Molex Sst-dn4-104-1 Operating and maintenance manual

SST-DN4-104-1

and SST-DN4-104-2

Hardware Reference Guide

Document Edition: 1.1

Document #: 715-0099

StockCheck.com

Hardware Reference Guide SST-DN4-104-1 and SST-DN4-104-2

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

Document Edition: 1.1

Date: August 8, 2008

This document applies to the SST-DN4-104-1 and SST-DN4-104-2 interface cards.

This document and its contents are the proprietary and confidential property of Woodhead

Industries Inc. and/or its related companies and may not be used or disclosed to others without

the express prior written consent of Woodhead Industries Inc. and/or its related companies.

SST is a trademark of Woodhead Industries Inc. All other trademarks belong to their respective

companies.

At Woodhead, we strive to ensure accuracy in our documentation. However, due to rapidly

evolving products, software or hardware changes occasionally may not be reflected in our

documents. If you notice any inaccuracies, please contact us (see Appendix E of this document).

Written and designed at Woodhead Software & Electronics, 50 Northland Road,

Waterloo, Ontario, Canada N2V 1N3.

Hardcopies are not controlled.

StockCheck.com

Downloaded from StockCheck.com

SST-DN4-104-1 and SST-DN4-104-2 Hardware Reference Guide

Contents iii

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

Contents

Preface ......................................................................................................................... vii

Purpose of this Guide ............................................................................................................... viii

Using this Guide ....................................................................................................................... viii

Conventions................................................................................................................................ix

Style......................................................................................................................................... ix

Terminology..............................................................................................................................x

Special Notation ...................................................................................................................... xi

Card Overview ............................................................................................................. 13

1.1 Warnings and Cautions.........................................................................................................14

1.2 Card Features........................................................................................................................15

1.3 Byte Ordering .......................................................................................................................15

1.4 DN4 Compatibility ...............................................................................................................15

1.5 Hardware Description...........................................................................................................16

1.5.1 CAN Connector..............................................................................................................17

1.5.2 LEDs...............................................................................................................................19

1.5.3 Switches .........................................................................................................................21

Installation ................................................................................................................... 25

2.1 System Requirements ...........................................................................................................26

2.2 Handling Precautions............................................................................................................26

2.3 Installing the Card ................................................................................................................27

2.4 Connecting to a Network......................................................................................................28

2.4.1 Connecting to a DeviceNet Network .............................................................................28

2.4.2 Connecting to a CAN Network ......................................................................................29

StockCheck.com

Downloaded from StockCheck.com

Hardware Reference Guide SST-DN4-104-1 and SST-DN4-104-2

iv Contents

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

Hardware Registers..................................................................................................... 31

3.1 DN4 Card Configuration Registers ......................................................................................32

3.1.1 Host Register Layout......................................................................................................32

3.1.2 Control Register .............................................................................................................33

3.1.3 AddrMatch Register .......................................................................................................34

3.1.4 WinSize Register............................................................................................................37

3.1.5 Bank Address Register ...................................................................................................38

3.1.6 HostIrq Register .............................................................................................................40

3.1.7 LedReg Register.............................................................................................................42

3.1.8 Reserved Register...........................................................................................................43

3.1.9 FamilyId Register...........................................................................................................43

Troubleshooting.......................................................................................................... 45

4.1 HLTH or PWR LED is Red..................................................................................................46

4.1.1 HLTH LED is Red .........................................................................................................46

4.1.2 PWR LED is Red ...........................................................................................................46

4.2 Memory Conflict ..................................................................................................................47

4.3 Card Not Found ....................................................................................................................47

4.4 General Troubleshooting ......................................................................................................47

Error Messages ........................................................................................................... 49

A.1 Introduction .........................................................................................................................50

A.2 FamilyID Messages .............................................................................................................50

A.3 Fatal Hardware Self-Test Flash Codes ................................................................................51

Technical Specifications ............................................................................................ 53

B.1 Technical Specifications ......................................................................................................54

Loading Firmware ....................................................................................................... 57

C.1 Loading Firmware................................................................................................................58

C.1.1 Verify Card Presence.....................................................................................................58

C.1.2 Check for Conflicting RAM..........................................................................................59

C.1.3 Test Channel RAM........................................................................................................60

C.1.4 Load and Start the Firmware Module............................................................................61

CE Compliance............................................................................................................ 63

D.1 CE Compliance....................................................................................................................64

Warranty and Support................................................................................................. 65

E.1 Warranty...............................................................................................................................66

E.2 Reference Documents ..........................................................................................................66

StockCheck.com

Downloaded from StockCheck.com

SST-DN4-104-1 and SST-DN4-104-2 Hardware Reference Guide

Contents v

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

E.3 Technical Support ................................................................................................................66

E.3.1 Getting Help...................................................................................................................67

Index............................................................................................................................. 69

StockCheck.com

Downloaded from StockCheck.com

Hardware Reference Guide SST-DN4-104-1 and SST-DN4-104-2

vi Contents

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

StockCheck.com

Downloaded from StockCheck.com

SST-DN4-104-1 and SST-DN4-104-2 Hardware Reference Guide

Preface vii

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

Preface

Preface Sections:

•Purpose of this Guide

•Using this Guide

•Conventions

StockCheck.com

Downloaded from StockCheck.com

Hardware Reference Guide SST-DN4-104-1 and SST-DN4-104-2

Purpose of this Guide

This guide contains technical and product-related information on the SST-DN4-104-1

and SST-DN4-104-2 network interface cards.

The SST-DN4-104-1 consists of a single DeviceNet network interface (or channel), and the

SST-DN4-104-2 comprises two independent interfaces, controlled by independent CPUs.

Each CPU executes downloadable application firmware modules, which enable application-level

product behavior. For more details, refer to relevant firmware documentation.

Note

An application running on one channel does not affect the performance

of other channels, as it does not share memory or processor resources

with them.

Note

In this manual, the SST-DN4-104-1 and SST-DN4-104-2 will be

referred to as the card, except where product differences apply.

Using this Guide

If you are running a 3rd party application or writing your own application using the card’s DLL

calls, the sections of interest in this guide will be “Card Overview”, “Installation” and potentially

“Troubleshooting”. If you are writing your own application in a non-Windows environment

(interfacing directly with the card’s memory registers), we recommend that you read the whole

guide.

viii Preface

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

StockCheck.com

Downloaded from StockCheck.com

SST-DN4-104-1 and SST-DN4-104-2 Hardware Reference Guide

Preface ix

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

Conventions

This guide uses stylistic conventions, special terms, and special notation to help enhance your

understanding.

Style

The following stylistic conventions are used throughout this guide:

Bold indicates field names, button names, tab names, executable files,

and options or selections

Italics indicates keywords (indexed) or instances of new terms and/or specialized

words that need emphasis

CAPS indicates a specific key selection, such as ENTER, TAB, CTRL, ALT,

DELETE

Code Font indicates command line entries or text that you’d type into a field

Underlining indicates a hyperlink

“>” delimiter indicates how to navigate through a hierarchy of menu selections/options

“0x” indicates a hexadecimal value

StockCheck.com

Downloaded from StockCheck.com

Hardware Reference Guide SST-DN4-104-1 and SST-DN4-104-2

x Preface

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

Terminology

The following special terms are used throughout this guide:

Card The SST-DN4-104-1 or SST-DN4-104-2 network interface card

Channel A DeviceNet network interface on the card

Firmware Module The embedded software module that gets loaded to the card’s memory and

runs on the card. This is the operating system of the card, enabling it to

respond to commands from the host and manage network

communications.

Host The computer system in which the card is installed

.ss4 Firmware module for the card

StockCheck.com

Downloaded from StockCheck.com

SST-DN4-104-1 and SST-DN4-104-2 Hardware Reference Guide

Special Notation

The following special notations are used throughout this guide:

Warning

Warning messages alert the reader to situations where personal injury

may result. Warnings are accompanied by the symbol shown, and

precede the topic to which they refer.

Caution

Caution messages alert the reader to situations where equipment damage

may result. Cautions are accompanied by the symbol shown, and

precede the topic to which they refer.

Note

A note provides additional information, emphasizes a point, or gives a

tip for easier operation. Notes are accompanied by the symbol shown,

and follow the text to which they refer.

Preface xi

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

StockCheck.com

Downloaded from StockCheck.com

Hardware Reference Guide SST-DN4-104-1 and SST-DN4-104-2

xii Preface

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

StockCheck.com

Downloaded from StockCheck.com

SST-DN4-104-1 and SST-DN4-104-2 Hardware Reference Guide

Card Overview 13

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

Card Overview

Chapter Sections:

•Warnings and Cautions

•Card Features

•Byte Ordering

•DN4 Compatibility

•Hardware Description

StockCheck.com

Downloaded from StockCheck.com

Hardware Reference Guide SST-DN4-104-1 and SST-DN4-104-2

1.1 Warnings and Cautions

The card is an electrical component and must be treated with the following precautions:

Warning

Only qualified electrical personnel familiar with the construction/

operation of this equipment and the hazards involved should install,

adjust, operate, and/or service this equipment. Read and understand this

guide in its entirety before proceeding. Failure to observe this precaution

could result in severe bodily injury or, in extreme cases, loss of life.

Warning

You must provide an external, hard-wired emergency stop circuit

outside the programmable controller circuitry. This circuit must disable

the system in case of improper operation. Uncontrolled machine motion

may result if this procedure is not followed. Failure to observe this

precaution could result in bodily injury.

Caution

The card contains static-sensitive components. Careless handling may

severely damage the card. Do not touch any of the connectors or pins on

the card. When not in use, the card should be stored in an anti-static bag.

Failure to observe this precaution could result in damage to or

destruction of the equipment.

14 Card Overview

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

StockCheck.com

Downloaded from StockCheck.com

SST-DN4-104-1 and SST-DN4-104-2 Hardware Reference Guide

Card Overview 15

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

1.2 Card Features

The card is a PC/104 interface for communication with DeviceNet and other CAN-based

networks. The main features of each channel are:

•16-bit PC/104 interface (compliant with PC/104, specification 2.4). Sixteen bits is the

width of the data bus and does not restrict the card from being used in a 32-bit operating

system.

•64 MHz NIOS Processor

•256 KB of shared RAM

•DeviceNet-compliant 5-pin CAN connector

•Data rate of up to 1 Mbaud for CAN, and 125K, 250K and 500K for DeviceNet and CAN

•Bi-color LEDs showing the card’s status

•Isolated physical CAN/DeviceNet layer

•The HOST interface is functionally identical to the DN3-104-2

1.3 Byte Ordering

The card uses Intel-style (little endian) byte ordering for multi-byte entities LSB-low address

and MSB-high address. If your host system uses Motorola (big endian) byte ordering (MSB-low

address and LSB-high address), you must compensate for byte ordering in software.

The following language macro will compensate for byte ordering in a 16-bit data entity:

#define SWAP_WORD (WordData) ((WordData<<8) | (WordData>>8))

1.4 DN4 Compatibility

For a comparison of DN4 with DN3, refer to Section E.2, Reference Documents.

StockCheck.com

Downloaded from StockCheck.com

Hardware Reference Guide SST-DN4-104-1 and SST-DN4-104-2

1.5 Hardware Description

The main features of the card are described in more detail in the following sections.

For information on card dimensions, refer to Section B.1, Technical Specifications.

Figure 1: SST-DN4-104-1 & 2 Interface Card

Table 1: Card Features

Feature

16 Card Overview

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

Description Feature Description

1 Channel A Switch 6 Channel B CAN Connector (J201)

2 Channel B Switch 7 PWR LED

3 Connector Hole (H1) 8 HLTH LED

4 Connector Hole (H2) 9 COMM LED

5 Channel A CAN Connector (J101)

Legend

1- and 2-channel

2-channel onl

StockCheck.com

Downloaded from StockCheck.com

SST-DN4-104-1 and SST-DN4-104-2 Hardware Reference Guide

1.5.1 CAN Connector

The 5-pin connector is a removable connector that conforms to the standard DeviceNet pinout.

Pin numbers, names and color codes are identified in the figure below.

Figure 2: 5-Pin CAN Connector

V+

CANH

SHIELD

CANL

V-

Red

White

Bare

Blue

Black

DeviceNet

Color Code:

Pin Name:

12 345

1.5.1.1 V+, V-

These terminals provide power to the isolated section of the network interface, and must

be connected and powered for the card to communicate on the network. On DeviceNet

networks, they connect directly to the red (V+) and black (V-) wires of the DeviceNet

cable. On non-powered CAN networks, they must be connected to an external 24VDC

supply.

Card Overview 17

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

StockCheck.com

Downloaded from StockCheck.com

Hardware Reference Guide SST-DN4-104-1 and SST-DN4-104-2

1.5.1.2 CANH, CANL

These are the CAN communication bus signal terminals. Use only shielded twisted pair cable.

When using the card on DeviceNet with DeviceNet approved cabling, these wires will already

be a twisted pair with the proper DeviceNet impedance.

1.5.1.3 SHIELD

This is the shield connector. This terminal is “snubbed” to the PC/104 chassis ground via a

1M-ohm resistor, through the PC/104 standoffs connected to holes H1 and H2.

Note

The shield should be connected directly to earth ground at only one point

in the network.

Note

PC-104 specifies that hole H1 be connected to chassis ground. If you’re

using the second channel, ensure that H2 is connected the same way.

18 Card Overview

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

StockCheck.com

Downloaded from StockCheck.com

SST-DN4-104-1 and SST-DN4-104-2 Hardware Reference Guide

1.5.2 LEDs

There are three LEDs per channel: Power (PWR), Health (HLTH) and Communications

(COMM).

Note

Card Overview 19

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

For information on troubleshooting using LEDs, refer to Section 4.1,

HLTH or PWR LED is Red.

1.5.2.1 PWR LED

The PWR LED indicates whether or not power is applied to the CAN connector. This LED’s

behavior is described in the following table:

Table 2: PWR LED Behavior

Color Status

Green CAN bus power present

Red CAN bus power not present

Off PC/104 power not present

StockCheck.com

Downloaded from StockCheck.com

Hardware Reference Guide SST-DN4-104-1 and SST-DN4-104-2

1.5.2.2 HLTH LED

The HLTH LED indicates the channel’s health status. This LED’s behavior is described in the

following table:

Table 3: HLTH LED Behavior

Color Status

Off Card initialization failed or the card is not powered

Green The firmware is running

The card has halted or there is a firmware run-time error

Red

Amber Startup self-test complete, no firmware loaded. The

firmware must be reloaded (refer to Section 4.1,

HEALTH or PWR LED is Red).

Note

If the HLTH LED is flashing, there may have been a startup failure.

For more details, refer to Section A.3, Fatal Hardware Self-Test Flash

Codes.

1.5.2.3 COMM LED

The COMM LED indicates the network status. This LED’s meaning and behavior are

determined by the currently loaded firmware module. Refer to the module’s reference

guide for more details.

20 Card Overview

Document Edition: 1.1, Document #: 715-0099, Template Edition: 1.1, Template #: QMS-06-045

Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.

StockCheck.com

Downloaded from StockCheck.com
