3-SPEED
TURNTABLE
User Manual
MODEL: MT-TT02

2
Welcome
Premium connectivity that fuels modern lifestyle and empowers innovation.
A better everyday experience through amazing products.
The user manual will provide everything you need to know about using your new product.
All our products are produced and tested to stringent standards of performance and safety, and are pleased to
provide a 2 Year Warranty with your purchase.
We hope you enjoy your purchase.

3
Welcome 2
Product Overview 4
Controls and Connections 8
Operation 10
Bluetooth 12
Troubleshooting 13
Specifications 14
Compliance and Responsible Disposal 15
Contents

4 | PRODUCT OVERVIEW
Product Overview
A. 3-Speed Turntable
B. Adaptor for 45RPM records
C. AC Adaptor
D. 3.5mm to RCA Audio Cable
E. RCA Audio Cable
F. Warranty Certificate
G. General Safety Warnings
H. User Manual
What’s in the box:

PRODUCT OVERVIEW | 5
Important Tips
• Place the turntable on a level surface.
• Place the turntable away from any source that may generate heat or vibrations.
• Make sure there is enough space around the turntable for airflow. Leave at least
10cm clearance around the product.
• Unplug the turntable before cleaning it.
• Clean using a dry cloth only - do not use water or chemicals.
• Only use the provided power supply.
• Keep liquid, children and pets away from the turntable at all times.
• Repack in its original packaging when transporting the turntable.

6 | PRODUCT OVERVIEW
Before first use
• Unpack the product but keep all packaging materials until you have made sure your new product is
undamaged and in good working order. Plastic wrapping can be a suocation hazard for babies and
young children, so ensure all packaging materials are out of their reach.
• Unwind the cord to its full length and inspect it for damage. Do not use the product if the product or
its cord have been damaged or are not working properly. In case of damage, contact our after sales
support line for advice on examination or repair or return of the damaged product.
• Read this manual to familiarise yourself with all the parts and operating principles of the product.
• Do not connect the unit to the mains power socket before checking the mains voltage and before all
other connections have been made.

PRODUCT OVERVIEW | 7
• Connect the DC plug into the DC IN power jack of the turntable.
• Plug in the adaptor into the AC power outlet.
Connect to power
Make sure the turntable is switched o at
the power outlet until you have finished
connecting your cables.
Don't forget to plug in the
turntable to the power
outlet. Leave the power
switched o until installation
is finished.

8 | CONTROLS AND CONNECTIONS
Controls and Connections
Product Overview
TOP VIEW
1
2
3
4
5
6
7
8
9
1. Anti-skating - slightly rotate to
adjust
2. Lift lever
3. Tone arm
4. Pitch control knob
5. Speed control knob
6. Mode knob - adjust to switch
between Phono, USB and
Bluetooth mode
7. Stylus
8. Turntable shaft
9. Turntable platter

CONTROLS AND CONNECTIONS | 9
REAR VIEW
SIDE VIEW
14
10
15 16 17 18
11 12 13
10. Phono/Line Out output - select
between phono or line out output
11. RCA output - use the supplied
3.5mm to RCA audio cable to
connect to your external speakers
(not included) for audio playback
12. DC port - use the supplied AC
adaptor to connect to the DC port
and the other end to a power source
13. On/O switch
14. Acrylic dust cover
15. USB port
16. button: press to play previous
song
17. button: press to play/pause song
18. button: press to play next song

10 | OPERATION
Operation
Power On and Mode selection
• Flick the On/O switch to turn the turntable on.
• Once you place the tonearm on the vinyl, the turntable will switch to vinyl mode and Bluetooth®mode
will automatically be disabled. Place the tonearm back to the arm rest to switch back to Bluetooth®
mode. When the tonearm is back in the arm rest, use the Mode knob to switch between Phono, USB and
Bluetooth mode.
Playing a Record
• Place a record on the turntable platter and select the correct playing speed: 33, 45, 78 RPM (according to the vinyl
being played).
• Remove the stylus guard and unlock the tone arm lock. Push the lift lever upward to raise the tone arm and then
gently move the tone arm to the desired position over the record. The platter will begin to spin when the tone arm
is moved toward the record.
• Push the lift lever forward to lower the tone arm slowly onto the desired position on the record and begin playing
the record.
To avoid damaging the stylus, ensure that the
included stylus guard is in place whenever the
turntable is being installed, moved or cleaned.
• When you have finished playing the record, push the lift lever
backward to raise the tone arm and gently move it back to its
rest.
• When you have finished playing records, engage the tone arm
lock to protect it from accidental movement. Flick the On/O
switch to turn the turntable o. Unplug it from the power supply
if you are not going to use it for a while.
• Note: when playing a record for the first time, you will need to
remove the rubber ring on the cartridge.

OPERATION | 11
• If a USB has already been inserted when the unit is switched on and the Mode knob is set
to USB, the music from the USB will be played automatically.
Connect to an External Amplifier using the Line Out Port
• Use the supplied 3.5mm to RCA audio cable to connect to the RCA output at the back of the turntable, and then
connect to the your external amplifier.
Playing Music from USB
• The USB port on the side of the turntable allows you to play music from a USB.
1. USB port: insert your USB for music
playback
2. : Play previous track.
3. : Press to play or pause.
4. : Play next track.
NOTE:
1 2 3 4
Tips to better performance
• When opening or closing the turntable cover, handle it gently, moving it either at the center or equally from both sides.
• Do not touch the stylus tip with your fingers; avoid bumping the stylus on the turntable mat or on the edge of the record.
• Clean the stylus tip frequently, using a soft brush with a back-to-front motion only.
• If you use a stylus cleaning fluid, use it very sparingly.
• Wipe the dust cover and turntable housing gently with a soft cloth. Clean the unit only with a dry, clean cloth.
Do not use liquid or aerosol cleaners.
• Never apply harsh chemicals or solvents to any part of the turntable system.
• Prior to moving the turntable, always unplug it from the AC power outlet and fasten the tone arm on the tone arm rest
with the vinyl twist-tie.

12 | BLUETOOTH
Bluetooth®
You can listen to tracks from a media device if connected
to the unit via Bluetooth®wireless technology.
• When the turntable is switched on and the tonearm is
placed on the arm rest, Bluetooth®mode is automatically
activated (if there is no USB plugged in).
• The first time you use your Bluetooth®device with the
turntable, you will need to pair them with one another.
• Activate Bluetooth®on your compatible device, and set it to
search for compatible devices.
• Select 'MT-TT02' from the list of found devices.
• If your device asks for a passkey (depending on the device
manufacturers, model, and software version), then enter
digits “0000” and press OK.
• You can also use the control buttons on the right side of the
turntable to play, play previous/next and pause the music.
• To unpair Bluetooth®connection , press and hold the
button
Pairing Bluetooth®Devices
The operational range between this turntable and
a Bluetooth®device is approximately 10 metres
(without any object between the Bluetooth®
enabled device and the unit). Any obstacle
between the devices can reduce the operational
range.
Before you connect a Bluetooth®enabled
device to this unit, ensure you know the device’s
capabilities. Compatibility with all Bluetooth®
devices is not guaranteed.
If the signal strength is weak, your Bluetooth®
receiver may disconnect, but it will re-enter pairing
mode automatically.
If a mobile phone on which you are playing music
receives a call, the music will be interrupted. The
phone call audio however is not played via the
speakers. Once you end the call, the devices are
connected to each other again and playback
resumes.
Your device will also be disconnected when your
device is moved beyond the operational range. If
you want to reconnect your device, place it within
the operational range.
If the connection is lost, follow the instructions
(left) to pair your device to the player again.

TROUBLESHOOTING | 13
For Technical and Warranty Support
1300 886 649
[e-mail]
monsterproducts.com.au
Distributed by Tempo (Aust) Pty Ltd,
PO Box 132, Frenchs Forest NSW 1640
If you have problems with the turntable, check below for advice. If you don't find a solution here, contact
After Sales Support on 1300 886 649.
Troubleshooting
Problem Solution
No power • Ensure that the power adaptor is properly connected.
• Ensure that there is power at the AC outlet.
No sound
• Check that the turntable is in the correct mode. If in Bluetooth®mode, check the Bluetooth®source
device to make sure that it's not muted or stopped playing.
• Check that the volume of the external amplifier is not muted/increase the volume.
The vinyl record
will not play
• Check that it is in the correct mode
• Make sure you have selected the correct speed (33, 45, 78rpm).
• Check whether the vinyl has already played to the end.
USB can not
playback
• Check that it is in the correct mode.
• Check that the music file format is mp3.

14 | SPECIFICATIONS
Specifications
Power Adaptor Input AC 100-240V, 50/60Hz 0.2A Max.
Power Adaptor Output DC 12V/0.2A
Dimensions
(Turntable) 430 x 140 x 334mm (W x H x D)
Stylus Cartridge Audio Technica ATN3600
USB Max 32GB
Supported Formats mp3
Vinyl Records
Speed
Supports playback
speed
33 / 45 / 78 RPM
Record size support
7” = 17.7cm
10” = 25.5cm SP
12” = 30cm LP
Net Weight 4.27kg
Gross Weight 11.1kg

SPECIFICATIONS | 15
Compliance and Responsible Disposal
Compliance
This product complies with the Australian
Safety Standard AS/NZS 62368.1 to ensure
the safety of the product.
Packaging
The packaging of your product has been
selected from environmentally friendly
materials and can usually be recycled. Please
ensure these are disposed of correctly. Plastic
wrapping can be a suffocation hazard for babies
and young children, please ensure all packaging
materials are out of reach and are safely disposed
of. Please recycle these materials rather than
throwing them away.
Product
At the end of its working life, do not throw this
product out with your household rubbish. An
environmentally friendly method of disposal
will ensure that valuable raw materials can be
recycled. Electrical and electronic items contain
materials and substances which, if handled or
disposed of incorrectly, could potentially be
hazardous to the environment and human health.
