monolith SBS 21 User manual

SBS 21 / XII/27/2011
Contents
2
1. Description of SBS 21 components
3
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: SBS 21
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
2. Technical data SBS 21
Model
Working width
Cutting capacity per cycle
Speed
Cutting process
Particle size
Volume collection bin for paper
Volume collection bin for CDs
Automatic start/stop function
REV reverse function
Nominal operating period
Nominal nonoperating period
Nominal voltage
Power rating
Safety class
Dimensions (W x D x H)
SBS 21
220 mm (A4)
Up to a maximum of 8 sheets (80 g/m2) / 1 CD / 1 credit card
3.5 m per minute for 1 sheet, 2,3 m per minute for 8 sheets
cross cut, CD shredder
4,2 x 18 mm
21 Litre
1 Litre
Yes
Yes
2 minute
60 minute
220 – 240 V ~ 50 Hz
300 Watt/1,2 A
III
346 x 198 x 415 mm
1. Description of SBS 21 components 3
2. Technical Data SBS 21 3
3. Important safety instructions 3
4. Safety symbols 4
5. Electrical safety guidelines 4
6. Proper use SBS 21 4
7. Starting up the device 5
8. Using the machine 5
9. Remedying a jam 5
10. Motor protection 6
11. Notes on care and maintenance 6
12. Machine malfunctions 6
13. Storage 7
14. Disposal 7
15. Warranty terms 8
16. Warranty card 9
All safety instructions and other important information are highlighted in grey.
The item has safety features.
However, to avoid damage or injury, read the safety instructions carefully and
only use the shredder as described in this guide.
Keep the guide for future reference.
If you are giving the machine to someone else, please keep this guide with the
product.
Information on safety instructions
1Sliding switch (Auto,O, Rev)
2Inlet slot
3CD cutting unit
Please complete this warranty card and enclose it with
the machine, together with your proof of purchase.
Warranty Card – Paper Shredder SBS 21
Paper Shredder SBS 21/ XII/27/2011
3 years’ warranty
from date of
purchase!
Surname, rst name:
Street, number:
Postcode, town: Country:
Telephone number with international dialling code:
Note:
When claiming on the warranty, the warranty card and the proof of purchase must be included with the
machine as well as a detailed description of the fault wherever possible. Warranty cards sent separately
afterwards will not be accepted.
Description of fault:
Date of purchase:
Date/signature:
Customer service:
monolith Service Hotline: 0 808 / 1 01 22 42 (UK), 1 800 / 65 50 09 (IR)
Service fax number: +49 (0) 6151 / 10 19 019
E-mail: [email protected]
Service address: Kentner Spedition, password: monolith, Steeler Straße 95, D-44866 Bochum
Customer data:
Operating Instructions and Warranty
Paper Shredder SBS 21
AFTER SALES SUPPORT
MODEL NUMBER: SBS 21
HELPLINE NO: 0 808 / 1 01 22 42 (UK)
1 800 / 65 50 09 (IR)
WEB SUPPORT: www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: SBS 21
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: SBS 21
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: SBS 21
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Items supplied / content of package
1 x shredder base unit, 2 x container elements for paper, 1 x container element for CDs, 2 x xing rails,
1 x user instructions incl. warranty card
1
3
5
2
4
6
4
4Collection bin for paper
5Collection bin for CDs
6Carrying handle

Importeur:monolith GmbH • SchwarzeHorn 1 • D-45127 Essen • Servicetelefon: 01803/ 852000 • www.monolithshop.de
5. Electrical safety instructions 12. Machine malfunctions
8. Using the machine
7
7654

13. Storage
Clean the shredder and store it, preferablyin its original packaging, when it is not being used. Keep the
machine dry and away from heatsources.
14. Disposal
The product pack aging is made fromrecyclable materials. Dispose of thispackaging in an environment-friendly
way. Donot dispose of the shredder, at the end of its useful life, with domestic waste. By law, it mustbe correctly
disposed of sothat recyclable substances containedin the shredder can be reused, protecting the environment.
Please contact your local authorities tond out about appropriatefacilities near you. Before disposing of it, make
the shredderunusable. Disconnect theshredder from the mainssupply and remove the power cable from the
machine.
8.1. The sliding switch (Auto, O, Rev) 1on the machine has the following functions: Auto position: The
machine is ready for use.
Insert the single CD into the designated inlet slot of the CD cutting unit 3.
8.2. The machine has micro-switches:The shredding operation of the cutting unit (max. cutting capacity
8 sheets) starts automatically as soon as paper is inserted through the inlet opening 2. The machine
switches to forward advance and pulls in the material.After the shredding procedure, the machine
switches o automatically.
8.3. O position: The unit is switched o.
8.4. Rev position: To keep back the remaining paper, you can push the sliding switch
in position Rev and the cutting unit will push back the material. The paper cutting unit runs backwards.
8.5 Please note: The capacity may not be exceeded, otherwise jamming will occur!
Please note that the thicknessof the paper is increased when folded, which would
then exceed the recommended sheet capacity. Reduce the paper amount for rough
bre paper as well. It is recommended not to allow the paper catch basket to ll
up directly to the cutting unit. This prevents the shredded material from jamming
the cutting unit. Regularly empty the catch baskets 45.
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: SBS 21
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: SBS 21
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: SBS 21
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: SBS 21
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
IMPORTANT WARRANTY DOCUMENT – KEEP SAFE!
Warranty Card – Paper Shredder SBS 21
Warranty terms
Paper Shredder SBS 21 / XII/27/2011
monolith GmbH • Schwarze Horn 1 • D-45127 Essen
Helpline No.: 0 808 / 1 01 22 42 (UK),1 800 / 65 50 09 (IR) • Model Number: SBS 21
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Dear customer,
Congratulations!You have made an excellent choice with the purchase of this quality product. Our commit-
ment to quality also includesour service. Should you, contrary to expectations, experience defects due to ma-
nufacturing faults during private use within 36 months of thedate of purchase we shall be liable for warranty
in accordance with statutory warranty regulations provided that:
- the device was not put to any use other than the intended
- was not overloaded
- was not used with the wrong accessories
- repairs were not carried out by any other than the authorized workshop
The warranty certicate is only valid in connection with the receipt. Please keep bothin a safe place. This
warranty does not aect yourstatutory rights.
This purchase is guaranteed for a period of threeyears beginning on the day of purchase. Keep your purchase
receipt safe as proof of date of purchase.The warranty can only be extended for the duration of any repair
required.
During the warranty period if theproduct becomes defective, in the rst instance, please call our service hot-
line. We will, at our discretion, either repair or exchange the device in accordance with warranty legislation.
If you are required toreturn the item please enclose the following:
1. Receipt(proof or purchase)
2. This warranty certicate with the fault report form overleaf complete with your name, contact details and
fault description.
If the original receipt is notenclosed the repair will be charged in all cases. After the warranty has expiredyou
can still send defective devices for repairs period to the address statedbelow. Quotes as well as repairs after
the warranty period are tobe paid for in all cases.
Ensure that the product is sent well packed as no responsibility can be acceptedfor items lost or damaged in
transit.
This warranty does not aect your statutory rights.
Our monolith products undergo strict quality controls.If this equipment does not function perfectly,
please contact our
Service Hotline: 0 808 / 1 01 22 42 (UK), 1 800 / 65 50 09 (IR)
Our service hours are: Mon.-Thur. 08:00-17:00 and Fri. 08:00-15:00
We hope you have lots of fun with your new Paper Shredder!
4. Safety symbols
3. Important safety instructions
!
To use all functions of your Paper Shredder, please read these instructions carefully
before using the machine.
Keep the machine away from children and pets! The machine may only be operated by adults.
The machine may only be operated by one person at a time. Do not perform any other activities on
the machine during operation (such as cleaning, for example).
Have qualied specialists perform any repairs.
Protect the machine from direct sunlight, extreme heat and humidity!
Safety note:
The wall outlet must be situated in the vicinity of the machine and easy to access. This enables you
to quickly disconnect the machine from the mains in case of an emergency.
Do not reach into the inlet slot!
Keep neckties, scarves and
loose clothing away from
the area of the inlet slot!
Keep children away
from the unit!
Keep long necklaces and other
jewellery away from the area of the
inlet slot!
Do not insert any paper clips or
staples in the inlet slot!
Keep long, loose hair away from the
area of the inlet slot!
Don´t use spray units/aerosols
in the area of the unit!
Don´t use oils/liquids
in the area of the unit!
Meaning of the warning symbols
Caution! Read the instructions!
NB: Failure to comply with these safety symbols may cause serious physical harm! If an object (bracelet,
tie etc.) does accidentally enter the feed slot, unplug at the mains immediately!
Not for disposal with
domestic waste
5.1. Pull the mains plug before emptying the catch baskets 45also during longer periods ofnon-use or
before cleaning the machine!
5.2. Do not use the machine if the power cord, mains plug or the machine itself is damaged
(risk of injuries)!
5.3. Do not overload the recommended capacity of the wall outlet!
5.4. Donot modify thepower cordas it has been designed for thespecied mains voltage.
6.1. Only use theSBS 21 PaperShredderto shred paperor CDs in the designated inletslots 23.
6.2. The material tobe shreddedmust be dry and comply with the requirements listed in thetechnicaldata!
6.3. Shredding other materials can cause injuries to yourself (e.g. splintering of solid materials, etc.) or damage
to the machine(e.g. destruction of the cutting unit, etc.).
6.4. Donot destroyany continuous forms withthis machine! Remove all paper clips and staples before feeding
paperinto the machine!
6.5. The machine may only be used in dry,closed rooms.
6. Proper use SBS 21
7. Starting up the device
7.1. Carefully remove all of the elements fromthe packaging.
Assemble thecontainers. To do so, take containerParts A
and B and the xingrails supplied and lay themout.
a.) Place container PartA upright on the oor in front ofyou.
Place the underside of PartB in the connection hooks of
containerPart A.
b.) Then press Part B along the nodules on the side in the
designated cutouts on Par t A .
c.) Whenyou have assembled thetwo elements, insert the
two plastic rails until theyclick into place over theconnec-
tion interfaceon the container elements.
7.2. Take the separate container for CDs and credit cards
and insert it into the provided rails on the underside of
the shredder element. Now place the shredder on the
assembled containers.
The wall outlet must be situated in the vicinity of the
machine and easy to access. This enables you to quickly
disconnect the machine from the mains in case of an
emergency!
Part A Part B
a.) b.)
c.)
11. Notes on care and maintenance
Please note:
Maintenance work may only be performed when the mains plug is disconnected! So that you can enjoy your
Paper Shredder for a long time, we recommend regularly removing residues from the cutting unit and apply-
ing special Paper Shredder oil to the cutting unit. This helps to extend the lifetime of the machine.
When too much paper is fed into the cutting unit, a jam occurs.
Proceed as follows: Push the sliding switch 1in Position Rev.
The cutting unit runs backwards and pushes the excess paper back out. Reduce the amount of paper and
switch back to Paper Auto.
The cutting unit now runs forwards again and the remainder is shredded. If the blockage is not eliminated
through the backwards/forwards advance, disconnect the mains plug and manually remove the remainder
from the cutting unit.
The motor switches o automatically in case of overload. Disconnect the mains plug from the wall outlet
and allow the motor to cool down to room temperature.Then reconnect the mains plug into the wall outlet
and continue operation.
9. Remedying a jam
10. Motor protection
Problem Cause Solution
Machine does not
work
Is the mains plug properly inserted
in the wall outlet?
Insert the mains plug correctly in the
wall outlet.
The motor does not start after
paper was fed?
Insert the paper or the CD into the
respective inlet slot until it touches the
sensor in the centre.
Machine no longer
works after a longer
period of operati-
on, or stops during
operation
Was the machine in continuous
operation for a longer period of
time? Is the surface of the machine
warm?
Disconnect the mains plug from the
wall outlet and allow the motor to cool
down to room temperature.
Jam Did you insert more than 8 sheets
of paper (80g/m²), or more than
one CD? Was the material fed croo-
kedly into the inlet slot?
Position the sliding switch to Rev to
push the paper back. Then switch back
to Auto to shred the remaining paper in
the cutting unit.
If you were unable to eliminate the error yourself, please contact your dealer or call the Service Hotline.
