Monster TULPAR T6 V1.1 User manual

01
EN
T6 V1.1
USER MANUAL
BENUTZERHANDBUCH
KULLANIM KILAVUZU
MANUAL DE USUARIO
MANUEL DE L’UTILISATEUR
MANUALE UTENTE
 

01
EN
TABLE OF CONTENT
CHAPTER 1 - Preface...............................................................
1.1 Regulations Information..............................................................
FCC Information....................................................................................
1.2 Safety Information........................................................................
1.3 Conventions For This Manual ....................................................
CHAPTER 2 - Getting To Know The Basics.............................
2.1 Product Specification....................................................................
2.2 Preparing your Computer ..........................................................
2.3 Product Overview..........................................................................
CHAPTER 3 - Getting Started.................................................
3.1 AC Adapter .......................................................................................
3.2 Knowing The Keyboard ..............................................................
3.2.1 For Keyboard Users...................................................................
3.3 Using the touchpad / clickpad ..................................................
CHAPTER 4 - BIOS Setup........................................................
4.1 About BIOS Setup..........................................................................
4.1.1 When To Use BIOS Setup? .......................................................
4.1.2 How to Run BIOS Setup ?........................................................
4.2 BIOS Setup Menu .........................................................................
4.2.1 Main Menu ...................................................................................
4.2.2 Advanced Menu.........................................................................
4.2.3 Security Menu............................................................................
4.2.4 Boot Menu...................................................................................
4.2.5 Exit Menu.....................................................................................
USER MANUAL
T6 V1.1

EN
02
CHAPTER 1
1.1 Regulations Information
Preface
•CE compliance
This device is classed as a information technology equipment (ITE) in class B and
is intended for use in living room and office. The CE-mark approves the conform-
ity by the EU-guidelines:
- EMC Directive 2014/30/EU,
- Low Voltage Directive 2014/35/EU(equals A2 : 2013) ,
- RF Directive 2014/53/EU
SAR/DAS refers to the rate at which the body absorbs RF energy.
The SAR limit set by the ICNIRP Guidelines is 2.0 W/kg(10g).
Testing for SAR is conducted using standard operating positions
accepted by the EN standard.
During testing, the radio is set to its highest transmission levels and
placed in positions that simulate use against the body.
This product is compliant with ICNIRP Guidelines with respect to
Electromagnetic Fields (EMF) which specifies a Specific Absorption
Rate (SAR) limit of 2W/kg. DAS*/SAR: 0.18 W/kg (corps/body)

03
EN
RECHARGEABLE BATTERY NOTICE
DO NOT:
1. Throw into fire or a hot oven, or mechanically crush or cutting of a BATTERY
2.Throw or immerse into water
3.Heat to more than 60°C
4.Repaire or disassemble
5.Leave in an extremely low air pressure environment
6.Leave in an extremely high-temperature environment A power cord is
connected to a socket-outlet with earthing connection.
The unit can be operated at an ambient temperature of max. 35°C (95°F).
Do not subject it to temperatures below 5°C (41°F) or above 40°C (104 °F).
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
PREVENTION OF HEARING LOSS
CAUTION: Listening to music at high volume levels and for extended durations
can damage one’s hearing. In order to reduce the risk of damage to hearing,
one should lower the volume to a safe, comfortable level, and reduce the amount
of time listening at high levels. Headsets should comply with EN 50332-2
requirements.

EN
04
FCC Information
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that in-
terference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/ TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the guarantee of this
device could void the user’s authority to operate the equipment.

05
EN
RF Exposure Information(SAR)
This device meets the government’s requirements for exposure to radio waves.
This device is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government.
The exposure standard employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR
are conducted using standard operating positions accepted by the FCC with the
EUT transmitting at the specified power level in different channels.
The FCC has granted an Equipment Authorization for this device with all reported
SAR levels evaluated as in compliance with the FCC RF exposure guidelines.
SAR information on this device is on file with the FCC and can be found under
the Display Grant section of www.fcc.gov/eot/ea/fccid after searching on FCC ID:
2AKHFAX201NG or 2AKHFAX211NG .
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CAUTION:
Any changes or modifications not expressly approved by the guarantee of this
device could void the user’s authority to operate the equipment.

EN
06
1.2 Safety Information
Do not apply heavy pressure to the computer
or subject it to any form of strong impact as
this can damage the computer’s components or
otherwise cause it to malfunction.
1
Never cover or block the air vents including
those located at the base of the computer.
Never cover your computer or AC adaptor with
any object.
Do NOT expose to or use near liquid,
rain, or moisture. Do NOT use the modem
during electrical storms.
Do not use or expose this device around
magnetic felds as magnetic interference may
aect the performance of the device.
To keep your computer in prime operating
condition, protect your work area from direct
sunlight.
2
3
4
5

07
EN
1.3 Conventions For This Manual
2.1 Product Specification
CAUTION:
This message contains important information that must be followed for
safe operation.
NOTE:
This message contains information for special situations.
CHAPTER 2
Getting To Know The Basics
This User’s Manual provides technical information of instructions and
illustrations on how to operate this notebook for the customer.
Please read this manual carefully before using this notebook.
Physical Characteristic
Processor - CPU
Graphic Card - GPU
Memory
Display
Dimension 358.44*267.6*22mm
Support Processor i7-13700H
Graphic Card 8 GB RTX4070
Weight 2.3Kg +/- 5%
RAM DDR4 3200MHz
LCD 16” Narrow,16:10 QHD 2560x1600

EN
08
Audio
Power
Webcam
Communication Port
Input
I/O Port
DC-in
USB
Codec: Realtek
ALC256USB
Speaker/MIC
AC Adapter
Battery
HD webcam
Wireless LAN +BT
Keyboard
Pointing Device
RJ45
Mini DP
HDMI
Mic / Audio Combo
Card reader
x 1
USB Type A @Right side x2:
USB 3.2 (Gen1)
USB Type A @Left side x1: USB 2.0
USB Type C @Rear side x1
USB 3.2 (Gen2)
*Azalia standard support
*D3 mode support
Build-in 2 speakers
Speaker : 2W/each
Digitial Microphone support
Automatics Voltage adjustment between 100 and 240VAC
50/60Hz, 230 Watts (19.5V/11.8A)，3 Pins
Li- polymer Battery, SW Gas Gauge IC, soft pack
4 cells (4s1p 4100mAh) 62.32 Wh
HD webcam with D-MIC*1
Intel Wi-Fi 6E AX211
IEEE802.11 a/b/g/n/ac/ax support
*Membrane KB
340*109.2*3.6mm, 4 Zone RGB Backlight support
TDA1470 (114.5*70*0.6mm) TP Glass
x 1
x 1
x 1 (HDMI 2.1)
x 2
x 1
-USB interface, SD/SDHC/SDXC, UHS-I speed
-Connecter: Full SD size

09
EN
2.2 Preparing your Computer
Connect the AC adaptor’s DC output plug to the DC IN jack.
The display panel can be opened to a wide range of angles for optimal viewing.
Press the power button to turn on your notebook computer.
A
B
C

EN
10
2.3 Product Overview
Please become familiar with each component before you operate the computer.
Top-Open View
The product’s color/ LED color, I/O port, indicator location,
and specication will depend upon the actually shipping product.
10
9
8
1
2
5
6
7
3
4

11
EN
Camera Status LED
A device that allows you to record video or take photographs with your
computer.
Camera
A device that allows you to record video or take photographs with your
computer.
Microphone
Built-in microphones.
LCD screen
Displays of your notebook computer.
Caps Lock Status LED
Default: ON (White)
Turbo / Balance / Oce Mode Switch
Oce mode: LED O
Balance mode: White (Faint Light)
Turbo mode: Both White (Bright)
Power Button
Press this button to turn the computer’s power on or o.
Power indicator
No charging:
Power ON: White
Suspend: White breath
Power O: OFF
Battery Low: Amber Blink
Charging: Amber
1
2
3
4
5
6
7
CAUTION:
When you are not using the computer,
keep the LCD screen closed to protect it from dust.

EN
12
Right Side View
12
Card Reader
- USB interface, SD/SDHC/SDXC, UHS-I speed
- Connecter: Full SD size
USB Port
Connects an USB device (such as USB Zip drive, keyboard or mouse)
into this jack. With charging function.
1
2
Keyboard
The keyboard provides keys with comfortable travel
(The keyboard legend will depend on the spec / region)
Touchpad LED indicator/ Touchpad switch
Click twice will open or close touchpad functionality
(Please see 3.3 Using the touchpad / clickpad instructions)
Touchpad/Clickpad
Touch-sensitive pointing device which functions like the mouse.
8
9
10

13
EN
Left Side View
12345
Kensington® Lock Port
To be secured using Kensington® Lock Port security products.
Vents
The thermal vents are designed to cool the internal components and
avoid overheating.
USB Port
Connects an USB device (such as USB Zip drive, keyboard or mouse) into
this jack. With charging function.
Mic In Jack
Connects amplied speakers into this jack.
Audio Combo
Connect the 3.5mm audio combo jack/headphones to this port.
1
2
3
4
5
4

EN
14
Bottom Side View
The product’s thermal vent will depend upon the actually shipping product.
1
2
Vents
The thermal vents are designed to cool the internal components and
avoid overheating.
Speaker
1
2
CAUTION:
To reduce the possibility of heat-related injuries or of overheating the computer,
do not place the computer directly on your lap or obstruct the computer air vents.
Use the computer only on a hard, flat surface. Do not allow another hard surface,
such as an adjoining optional printer, or a soft surface, such as pillows or rugs or
clothing, to block airflow. Also, do not allow the AC adapter to come into contact with
the skin or a soft surface, such as pillows or rugs or clothing, during operation.

15
EN
Compartment View
Specication will depend upon the actually shipping product.
SSD
SSD
BATTERY
RAM
RAM
Front Side View

EN
16
Back Side View
Vents
The thermal vents are designed to cool the internal components and
avoid overheating.
Mini Display Port
Supports high-denition digital video connections.
USB Port (Type C)
Connects an USB device.
(such as USB Zip drive, keyboard or mouse) into this jack.
HDMI port
Connected to the screen, or home theater system.
Network Jack
This jack lets you connect to a LAN.
Power Connector
Connects the AC adapter into this connector.
1
2
3
4
5
6
45 3
16
2

17
EN
CHAPTER 3
Getting Started
3.1 AC Adapter
Please be noted that it is strongly recommended to connect the AC adapter
and use the AC power while using this notebook for the first time. When the AC
adapter is connected, the battery is being charged immediately. Attach the AC
adapter when you need to charge the battery or you want to operate from AC
power. It is also the fastest way to get started, because the battery pack will
need to be charged before you can operate from battery power. Note that the
AC adapter included in the package is approved for your notebook; using other
adapter model may damage either the notebook or other devices attached to it.
DC IN
CAUTION:
The use of inferior extension cords may result in damage to your notebook. Your note-
book comes with its own authorized AC adapter. Use of a different AC adapter or cable
extension which is not authorized for use will void
warranty protection if damage to hardware is found in association to said
adapter or extension cable.
NOTE:
The power adapter can become hot when in use. Please be sure the AC adapter is not
covered with any materials keep it away from exposed parts of your body. The AC
adapter appearance may vary depending on your region.

EN
18
3.2 Knowing The Keyboard
3.2.1 For Keyboard Users
The following defines the hot keys on the Keyboard. The commands can only be
accessed by first pressing and holding the function key while pressing a key with
a command.
To activate these functions, press the hot key associated with the
desired function as below :
The design of the number of keys available on the keyboard, printing color or
backlight depends on the country (region) in which the keyboard was
designed and built in which the keyboard was designed and built.
Suspend
Press this key combination (Fn+F2) to turn
Windows Lock/On .
Press this key combination (Fn+F1) to enter
Sleep Mode.
Press this key combination (Fn+F3)
to enable Display Mode.
Press this key combination (Fn+F4) to turn all
radios on or off.
Press this key combination (Fn+F5) to On/Off
Touch pad mode.
Windows Lock/On
Display Mode
RADIO On/Off
Touchpad On/Off
Keypad Function Description

19
EN
Keyboard Brightness
Down
Press this key combination (Fn+F6) to
decrease brightness of Keyboard.
Press this key combination (Fn+F7) to increase
brightness of Keyboard.
Press this key combination (Fn+F8) to enter
MUTE mode.
Press this key combination (Fn+F9) to enter
Volume down mode.
Press this key combination (Fn+F10) to enter
Volume up mode.
Press this key combination (Fn+F11) to
decrease brightness of LCD display.
Press this key combination (Fn+F12) to
increase brightness of LCD display.
For a full list of Windows keyboard shortcuts,
please visit the Microsoft official website.
https://support.microsoft.com/en-us/
Keyboard Brightness
Up
MUTE
Volume Down
Volume Up
Brightness Down
Brightness Up
Search Charm
Keypad Function Description
