
government regulations.
3. Gases or vapors with poor warning properties or those which generate high heats
of reaction, or paint sprays containing isocyanates.
4. Sandblasting.
5. Oil-based mists with N filters.
RESTRICTIONS
01. This respirator does not supply oxygen and must not be used in atmospheres
containing less than 19.5% oxygen.
02. Do not remain in contaminated area if any physical distress occurs, for example
breathing difficulty, dizziness or nausea.
03. Leave contaminated area and replace respirator and/or cartridge or filter if it is
damaged, distorted, a proper fit cannot be obtained, you taste, smell or become
irritated by contaminants, or breathing becomes difficult.
04. Do not alter, modify, or abuse this respirator.
05. Store respirator in sealed bag in a clean, dry, non-contaminated area.
06. Dispose of facepiece, and/or cartridges and disks/filters according to your
employer’s policy and applicable regulations.
07. N, R or P filters are required for particulates.
08. Where oil mists are present, either alone or in combination with solid particulates,
do not use the R or P filters for longer than one eight-hour work shift. Dispose
no later than eight hours after first use. Do not exceed 10x or 50x PEL (see
Do Not Use Against, item 2) and 200 mg loading per respirator. It is the user’s
responsibility to know the PEL and concentration of the contaminant, the
maximum work rate of the employee, and any other work site-specific information
to calculate the loading of the filter. Where oil mists are present do not use
N filters.
09. Dispose of all cartridges and N filters no later than thirty days after
a) first use, and/or b) removing from sealed bag.
10. Use cartridges, filters, and facepieces before the “use by” expiration date printed
on box or bag.
WARNINGS TO USER
1. Follow all instructions and warnings on the use of this respirator and wear during
all times of exposure. Failure to do so will reduce respirator effectiveness, wearer
protection, and may result in sickness or death.
2. For proper use, ask your supervisor or call [phone] or
[phone], ext. 512/550.
3. The user must first be trained by the employer in proper respirator use, in
accordance with applicable safety and health standards, for the contaminant and
exposure level in the assigned work area. A written Respiratory Training Program
must be in place and followed by each user before first use. It must meet all
requirements of all applicable standards, including OSHA 29 CFR 1910.134, and in
Canada CSA Z 94.4, e.g. training, fit testing, medical evaluation, and applicable
OSHA substance specific standards.
4. The vapors, gases, dusts, mists, fumes, and other contaminants which can be
dangerous to your health include those which you cannot see, taste, or smell.
5. Check with your supervisor for the appropriate cartridges and/or filters for the
contaminants in your work area.
6. A qualitative or quantitative fit test must be performed before a respirator is
assigned. Refer to current OSHA 29 CFR 1910.134 (f).
TECHNICAL SERVICE LINE
Moldex maintains a toll-free Technical Service Line to answer questions about the use
of Moldex respirators, contaminants and regulations. If you have any questions call
[phone] or [phone], ext. 512/550.
LIMITED WARRANTY – IMPORTANT NOTICE TO PURCHASER
This limited warranty is made in lieu of the warranties of merchantability, fitness for
particular purposes and all other warranties, express or implied. There are no other
warranties which extend beyond the description on the face hereof. The physical
standards and specifications of Moldex will be met by products sold. Exclusive
Remedies: damages for the breach of this limited warranty are limited to the
replacement of such quantity of Moldex products proved to be defectively manufac-
tured. Except as provided above, Moldex shall not be liable or responsible for any loss,
damage, or liability, direct, indirect, incidental, special, or consequential, arising out of
sale, use, or misuse, or the inability to use products by the user.
DISTRIBUTED BY:
MOLDEX-METRIC, INC. CANADIAN CUSTOMER SERVICE
10111 W. Jefferson Blvd., Culver City, CA 90232 Tel: [phone], Ext. 517
Tel: [phone] or [phone] Fax: [phone]
Fax: [phone]
Email: [email protected] www.moldex.com
Moldex, Ideas that wear well, the PVC-Free logo and Smart are registered trademarks. U.S. Patents Pending.
7140-807 REV A 08/11
®
