Monessen Hearth 624DVNVC User manual
42D0200 1/13 Rev. 17
420200
6000DV cover
Installation and Operating
Instructions
242D0200
Designer Series Gas Fireplaces
High Elevations ........................................................5
Gas Pressures .........................................................5
Gas Specications & Orice Sizes ...........................5
Before You Start .......................................................5
Fireplace Dimensions ..............................................6
Peninsula Fireplace Framing ...................................7
Corner Fireplace Framing ........................................7
See Through Fireplace Framing ..............................8
Fireplace Location ..................................................10
Secure Fireplace ....................................................10
Canopy Installation ................................................10
Installation Precautions ..........................................12
Installation Clearances ...........................................13
Installation Planning ...............................................13
Installation for Vertical Termination ........................13
Termination Location ..............................................14
How to Use the Vent Graph ...................................15
Rear Wall Vent Installation .....................................16
Horizontal Termination Conguration .....................18
Below Grade Installation ........................................20
Vertical Through-the-Roof Installation ....................21
Installation for Vertical Termination ........................21
Flat Ceiling Installation ...........................................22
Check Gas Type.....................................................23
Installing Gas Piping ..............................................23
Electrical Wiring .....................................................25
Remote Wall Switch ...............................................26
Remote Wall Switch ...............................................26
What To Do If You Smell Gas .................................32
Lighting Pilot for the First Time ..............................32
Lighting Pilot ..........................................................33
Lighting Burner .......................................................34
To Turn Off Gas ......................................................34
Venting System ......................................................35
Cleaning Glass .......................................................35
Pilot and Burner Flames ........................................35
Firebox Cleaning ....................................................35
Firebox Components ..............................................39
Standing Pilot - Millivolt Control .............................40
Electronic Ignition ...................................................41
Log .........................................................................42
Venting Components ..............................................43
42D0200
Designer Series Gas Fireplaces
3
4. Never install the replace
• in a recreational vehicle
• where curtains, furniture, clothing, or other am-
mable objects are less than 42" from the front, top,
or sides of the replace
• in high trafc areas
• in windy or drafty areas
5. This replace reaches high temperatures. Keep chil-
dren and adults away from hot surfaces to avoid burns
or clothing ignition. Fireplace will remain hot for a time
after shutdown. Allow surfaces to cool before touch-
ing.
6. Carefully supervise young children when they are in
the room with replace.
7. Do not modify replace under any circumstances. Any
parts removed for servicing must be replaced prior to
operating replace.
8. Turn replace off and let cool before servicing, install-
ing, or repairing. Only a qualied service person should
install, service, or repair the replace. Have burner
system inspected annually by a qualified service
person.
9. You must keep control compartments, burners, and
circulating air passages clean. More frequent cleaning
may be needed due to excessive lint and dust from
carpeting, bedding material, pet hair, etc. Turn off the
gas valve and pilot light before cleaning replace.
10. Have venting system inspected annually by a quali-
ed service person. If needed, have venting system
cleaned or repaired. Refer to Cleaning and Mainte-
nance, page 41.
11. Keep the area around your replace clear of combus-
tible materials, gasoline, and other ammable vapor
and liquids. Do not run replace where these are used
or stored. Do not place items such as clothing or deco-
rations on or around replace.
12. Do not use this replace to cook food or burn paper or
other objects.
13. Never place anything on top of replace.
Please leave these instructions with the owner.
Please retain these instructions for future reference
.
This replace is a vented product. This replace must be
properly installed by a qualied service person. The glass
door must be properly seated and sealed. If this unit is not
properly installed by a qualied service person with glass
door properly seated and sealed, combustion leakage
can occur.
Early signs of carbon
monoxide poisoning are similar to the u with headaches,
dizziness and/or nausea. If you have these signs, the re-
place may not have been installed properly. Get fresh air
at once! Have the replace inspected and serviced by a
qualied service person. Some people are more affected
by carbon monoxide than others. These include pregnant
women, people with heart or lung disease or anemia,
those under the inuence of alcohol, and those at high
altitudes.
Propane/LP gas and natural gas are both odorless. An
odor-making agent is added to each of these gases. The
odor helps you detect a gas leak. However, the odor added
to these gases can fade. Gas may be present even though
no odor exists.
Make certain you read and understand all warnings. Keep
this manual for reference. It is your guide to safe and proper
operation of this replace.
1. This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases unless a certied
kit is used.
2. For propane/LP replace, do not place propane/LP
supply tank(s) inside any structure. Locate propane/
LP supply tank(s) outdoors. To prevent performance
problems, do not use propane/LP fuel tank of less than
100 gal. capacity.
3. If you smell gas
• shut off gas supply.
• do not try to light any appliance.
• do not touch any electrical switch; do not use any
phone in your building .
• immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
442D0200
Designer Series Gas Fireplaces
14. Do not use any solid fuels (wood, coal, paper, card-
board, etc.) in this replace. Use only the gas type
indicated on rating plate.
15. This appliance, when installed, must be electrically
grounded in accordance with local codes or in the
absence of local codes, with the National Electrical
Code, ANSI/NFPA 70, or the Canadian Electrical Code,
CSA C22.1.
16. Do not obstruct the ow of combustion and ventilation
air in any way. Provide adequate clearances around
air openings into the combustion chamber along with
adequate accessibility clearance for servicing and
proper operation.
17. When the appliance is installed directly on carpeting,
tile or other combustible material other than wood
ooring, you must set appliance on a metal or wood
panel or hearth pad extending the full width and depth
of the appliance.
18. Do not use replace if any part has been exposed to
or under water. Immediately call a qualied service
person to arrange for replacement of the unit.
19. Do not operate replace if any log is broken.
20. Do not use a blower insert, heat exchanger insert, or
any other accessory not approved for use with this
replace.
21. Do not operate the replace with glass door removed,
cracked, or broken.
22. This unit is approved for bedrooms and bathrooms.
Direct Vent type appliances draw all combustion air from outside of the dwelling through the
vent pipe.
These appliances have been tested by CSA and found to comply with the established standards for
DIRECT VENT GAS FIREPLACE HEATERS in the USA and Canada as follows:
Tested To: ANSI Z21.88-2009 / CSA 2.33-2009 Standards
A manufactured home (USA only) or mobile home OEM installation must conform with the Manufac-
tured Home Construction and Safety Standard, or when such a standard
is not applicable, the , or
.
It is normal for replaces fabricated of steel to give off
some expansion and/or contraction noises during the
start up or cool down cycle. Similar noises are found
with your furnace heat exchanger or car engine.
It is not unusual for gas replaces to give off some
odor the rst time it is burned. This is due to the
manufacturing process.
It is recommended that you burn your replace for at
least ten (10) hours the rst time you use it. Place the
fan switch in the “OFF” position during this time.
WARNING
!
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
AVERTISSEMENT
!
Un panneau vitré chaud peut
causer des brûlures.
Laissez refroidir le panneau
vitréavant d’y toucher.
Ne laisser jamais les enfants
toucher le panneau vitré.
42D0200
Designer Series Gas Fireplaces
5
• This appliance has been certified for use with
either natural or propane gas. See appropriate data
plates.
• This appliance is not for use with solid fuels.
• The appliance is approved for bedroom or bedsitting
room installations.
• The appliance must be installed in accordance with
local codes if any. If none exist use the current instal-
lation code. ANSI Z223.1/NFPA 54 in the USA, CSA
B149 in Canada.
• This appliance is mobile home approved.
• This appliance is approved for bathroom installa-
tion.
• The appliance must be properly connected to a vent-
ing system.
• The appliance is not approved for closet or
recessed installations.
The efciency rating of this appliance is a product thermal
efciency rating determined under continuous operating
conditions and was determined independently of any
installed system.
FP2276
FP2276
6000DV prod features
Optional
Remote
Receiver
Hi/Lo Knob
Off/Pilot/On
Knob
Control Panel Blower Control
Figure 1 -
Designer Series Fireplace Controls
Input ratings are shown in BTU per hour and are certied
without deration for elevations up to 4,500 feet (1,370
m) above sea level.
For elevations above 4,500 feet (1,370 m) in USA,
installation must be in accordance with the current
ANSI Z223.1/NFPA 54 and/or local codes having juris-
diction.
In Canada, please consult provincial and/or local
authorities having jurisdiction for installation at eleva-
tions above 4,500 feet (1,370 m).
Natural Propane (LP)
Inlet Minimum 4.5” w.c. 11.0” w.c.
Inlet Maximum 10.5” w.c. 13.0” w.c.
Manifold Pressure 3.5” w.c. 10.0” w.c.
624DVNVC Nat. 36,000 25,000 #44
624DVNEC Nat. 36,000 25,000 #44
624DVPVC LP 36,000 26,000 #54
624DVPEC LP 36,000 26,000 #54
Read this homeowner manual thoroughly and follow all
instructions carefully. Inspect all contents for shipping
damage and immediately inform your dealer if any damage
is found. Do not install any unit with damaged, incomplete,
or substitute parts. Check your packing list to verify that
all listed parts have been received. You should have the
following:
• Fireplace (Firebox and Burner System)
• Log Set • Lava Rock • Rock Wool
• Deector Shield (to be used with DuraVent Horizontal
Termination – P/N 985)
• Phillips Screwdriver • Framing Materials
• Hammer • Wall Finishing Materials
• Saw and/or saber saw • Level
• Measuring Tape • Electric Drill and Bits
• Tee Joint • Pliers
• Square • Pipe Wrench
• Caulking Material (Noncombustible)
• Fireplace Surround Material (Noncombustible)
• Piping Complying with Local Codes
• Pipe Sealant Approved for use with Propane/LPG
(Resistant to Sulfur Compounds)
642D0200
Designer Series Gas Fireplaces
236M”
(603 mm)
396” (981 mm)
18(6”
(479 mm)
4(6QE”
(113 mm)
2(6QE” (62 mm)
44” (1118 mm)
3456O”
(876 mm)
4056QE”
(1040 mm) 5/8” (16 mm)
1/2” (13 mm) 326M”
(832 mm)
C
L
5/8” (16 mm)
1/2” (13 mm)
420200
6000Dv penin dims
376M”
(959 mm)
3256M” (819 mm)
16M”
(45 mm) 1956O”
(495 mm)
36" (914 mm)
Gas/Electric Access
3256M” (819 mm)
356M”
(83 mm)
18(6”
(479 mm)
4(6QE”
(113 mm) 396” (1007 mm)
2456O”
(622 mm)
16M”
(45 mm)
1956O”
(495 mm)
376M”
(959 mm)
4056QE”
(1040 mm)
5/8” (16 mm)
1/2” (13 mm)
44” (1118 mm)
376M”
(959 mm)
5/8” (16 mm)
1/2” (13 mm)
420200
6000DV corner dims
5” (127 mm)
36” (914 mm)
Gas/Electric Access
(Right, Top Vent Shown)
Figure 2 -
Fireplace Dimensions
42D0200
Designer Series Gas Fireplaces
7
It is best to build rebox framing the appliance is set in place. Refer to the dimensions for
your replace on Page 7. The framing headers may rest on the top of the rebox standoffs.
The rebox may be installed directly on a combustible oor or raised on a platform of an appropri-
ate height. Do not place rebox on carpeting, vinyl, or other soft oor coverings. It may, however,
be placed on a at wood, plywood, particle board, or other hard surfaces. Be sure rebox rests on
a solid continuous oor or platform with appropriate framing for support. No cold air should enter
room from under the rebox.
1/2" Drywall 5/8" Drywall
A1 43Z\x" (1105 mm) 43C\," (1102 mm)
A2 39M\," (1013 mm) 39C\v" (1010 mm)
B 41Z\," (1045 mm) 41Z\," (1045 mm)
C 22C\v" (578 mm) 22Z\x" (572 mm)
D 24" (610 mm) 23M\," (606 mm)
A2
B
A1
D
A1
A2
C
FP2037
design corner framing
10/08
Gas Connection
2 x 4
(Minimum)
2 x 2
(Minimum)
2 x 4
(Minimum)
FP2037
C
A2
B
A1
A1
A2
C
FP2038
designer see thru framing
10/08
2 x 4 (Minimum)
Gas Connection
FP2038
Figure 3 -
Peninsula Framing
Figure 4 -
Corner Unit Framing
(Right Hand Conguration shown)
842D0200
Designer Series Gas Fireplaces
For ease of installation, frame around the
rebox after it has been set. Refer to chart below for
specications.
When installing into existing framed (A1) openings, loosen
the junction box. Remove the rear-mounted ue pipe adap-
tor. Refer to Page 16, Figures 10 and 11. Reattach both
assemblies.
The combustible area above the facing must
not protrude more than 3/4" from the facing. If it does,
it is considered a mantel and must meet the mantel
requirements listed in this manual.
Figure 6 -
Mantel Clearances
2”
(51 mm)
4” (102 mm)
6” (152 mm)
8” (203 mm)
10” (254 mm)
4”
(102 mm)
6”
(152 mm)
8”
(203 mm)
10”
(254 mm)
12”
(305 mm)
FP2279
mantel clearance
2/09
Wall
Insulation
Board
Standoff
Top of Louvers
FP2279
1/2" Drywall 5/8" Drywall
A1 44Z\v" (1124 mm) 44Z\v" (1124 mm)
A2 40B\," (1032 mm) 40B\," (1032 mm)
B 41Z\," (1045 mm) 41Z\," (1045 mm)
C 22C\v" (578 mm) 22Z\x" (572 mm)
C
A2
B
A1
A1
A2
C
FP2038
designer see thru framing
10/08
2 x 4
(Minimum)
Gas
Connection
2 x 4
(Minimum)
FP2038
Figure 5 -
See-Through Framing
C
A2
B
A1
A1
A2
C
FP2038
designer see thru framing
10/08
42D0200
Designer Series Gas Fireplaces
9
Any remote wiring (i.e. remote control, wall switch,
and optional fan) must be done prior to nal nishing to
avoid costly reconstruction.
Only noncombustible materials (i.e. brick, tile, slate, steel,
or other materials with a UL re rating of Zero) may be used
to cover the black-painted face of the appliance. A 300°F
minimum adhesive may be used to attach facing materi-
als to the black surface. If joints between the nished wall
and the replace surround are sealed, a 300°F minimum
sealant material (General Electric RTV103 or equivalent)
must be used. Combustibles may come to the top and side
edges but not overlay the face.
This gas replace should be installed by a qualied installer
in accordance with local building codes and with current
CSA-B149 (.1 or .2) Installation codes for Gas Burning
Fireplaces and Equipment. If the unit is being installed in a
mobile home the installation should comply with the current
CAN/CSA Z 240 .4 code.
FOR U.S.A. Installations follow local codes and/or the cur-
rent National Fuel Gas Code. ANSI Z223.1.
1. This replace gives off high temperatures and should
be located out of high trafc areas and away from
furniture and draperies.
2. Children and adults should be alerted to the hazards
of the high surface temperatures of this replace and
should stay away to avoid burns or ignition of cloth-
ing.
3. Caution, due to high glass surface temperature children
should be carefully supervised when they are in the
same room as the replace.
4. Under no circumstances should this replace be modi-
ed. Parts removed for servicing should be replaced
prior to operating the replace again.
5. Installation and any repairs to this replace should
be carried out by a qualied service person. A profes-
sional service person should be contacted to inspect
this replace annually. Make it a practice to have all of
your gas replaces checked annually. More frequent
cleaning may be required due to excess lint and dust
from carpeting, bedding material, etc.
6. Control compartments, burners and air passages in this
replace should be kept clean and free of dust and lint.
Make sure that the gas valve and pilot light are turned
off before you attempt to clean this replace.
7. The venting system (chimney) of this replace should
be checked at least once a year and if needed your
venting system should be cleaned.
8. Keep the area around your replace clear of combus-
tible materials, gasoline and other ammable vapor and
liquids. This replace should not be used as a drying
rack for clothing, nor should Christmas stockings or
decorations be hung on or around the replace.
9. Under no circumstances should any solid fuels (wood,
coal, paper or cardboard etc.) be used in this re-
place.
10. The ow of combustion and ventilation air must not be
obstructed in any way.
11. When the replace is installed directly on carpeting,
vinyl tile or any combustible material other than wood,
the replace must be installed on a metal or wood panel
extending the full width and depth of the replace.
12. This replace requires adequate ventilation and com-
bustion air to operate properly.
13. This replace must not be connected to a chimney ue
serving a separate solid fuel burning replace.
14. When the replace is not in use it is recommended that
the gas control valve be left in the “OFF” position.
This appliance has been approved for after-market
mobile home installations.
IMPORTANT:
PLEASE READ THE FOLLOWING CAREFULLY
Remove any plastic from trim parts before turning the
replace ON.
It is normal for replaces fabricated of steel to give off some
expansion and/or contraction noises during the start up or
cool down cycle. Similar noises are found with your furnace
heat exchanger or car engine.
It is not unusual for your Monessen gas replace to give
off some odor the rst time it is burned. This is due to the
curing of the paint and any undetected oil from the manu-
facturing process.
Please ensure that your room is well ventilated — open
all windows.
It is recommended that you burn your Monessen replace
for a least ten (10) hours the rst time you use it. If the
optional fan kit has been installed, place the fan switch
in the “OFF” position during this time.
10 42D0200
Designer Series Gas Fireplaces
Minimum distance between a glass panel and a parallel
wall = 42"
Minimum distance between the edge of a glass panel and
an adjacent wall = 3"
(Maximum length of horizontal venting = 20'. Refer to the
venting section of this manual for specic dimensions.
Figure 7 -
Possible Fireplace Locations
FP2277
A Flat on Wall
B Room Divider
XX
X
A
B
YY
ZA
Y
FP2277
locate fireplace
The replace must be secured to the oor and/or to framing
studs as shown in Figure 8. Use two (2) wood screws or
masonry/ concrete screws to secure replace to the oor.
Use four (4) screws to attach replace to framing. The side
brackets are adjustable from 1/2" to 5/8" to accommodate
different thickness of noncombustible material.
FP2278
secure fireplace
Figure 8 -
Secure Fireplace to Floor and Framing Studs
Screws
FP2278
1. Unlatch and remove glass door. Refer to Page 30.
2. Remove three (3) top louvers by pulling rmly.
3. Locate screws on upper frame and remove. (Five (5)
screws on long side and three (3) screws on short
side.) Figure 9
4. Install canopy hood and secure using
screws previously removed.
5. Reinstall louvers and glass door.
FP2918
canopy install
Figure 9 -
Install ALL Canopies FP2918
42D0200
Designer Series Gas Fireplaces
11
The appliance is shipped as a rear vent unit. If the installa-
tion layout requires the unit to be a top vent conguration
the appliance can be converted by following the steps
below.
When removing and retting the plates and adapter be
sure the associated gaskets are undamaged and retted
as required.
1. Remove the eight (8) screws securing the ue pipe
adapter to the replace body. Figure 10
2. Set the ue pipe adapter aside, complete with the
gasket. Do not damage the gaskets as the adapter and
gasket must be retted.
B\,
FP1991
remove screws
Screws
Flue Pipe
Adapter
Flue Pipe
Adapter
FP1991
Figure 10 -
Remove 16 Screws from Flue Pipe
Adapter and Flue Pipe Cover
FP1992
remove flue pipe
Screws
Flue Pipe
FP1992
Figure 11 -
Remove Flue Pipe
Flue Pipe
Cover
FP1993
replace flue pipe
Screws
Flue Pipe
FP1993
Figure 12 -
Attach Flue Pipe to Top Vent Coln-
guration
3. Remove the eight (8) screws securing the ue pipe cover
to the top of the intake box and remove the cover and
gasket. Figure 10
4. Remove eight (8) screws securing the ue pipe to the
back of the intake box and remove the pipe and gasket.
Figure 11
5. Replace ue pipe to top of rebox. Ensure the gasket is
in place and undamaged. Secure with eight (8) screws.
Figure 12
6. Place the ue pipe cover and gasket removed in step
3 over the ue opening in bottom of the intake box.
7. Ret the ue pipe adapter and gasket to the top of re-
place. Secure the adapter with eight (8) screws removed
in step 1.
12 42D0200
Designer Series Gas Fireplaces
This appliance must be installed with an Vermont
Castings Group approved venting system only.
Consult local building codes before beginning the
installation. The installer must make sure to select the
proper vent system for installation. Before installing vent
kit, the installer must read this replace manual and vent
kit instructions.
Only a qualied installer/service person should install vent-
ing system. The installer must follow these safety rules:
• Wear gloves and safety glasses for protection.
• Use extreme caution when using ladders or when
on rooftops.
• Be aware of electrical wiring locations in walls and
ceilings.
The following actions will void the warranty on your vent-
ing system:
• Installation of any damaged venting component.
• Unauthorized modication of the venting system.
• Installation of any component part not manufactured
or approved by Vermont Castings Group.
• Installation other than permitted by these instruc-
tions.
**1"
*3"
FP2280
vent pipe clear
**1” **1"
(25 mm)
**1”
*3" (76 mm)
326M”
(832 mm)
FP2280
until
the flue penetrates the outside wall.
Figure 13 -
Combustible Clearances for Vent Pipe
* A minimum of 3" clearance to the top is required along horizontal
length until ue pipe penetrates outside wall.
** A minimum 1" clearance to combustibles permitted all around
ue at outside wall.
42D0200
Designer Series Gas Fireplaces
13
There are two basic types of direct-vent installation:
• Horizontal Termination
• Vertical Termination
It is important to select the proper length of vent pipe for
the type of termination you choose. It is also important to
note the wall thickness.
Select the amount of vertical rise desired. All horizontal run
of venting must have 1/4" rise for every 12" of run towards
the termination.
You may use up to three 90° elbows in this vent congu-
ration. Refer to Horizontal Termination Congurations on
Pages 22 and 23.
Measure the distance from the replace oor to the ceil-
ing. Add the ceiling thickness, the vertical rise in an attic
or second story, and allow for sufcient vent height above
the roof line.
You may use two 45° elbows in place of a 90° elbow.
You must follow rise to run ratios when using 45° elbows.
The appliance is approved for use with three 90° elbows
maximum or a combination of 90° and 45° elbows up to
a maximum of 270°.
For two-story applications, restops are required at each
oor level. If an offset is needed in the attic, additional pipe
and elbows will be required.
You may use a chase with a vent termination with exposed
pipe on the exterior of the house. Refer to Installing Vent
System in a Chase below. If pipe is enclosed in chase, it
is not exposed.
It is very important that the venting system maintain its bal-
ance between the combustion air intake and the ue gas
exhaust. Certain limitations apply to vent congurations
and must be strictly followed.
A chase is a vertical boxlike structure built to enclose
venting that runs along the outside of a building. A chase
is required for such venting.
14 42D0200
Designer Series Gas Fireplaces
A = Clearance above grade, veranda, porch, 12” (30 cm) 12” (30 cm)
deck, or balcony
B = Clearance to window or door that may be 6” (15 cm) for appliances 6” (15 cm) for appliances
opened < 10,000BTU/h (3kW), 12” (30 cm) < 10,000 BTU/h (3kW), 9”
for appliances > 10,000 Btuh (3kW) and (23 cm) for appliances > 10,000
< 100,000 BTU/h (30kW), 36” (91 cm) Btuh (3kW) and < 50,000 BTU/h
for appliances > 100,000 BTU/h (30kW) (15kW), 12” (30 cm) for
appliances > 50,000 BTU/h(15kW)
C = Clearance to permanently closed window 12” (305 mm) recommended to 12” (305 mm) recommended to
prevent window condensation prevent window condensation
D = Vertical clearance to ventilated soft located
above the terminal within a horizontal 18” (458 mm) 18” (458 mm)
distance of 2’ (610mm) from the center
line of the terminal
E = Clearance to unventilated soft 12” (305 mm) 12” (305 mm)
F = Clearance to outside corner see next page see next page
G = Clearance to inside corner (see next page) see next page see next page
H = Clearance to each inside of center line 3’ (91 cm) within a height of 15’ (5 m) 3’ (91 cm) within a height of 15’
extended above meter/regulator assembly above the meter/regulator assembly (5 m) above the meter/regulator
assy
I = Clearance to service regulator vent outlet 3’ (91 cm) 3’ (91 cm)
J = Clearance to nonmechanical air supply inlet 6” (15 cm) for appliances < 10,000 6” (15 cm) for appliances
to building or the combustion air inlet to any BTU/h (3kW), 12” (30 cm) for < 10,000 BTU/h (3kW), 9”
other appliances appliances > 10,000 BTU/h (3kW) and (23 cm) for appliances > 10,000
< 100,000 Btuh (30kW), 36” (91 cm) BTU/h (3kW) and < 50,000 BTU/h
for appliances > 100,000 BTU/h (30kW) (15kW), 12” (30 cm) for
appliances > 50,000 BTU/h(15kW)
K = Clearance to a mechanical air supply inlet 6’ (1.83 m) 3’ (91 cm) above if within 10'
(3 m) horizontally
L = Clearance above paved sidewalk or paved 7’ (2.13 m)† 7’ (2.13 m)†
driveway located on public property
M = Clearance under veranda, porch, deck or 12” (30 cm) 12” (30cm)
balcony
V
X
X
X
D
E
B
B
B
C
B
M
B
A
J
K
F
L
VENT TERMINATION AIR SUPPLY INLET AREA WHERE TERMINAL IS NOT PERMITTED
H
I
Fixed
Closed
Operable
Operable Fixed
Closed
B
CFM145a
DV Termin Location
5/01/01 Rev. 12/05/01
sta
INSIDE
CORNER DETAIL
A
G
CFM145a
V
V
V
VV
V
V
V
1 In accordance with the current CSA-B149 Installation Codes
2 In accordance with the current ANSI Z223.1/NFPA 54 National Fuel
Gas Codes
† A vent shall not terminate directly above a sidewalk or paved
driveway which is located between two single family
dwellings and serves both dwellings
only permitted if veranda, porch, deck or balcony is fully open on a
minimum 2 sides beneath the oor:
NOTE: 1. Local codes or regulations may require different
clearances.
2. The special venting system used on Direct Vent Fireplaces
are certied as part of the appliance, with clearances
tested and approved by the listing agency.
3. Vermont Castings Group assumes no responsibility for the
improper performance of the appliance when the venting
system does not meet these requirements.
Figure 14 -
Termination Locations
42D0200
Designer Series Gas Fireplaces
15
The Vent Graph should be read in conjunction with the
following vent installation instructions to determine the
relationship between the vertical and horizontal dimensions
of the vent system.
1. Determine the height of the center of the horizontal vent
pipe exiting through the outer wall. Using this dimen-
sion on the Sidewall Vent Graph below, locate the point
intersecting with the slanted graph line.
2. From the point of this intersection, draw a vertical line
to the bottom of the graph.
3. Select the indicated dimension, and position the re-
place in accordance with same.
If the vertical dimension from the oor of the
replace is 11' (3.4 m) the horizontal run to the face of
the outer wall must not exceed 14' (4.3 m).
If the vertical dimension from the oor of the
unit is 7’ (2.14m), the horizontal run to the face of the
outer wall must not exceed 8Z\x' (2.6 m).
Sidewall Vent Graph showing the relationship between
vertical and horizontal dimensions for a Direct Vent ue
system.
Figure 16 -
Rear Wall Venting Graph
Horizontal Dimension From the Outside Face of the
Wall to the Center of the Fireplace Vent Flange
Vertical Dimension From the Floor of Unit to the Center of the
Horizontal Vent Pipe
40
38
36
34
32
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2
2 4 6 8 10 1214 16 1820
eg: A
Dimensions in
Feet
20"
FP2248
sidewall vent graph
Outside Corner
Inside Corner
Termination Clearances
Termination clearances for buildings with combustible and noncombustible exteriors.
G =
Combustible
6" (152 mm)
Noncombustible
2" (51 mm)
F =
Combustible
6" (152 mm)
Noncombustible
2" (51 mm)
G
Balcony -
with no side wall
M =
Combustible &
Noncombustible
12" (305 mm)
M
Balcony -
with perpendicular side wall
M = 12" (305 mm)
P = 6” (152 mm)
M
F
Alcove Applications*
C
D
C
E
V
V
Combustible &
Noncombustible
E= Min. 2” (51 mm) for
non-vinyl sidewalls
Min. 12” (305 mm) for
vinyl sidewalls
O= 8’ (2.4 m) Min.
O
P
V
V
V
584-15
No.
of Caps DMin. CMax.
1 3’ (914 mm) 2 x DActual
2 6’ (1.8 m) 1 x DActual
3 9’ (2.7 m) 2/3 x DActual
4 12’ (3.7 m) 1/2 x DActual
DMin. = # of Termination caps x 3
CMax. = (2 / # termination caps) x DActual
Termination in an alcove space (spaces open only on one side and with an overhang) is permitted with the dimensions specied for vinyl or
non-vinyl siding and softs. 1. There must be a 3’ (914 mm) minimum between termination caps. 2. All mechanical air intakes within 10’ (1 m) of a
termination cap must be a minimum of 3’ (914 mm) below the termination cap. 3. All gravity air intakes within 3’ (914 mm) of a termination cap must
be a minimum of 1’ (305 mm) below the termination cap.
Figure 15 -
Termination
Clearances
16 42D0200
Designer Series Gas Fireplaces
When installed as a rear vent unit this appliance may be vented directly to a termination located on
the rear wall behind the appliance
• The maximum horizontal distance between the rear of the appliance and the outside face of the
rear wall is 20" (508 m). Figure 17
• Only one 45° elbow is allowed in these installations.
1. Locate and cut the vent opening in the wall. For
combustible walls rst frame in opening.
Cut a 11Z\x"H x 9Z\x" W (292 x 241
mm) hole through the exterior wall and frame as shown.
Figure 18
Hole opening should be 7Z\x"
(190 mm) in diameter.
2. Rigid vent pipes and ttings have special twist-lock
connections. Assemble the desired combination of pipe
and elbows to the appliance adaptor with pipe seams
oriented towards the wall or oor.
Twist-lock Procedure: The female ends of the pipes
and ttings have three locking lugs (indentations).
These lugs will slide straight into matching slots on
the male end of adjacent pipes and ttings. Push the
pipe sections together and twist one section clockwise
approximately one-quarter turn until the sections are
fully locked. Figure 19
3. Attach vent pipe assembly to the replace. Set replace
in front of its permanent location to insure minimum
clearances. Mark the wall for a 11Z\x"H x 9Z\x"W (292 x
241 mm) rectangle hole (for noncombustible material
such as masonry block or concrete, a 7Z\x" [190 mm]
diameter hole is acceptable). Figure 18. The center of
the hole should line up with the center line of the hori-
zontal rigid vent pipe end. Be sure to allow for minimum
rise. Cut a 11Z\x"x9Z\x" rectangle hole through combus-
tible exterior wall (7Z\x" diameter hole if noncombustible).
Frame as necessary. Allow 1/4" minimum rise per foot.
Figure 18
Figure 17 -
Rear Vent Application, Maximum
Horizontal Distance
Top View Flat
Installation
Figure 18 -
Vent Opening Requirements
FP1954
wall framing
9Z\x"
(241 mm)
11Z\x"
(292 mm)
7Z\x"
(190 mm)
FP1954
Horizontal runs of vent must
be supported every three (3) feet
(914 mm). Use wall straps for this
purpose.
Figure 19 -
Rigid Vent Pipe Connections
Female Locking
Lugs
Male Slots
FP1953
rigid pipe
FP1953
DVR584-600
Rear vent no elbows
2/99 djt
20"
(508 mm)
42D0200
Designer Series Gas Fireplaces
17
4. Apply a bead of non-hardening mastic around the
outside edge of vent cap. Position the vent cap in the
center of hole on the exterior wall with the word “UP”
on the vent cap facing up. Insure proper clearance of
1" to combustibles is maintained. Attach the vent cap
with four wood screws supplied. Figure 20
Replace the wood screws with appropriate fasteners
for stucco, brick, concrete, or other types of siding.
For vinyl siding, stucco, or wood exterior use vinyl siding
standoffs between vent cap and exterior wall. The vinyl
siding standoff prevents excessive heat from melting the
vinyl siding material. Bolt the vent cap to the standoff. Apply
non-hardening mastic around outside edge of the standoff
instead of the vent cap assembly. Use wood screws pro-
vided to attach the standoff. Figure 21
5. Slide re stop over the vent pipe before connecting
horizontal run to vent cap. Figure 22
6. Insert vent pipe into the horizontal termination. The pipe
overlap should be a minimum of 1Z\v". Fasten all vent
connections with screws provided.
7. Slide re stop against the interior wall surface and attach
with screws. Figure 22
HOT
FP1956
vinyl siding standoff
Figure 21 -
Installing Vinyl Siding Standoff
Apply
Mastic to All
Four Sides
Cut Vinyl Siding Away
to Fit Standoff
Wood Screw
Vent Cap
Bolt
Nut
Standoff
Deecting
Shield
HOT
FP1955
horizontal vent cap
Figure 20 -
Installing Horizontal Vent Cap
Vent Cap
Wood Screw
Apply Mastic to
All Four Sides
Deecting
Shield
FP1955
FP1956
FP1957
install firestop
Figure 22 -
Connecting Vent Cap with Horizontal Vent Pipe
Interior Wall
Surface
Horizontal
Vent Pipe
Screw
Vent Cap
(Horizontal
Termination)
FP1957
18 42D0200
Designer Series Gas Fireplaces
The Vent Graph, showing the relationship between vertical
and horizontal side wall venting, will help to determine the
various dimensions allowable. Figure 23
When vent termination exits through foundations less than
20" below siding outcrop, the vent pipe must ush up with
the siding.
It is best to locate the replace in such a way that minimizes
the number of offsets and horizontal vent length.
The horizontal vent run refers to the total length of vent
pipe from the ue collar of the replace (or the top of
he Transition Elbow) to the face of the outer wall.
• The maximum number of 90° elbows per side wall
installation is three (3). Figure 24
• If a 90° elbow is tted directly on top of the replace
ange the maximum horizontal vent run before the ter-
mination or a vertical rise is 36” (914 mm). Figure 25 Figure 23 -
Rear Wall Venting Graph
Horizontal Dimension From the Outside Face of the
Wall to the Center of the Fireplace Vent Flange
40
38
36
34
32
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2
2 4 6 8 10 1214 16 1820
eg: A
Dimensions in
Feet
20"
FP2248
sidewall vent graph
FP1176
max 90 bends
Figure 24 -
Maximum Three (3) 90° Elbows Per Installation
3 x 90°
Elbows
3 x 90°
Elbows
FP1176
Max 20"
Max 20"
36"
(914 mm)
Max.
36"
(914 mm)
Max.
FP1177
max horizontal run
Figure 25 -
Maximum Horizontal Run with No Rise
FP1177
42D0200
Designer Series Gas Fireplaces
19
• If a 90° elbow is used in the horizontal vent run, the hori-
zontal vent length is reduced by 36" (914 mm). Figure
26. This does not apply if the 90° elbows are used to
increase or redirect a vertical rise. Figure 26
According to the vent graph, Figure 23, the
maximum horizontal vent length in a system with a 7.5'
vertical rise is 20’ (6 m) and if a 90° elbow is required in
the horizontal vent it must be reduced to 17' (5.2 m). Refer
to Page 17 “How to Use Vent Graph.”
In Figures 27 and 28, Dimension A plus B must not be
greater than 17' (5.2 m).
• The maximum number of 45° elbows permitted per side
wall installation is two (2). These elbows can be installed
in either the vertical or horizontal run.
• For each 45° elbow installed in the horizontal run, the
length of the horizontal run MUST be reduced by 18" (45
cm). This does not apply if the 45° elbows are installed
on the vertical part of the vent system.
• The maximum number of elbow degrees in a system is
270°. Figure 26
7’6”
AB
90°
FP2305
run reduction
Figure 26 -
Horizontal Run Reduction
FP2305
A
10’
B
7’
7’6”
FP2306
max vent run elbows
Figure 27 -
Maximum Vent Run with Elbows
Example: Elbow 1 = 90°
Elbow 2 = 45°
Elbow 3 = 45°
Elbow 4 = 90°
Total Angular Variation = 270°
A + B = 17' Maximum
90° Elbow = 3'
FP2306
1
2
3
4
1
2
3
4
FP2307
max elbows
Figure 28 -
Maximum Elbow Usage
1 + 2 + 3 + 4 = 270°
FP2307
20 42D0200
Designer Series Gas Fireplaces
When it is not possible to meet the required vent terminal
clearances of 12" above grade level, a snorkel kit is recom-
mended. It allows installation depth down to 7" (178 mm)
below grade level. The 7" (178 mm) is measured from the
center of the horizontal vent pipe as it penetrates through
the wall.
If installing a snorkel, a minimum 24" vertical rise is nec-
essary. The maximum horizontal run with the 24” vertical
pipe is 36". This measurement is taken from the collar of
the replace (or transition elbow) to the face of the exterior
wall. Refer to the Sidewall Venting Graph for extended
horizontal run if the vertical exceeds 24".
1. Establish vent hole through the wall. Refer to Page 18,
Figure 18
2. Remove soil to a depth of approximately 16" below base
of snorkel. Install drain pipe. Install window well (not
supplied). Rell hole with 12" of coarse gravel leaving
a clearance of approximately 4" below snorkel. Figure
29
FP1965
below grade install
Figure 29 -
Below Grade Installation
Screws
Minimum
4" Clearance
Ground
Window
Well
Gravel
Drain
Foundation Wall
Firestop
24"
Minimum
FP1965
FP1966
snorkel
Figure 30 -
Snorkel Installation, Recessed Foundation
Foundation
Recess
Watertight Seal
Around Pipe
Sheet Metal
Screws
Wall Screws
Snorkel
FP1966
3. Install vent system.
4. Ensure a watertight seal is made around the vent pipe
coming through the wall.
5. Slide the snorkel into the vent pipes and secure to the
wall.
6. Level the soil so as to maintain a 4" clearance below
snorkel. Figure 29
If the foundation is recessed, use recess brackets (not
supplied) for securing lower portion of the snorkel. Fasten
brackets to wall rst, then secure to snorkel with self drill-
ing #8 x 1/2" sheet metal screws. It will be necessary to
extend vent pipes out as far as the protruding wall face.
Figure 30
This manual suits for next models
7
Table of contents
Other Monessen Hearth Indoor Fireplace manuals
Monessen Hearth
Monessen Hearth Lo-Rider LCUF36C-R Installation instructions
Monessen Hearth
Monessen Hearth HWB700OD Installation instructions
Monessen Hearth
Monessen Hearth Artisan AVFL Series User manual
Monessen Hearth
Monessen Hearth Direct Vent Gas Insert IDV380NVC User manual
Monessen Hearth
Monessen Hearth 624WBPF Peninsula Installation instructions
Monessen Hearth
Monessen Hearth Direct Vent CDVR33 Installation instructions
Monessen Hearth
Monessen Hearth 624WBPF Peninsula User manual
Monessen Hearth
Monessen Hearth Indoor Gas Fireplace none Installation instructions
Monessen Hearth
Monessen Hearth 36" and 42" Wood Burning Fireplaces BWB400A User manual
Monessen Hearth
Monessen Hearth GDVR36 Owner's manual
Monessen Hearth
Monessen Hearth GCUF Series User manual
Monessen Hearth
Monessen Hearth DIS33NTAS User manual
Monessen Hearth
Monessen Hearth Direct Vent Gas Fireplace KHLDV SERIES User manual
Monessen Hearth
Monessen Hearth KSTDV500 User manual
Monessen Hearth
Monessen Hearth Indoor Gas Fireplace 624BVPF Installation instructions
Monessen Hearth
Monessen Hearth B Vent 724BV4536C Installation instructions
Monessen Hearth
Monessen Hearth Direct Vent BDV300C Installation instructions
Monessen Hearth
Monessen Hearth LO-Rider Designer Vent Free Fireboxes LSTF36 User manual
Monessen Hearth
Monessen Hearth M400BFC Mounting instructions
Monessen Hearth
Monessen Hearth SBV400A B Vent Installation instructions
Popular Indoor Fireplace manuals by other brands
Legend
Legend Ethos Landscape Installation and user instructions
Majestic
Majestic Vemont Castings RHE25 Installation instructions & homeowner's manual
Astria
Astria VILLA VISTA Installation and operation instructions
Dimplex
Dimplex Montclair owner's manual
Olmo
Olmo OL-L6G Installation instructions and homeowner's manual
Heatilator
Heatilator LM42 owner's manual
Riello
Riello PRESS GW Installation, use and maintenance instructions
Nordpeis
Nordpeis Monaco C High Base Right installation manual
BuckMaster
BuckMaster ZCBB VENTLESS user manual
Dimplex
Dimplex Optiflame Electric Fireplace user guide
Ambiance Fireplaces
Ambiance Fireplaces Intrigue INT-200 Installation and operating manual
White Mountain
White Mountain DVX36FP32CL(N Installation instructions and owner's manual
Bellfires
Bellfires BEL VBMT-3NG-SB installation manual
Dimplex
Dimplex CAS500P-RGB-EU Operating instructions manual
Style selections
Style selections SSFBD28T manual
Desa
Desa VM42P OWNER'S OPERATION AND INSTALLATION MANUAL
Amantii
Amantii 30-TRV-SLIM Installation and operation instructions
komodo
komodo SP5736 user manual
