monolith MS 555s User manual

MS 555s / 09/2010
Contents
2
1. Description of MS 555s components
3
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: MS 555s
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
2. Technical data MS 555s
Model
Working width
Cutting capacity per cycle
Speed
Cutting process
Particle size
Diameter bin
Automatic start/stop function
REV reverse function
Nominal operating period
Noise level
Nominal voltage
Power rating
Safety class
Dimensions (W x D x H)
MS 555s
217 mm (A4)
Up to a maximum of 5 sheets (80 g/m2)
2.5 m per minute
Ribbon cut
8 mm cut width
27.5 mm to 33.5 mm
Yes
Yes
1 minute
73 DB
220 – 240 V ~ 50 Hz
160 Watt/0.8 A
II
296 x 113,5 x 67 mm
1. Description of MS 555s components 3
2. Technical Data 3
3. Before using your shredder 4
4. Key to warning symbols 4
5. Electrical safety instructions 5
6. Operation 6
7. Protecting the motor 6
8. Maintenance and care 6
9. Trouble shooting 7
10. Storage 7
11. Disposal 7
12. Terms of guarantee 8
13. Guarantee card 9
All safety instructions and other important information are highlighted in grey.
The item has safety features.
However, to avoid damage or injury, read the safety instructions carefully and
only use the shredder as described in this guide.
Keep the guide for future reference.
If you are giving the machine to someone else, please keep this guide with the
product.
Information on safety instructions
1Sliding switch
(REV/OFF/AUTO)
2READY/ON lamp
3Mains cable
4Retractable bar for attachment to
a waste bin
5Paper sensor
6Paper feed slot
Please complete this warranty card and enclose it with
the machine, together with your proof of purchase.
Warranty Card – Strip Cut Paper Shredder
Strip Cut Paper Shredder MS 555s/ 09/2010
3 years’ warranty
from date of
purchase!
Surname, rst name:
Street, number:
Postcode, town: Country:
Telephone number with international dialling code:
Note:
When claiming on the warranty, the warranty card and the proof of purchase must be included with the
machine as well as a detailed description of the fault wherever possible. Warranty cards sent separately
afterwards will not be accepted.
Description of fault:
Date of purchase:
Date/signature:
Customer service:
monolith Service Hotline: 0 808 / 1 01 22 42 (UK), 1 800 / 65 50 09 (IR)
Service fax number: +49 (0) 6151 / 10 19 019
E-mail: [email protected]
Service address: Kentner Spedition, password: monolith, Industriestr. 40 G, D-44892 Bochum
Customer data:
Operating Instructions and Warranty
MS 555s Strip Cut
Paper Shredder
AFTER SALES SUPPORT
MODEL NUMBER: MS 555s
HELPLINE NO: 0 808 / 1 01 22 42 (UK)
1 800 / 65 50 09 (IR)
WEB SUPPORT: www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: MS 555s
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: MS 555s
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: MS 555s
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
3
6
5
1
42

Importeur:monolith GmbH • SchwarzeHorn 1 • D-45127 Essen • Servicetelefon: 01803/ 852000 • www.monolithshop.de
5. Electrical safety instructions 9.Trouble shooting
6. Operation
3. Before using your shredder
7
7654

The shredder is designed for a maximum use time of 1 minute. Please allow the motor
to cool for approximately 30 minutes after 1 minute use.
The motor will switch itself o automatically when overloaded. Unplug at the mains
and ensure that the sliding switch is set to AUTO. Allow the motor to cool o at room
temperature for approximately 30 minutes before you plug the shredder back in.
Continue shredding.
Please avoid overloading the motor, for example, by inserting more paper than advi-
sed into the shredder.This can lead to other defects such as damage to the internal
rollers.
5.1 Only connect the shredder to the mains indoors, using a professionally instal-
led 230 V socket with protective conductor contact.This must be close to the
shredder and easily accessible in order to enable disconnection by pulling
the mains plug in the event of an emergency. Adapter plugs or extension
cables must also be tted with a protective contact and must be easily acces-
sible in order to enable disconnection from the mains power in the event of
an emergency.
5.2 Protect the shredder against moisture. It must be situated in a dry location.
5.3 The shredder must not come into contact with water or other liquids.
Risk of short circuit.
5.4 Do not place the shredder near to heaters or radiators and do not place it in
direct sunlight.
5.5 Before emptying the bin, pull out the mains plug. Also pull out the mains
plug if you are not going to be using the shredder for a long time or before
cleaning the machine.
5.6 Do not operate the shredder if the mains cable, the mains plug or the
machine itself are damaged. Risk of injury.
5.7 Do not overload the socket with more than its recommended capacity.
5.8 Do not make any modications to the mains cable as it is designed for the
specied mains voltage.
Safety class II:The shredder has protective insulation and therefore has no
metal parts that can be touched and which could become live in the event of
a fault.
10. Storage
Clean the shredder and store it, preferably in its original packaging, when it is not
being used. Keep the machine dry and away from heat sources.
11. Disposal
The product packaging is made from recyclable materials. Dispose of this packaging in
an environment-friendly way. Do not dispose of the shredder, at the end of its useful life,
with domestic waste. By law, it must be correctly disposed of so that recyclable substances
contained in the shredder can be reused, protecting the environment. Please contact your
local authorities to nd out about appropriate facilities near you. Before disposing of it,
make the shredder unusable. Disconnect the shredder from the mains supply and remove
the power cable from the machine.
3.1 Before you use the shredder for the rst time, please read the user guide through
carefully.
3.2 This machine has been designed to shred paper. Please use it only for this pur-
pose and as described in the instructions.
3.3 Do not shred any paper sizes larger than A4 or continuous sheets of paper and
do not shred more sheets than specied (max. 5 sheets of 80 g/m2).
3.4 The shredder is designed for short-term use of maximum 1 minute duration.
Please allow the motor to cool for approximately 30 minutes after 1 minute
operation.
3.5 The device is designed for home use only.
3.6 Place the bin over which the shredder is to be mounted onto a stable, at surface
so that it cannot tip or fall over. Please use a bin with a diameter of 27 to 33,5 cm
3.7 Do not sit on the shredder and do not place any object on it.
3.8 The product has the necessary safety features and markings. However, to avoid
accidental damage or injury, you must read the safety instructions carefully and
only use the machine as described in this guide.
3.9 Children must only use this shredder under adult supervision.
3.10 Keep the shredder away from pets.
3.11 Plastic bags may be a hazard. To avoid danger of suocation, keep bags out of
the reach of babies and small children.
3.12 Keep the guide in a safe place for future reference.
3.13 Only give the shredder to other people together with this guide.
3.14 All safety instructions and other important information are highlighted in grey.
NB: Failure to comply with these safety symbols may cause serious physical harm! If an object
(bracelet, tie etc.) does accidentally enter the feed slot, unplug at the mains immediately!
Do not reach into the inlet slot!
Keep neckties, scarves and
loose clothing away from
the area of the inlet slot!
Keep long necklaces and other
jewellery away from the area of
the inlet slot!
Do not insert any paper clips or
staples in the inlet slot!
Keep long, loose hair away from
the area of the inlet slot!
6.1 Remove the shredder carefully from its packaging.
6.2 If appropriate, take the xing rail 4out and place the shredder on the round bin of
your choice (ts a diameter of 27.5 to 33.5 cm). Ensure that the shredder is seated
securely on top of the bin.
6.3 Now plug in the shredder.
6.4 Set the sliding switch 1to AUTO. The READY/ON will light up.
6.5 Feed the paper through the feed slot 5into the cutter. Ensure that the paper is
inserted centrally and straight. Before inserting the paper, remove all metal items
(staples, paper clips etc.) from the paper.
In the middle of the feed slot there is a sensor 6that is activated as soon as you
insert paper.Therefore always insert smaller paper sizes centrally.
If the sliding switch is set to AUTO, the machine will switch itself o automati-
cally as soon as the paper has been shredded.
6.5 If you do not work with the machine switch the sliding to OFF. The READY/ON lamp
goes out.
Ensure that you empty the bin regularly.
8. Maintenance and care of your shredder
Caution! Read the guide! Not for disposal with
domestic waste
Clearing a paper jam:
If too much paper is fed into the cutter, this will cause a paper jam. To clear the paper
jam:
- Set the slide switch into the REV position.The cutter will then run backwards or
forwards and push the excess paper out.
- Reduce the quantity of paper being fed in, and switch back on to AUTO.
- If the paper blockage cannot be cleared, unplug the shredder and remove the resi-
dual paper manually from the cutter.
The shredder does not switch itself o automatically:
If the sliding switch is set to REV (e.g. when there is a paper jam), it is possible that
there is still some residual paper present under the paper sensor. Do not set the sliding
switch back to AUTO as the shredder cannot switch itself o automatically.
In most cases, residual scraps of paper can be cleared by inserting another sheet of paper
into the feed slot. If the shredder still will not switch o on its own, proceed as follows:
- Unplug at the mains and turn the machine over.
- Remove the residual scraps of paper carefully from the feed slot using tweezers etc.
Please ensure that you do not damage the blades.
8.1 Unplug at the mains before you clean the shredder.
8.2 Clean the shredder only with a damp cloth.
8.3 Do not try to repair this shredder yourself. We cannot accept liability for injury
caused by improper handling.
8.4 The shredder is maintenance-free and special oil must not be used on the cutter.
7. Protecting the motor
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: MS 555s
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: MS 555s
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: MS 555s
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: MS 555s
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
IMPORTANT WARRANTY DOCUMENT – KEEP SAFE!
Warranty Card – Strip Cut Paper Shredder
Warranty terms
Strip Cut Paper Shredder MS 555s / 09/2010
monolith GmbH • Schwarze Horn 1 • D-45127 Essen
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: MS 555s
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Dear customer,
Congratulations!You have made an excellent choice with the purchase of this quality product. Our commit-
ment to quality also includesour service. Should you, contrary to expectations, experience defects due to ma-
nufacturing faults during private use within 36 months of thedate of purchase we shall be liable for warranty
in accordance with statutory warranty regulations provided that:
- the device was not put to any use other than the intended
- was not overloaded
- was not used with the wrong accessories
- repairs were not carried out by any other than the authorized workshop
The warranty certicate is only valid in connection with the receipt. Please keep bothin a safe place. This
warranty does not aect yourstatutory rights.
This purchase is guaranteed for a period of threeyears beginning on the day of purchase. Keep your purchase
receipt safe as proof of date of purchase.The warranty can only be extended for the duration of any repair
required.
During the warranty period if theproduct becomes defective, in the rst instance, please call our service hot-
line. We will, at our discretion, either repair or exchange the device in accordance with warranty legislation.
If you are required toreturn the item please enclose the following:
1. Receipt (proof or purchase)
2. This warranty certicatewith the fault report form overleaf complete with your name, contact details and
fault description.
If the original receipt is notenclosed the repair will be charged in all cases. After the warranty has expiredyou
can still send defective devices for repairs period to the address statedbelow. Quotes as well as repairs after
the warranty period are tobe paid for in all cases.
Ensure that the product is sent well packed as no responsibility can be acceptedfor items lost or damaged in
transit.
This warranty does not aect your statutory rights.
Our monolith products undergo strict quality controls.If this equipment does not function perfectly,
please contact our
Service Hotline: 0 808 / 1 01 22 42 (UK), 1 800 / 65 50 09 (IR)
Our service hours are: Mon.-Thur. 08:00-17:00 and Fri. 08:00-15:00
We hope you have lots of fun with your new Strip cut paper shredder!
4. Key to warning symbols
