Monoprice 43021 User manual

34" WQHD Monitor
Desktop Monitor with
Height Adjustable Stand
P/N 43021
User's Manual

SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
-This monitor is intended for indoor use only.
-Do not expose this monitor to water or moisture of any kind. Do not place drinks or
other containers with moisture on or near the device. If moisture does get in or on
the device, immediately unplug it from the power outlet and allow it to fully dry
before reapplying power.
-Do not touch the monitor, the power cord, or any other connected cables with wet
hands.
-Do not place the monitor on an unstable surface where it could fall and cause either
personal injury or damage to the monitor and/or other equipment.
-Do not subject the monitor to extreme force, shock, or fluctuations in temperature
or humidity.
-Do not block the ventilation holes in the monitor's casing. Do not place the monitor
in a confined space with inadequate ventilation. Periodically check the ventilation
holes to ensure they do not become clogged with dust, debris, or nearby items.
-Do not place the monitor near a heat source, such as a fireplace, heating vent,
radiator, etc.
-Do not place or install this monitor in an area where it can be exposed to excessive
amounts of dust, humidity, oil, smoke, or combustible vapors.
-Prior to operation, check the monitor and power cord for physical damage. Do not
use if physical damage has occurred.
-Unplug this monitor from the power source when not in use.
-Take care to prevent damage to the power cord. Do not allow it to become
crimped, pinched, walked on, or become tangled with other cords. Ensure that the
power cord does not present a tripping hazard.
-Never unplug the monitor by pulling on the power cord. Always grasp the
connector head or adapter body.
1

-Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
-This monitor has no user serviceable parts. Do not open the case or otherwise
attempt to modify this monitor.
-Do not leave a single image on the display for a long period of time. Doing so could
cause "burn-in" of the image. It is recommended to use a variable desktop
background and to use a screen saver to prevent "burn-in". Alternatively, ensure
that the monitor is powered st 2 hours out of every 12.
-
PACKAGE CONTENTS
1 x 34” Monitor
-1x Base
-1x Stand
-1x Thank You Card and User Manual
-1x Power Cable、1xAdapter
-1x HDMI Cable
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-
6pm PT) or via email at s[email protected]
2

USING THE KENSINGTON LOCK
The Kensington security connector is located on the back side of the
monitor. For more information on installation and usage please visit
the Kensington website at http://www. kensington.com.
Below is an example of setting up the Kensington lock on a table for
your reference.
*This picture is for reference only
3

4
Perform the following steps to prepare your monitor for use.
1. Either assemble the stand and attach it to the rear of the monitor or mount the
monitor to a wall or desk mount.
2. Plug one end of the included HDMI cable into one of the HDMl inputs on the
monitor,then plug the other end into the HDMl video output on your computer.
Alternatively,you can connect using a DisplayPort/ Type-C Cable(not included).
3.(Optional) Plug a pair of headphones or powered speakers into the audio
output on the monitor.
4. The power cord AC plug connection adapter,the adapter DC plug connection
monitor, power plug connected power supply.The LED power indicator on the
monitor will illuminate orange.
*This picture is for reference only

5
POWER ON
Turn On LCD Monitor and Computer
Turn ON the LCD Monitor, then turn ON the computer. This
particular order (LCD monitor before computer) is important.

6
ADJUSTING THE SCREEN IMAGE
SETTING THE TIMING MODE
Set your monitor resolution to its recommended resolution (see
section "specification") to get the best experience possible, with
brilliant color and crisp text. Here is how:
1. Go to your display resolution settings window (each operating
system will have a different process to get there).
2. Next, adjust the display resolution setting to match your
monitor’s native resolution. This will provide you with your best
usage experience.
If you have difficulty setting the resolution or you do not see
recommended resolution as an available option, you may need
a newer video card driver. Contact your computer or video card
manufacturer to obtain the latest driver.
• If necessary, make small adjustments using H. POSITION and
V. POSITION until the screen image is completely visible. (*for
analog only). (The black border around the edge of the screen
should barely touch the illuminated “active area” of the LCD
monitor.)

7
USING THE CONTROL PANEL
After setting the timing mode, use the buttons on the Front or
rear control panel to display and adjust OSD for screen image
adjustment.
* The postition refer to section 2.2
Front & OSD symbol explanation
The symbol explanation is stated below:
NOTE: Power light
Blue = ON
Orange = Power Saving
Toggles between the various input options that are available for
that particular monitor.
Main menu icon that allows users to access the main menu.

8
13
The OSD Menu and OSD Quick-Menu Symbol explanations and
their functional uses are stated below.
Activation symbol to turn the various modes on when operating
the menu system.
Activation symbol to exit, go back or deactivate the desired
function that is selected.
Scrolls through menu options and adjusts the monitor controls.
Symbol used to go back or revert back to the previously
selected menu
Main menu icon that allows users to access the main menu.
Hold down the icon for a few seconds to turn off the main menu
Left and right icons toggle your selected choice horizontally.

9
14
OSD MENU INTRODUCTION
OSD MENU TREE
For an explanation of the OSD tree and pertaining functions, please
refer to the 4-1 OSD explanation below. The OSD tree visually
represents the complete OSD menu that can be accessed by your
monitor. If you aren’t sure where an option/function is or cannot
locate a specific feature, please utilize the OSD tree below.
View Mode
Input Select
Main Menu
Exit

10
OSD MENU EXPLANATION
NOTE: The OSD menu items listed in this section indicate the entire
OSD items of all models. Some of these items may not exist in your
product OSD. Please disregard OSD menu item explanations if they
do not exist in your OSD Menu. Please refer to the 4-1 OSD Tree
(above), for your monitor’s available OSD menu items. Please refer
to the OSD explanation below (in alphabetical order), for a clearer
explanation of what each function does.
AAdvanced DCR
Advanced DCR technology automatically detects the image signal and
intelligently controls the backlight brightness and color, to improve on
the ability to make the black blacker in a dark scene, and make the white
whiter in a bright environment.
Auto Detect
If current input source is no signal, monitor will automatically switch to
next input option. This function on some model is disabled by default.
BBlack stabilization
Monoprice’s Black stabilization provides heightened visibility and detail
by brightening dark scenes.
Blue light filter
Adjusts the filter that blocks high-energy blue light for a safer experience
for our users.
Brightness
Adjusts background black levels of the screen image.

11
CColor adjust
Provides several color adjustment modes, to help adjust the color
settings to fit our users’ needs.
Color range
Adjusts the color range, allowing users to adjust the range in RGB and
YUV color settings.
Color space
Allows users to choose which color space they would like to use for
monitor color output (RGB, YUV).

12
CColor temperature
Allows users to select specific color temperature settings to further
customize their viewing experience.
Explanation
sRGB Standard color space used for the windows system, digital
cameras and the Internet.
NATIVE Native is a default color temperature.
Recommended for general graphic design and regular use.
Contrast
Adjusts the difference between the image background (black level) and
the foreground (white level).
Custom
Providing even more support, three customizable ‘Custom’ settings are
available to help match individual preferences and adapt to every type of
game on the market. Select one of the ‘Custom’ options (Custom
1, Custom 2 etc. ) in the Menu and adjust the advanced options. After
exiting the setting will automatically be saved under that particular
‘Custom’ setting or rename the setting to your liking by selecting
‘Rename’. You can access your saved ‘GAME MODE’ settings with the
Quick Menu as well.
GGame mode
Integrating a gaming-oriented OSD design including pre-calibrated FPS,
RTS and MOBA gaming settings, each mode is functionally customized
with in-game testing and adjustments made for the best blend of color
and technology. To access the game mode first open the Main Menu
setting, then go to ‘ViewMode’, select ‘Game’ and change your ‘GAMER’
settings from there.

13
IInformation
Displays the timing mode (video signal input) coming from the graphics
card in the computer, and the LCD model number.
See your graphics card’s user guide for instructions on changing the
frequency).
NOTE: VESA 1024 x 768 @ 60Hz (example) means that the resolution
is 1024 x 768 and the refresh rate is 60 Hertz.
Input select
Toggles between the various input options that are available for that
particular monitor.
MManual image adjust
Displays the Manual Image Adjust menu. You can manually set a variety
of image quality adjustments.
Memory recall
Returns the adjustments back to factory settings if the display is
operating in a factory Preset Timing Mode listed in the Specifications of
this manual.
Exception: This control does not affect changes made with the
Language Select or Power Lock setting
OOverscan
Can be used to adjust the aspect ratio of the input signal received by
your monitor to adjust the image so it appears on the monitor.
resolution and refresh rate (vertical

14
19
RResponse time
Adjusts the response time, creating smooth images without streaking,
blurring or ghosting. A low response time is perfect for the most graphic-
intense gaming, and provides amazing visual quality while watching
sports or action movies. Setting the menu to ‘Ultra Fast’ is advised.
Resolution notice
The notice tells users that the current viewing resolution is not the
correct native resolution. This notice will appear in the display settings
window, when setting up the display resolution.
Recall
Resets the ViewMode monitor settings.
SSetup menu
Adjusts On-screen Display (OSD) settings. Many of these settings can
activate on-screen display notifications so users do not have to reopen
the menu.
Sharpness
Adjusts the sharpness and picture quality of the monitor.
VViewMode
The unique ViewMode feature offers “Game,” “Movie,” “Web,”
“Text,” and “Mono” presets. These presets are specifically designed to
deliver an optimized viewing experience for different screen applications.

15
20
Monitor Setting Management
OSD Timeout
The OSD Timeout function, allows users to choose how long the
OSD will reside on the screen after in-activity (number of seconds).
OSD Background
The OSD Background function allows users to turn off the OSD
background while selecting and adjusting OSD settings.
Power Indicator
The power indicator is the light that displays whether the monitor is
on or off.
Auto Power Off
Selecting Auto Power Off, allows the monitor to shut its power off
after a certain amount of time.
Sleep
This setting allows users to adjust the time of inactivity before the
monitor goes on a reduced power mode. The screen will be on
‘sleep mode’ during this time.
Eco Mode
Allows users to choose between various modes, based on power
consumption.
DDC/CI (Display Data Channel Command Interface)
Activating this setting allows monitor control via the graphics card.

16
27
SPECIFICATIONS
LCD Type TFT (Thin Film Transistor), Active Matrix
3440 x1440 LCD, 0.2325 (H) x 0.2325 (V)mm
pixel pitch
Display Size Metric: 86.7 cm
Imperial: 34” (34” viewable)
Color Filter RGB vertical stripe
Glass Surface Anti-Glare
Input Signal Video Sync TMDS digital (100ohms)
HDMI: f h:84-112 kHz, f v:56-75 Hz
DP: f h:84-112 kHz, f v:56-75 Hz
Compatibility PC
Macintosh1
Up to 3440X1440 Non-interlaced
Power Macintosh up to 3440X1440
(Supported by limited graphic cards)
Resolution 2Recommended
Supported
3440X1440@60Hz
2560X1440@60Hz
1920 x 1080 @ 60 Hz
1680 x 1050 @ 60 Hz
1280 x 1024 @ 60, 75 Hz
1440 x 900 @ 60 Hz
1024 x 768 @ 60, 70, 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
Power
Adaptor 3
Input Voltage
12 V 5A DC
Display area Full Scan 799.8mm (H) x 334.8 mm (V)
31.5” (H) x 13.2” (V)

17
Operating
conditions
Temperature
Humidity
Altitude
+32 °F to +104 °F (0 °C to +40 °C)
10% to 90% (non-condensing)
To 16,404 feet
Storage
conditions
Temperature
Humidity
Altitude
-4 °F to +140 °F (-20 °C to +60 °C)
5% to 90% (non-condensing)
To 40,000 feet
Dimensions Physical 827.4 mm(W) x 532.7 mm(H) x 185 mm(D)
32.6” (W) x 21” (H) x 7.3” (D)
Wall Mount Max
Loading
Hole pattern
(W x H; mm)
Interface Pad
(W x H x D)
Pad
Hole
Screw Q’ty &
14kg 100mm x
100mm
115 mm x
115 mm x
2.6 mm
Ø 5mm 4 piece
M4 x 12mm
Weight Physical 24.3lb (11 kg)
Power saving
modes
On 60W (Typical)
<0.5W

18
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our websitewww.monoprice.com
during regular business hours, 7 days a week. You can also get assistance through email by
sending a message to [e-mail]
REGULATORY COMPLIANCE
Notice for FCC
Modifying the equipment without Monoprice’s authorization may result in the equipment
no longer complying with FCC requirements for Class B digital devices. In that event,your
right to use the equipment may be limited by FCC regulations, and you may be required to
correct any interference to radio or television communications at your own expense.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.

19
24
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Notice for Industry Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
AMD® and FreeSync™ are trademarks of Advanced Micro Devices, Inc. in the United States
and/or other jurisdictions.
HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
