Monessen Hearth HWB700OD Installation instructions

To avoid personal injury or property damage, the product described by this brochure must be installed,operated and maintained in strict compliance with the instructions packaged with the product and all applicable
building or fire codes.Contact local building or fire officials about restrictions and installation inspection requirements.All photographs and drawings on this brochure are for illustrative purposes only and are not intended
for,nor should they be used as a substitute for the instructions packaged with the unit.Appearance and specifications of the product are subject to change without notice. © 2007 Monessen Hearth Systems Co.
A Brand of Monessen Hearth Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
www.monessenhearth.com
INTERIOR DIMENSIONS
Front opening width: 44"
Front opening height: 27"
Rear wall width:34"
Firebox depth: 22"
TECHNICAL INFORMATION
Flue Series (Std.): “L” Series DoubleWall
Flue Size: 11" Inner; 13" Outer
Clearance to Flue: 2"
Firestop Framing: 17" x 17"
Minimum Flue Height: 15'
Maximum Flue Height: 86'
Minimum Height with 2 Elbows: 15'
Minimum Height with 4 Elbows: 21'
Clearance to Fireplace: 1-1/2"
Minimum Hearth Size (D x L): 20" x 68"
OMNI Design Certified
FIELD INSTALLED ACCESSORIES
Glass Door: GD54SS (Stainless)
Outside Air Kit: AK4, FP4U, 403
Terminations(Std.): “L” Series LC, LCL, CF11, SQ8, LFSQT, LPC
PRODUCT SPECIFICATIONS
HWB700OD Indoor/Outdoor Radiant Wood Burning
* “I” indicates insulated model.
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
