Monoprice 34712 User manual

32”
QHD
User’s Manual
P/N 34712
Monoprice 32” QHD HDR Freesync Monitor

2560x1440p @60Hz maximum video resolution
5ms GTG response time
300 cd/m² brightness
More than 1.07G colors
Fully compliant with the HDMI 1.4 and DisplayPort 1.2 specifications.
One HDMI、One DVI、One Display Port Inputs

1x32” Monitor
DC DVI HDMI DP AUDIO
IN
AUDO IN : 3.5mm stereo analog audio input.

DP : DisplayPort video input supporting the DisplayPort 1.2 specification at resolutions
up to 2560x1440p @60Hz.
LED Indicator/IR
signal receiver Base Screen
HDMI : HDMI video input supporting the HDMI 1.4 specification at resolutions up to
2560x1440p @60Hz.
DVI : DVI video input supporting the DVI-D at resolutions up to 2560x1440p @60Hz.

Speaker Hole VESA hole
100mm x 100mm
I/O Port Keypad

SOURCE
MUTE SCALE
MENU
EXIT
SOURCE
MUTE
SCALE
Press the 5-way button vertically to display the OSD small menu as shown on the right：
Then press the 5-way button to select the menu item you
want to enter，After selecting the menu item to enter,
press the 5-way buttons vertically to enter the selected
menu item.
OSD Menu Adjustment Item
Select Menu Item
Display Mode Hotkey Item
Power Off Item
Exit Item

F1
P
F2
MENU
EXIT
DVI
HDMI
DP
AUTO

Main Menu
Item
Sub Menu
Item Option Function
Level can be adjusted from 0 to 100
0～100BRIGHTNESS
0～100
CONTRAST
Choose the picture mode:
For videos games there is three mode:
GAME / FPS / RTS to choose according to
your use.
STANDARD
GAME
MOVIE
TEXT
FPS
RTS
MODE
Dynamic contrast ratio (to add more
contrast).
OFF
Level can be adjusted from 0 to 4
ON
DCR
BRIGHTNESS
H.POSITION 0～100 Not available
V.POSITION 0～100
CLOCK 0～100
PHASE 0～100
WIDE
4 : 3
ASPECT
COLOR TEMP.
COOL
GREEN
BLUE
NA
RED
COLOR
TEMP.
OSD H.POS. 0～100
OSD V.POS. 0～100
OSD TIME 0～60 Time can be adjusted from 5 sec to 60 sec.
OSD
SETTINGS
Level can be adjusted from 0 to 100
SHARPNESS 0～4
Not available
Not available
Not available
Choose aspect ratio
WARM
USER
Choose color temperature.
When selectiong USER you can adjust
each level of RED,GREEN,BLUE.
Level can be adjusted from 0 to 100
0～100
Level can be adjusted from 0 to 100
0～100
Level can be adjusted from 0 to 100
0～100
LANGUAGE
Choose the OSD menu language
English etc...
Level can be adjusted from 0 to 100
Level can be adjusted from 0 to 100
TRANSPARENCY
0～100
Level can be adjusted from 0 to 100
COLOR
AUTO. ADJUST
AUTO. ADJUST
NA
RESET
Reset all settings to or original factory settings.
AUTO
POWER DOWN
ON
OFF Monitor power will turn off when no signal.
RESET
HDR OFF
AUTO
2084
Set up the HDR function

0/25/50/75/100
SIGNAL
SOURCE
DVI
HDMI
DP
Select signal source.
LOW BLUE LIGHT
Main Menu
Item
Sub Menu
Item Option Function
About FreeSync
MISC.
Make sure your graphic card supports FreeSync (AMD only but not all AMD graphic card
does).
If the graphics card does not support freesync, Turn the option to Off on the monitor to
avoid issues
About HDR
VOLUME Level can be adjusted from 0 to 100.
FREESYNC ON Set up Freesync function ON/OFF (to be set
to OFF when using non-AMD card).
OD Set the overdrive ON or OFF. Setting it ON
will response time faster.
OFF
0～100
ON
OFF
Before using this feature, please make sure the input signal source are HDR function of
stream in the future.

34712
32”(812.8mm)
27.89”x15.69”(708.4x398.5mm)
2560x1440p @60Hz
178°/178°
5ms
300 cd/m²
＞1.07G
72 watts
24VDC/3A
