Monoprice CrystalPro 37922 User manual

27" CrystalPro WQHD Monitor
P/N 37922, 38940
User's Manual

2
CONTENTS
SAFETY WARNINGS AND GUIDELINES.......................................................................................................................................3
CUSTOMER SERVICE....................................................................................................................................................................................4
PACKAGE CONTENTS.................................................................................................................................................................................4
SETUP........................................................................................................................................................................................................................5
KENSINGTON SECURITY SLOT............................................................................................................................................................6
OSD MENU........................................................................................................................................................................................................... 7
Button Labels and Functions ........................................................................................................................................................ 7
Menu Structure..........................................................................................................................................................................................8
TECHNICAL SUPPORT...............................................................................................................................................................................12
SPECIFICATIONS............................................................................................................................................................................................13
REGULATORY COMPLIANCE..............................................................................................................................................................14
Notice for FCC ..........................................................................................................................................................................................14
Notice for Industry Canada...........................................................................................................................................................15
EU Declaration of Conformity ....................................................................................................................................................15
WEEE Information .................................................................................................................................................................................15
Safety Notice.............................................................................................................................................................................................16

3
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
This monitor is intended for indoor use only.
Do not expose this monitor to water or moisture of any kind. Do not place drinks or
other containers with moisture on or near the monitor. If moisture does get in or on
the monitor, immediately unplug it from the power outlet and allow it to fully dry
before reapplying power.
Do not touch the monitor, the power cord, or any other connected cables with wet
hands.
Do not place the monitor on an unstable surface where it could fall and cause either
personal injury or damage to the monitor and/or other equipment.
Do not subject the monitor to extreme force, shock, or fluctuations in temperature
or humidity.
Do not block the ventilation holes in the monitor's casing. Do not place the monitor
in a confined space with inadequate ventilation. Periodically check the ventilation
holes to ensure they do not become clogged with dust, debris, or nearby items.
Do not place the monitor near a heat source, such as a fireplace, heating vent,
radiator, etc. Do not leave it in direct sunlight.
Do not place or install this monitor in an area where it can be exposed to excessive
amounts of dust, humidity, oil, smoke, or combustible vapors.
Prior to operation, check the monitor and power cord for physical damage. Do not
use if physical damage has occurred.
Unplug this monitor from the power source when not in use.
Take care to prevent damage to the power cord. Do not allow it to become
crimped, pinched, walked on, or become tangled with other cords. Ensure that the
power cord does not present a tripping hazard.
Never unplug the monitor by pulling on the power cord. Always grasp the
connector head or adapter body.

4
Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
This monitor has no user serviceable parts. Do not open the case or otherwise
attempt to modify this monitor.
Do not leave a single image on the display for a long period of time. Doing so could
cause "burn-in" of the image. It is recommended to use a variable desktop
background and to use a screen saver to prevent "burn-in". Alternatively, ensure
that the monitor is powered off for at least 2 hours out of every 12.
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com or via email at [email protected]. Check the website for
support times and links.
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x 27" CrystalPro WQHD Monitor
1x Stand Base
1x Stand Stem
5x Stand Screws
1x Screwdriver
1x HDMI® Cable
1x AC Power Cord
1x User's Manual
1x Thank You Card

5
SETUP
Perform the following steps to prepare your monitor for use.
1. Either assemble the stand and attach it to the rear of the monitor or mount the
monitor to a wall or desk mount.
2. Plug one end of the included HDMI® cable into one of the HDMI inputs on the
monitor, then plug the other end into the HDMI video output on your computer.
Alternatively, you can connect using a DisplayPort® cable (not included).
3. (Optional) Plug a pair of headphones or powered speakers into the audio output on
the monitor.
4. Plug one end of the included AC power cord into the AC input on the monitor, then
plug the other end into a nearby AC power outlet. The LED power indicator on the
monitor will illuminate orange.

6
KENSINGTON SECURITY SLOT
This monitor features a Kensington Security Slot™, which can be used to secure your
monitor to prevent theft. The connector is located on the rear of the monitor. The
following image illustrates an example of usage to secure the monitor to a table or desk.
For more information on installation and usage, please visit the Kensington website at the
following address:
http://www.kensington.com

7
OSD MENU
Button Labels and Functions
Pressing any of the control buttons, other than the Power Button ( ), causes the button
labels to appear on screen above their respective buttons. Following are the basic menu
level button labels, from left to right.
View Mode: Displays a quick menu that allows for selection of one of nine video
equalization presets (Standard, FPS Game, RTS Game, MOBA Game, Movie, Web,
Text, MAC, and Mono).
Input Select: Displays a quick menu that allows for selection of one of three video
inputs (HDMI® 1, HDMI 2, and DisplayPort®)
Menu: Displays the full OSD menu.
Exit: Turns off the on-screen button labels.
Once inside one of the above three menus, the button labels will change to indicate their
functions in operating the menus. Following are the various labels and their purpose.
Select: Enters the highlighted submenu or edits the selected menu entry.
Back: Goes back to the previous menu or exits editing an entry.
Exit: Closes the OSD menu.
Up: Moves the highlight up.

8
Down: Moves the highlight down.
Left/Decrease: Moves the highlight to the left or decreases the displayed value
when editing an entry.
Right/Increase: Moves the highlight to the right or increases the displayed value
when editing an entry.
Menu Structure
Input Select
HDMI 1
HDMI 2
DisplayPort
Audio Adjust
Volume (0-100)
Mute (On/Off)
View Mode
Standard
FPS Game
RTS Game
MOBA Game
Movie
Web

9
Text
MAC
Mono
Color Adjust
Contrast/Brightness
Contrast (0-100)
Brightness (0-100)
Color Temperature
sRGB
Bluish
Cool
Native
Warm
User Color
Red (0-100)
Green (0-100)
Blue (0-100)
Color Space
Auto
RGB Mode
YUV Mode
Color Range
Auto
Full Range

10
Limited Range
HDR (On/Off)
Manual Image Adjust
Sharpness (0-100 in increments of 25)
Blue Light Filter (0-100)
Aspect Ratio
Fill Aspect Ratio
Full Screen
Overscan (On/Off)
Black Stabilization (0-100 in increments of 10)
Advanced DCR (0/25/50/75/100)
Response Time
Standard
Advanced
Ultra Fast
Setup Menu
Language Select
English
French
German
Spanish
Italian
Finnish

11
Russian
Turkish
Japanese
Korean
Traditional Chinese
Simplified Chinese
Resolution Notice (On/Off)
Information
Resolution
H. Frequency
V. Frequency
Pixel Clock
OSD Timeout (5/15/30/60 seconds)
OSD Background (On/Off)
Auto Power Off (On/Off)
Sleep (30/45/60/120 minutes/Off)
ECO Mode
Standard
Optimize
Conserve
DDC/CI (On/Off)
Memory Recall

12
View Mode Quick Menu
Standard
FPS Game
RTS Game
MOBA Game
Movie
Web
Text
MAC
Mono
Input Select Quick Menu
HDMI 1
HDMI 2
DisplayPort
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com
or through email by sending a message to [email protected]. Check the website for
support times and links.

13
SPECIFICATIONS
Model
37922, 38940
Display Size
27" (686 mm)
Display Type
TFT Active Matrix
Display Finish
Anti-glare
Display Area
23.5" x 13.2" (597 x 336 mm)
Video Inputs
2x HDMI®, 1x DisplayPort®
Maximum Resolution
2560 x 1440 @60Hz
Color Filter
RGB vertical stripe
Pixel Pitch
0.2311 x 0.2311 mm
VESA® Mount Size
100 x 100
Input Power
100 ~ 240 VAC, 50/60 Hz, auto switching
Maximum Power Consumption
35 watts
Standby Power Consumption
< 0.5 watts
Operating Temperature
+32 ~ +104°F (0 ~ +40°C)
Storage Temperature
-4 ~ +140°F (-20 ~ +60°C)
Operating Humidity
10 ~ 90% RH, noncondensing
Storage Humidity
5 ~ 90% RH, noncondensing
Dimensions
24.1" x 17.4: x 6.9": (613 x 442 x 175 mm)
Weight
10.5 lbs. (4.75 kg)

14
REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Modifying the equipment without Monoprice's authorization may result in the equipment
no longer complying with FCC requirements for Class B digital devices. In that event, your
right to use the equipment may be limited by FCC regulations, and you may be required to
correct any interference to radio or television communications at your own expense.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

15
Notice for Industry Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
EU Declaration of Conformity
Monoprice, Inc. declares the product described within this user guide or manual is in
compliance with below applicable directives. The full text of the EU Declaration of
Conformity is available at the following internet address:
https://www.monoprice.com/product?p_id=37922 or the CE DoC can be found within this
user manual
EMC Directive 2014/53/EC
Low Voltage Directive 2014/35/EU
RoHS2 Directive 2011/65/EU
WEEE Directive 2012/19/EC
Packaging & Packaging Waste Directive 94/62/EC
REACH Directive 1907/2006/EC
WEEE Information
User information for consumer products covered by EU Directive 2012/19/EU on Waste
Electric and Electronic Equipment (WEEE).
This document contains important information for users with regards to the proper
disposal and recycling of Monoprice products. Consumers are required to comply with this
notice for all electronic products bearing the following symbol:

16
For Consumers in the European Union: This EU Directive requires that the product bearing
this symbol and or its packaging must not be disposed of with unsorted municipal waste.
The symbol indicates that this product should be disposed of separately from regular
household waste streams. It is your responsibility to dispose of this and other electrical and
electronics products via designated collection facilities appointed by the government or
local authorities. Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health. For more detailed information about
the disposal of your unwanted product, please contacts your local authorities, waste
disposal service, or the shop where you purchased the product.
Safety Notice
WARNING: Do not use this product near water, for example, in a wet basement or near
swimming pool or in an area where accidental contact with water or liquid might occurs
WARNING: Avoid using this product during an electrical storm. There may be a remote risk
of electric shock from the surge caused by lightning
WARNING: The external power adapter or AC power cord is the equipment's disconnection
device. The power outlet must be located near the equipment and its access must be easy
WARNING: Use this product in a well-ventilated area

17
HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
VESA®, DisplayPort®, and the DisplayPort® logo are registered trademarks of the Video
Electronics Standards Association.
Kensington Security Slot™ is a trademark of Kensington Computer Products Group.
