Monoprice MP CADET User manual

MONOPRICE
MP Cadet Robot Vacuum
P/N 21715
User's Manual

2
CONTENTS
SAFETY WARNINGS AND GUIDELINES.......................................................................................................................................3
INTRODUCTION................................................................................................................................................................................................4
CUSTOMER SERVICE....................................................................................................................................................................................4
PACKAGE CONTENTS.................................................................................................................................................................................4
PRODUCT OVERVIEW.................................................................................................................................................................................5
PREPARATION FOR USE............................................................................................................................................................................6
OPERATION.......................................................................................................................................................................................................... 7
MAINTENANCE................................................................................................................................................................................................. 7
TROUBLESHOOTING ....................................................................................................................................................................................9
TECHNICAL SUPPORT................................................................................................................................................................................11
REGULATORY COMPLIANCE...............................................................................................................................................................11
Notice for FCC ...........................................................................................................................................................................................11

3
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
This device is intended for indoor use only.
Do not use this device in a wet or moist environment, such as a bathroom or
laundry.
Do not touch the device, the power cord, or any other connected cables with wet
hands.
Do not expose this device to excessively high temperatures. Do not place it in, on,
or near heat sources, such as a fireplace, stove, radiator, etc. Do not leave it in direct
sunlight.
Do not use this vacuum in proximity to curtains, cords, loose cables, fragile objects,
papers, loose debris, or anything that could get easily knocked over.
Do not use this vacuum around cigarette ends, lighters, matches, volatile liquids
such as gasoline, or any other flammable materials.
If the vacuum needs to be cleaned, it should be fully charged beforehand.
Do not sit on the vacuum or allow pets or children to sit on it. Take care when using
this around children or pets.
Do not use this product where it can easily fall, such as on tables, chairs, or next to
stairs.
Turn off the vacuum when transporting it or when it will not be used for a long
time.
Empty and clean the dust bin and filter after each use.
Fully charge the battery before first use and at least once every three months.
This device contains a rechargeable battery. Dispose of the device or battery only in
accordance with local, state, or federal regulations for electronic waste.
Do not allow small children to use or play with this vacuum.

4
INTRODUCTION
Explore the benefits of your own robotic vacuum at a cost that makes sense. Ultra-
compact at just over 3" tall (3.34"), the MP Cadet Robot Vacuum will easily clean under your
furniture with the dual side brushes giving you a wide cleaning path. The 10-watt motor is
powerful enough to tackle pet hair, carpet, and hardwood floors. It is loaded with features
you would find at prices over 4 times higher. The anti-drop sensor enables the vacuum to
easily navigate around stairs or other precarious zones. The anti-collision bump sensor will
keep your vacuum from shifting your furniture, such as chairs or other small objects,
around your home.
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-
6pm PT) or via email at [email protected]
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x MP Cadet Robot Vacuum
1x AC Power Adapter
2x Left Side Brushes
2x Right Side Brushes
1x User's Manual

5
PRODUCT OVERVIEW

6
PREPARATION FOR USE
Perform the following steps to prepare the MP Cadet for first use.
1. Turn the vacuum over so it rests on its top.
2. Slide the battery cover off to reveal the
battery compartment and rechargeable
battery.
3. Remove the battery from the
compartment, then remove the
insulating strip from the battery contact
points.
4. Replace the battery in the
compartment, then slide the battery
cover back into place.
5. Locate one side brush marked L, then press it onto
the side brush drive shaft next to the Lmark on the
vacuum.
6. Locate one side brush marked R, then press it onto
the side brush drive shaft next to the Rmark on the
vacuum.
7. Turn the vacuum back over to rest on its wheels.
8. Plug the DC barrel connector on the included AC
power adapter into the power input jack on the
vacuum. The LED indicator around the On/Off Switch
will begin flashing blue.
9. Charge the vacuum for at least 4 hours. When the
battery charge is full, the LED indicator ceases flashing
and will glow blue.

7
OPERATION
Perform the following steps to use your MP Cadet Robot Vacuum.
1. Place the vacuum on the floor in the room you want to clean.
2. Press the On/Off Switch to turn the vacuum on. The vacuum will begin cleaning the
room.
3. When the battery power is low, the LED indicator around the On/Off Switch will
glow red.
4. Press the On/Off Switch to turn the vacuum off.
5. Plug the DC barrel connector on the included AC power adapter into the power
input jack on the vacuum. The LED indicator around the On/Off Switch will begin
flashing blue.
6. When the battery charge is full, the LED indicator cease flashing and will glow blue.
7. Clean the vacuum by following the steps in the MAINTENANCE section.
MAINTENANCE
Fully charge the battery, then clean the vacuum after each use.
1. Ensure that the vacuum is powered off.
2. Lift the lid on the top of the vacuum.
3. Grasp the Dust Bin and remove it from the vacuum.

8
4. Remove the Lid from the Dust Bin.
5. Remove the Filter from the Dust Bin.
6. Empty the Dust Bin into the trash.
7. Thoroughly wash the Dust Bin and Lid using warm
water and mild soap.

9
8. Wash the Filter using warm water and a soft bristle
brush (not included).
9. Close the vacuum lid, then turn it over onto its top. Using a soft, dry cloth, clean the
Vacuum Intake. If necessary, moisten the cloth with warm water.
10. Using a soft, dry cloth clean the Anti-drop Sensors on the bottom of the vacuum.
11. Clean the Side Brushes. If necessary, remove them first.
12. Thoroughly dry all parts or allow them to fully dry before reassembly.
13. Turn the vacuum back over so that it rests on its wheels, then open the lid.
14. Insert the Filter into the Dust Bin, then put the Lid back on it.
15. Reinsert the Dust Bin into the vacuum, then close the vacuum lid.
TROUBLESHOOTING
Problem
Possible Cause
Solution
The LED indicator glows
red, even after power on
The battery charge is low
Fully charge the battery
The vacuum was lifted off
the floor
Place the vacuum on the
floor
The vacuum is on, but
cannot collect dirt or hair
The Dust Bin is full
Empty and clean the Dust
Bin
The filter is not installed
properly
Remove the Dust Bin then
reinstall the filter

10
The vacuum moves
backwards after being
switched on
The vacuum is on a dark
floor
Place the vacuum on a light
colored floor
One or more of the anti-
drop sensors is covered
Ensure that the anti-drop
sensors are clean and
unobstructed
The LED indicator still
flashes blue after 4 hours of
charging
The power supply may have
been cut off during
charging
Continue to charge the
battery until the LED
indicator ceases flashing
The side brushes are
crooked and do not clean
well
The side brushes have been
used for a long time
Remove the brushes then
soak them in scalding hot
water to recover their
original shape
The vacuum won't start
The battery is not installed
properly
Reinstall the battery
The battery has been
drained
Recharge the battery
The vacuum is in protected
status
Turn the vacuum off then
back on
The insulating strip has not
been removed from the
battery terminals
Remove the insulating strip
The vacuum runs in circles
and never runs straight
One of the power wires for
the wheel motor has come
loose
Remove the wheel drive
cover and reconnect the
loosened wire

11
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com
during regular business hours, 7 days a week. You can also get assistance through email by
sending a message to [e-mail]
REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Modifying the equipment without Monoprice’s authorization may result in the equipment
no longer complying with FCC requirements for Class B digital devices. In that event, your
right to use the equipment may be limited by FCC regulations, and you may be required to
correct any interference to radio or television communications at your own expense.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or

12
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
