Money Controls Ardac IBA5 Guide

Specification and Adjustment Manual
Ardac Imbedded Bill Acceptor System 5(Ardac IBA5)
Document Number 44X501R2
BANKNOTE ACCEPTORS IN OVER 80 COUNTRIES AROUND THE WORLD

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
0-1
Specification and Adjustment Manual
Ardac Imbedded Bill Acceptor System 5 (Ardac IBA5)
Supporting IGT NETPLEX Protocol ID024
Manual Part Number 44X501
Revision R1 -February 7, 2004–Initial Release
Revision R2 –March 15, 2004–Improved exploded view drawing on page 7-4.
Copyright © 2004 by Money Controls / Money Controls, Inc.
The copyright laws of the United States of America and other countries protect this document.
This document may not, in whole or in part, be copied or converted to any mechanical, electronic, or machine-
readable form without consent of Money Controls, Inc. Exception is made for authorized distributors or agents of
Money Controls, Inc. who may make copies as needed to support sales efforts or end users of this equipment.
Money Controls, Inc. reserves the right to revise the product or contents of this manual at any time without notice or
obligation.
No warranty is expressed or implied concerning use of this documentation or associated hardware and software. In
no event will Money Controls, Inc. be liable for any associated costs, losses, or damages incurred through their use,
even if advised of such possibility. Any risks are assumed completely by the user.
This document contains company-confidential, proprietary information, which may not be disclosed to unauthorized
parties without consent of Money Controls, Inc.
Money Controls, Inc. Money Controls, Inc.
34099 Melinz Parkway 6672 Spencer Street, Suite 400
Eastlake, Ohio USA 44095 Las Vegas, Nevada USA 89119
Phone: [phone] Fax: [phone] Phone: [phone] Fax: [phone]
Money Controls Ltd
Royton, Oldham OL2 6JZ, England.
Phone: [phone] Fax: [phone]
Protocol Disclaimer
IGT Netplex (ID024) is a proprietary protocol owned by International Game Technology (IGT) and is licensed to
Money Controls. Any reference to this protocol is solely for configuration of products by Money Controls for sale
to IGT or products repaired for IGT and their customers.
0.
Conventions used in this manual
In this manual, certain information will be set off from the main text for special consideration:
NOTE identifies additional information or instructions that may help clarify an operation or procedure.
CAUTION identifies additional information or instructions that must be followed to avoid damage to the
equipment.
WARNINGidentifies safety-related information or instructions that must be followed to avoid personal injury.

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
0-2
Table of Contents
1 Description and Specifications 1-1
System Description -Money Controls Imbedded Bill Acceptor System 5 (IBA5) 1-1
Terminology 1-3
Main Subassembly Part Numbers 1-4
Chassis Mounting Recommendations 1-5
Features 1-5
Specifications 1-7
Connector Description 1-9
Connector Specifications 1-9
CAPS Diagnostic Connections 1-13
DIP Switch Settings and Functions 1-14
2 Installation 2-1
Host Installation and Setup 2-1
Installation Overview 2-1
Power Supply and Voltage Requirements 2-1
Connecting of the IBA5 system to the host 2-2
Install New or Up-Graded EPROM on Microprocessor Board (Optional) 2-2
Burning New Software Into An EPROM 2-3
EPROM Removal and Replacement 2-4
Check The DIP Switch Settings And Re-set As Required 2-5
Insert Stacker Module Into The Chassis 2-5
Insert Note Acceptor Module 2-5
System Power-up 2-7
3 System Operation 3-1
Functional Description of System Modules 3-1
Operational Notes -Acceptor 3-4
Removal of the Note Acceptor 3-6
To remove the acceptor: 3-6
To open the acceptor (after acceptor is removed from the chassis): 3-6
Operational Notes -Cassette Stacker 3-6
Removal of the Cassette Stacker 3-6
Opening The Cassette Stacker 3-7
Closing and Locking The Cassette Stacker 3-8
Replacement of the Cassette Stacker 3-8
Operational Notes -Chassis 3-9
Operational Notes -System Power-up Sequence 3-9
Before Applying Power To The System 3-9
Power-up Sequence 3-10
Storage of Calibration Values 3-10
Dual Density Values 3-11
System Stalls And Incomplete Power-up 3-11
Dipswitch note inhibits and string sensor 3-11

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
0-3
4 System Diagnostics 4-1
4A NETPLEX host simulator operation
Introduction 4-1
Equipment and Software Required for Diagnostic (Bench) Mode 4-1
Money Controls NETPLEX CAPS Interface and Adapter Harness 4-1
Connections 4-3
Host Software Installation 4-3
Fixed Disk Or Floppy Diskette 4-3
Host Setup Files 4-4
Running the Host Software 4-4
Simulator Start-up Command 4-4
Host Software Main Screen Display 4-5
Commands 4-5
From Host 4-5
From Acceptor 4-5
Communications 4-6
Status Line 4-6
Message Window 4-6
Options menu 4-6
Netplex host simulator set-up 4-7
4B DIAGNOSTIC mode operation
Diagnostic (Bench) Mode Set-up 4-7
Diagnostic (Bench) Mode Operations 4-8
To Monitor Note Acceptance: 4-9
To Control the Transport Motors: 4-10
To Cycle the Cassette Stacker: 4-10
Error Code Listing 4-11
To Show Calibration Voltages: 4-12
Dual Density Calibration 4-13
Calibration Procedure 4-13
5 Maintenance 5-1
Introduction 5-1
Adjustments 5-1
Cleaning 5-1
Cleaning Materials 5-1
Cleaning Instructions 5-3
Cleaning Card Mode 5-4

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
0-4
6 NETPLEX & CAPS Interface 6-1
Introduction 6-1
Description 6-1
Interface Board Pin –out 6-2
Theory of Operation 6-3
Diagnostic (Bench) mode 6-5
Diagnostics (bench mode) operations. 6-5
To show calibration voltages. 6-6
7 Recommended Spare Parts and Diagrams 7-1
Introduction 7-1
Service And Replacement Parts Manual 7-1
Spare Parts Recommendation 7-1
Board Locations 7-2
Recommended spare parts list 7-3
Acceptor head exploded view drawing 7-4
Complete parts list –88X3500 Acceptor Head Transport Assembly 7-5
Addendum A: Gathering Note Data
Introduction 7-8
Setting Up The System 7-9
How To Gather Data 7-10

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-1
1.1
Description and
Specifications
System Description -Imbedded Bill Acceptor System 5 (ARDAC IBA5)
The Money Controls Imbedded Bill Acceptor System 5 (ARDAC IBA5) identifies, collects, and stacks
paper currency or the equivalent barcode ticket coupon into a secure, lockable, removable cassette stacker.
The IBA5 is a modular system consisting of a note acceptor, cassette stacker, and mounting chassis. These
three modules and other system components are identified and illustrated in Figure 1-1.
The IBA5 offers world capability and can be used for any country or currency set within the dimensional
limits detailed in the Specifications in this chapter. Changing acceptance from one country or currency set
to another is easily accomplished by updating the acceptor’s EPROM. The acceptor resident software
determines system operating features and the bank notes accepted. Refer to Table 1-1 for software and bank
note acceptance information.
Section 3, System Operation describes the functions and operations of the major System components.

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-2
Figure 1-1 IBA5 System Components

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-3
Terminology
For convenience and clarity several terms are used interchangeably throughout this manual. These and other system
terms and components are illustrated in Figure 1-1.
-The terms Money Controls Imbedded Bill Acceptor System 5, Ardac IBA5 and System describe the
complete system, which includes all three modules (note acceptor, cassette stacker, and chassis).
-The chassis is the rectangular frame mounted permanently in the host equipment. The chassis secures the
acceptor and stacker in precise alignment in the host. It contains a read only memory to store and
communicate its specific chassis ID number. The stacker home sensor and system wiring harness are
chassis components.
-The terms imbedded note acceptor, note acceptor and acceptor describe only that portion of the System
which actively transports and identifies the notes / ticket coupons.
-The terms cassette stacker, cassette, and stacker refer to the removable, lockable box located in the bottom
section of the System chassis. It contains the memory device to store acceptor data.
-The terms note, bank note, and bill refer to paper currency or equivalent barcode ticket coupon that is
inserted into the note acceptor and stored in the stacker.

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-4
Main Subassembly Part Numbers
The part numbers for the Ardac IBA5 main modules are listed below. Figure 1-1 illustrates these modules
and various other subassemblies of the System. Refer to Section 8, Diagrams and Parts Listings for more
details parts information.
IGT# Ardac# Description
62544190 77x214 IBA5 System (Complete with plastic cassette, and no ‘smart’ function)
62544290 77x215 IBA5 System (Complete with metal cassette, and no ‘smart’ function)
62544390 2x7283 Chassis, IBA5 System (used in both 77x214, 77x215 systems)
N/A 2x7311 Main Chassis Harness, IBA5 no ‘smart’ function.
50035290 48x862 ‘Standard’ plastic cashbox (used in 77x214 system)
50035390 48x863 ‘Smart’ plastic cashbox
62526190 48x828 ‘Standard’ metal cashbox (used in 77x215 system)
50042490 48x829 ‘Smart’ metal cashbox
62544390 88x3500 IBA5 (Acceptor head transport assembly)

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-5
Chassis Mounting Recommendations
The chassis must be supported from underneath and be bolted to the host housing. The Dimension Drawing (Figure 1-3)shows
the location of the chassis mounting hardware (notes 1 through 4).
Asa minimum,secure thechassis tothe hosthousing bybolting:
a. One side and the bottom of the chassis to the housing.
b. One side and the back of the chassis to the housing. (Although the chassis must be supported from underneath, it is not
necessary to bolt the bottom if the back is bolted to the host housing.)
c. Both sides of the chassis to the housing. (Bottom support is not required.)
Features
The Money Controls Imbedded Bill Acceptor System 5 (IBA5) has a number of features that minimize the need for
maintenance, and simplify installation and operation:
-MODULAR DESIGN: The acceptor and cassette stacker are easily removed from the chassis. The acceptor provides
all mechanical drive for itself and the cassettestacker. This simplified design makes the cassette stacker useful as an
exchangeable, lockable cash box.
-SOFTWARE-CONTROLLED OPERATING SYSTEM: A microprocessor located in the acceptor controls: note
identification,notehandling,stacking,andcommunicationwith the host.Output signals indicate notedenomination
and acceptor status. Two drive motors in the acceptor drive the acceptor and the cassette stacker components.
-BENCH TEST DIAGNOSTICS: The IBA5 software includes a Computer Analysis Program System (CAPS). When a
CAPS Interface board connects the IBA5 to a Personal Computer, the computer can access the CAPS software. The
computer then monitors and operates some System components for diagnostic and bench test functions.
-LOCKABLE CASSETTE STACKER: The cassette stacker contains locations for two independent key locks for
maximum security.
-STABLE, RELIABLE OPERATION: Note / coupon recognition devices are self-compensating and require no
adjustments or maintenance. Systems are ready for immediate installation.
-13VDC OPERATION: The ARDAC IBA5 System operates from a single, regulated 13Vdc source which must be
suppliedbythehostsystem.
-EASY ACCESS TO THE NOTE PATH FOR MAINTENANCE: The acceptor opens to fully expose the sensors and
note transport mechanism. This facilitates inspection, cleaning, and servicing.
-SOLID CONSTRUCTION: Structural components of the acceptor and cassette stacker are made of ruggedized plastic.
The mounting chassis is made of welded steel construction for durability,strength,andsecurity.
-STRING DETECTOR: This security system provides maximum protection against all types of stringing and numerous
other intrusive fraud devices.

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-6
Figure 1-2Phantom view: Top, Front, and Sides

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-7
Specifications
NOTE SIZE RANGE: 62mm x 120mm to 85mm x 172mm
ACCEPTANCE RATE: 95% or better on first insertion with street-gradenotes.
STACKER CAPACITY: 550 notes, minimum, in street-gradecondition.
STACKER LOCKS: Dual locks, 0.625" to 1.125" barrel length
CYCLE TIME, MAXIMUM: 1.5 seconds to note identification ;3.5 seconds total cycle time
POWER SUPPLY: External to IBA5
Mounting Requirements: Separate from System chassis
Supply Voltage: 13 volts DC +10% -2%
POWER CONSUMPTION: 15 VA nominal, 36 VA maximum
I/O COMMUNICATION 5-pin Molex 701-07-0005
CONNECTOR: Mating Connector: 35x592-05, Pins: 35x593
POWER SUPPLY CONNECTOR: 2-pin Molex Connector 35x552-2 with crimp terminals 35x435.
Mating connector: 35x436-2 with 35x434 crimpterminals
STATUS MONITOR CONNECTOR: 4-pin Molex 701-07-0004
Mating Connector: 35x592-04, Pins: 35x593
DIAGNOSTIC CONNECTIONS 1: The 4-pin and 5-pin connectors connect to a 2x6434 interface board
To run the acceptor with NETPLEX slot machine simulator
DIAGNOSTIC CONNECTIONS 2: The 9 pin flat connector connects to a 2x5665 CAPS interface board
To run the more advanced bench diagnostics mode
HOST COMMUNICATION 1: Optically Isolated NETPLEX (proprietary), as defined by host system
DIAGNOSTICS COMMUNICATION RS-232 ASCII, 19200,O,8,1
(For Use with Hyper terminal or equivalent)
SYSTEM DIMENSIONS:
Acceptor: 3.520"H x 4.210"W x 9.000"L
Stacker: 8.042"H x 3.476"W x 7.940"L
Overall: 12.442"H x 4.558"W x 7.100"L
Mounting Arrangements: Refer to Figure 1-3.
OPERATING ENVIRONMENT: 0° To 50° C, 15% To 90% Relative Humidity non-condensending.
SOFTWARE: Version: Refer To Table 1-1.
Currency: Refer To Table 1-1.
Direction: Refer To Table 1-1.

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-8

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-9
Connector Description
Refer to Figure 1-4. Power and I/O connections to the system electronics are made through the main system
internal wiring harness (not shown) to a single connector located at the top rear of the chassis. The acceptor
unit makes or breaks all connections when the acceptor is installed or removed from the chassis. The
external wiring harness is permanently mounted to the chassis connector, and provides cabling and
termination for the power supply, and Host I/O or Money Controls Host Simulator connections.
Connector Specifications
Figure 1-5 shows the pin-outs of the main chassis to note acceptor connections. These connectors appear as
viewed from the rear of the acceptor and the rear of the Main Chassis Connector.
Figures 1-5 through 1-9 show the pin-outs of the external harness connectors:
-The 2-pin power supply connector (Figure 1-6) connects the IBA5 to the host or bench power supply.
-The 5-pin host I/O connector (Figure 1-7) passes control signals between the Host and IBA5.
-The 4-pin status monitor connector (Figure 1-8) passes IBA5 system status signals to the Host.
-The 9-pin CAPS connector (Figure 1-9) is not used in NETPLEX applications.
Figure 1-4 NETPLEX Bench Interface

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-10
MAIN CHASSIS CONNECTOR TO SYSTEM
WIRING HARNESS
PIN # FUNCTION HARNESS COLOR
1M Reset White / Yellow
2Net Ground White / Gray
3Stacker Present White / Red
4Enable Ready LED Gray
5Net VDC Red
6Caps In Violet
7Ground Green
8Caps -Green
9Caps + Yellow
10 Stacker Home Orange
11 +13V White / Orange
12 Ground Green
13 Net In –RXD White / Blue
14 Net Out -TXD White / Violet
Figure 1-5 14 Pin Rear Connector

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-11
2-PIN POWER CONNECTOR (13VDC)
PIN # FUNCTION HARNESS COLOR
1+13VDC White / Orange
2Ground Green
Money Controls Part Numbers: 35x592 housing with 35x593 pins
Figure 1-6Two pin Power Connector
5-PIN HOST COMMUNICATIONS CONNECTOR
PIN FUNCTION HARNESS COLOR
1M Reset White / Yellow
2Net Transmit White / Violet
3OPTO Net VDC Red
4Net Receive White / Blue
5Net Ground White / Gray
Money Controls Part Numbers: 35x592-5 housing with 35x593 pins
Figure 1-7Five Pin Isolated I/O Connector

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-12
4-PIN SYSTEM MONITOR CONNECTOR
PIN FUNCTION COLOR
1+13VDC White / Orange
2Enable LED Gray
3Ground Green
4Stacker Present White / Red
Money Controls Part Numbers: 35x592-4 housing with 35x593 pins
Figure 1-8A Four Pin Status Connector
Figure 1-8B Status Connector Schematic Drawing

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-13
CAPS Diagnostic Connections
The 9-pin Molex connector is used for CAPS interface in diagnostics mode only. This connector is unused in the
slot machine. Connection pin outs information is provided for the sake of completeness only.
Connection to the CAPS interface is made through the flat 9 pin connector, as illustrated in Figure 1-10. CAPS
connection, theory of operation and y-harness pin-outs are detailed in section 7, CAPS Interface.
9 PIN CONNECTOR FOR DIAGNOSTICS
PIN # FUNCTION HARNESS COLOR
1----- -----
2----- -----
3----- -----
4IBA Receive Data Violet
5----- -----
6----- -----
7+ 13 Volts D.C. White / Orange
8Ground Green
9IBA Transmit Data Yellow
Figure 1-9Nine Pin CAPS Diagnostic Interface

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-14
Figure 1-10 Caps Diagnostic Interface
DIP Switch Settings and Functions
The microprocessor board used in the System note acceptor has 2 banks of eight DIP switches. These switchesset
the System’s operating mode and enable or inhibit acceptance of certain notes. For the location of these DIP
switches, refer to Figure 1-1. Table 1-1 describes the DIP switch functions. DIP switch settings may vary from table
1-1 depending on specific firmware version installed in machine.

Specification and Adjustment Manual -ARDAC IBA5
Document Number 44X501R2 –March 15, 2004
1-15
Figure 1-11 EPROM and Dip Switch Location on DSP (Micro) board
