Monster HT 800G PowerCenter Installation guide

HT 800G PowerCenter™
Instructions and
Warranty Information
™

ENGLISH
A Note From The Head Monster
THANK YOU for purchasing the Monster GreenPower™HT 800G PowerCenter.™
The HT 800G features advanced surge protection to protect your home theater
equipment, plus GreenPower outlets to stop standby mode energy waste.
For an added layer of protection, the PowerCenter’s internal components are
designed to reduce the risk of fire that can damage not only your equipment, but
your home as well. Unlike plastic-coated MOVs that are in most surge protectors,
the HT 800G features fireproof, ceramic-encased MOVs.
The HT 800G includes GreenPower switched outlets that automatically shut off
when you’re not using the equipment connected to them. This stops energy
waste caused by flatscreen TVs, DVD/Blu-ray Disc™players, subwoofers and other
components in stand-by mode.
Exclusive Dual Mode Plus™automatic disconnect protection circuitry protects
against even the most powerful surges. There are also surge-protected coax
connections to protect against dangerous power conditions on cable, satellite,
and antenna lines.

ENGLISH
Because electrical interference can affect performance of your home theater
components, patented Monster Clean Power®is specifically engineered to virtually
stop the electromagnetic and radio frequency noise that goes right through
typical surge protectors. This advanced technology reduces stress on delicate
digital circuitry, maximizing the lifespan of connected equipment and delivering
better picture and sound.
These days, AV components are better than ever, providing thrilling surround
sound and razor sharp HD picture. With Monster Power, you’ll have peace
of mind knowing your home theater – and your home – is protected and that
you’re getting all the performance you paid for.
Noel Lee,
The Head Monster

ENGLISH
Save Energy. Save the Earth.
Monster GreenPower™is a revolutionary new way
to automatically eliminate energy waste and save
money. Simply plug your HDTV or AV receiver into
the PowerCenter’s Control outlet. When it’s turned
off or goes to sleep, the Monster GreenPower outlets switch off, automatically
eliminating stand-by energy waste by your subwoofer, DVD player, and more.
When your HDTV or AV receiver switches back on, the GreenPower outlets
automatically power up again.
Patented Clean Power®Removes Electrical Interference
for Better Picture and Sound
Your home’s electricity is full of noise and
interference caused by all of your appliances and
electronics: mobile phones, computers, even your
lights, all contribute to the problem. This“dirty
power” can degrade video performance resulting
in“snow”, vertical lines, and pixelation on your screen. Your audio output could
be affected by hissing and popping.
However, ordinary surge protectors can’t remove the effects of dirty power. The
HT 800 features Clean Power filtering that is precision-engineered to eliminate
interference to ensure the best possible picture and sound performance.
®

ENGLISH
Advanced Monster Dual Mode Plus™
for Enhanced Power Protection and Safety
For added protection against more powerful
surges and spikes, advanced Monster Dual Mode
Plus™circuitry automatically disconnects your AV
equipment from the live power line to isolate your
equipment from dangerous AC power conditions. Dual Mode Plus also sounds an
alarm to alert you that your PowerCenter has protected your electronics.
“Small surges can occur several times a day or a hundred times an hour ranging
from several thousand volts to under 100 volts…A single, powerful surge literally
melts, welds, pits and burns its way through solid state circuits.”
- PG&E, One of the Largest
Power Utilities in the U.S.

ENGLISH
Fireproof MOV Technology
Protects Your Equipment and Your Home
Power surges can harm not only your valuable
home theater equipment but can also start a fire in
your home – even if you’re using a surge protector.
Ordinary surge protectors use plastic-coated
MOVs – metal oxide varistors – to absorb excess voltage. But powerful surges can
overheat and melt the plastic coating, potentially causing a fire.
This Monster PowerCenter features ceramic-encased MOVs for superior fire protection.
The ceramic enclosure is made of the same fireproof material used on the space
shuttle to give you peace of mind that your home theater and, more importantly,
your home is safe.

ENGLISH

ENGLISH
MONSTER GREENPOWER™
POWERCENTER™HT800G FEATURES
Mountable Design
For easy mounting to desk or AV cabinet
2
4 3
9
6
5
11
13
12
1
10
78

ENGLISH
1. Power ON/OFF Switch With
Built-in Circuit Breaker
Turns the PowerCenter on and off
2. GreenPower Switch
Disables/enables GreenPower
3. “Protection On” Diagnostic Indicator Light
Indicates that your equipment is protected
4. “Ground OK” Diagnostic Indicator Light
Indicates that your electrical wiring
is properly grounded
5. Ultra-Wide Spaced Outlets
Easily fits bulky power adapter
without blocking adjacent outlets
6. Protected Phone Connections
Protects against surges and spikes
on DVR and modem lines
7. Low Loss Protected Cable
TV/Antenna Connections
Protects against surges on cable TV and antenna lines
8. Patented Color-Coded Outlets
with Matching Cord Labels
Makes hookup easy and prevents unplugging
wrong component
9. GreenPower Switched Outlets
Automatically switches GreenPower outlets ON or OFF
10. GreenPower Control Outlet
Controls switched outlets for automatic energy savings
11. 24K Gold Contacts
For maximum corrosion resistance and power transfer
12. FlatProfile®Plug
Lays flat to let furniture hug walls
13. Extra-Long, 8 ft. PowerLine™100 Cable
Easily reaches wall outlets

ENGLISH
HOOK UP GUIDE
Attach a Monster Power®identification label to each
component’s power cord before you plug it into the
appropriate color-coded PowerCenter™outlet.
Plug each component’s power cord (HDTV,
AV receiver, Cable/Satellite box, etc.) into
the PowerCenter’s corresponding outlet.
NOTE: The outlets on your PowerCenter are labeled for your convenience. It will not
harm your equipment to plug into an outlet that’s labeled differently.
Connecting To Monster GreenPower™Outlets
Please read these instructions before connecting any equipment to the PowerCenter:
ATTENTION:
1. You must connect an electronic device that draws sufficient power in operational
mode to activate GreenPower switched outlets. If you do not, the GreenPower
switched outlets will not deliver power to connected equipment.
2. Some components can take up to 10 minutes to switch to stand-by or sleep
mode. If the Monster GreenPower™switched outlets on your PowerCenter do
not turn off immediately, please wait approximately 10 minutes to allow the
component plugged into GreenPower Control outlet to switch to stand-by
mode. Once this component is in stand-by mode, the GreenPower switched
outlets will turn off, eliminating energy waste by that component.

ENGLISH
WARNING: Important data and settings stored on hard drives (recorded TV shows,
game saves, etc.) may be corrupted or deleted if power is turned off while the hard
drive is being read from or written to.
If you hook up a hard drive-based device such as a TiVo,® DVR or video game
console to a“GREENPOWER CONTROLLED”switched outlet, make sure the device is
NOT being read from or written to when you turn off the equipment connected to
the“GREENPOWER CONTROL”outlet.
To ensure against the possibility of data loss or corruption, you should connect
hard drive-based devices to unswitched outlets or disable GreenPower using the
switch located on the end of the PowerCenter.
Monster assumes no responsibility for data loss, corruption or damage to hard
drive-based devices connected to PowerCenters with GreenPower automatic
outlet switching.

ENGLISH
Connect Equipment As Follows:
1. Connect your AV Receiver or
HDTV to the “GREENPOWER
CONTROL” outlet.
2. Connect devices such as Plasma
TV, Subwoofer, and DVD/Blu-ray
Disc™Player to“GREENPOWER
CONTROLLED” switched outlets
so they won’t use power when
the component connected to
the“GREENPOWER CONTROL”outlet is powered off or in sleep mode.
NOTE: If you don’t want any outlets to automatically switch off, Monster GreenPower
can be disabled by the switch located on the end of the PowerCenter.
CABLE/SATELLITE/ANTENNA CONNECTIONS HOOK-UP
Coaxial Connections provide surge protection against damaging voltage surges
and spikes on the incoming cable TV, satellite, and antenna lines.
IN OUT
CABLE/SAT/ANT
OUTIN
PHONE
CABLE/SAT/ANT
To
TV/Cable
Box
RECEIVER/HDTV
OUTLET 2
CCESSORY 1 DVD/Blu-ray
TiVo/DVR
Subwoofer DVD/Blu-ray™Receiver
Amplier

ENGLISH
WALL-MOUNTING INSTRUCTIONS
The PowerCenter comes with keyholes for convenient wall-mounting.
1. Select the best location to mount the PowerCenter and mark the position for the
four mounting screws (screws not supplied).
2. Drive pan-head screws with spacer eyelets into the wall (use drywall anchors for
hollow walls) at the locations you marked, leaving the eyelet exposed.
3. Position the key-holes on the back of the unit over the screw/eyelets and slide
the PowerCenter down until it locks into position.
ACCESSORY 2

ENGLISH
SAFETY PRECAUTIONS
IMPORTANT SAFETY INFORMATION
Please read and observe the following safety points at all times.
WARNING – Power Sources
Do not plug this PowerCenter™into a power outlet that differs from the source
indicated for safe use on the PowerCenter. If you don’t know the type of electrical
power that is supplied to your home, consult your local power company or
a qualified electrician.
WARNING – Grounding and Polarization
A. Do not force your PowerCenter plug into an outlet that is not designed to
accept a three-wire grounded-type AC plug (a three-prong plug). This plug is
designed to be inserted into a grounded-type outlet only. If this plug doesn’t
fit directly inside your outlet, do not attempt to force it into the outlet. Never
attempt to dismantle the plug in any way (or to alter the power cord). Do not
attempt to defeat the grounding feature by using a 3-to-2 prong adapter.
If you have questions about grounding, consult your local power company
or a qualified electrician.
B. If you use rooftop devices such as satellite dishes, antennas, or any other
component with wire that connects to your PowerCenter, be sure the wire(s)
is properly grounded. This protects against voltage surges and static charges.

ENGLISH
C. Do not place any antenna near overhead power lines or any other power circuit.
Do not touch any power line or power circuit. Doing so may cause severe physical
injury or possibly death.
WARNING – Liquid: Avoiding Electrical Shocks
A. Do not operate your Monster PowerCenter™ if liquid of any kind is spilled onto
or inside the unit.
B. Do not operate your Monster PowerCenter near rain or water that’s spilled
or contained (e.g., bathtub, or kitchen sink).
WARNING – Power Cord Safety
A. When routing your PowerCenter’s AC power cord, do not place it near heavy foot
traffic areas (e.g., hallways, doorways, and floors). Do not create a trip hazard
with the power cord.
B. If your power cord’s protective jacket begins to rip or fray, exposing the internal
wiring, shielding, etc., disconnect it from the AC power source and discontinue
use of the Monster PowerCenter immediately. See the Warranty Information
section of this owner’s manual for important details.

ENGLISH
WARNING – No User Serviceable Parts Inside
If, for any reason, your PowerCenter is not operating properly, do not remove any
part of the unit (cover, etc.) for repair. Unplug the unit and consult the Warranty
Information section of this owner’s manual for important details.
CAUTION – Exposure To Heat
Do not expose your PowerCenter to direct sunlight or place it near wall heaters,
space heaters, or any enclosed space prone to temperature increase.
CAUTION – Proper Cleaning
In general, the only cleaning necessary for your Monster PowerCenter is a light
dusting. Unplug your component from the wall outlet before cleaning it. Do not
use any type of liquid or aerosol cleaners.

ENGLISH

ENGLISH
SYMPTOM POSSIBLE CAUSE REMEDY
The PowerCenter™is not
receiving power.
The PowerCenter is not turned On.
Too many devices are connected, causing an overload,
tripping the Circuit Breaker.
• Turn the PowerCenter switch on.
• Make sure the PowerCenter’s AC power plug is plugged into a properly grounded 120 volts (nominal) wall outlet.
• In some households, a wall switch may need to be thrown to make the wall plug active. Try turning on the light switches
located near the wall unit.
• Press the PowerCenter main power switch to “OFF” and then again to “ON” to reset.
Component is not receiving power. The component is plugged into a GreenPower switched outlet and the
PowerCenter has not been turned On.
The PowerCenter is plugged into a Switched outlet, but power on the
component is not On. In some instances, a component plugged into
a switched outlet won’t receive power when the PowerCenter is turned
On unless the component power is also switched On.
The component is plugged into a GreenPower switched outlet
and the component connected to the GreenPower Control Outlet
has not been turned On.
• Turn the PowerCenter On.
• Turn On the component plugged into the Switched outlet.
• Turn On the component plugged into the GreenPower Control outlet.
Speakers emit a humming
or buzzing noise.
The PowerCenter is sharing AC power with equipment
that is not properly grounded.
• Connect your PowerCenter to a dedicated outlet.
• Try unplugging different components from the PowerCenter one at a time to see if the noise stops.
• Make sure all components are plugged into PowerCenter.
“Ground OK” Diagnostic Indicator Light
does not come on.
Make sure PowerCenter is plugged into grounded outlet. Contact a qualified electrician to check outlet(s) for proper grounding.
Alarm beeps continuously. The PowerCenter protection circuitry has sacrificed itself to protect
connected equipment from a catastrophic surge.
The PowerCenter must be replaced. See the Warranty Information section for important details.
TROUBLESHOOTING
TROUBLESHOOTING

ENGLISH
SYMPTOM POSSIBLE CAUSE REMEDY
The PowerCenter™is not
receiving power.
The PowerCenter is not turned On.
Too many devices are connected, causing an overload,
tripping the Circuit Breaker.
• Turn the PowerCenter switch on.
• Make sure the PowerCenter’s AC power plug is plugged into a properly grounded 120 volts (nominal) wall outlet.
• In some households, a wall switch may need to be thrown to make the wall plug active. Try turning on the light switches
located near the wall unit.
• Press the PowerCenter main power switch to “OFF” and then again to “ON” to reset.
Component is not receiving power. The component is plugged into a GreenPower switched outlet and the
PowerCenter has not been turned On.
The PowerCenter is plugged into a Switched outlet, but power on the
component is not On. In some instances, a component plugged into
a switched outlet won’t receive power when the PowerCenter is turned
On unless the component power is also switched On.
The component is plugged into a GreenPower switched outlet
and the component connected to the GreenPower Control Outlet
has not been turned On.
• Turn the PowerCenter On.
• Turn On the component plugged into the Switched outlet.
• Turn On the component plugged into the GreenPower Control outlet.
Speakers emit a humming
or buzzing noise.
The PowerCenter is sharing AC power with equipment
that is not properly grounded.
• Connect your PowerCenter to a dedicated outlet.
• Try unplugging different components from the PowerCenter one at a time to see if the noise stops.
• Make sure all components are plugged into PowerCenter.
“Ground OK” Diagnostic Indicator Light
does not come on.
Make sure PowerCenter is plugged into grounded outlet. Contact a qualified electrician to check outlet(s) for proper grounding.
Alarm beeps continuously. The PowerCenter protection circuitry has sacrificed itself to protect
connected equipment from a catastrophic surge.
The PowerCenter must be replaced. See the Warranty Information section for important details.

ENGLISH
LIMITED WARRANTY FOR CONSUMERS
Monster, LLC,7251Lake Mead BlvdWest,LasVegas,NV89128, USA(“Monster”)extendstoYouthisLimitedWarranty.Statutoryorcommonlawmay
provideYou with additional rights or remedies, which shall not be affected by this LimitedWarranty.
DEFINITIONS
“Adequate Use” means use of the Product and Connected Equipment (i) within a home or dwelling, (ii) for private (as opposed to commercial)
purposes, (iii)inconformancewithallapplicablelocal,state orfederal law,codeorregulations(includingwithoutlimitationbuildingand/orelectrical
codes),(iv)inaccordancewithmanufacturerrecommendationsand/or instructionsinthe materialsand documentationthataccompanytheProduct
andanyConnectedEquipment,(v)withproperelectricalgrounding,(vi)withproperanddirectconnectionbetweentheProductandanACpower
source thathasprotectivegrounding(excluding gasordieselpoweredgenerators),(vii)withcableortelephonelinestoany ConnectedEquipment
properly connected to the Product, and (viii) without a connection in a“daisy-chain”fashion to or with any extension cord, surge suppressor, power strip,
uninterruptible power supply (“UPS”) or other equipment.
“Authorized Dealer”means any distributor, reseller or retailer that (i) was duly authorized to do business in the jurisdiction where it sold the Product
toYou,(ii)waspermittedto sellYoutheProductunder thelawsofthejurisdictionwhereYouboughttheProduct, and(iii)soldYou theProductnewand
in its original packaging.
“Connected Equipment”means any device that is (i) generally suited to be used with the Product or products of the same kind, (ii) meets the
requirements of all applicable laws and safety standards, (iii) contains only parts manufactured, sold or recommended by the original manufacturer of
theConnectedEquipment,and(iv)hasnotbeenaltered,tamperedwithormodifiedbyany personotherthanits manufacturerorservicepersonnel
authorized or recommended by the manufacturer of the Connected Equipment.
“Connected Equipment Damage”means physicaldamageto ConnectedEquipmentcausedbyaProductDefectbyatransientACpower,cable,
telephone, orlightningsurgewhile connectedtoa properlyinstalledProduct. ConnectedEquipmentDamage(i)maynotbe causedbyadefector
unrelated damagingoftheConnectedEquipmentorasurge/spike orlightningstrike throughasource,mediumorconnectionotherthanthroughthe
Product, and (ii) does not extend to loss of data, or consequential, indirect or special damages resulting from the Connected Equipment Damage.
“Fair Market Value”(“FMV”) means the fair market value of the Connected Equipment at the time Connected Equipment Damage occurs.
“Formal Warranty Claim”means a claim made in accordance with the section“FormalWarranty Claims”herein.
“Maximum Coverage Amount” meansthe maximumamountthatMonsterwillpaytoYouunderthisLimitedWarrantyforConnectedEquipment
Damages and is defined in relation to each Product in the SpecificationsTable below.
