Instruction Manual
Item: 761509
Wards.com 1•888•557•3848
Recipes
in back!
1.1 Cu. Ft. Microwave Oven

Thank you for purchasing your
Montgomery Ward 1.1 Cu. Ft. Microwave Oven.
Put through the paces by the experts, we guarantee that it will per-
form to the highest standard, time after time, with all the convenience,
easy cleanup and durability you rely on from Wards.
Important Safeguards ...............3-4
Electrical Safety ...............................4
Specifications.................................... 4
Parts & Features............................... 5
How to Use................................... 6-10
Troubleshooting...............................11
Recipes and Notes...................12–19
Return Informaion.........................20
Warranty..............................................21
Table of Contents
2Wards.com
Thank you
for your
purchase!

3
1•888•557•3848
Important Safeguards
READ CAREFULLY BEFORE
USING AND SAVE THESE
INSTRUCTIONS!
• FOR HOUSEHOLD USE ONLY. DO NOT use this appliance for other than its
intended use.
• REMOVE all packaging materials and labels before first use. Remove any
protective film found on the microwave oven cabinet surface. DO NOT remove
the light brown Mica cover inside the oven cavity. Please dispose of the
packaging materials via the appropriate recycling system, in an
environmentally friendly manner.
• WASH all removable parts and wipe down the inside of the oven before
first use. Wipe up spills with a damp cloth as they occur.
• A SHORT CORD is provided to reduce the hazards resulting from
entanglement or tripping. Do not drape the cord over the counter or tabletop,
where it can be pulled on or tripped over.
• We DO NOT recommend using an extension cord with this appliance.
However, IF AN EXTENSION CORD IS USED, the marked electrical rating
should be at least as great as the electrical rating of this appliance.
• CLOSE SUPERVISION is necessary when using this appliance near CHILDREN.
• A FIRE may occur if this appliance is used near FLAMMABLE MATERIALS.
DO NOT overcook food. DO NOT use metal utensils or styrofoam in this oven.
DO NOT place the oven or its cord on or near a heated surface.
• IF MATERIALS INSIDE THE OVEN SHOULD IGNITE, KEEP OVEN DOOR
CLOSED, TURN OVEN OFF, AND DISCONNECT THE POWER CORD OR SHUT
OFF POWER AT THE CIRCUIT BREAKER PANEL.
• This appliance should always be used on a STABLE, DRY, HEAT-RESISTANT
SURFACE.
• DO NOT use an accessory or attachment not recommended by Wards, as this
may cause injury, or damage the appliance.
• Keep hands, hair and clothing away from all MOVING PARTS.
• Always use OVEN MITTS when handling hot food or appliances.
• DO NOT ATTEMPT TO OPERATE THIS OVEN WITH THE DOOR OPEN. Open-
door operation can result in harmful exposure to microwave energy. DO NOT
TAMPER WITH THE DOOR SAFETY LOCKS. DO NOT ALLOW FOOD OR
CLEANER RESIDUE TO BUILD UP AROUND DOOR AREA.
• Products such as whole eggs in the shell and sealed containers should NOT be
heated in this oven, as they may EXPLODE.
• Liquids can be OVERHEATED BEYOND THE BOILING POINT WITHOUT
APPEARING TO BE BOILING due to surface tension of the liquid. Visible
bubbling or boiling when the container is removed from the oven is not always
present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING
OVER WHEN A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID.
• DO NOT HEAT OIL or fat in large quantities (like for deep frying) in this
microwave!
• Pierce foods with heavy skins, such as whole potatoes or whole squash,
before cooking, as they may EXPLODE.
(continued on next page)

Specifications
Electrical Safety
Wards.com
4
This appliance is equipped with a 3-prong grounding plug. This is a safety
feature to reduce the risk of electrical shock. Using an extension cord is not
recommended with this appliance. The plug should be attached to the appliance
before connecting to an electrical outlet. It is recommended that an electrical out-
let serving ONLY this appliance be used. This outlet must be properly installed and
grounded. If you have any questions about the grounding or electrical
instructions, contact a qualified electrician. Do not attempt to modify the plug in
any way. Montgomery Ward cannot accept any liability for damage or injury
resulting from failure to observe these safety procedures.
• DO NOT cover or block any openings on the appliance. Allow 4" for the
back, 8" above and 3" on the sides between the oven and wall or cabinet.
• This oven generates, uses, and can radiate radio frequency energy and
may cause interference to your TV or radio. Try to correct interference by
increasing the separation between the equipment and the oven. Consult
an experienced radio/TV technician for help.
• DO NOT use outdoors. Do not use this product near water.
• NO SERVICEABLE PARTS INSIDE THIS APPLIANCE.
• DO NOT USE AN APPLIANCE WITH A DAMAGED CORD OR PLUG, OR
AFTER THE APPLIANCE MALFUNCTIONS, OR HAS BEEN DAMAGED IN
ANY MANNER.
• Appliances/tools contain valuable materials that can be recycled. Please
dispose of your old appliances/tools using appropriate collection
systems.
OUTPUT REQUIREMENTS 120V/60 Hz/1000W
POWER RATING INPUT 120V/60 Hz/1500W
CAPACITY 1.1 CU FT
CORD LENGTH 36"
OUTSIDE DIMENSIONS 20.2" W x 15.3" D x 12.1" H
INSIDE DIMENSIONS 13.9" W x 14.5" D x 9.1" H
NET WEIGHT APPROXIMATELY 31.3 LBS.
MODEL SMW-0110
Important Safeguards

Parts & Features
1•888•557•3848 5
(1) Time Cook
(2) Time Defrost
(3) Weight Defrost
(4) Power
(5) Clock
(6) Kitchen Timer
(7) Auto Cook Menu
(8) Number Pad
(9) Express Cook (1-6)
(10) START/+30SEC
(11) Stop/CANCEL
(12) Memory function
A) Control panel
B) Turntable shaft
C) Turntable ring
D) Glass tray
E) Window
F) Door
G) Safety lock system
F
G
A
C B
ED
12
11
8
7
5
4
1
2
3
10
9
6

How to Use
Aluminum foil Shielding only. Small, smooth pieces can be used to cover
parts of meat or poultry to prevent overcooking. Arcing
can occur if foil is too close to oven walls. Keep at least 1
inch (2.5cm) away from oven walls.
Browning dish Follow manufacturer instructions. The bottom of brown-
ing dish must be at least ⁄ inch (5mm) above the turnta-
ble. Incorrect usage may cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions.
Do not use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm.
Most glass jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no
metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer instructions. Do not close with
metal tie. Make slits to allow steam to escape.
Paper plates/cups Use for short term cooking/warming only. Do not leave
oven unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use
with supervision for short-term cooking only.
Parchment/wax
paper
Use as a cover to prevent splattering or a wrap for steam-
ing.
Plastic Microwave-safe only.
Plastic wrap Microwave-safe only. Use to cover food during cooking to
retain moisture. Do not allow plastic wrap to touch food.
“Boiling bags” and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Thermometers Microwave-safe only.
Microwave-safe materials
DO NOT use these materials in your microwave: aluminum trays,
cartons with metal handles, metal or metal-trimmed utensils, metal twist ties,
paper bags, plastic foam and wood.
Wards.com
6

How to Use
POWER LEVEL
10 power levels are available.
Level 10 9 8 7 6 5 4 3 2 1
Power 100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
Display PL10 PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1
CLOCK SETTING
(1) Press CLOCK, 00:00 will display.
(2) Press the number keys to enter the current time.
(3) Press CLOCK to finish clock setting. “:” will flash and the clock will be lighted.
(4) Numbers must be within the range of 1:00–12:59. In the process of clock
setting, if STOP/CANCEL is pressed or if there is no operation
within 1 minute, the oven will go back to the former setting automatically.
MICROWAVE COOK
(1) Press TIME COOK once, the screen will display 00:00.
(2) Press number keys to input the cooking time; the maximum cooking time is 99
minutes and 99 seconds.
(3) Press POWER once, screen will display PL10. The default power is 100%.
Press number keys if you want to adjust the power level.
(4) Press START/+ 30SEC to start cooking.
Example: To cook the food with 50% microwave power for 15 minutes.
a. Press TIME COOK once. 00:00 displays.
b. Press 1,5,0,0 in order.
c. Press POWER once, then press 5 to select 50% microwave power.
d. Press START/+ 30SEC.
KITCHEN TIMER
(1) Press KITCHEN TIMER once, the screen will display 00:00.
(2) Press the number keys to enter the time. (The maximum time is 99 minutes
and 99 seconds.)
(3) Press START/+ 30SEC to begin timing. When the timer finishes, the buzzer
sounds 5 times.
EXPRESS COOKING
(1) Instant cooking at 100% power level with 30 seconds’ cooking time can be
started by pressing START/+ 30SEC. Each press of this button will increase
cooking time by 30 seconds. The maximum cooking time is 99 minutes and 99
seconds.
(continued on next page)
33
1•888•557•3848 7

How to Use
(2) If not already cooking, press number pads 1–6 (for 1–6 minutes express
cooking at 100% power). Press START/+ 30SEC to increase the cooking time
by 30 second intervals.
CANCEL
Press STOP/CANCEL to stop any operation.
WEIGHT DEFROST FUNCTION
(1) Press WEIGHT DEFROST once, screen will display dEF1;
(2) Press numerical buttons to input weight to be defrosted (4–100 oz.).
(3) Press START/+ 30SEC to begin defrosting.
TIME DEFROST FUNCTION
(1) Press TIME DEFROST once, screen will display dEF2.
(2) Press number keys to input defrosting time. (00:01–99:99).
(3) Press POWER once, screen will display PL3. The default power is 30%.
(4) Press START/+30SEC to begin defrosting.
POPCORN
(1) Press POPCORN repeatedly until the number you want appears in the
display (1.75, 3.0, 3.5 oz.).
BEVERAGE
(1) Press BEVERAGE repeatedly until the number of cups you want appears in
the display (1 cup is about 120ml).
(2) Press START/+ 30SEC to cook. When cooking finishes, buzzer sounds 5
times.
PIZZA
(1) To reheat pizza, press PIZZA repeatedly until the number you want appears
in the display, (4.0, 8.0, 14.0 oz.).
(2) Press START/+ 30SEC to cook. When cooking finishes, buzzer sounds 5
times.
POTATO
(1) Press POTATO repeatedly until the number you want appears in the display,
(1, 2, 3).
(2) Press START/+ 30SEC to cook. When cooking finishes, buzzer sounds 5
times.
FROZEN VEGETABLE
(1) Press FROZEN VEGETABLE repeatedly until the number you want appears in
the display (4.0, 8.0, 16.0 oz.).
(2) Press START/+ 30SEC to cook. When cooking finishes, buzzer sounds 5
times.
8Wards.com
(2) Press START/+ 30SEC to cook. When cooking finishes, buzzer sounds 5
times.

How to Use
DINNER PLATE
(1) Press DINNER PLATE repeatedly until the number you want appears in the
display (9.0, 12.0, 18.0 Oz.).
(2) Press START/+ 30SEC to cook. When cooking finishes, buzzer sounds 5
times.
MEMORY FUNCTION
1) Press 0/MEMORY to choose memory 1–3 procedure.
(2) If the procedure has been set, press START/+30SEC. Only one or two stages
can be set.
(3) If the procedure has not been set, after finishing the setting, press
START/+30SEC once to save the procedure.
(4) Press START/+30SEC to start cooking procedure and to save the procedure.
Example:
To set the following procedure as the second memory, that is memory 2. To
cook the food with 80% microwave power for 3 minutes and 20 seconds, the
steps are:
a. Press 0/MEMORY twice.
b. Press TIME COOK once then press 3, 2, 0 in order.
c. Press POWER once, PL10 displays, then press 8 and PL8 displays.
d. Press START/+30SEC to save the setting. Press again, the procedure will be
operated as the memory 2 .
e. If the electricity is cut off at any time, the procedure will need to be reset.
f. When you want to run the saved procedure, press 0/MEMORY twice, then
START/+30SEC.
Note: Auto menu can not be set in memory function.
MULTI-STAGE COOKING
At most, 2 stages can be set for cooking. In multi-stage cooking, if one stage is
defrosting, then defrosting shall be placed at the first stage automatically.
Note: Auto menu cannot work in the multi-stage cooking.
Example:
If you want to cook with 80% microwave power for 5 minutes + 60% microwave
power for 10 minutes. The cooking steps are:
a. Press TIME COOK once, then press 5, 0, 0 to set the cooking time;
b. Press POWER once, then press 8 to select 80% microwave power.
c. Press TIME COOK once, then press 1, 0, 0, 0 to set the cooking time;
d. Press POWER once, then press 6 to select 60% microwave power.
e. Press START/+30SEC to start cooking.
9
1•888•557•3848

Wards.com
10
How to Use
INQUIRING FUNCTION
While cooking, press:
(1) POWER to check the power level (current microwave power will be
displayed). After three seconds, the display will turn back to the previous
state. (This also works in multi-stage cooking.)
(2) CLOCK to inquire the current time.
LOCK FUNCTION FOR CHILDREN
Press STOP/CANCEL for 3 seconds, there will be a long beep when the lock is set
(and the lock indicator will light). To unlock, press STOP/CANCEL for 3
seconds, there will be a long beep when the lock is released

1•888•557•3848 11
Troubleshooting
Oven will not
start
a. Electrical cord is unplugged.
b. Door is open.
a. Plug into the outlet.
b. Close the door.
Arcing or
sparking
a. Materials to be avoided in
microwave oven were used.
b. The oven is operated when
empty.
c. Spilled food remains in the
cavity.
a. Use microwave-safe
materials only.
b. Do not operate with
oven empty.
c. Clean cavity with wet
towel.
Unevenly
cooked foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Cooking time or power level
is not suitable.
d. Food is not turned or stirred.
a. Use microwave-safe
materials only.
b. Completely defrost
food.
c. Use correct cooking
time and power level.
d. Turn or stir food.
Overcooked
foods
Cooking time or power level is
not suitable.
Use correct cooking time
and power level.
Undercooked
foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Oven ventilation ports are
restricted.
d. Cooking time or power level
is not suitable.
a. Use microwave-safe
materials only.
b. Completely defrost
food.
c. Check to see that
ventilation is not
restricted.
d. Use correct cooking
time and power level.
Improper
defrosting
a. Materials to be avoided in
microwave oven were used.
b. Cooking time or power level
is not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe
materials only.
b. Use correct cooking
time and power level.
c. Turn or stir food.
Trouble Possible Cause Possible Remedy

Recipes
12
21
Wards.com
Twice-Baked Potatoes
4 medium-sized baking potatoes, scrubbed
3–4 green onions,
2 Tbsp. butter
½ cup milk, heated
½ tsp. salt (or more to taste)
¼ tsp. garlic powder
2–3 Tbsp. cheddar cheese, grated
2–3 Tbsp. Parmesan cheese, grated
pepper and paprika, to taste
1. Bake potatoes per your microwave instructions. Let cooked potatoes cool until
able to handle.
2. Cut potatoes in half, lengthwise. Using a tablespoon, scoop out the cooked
potato and place it in a mixing bowl (take special care to keep the potato skins
intact).
3. Mash the potatoes. Add the onions, butter, milk, salt and garlic powder. Whip
potatoes until smooth (use a mixer if you have one to make this easier).
4. Spoon the potato mixture back into the potato skins and arrange on a
microwave-safe plate. Cook on HIGH for 2 minutes.
5. Sprinkle the potatoes with both cheeses. Heat again on HIGH for another 2
minutes or until cheese is melted.
6. Sprinkle the potatoes with pepper and paprika. Let cool for a minute or 2.
7. Serve with sour cream, bacon bits, or your favorite toppings.
Serves 6–8

Recipes
13
1•888•557•3848
Cauliflower Salad
1 head cauliflower 1 tsp. olive oil
2 tsp. lemon zest 2 tsp. Dijon mustard
6 green onions, sliced 3 Tbsp. apple cider vinegar
½ cup plain yogurt 2 tsp. lemon juice
5 Tbsp. honey salt & pepper, to taste
1. Cut the cauliflower into bite-size pieces and steam in a covered dish for 5-7
minutes, until tender (but not mushy).
2. Toss the cauliflower with the lemon zest and onions in a bowl.
3. In a separate bowl, whisk together the remaining ingredients until creamy and
well blended.
4. Pour the dressing over the cauliflower and serve.
Serves 4
Microwave Mac & Cheese for One
½ cup elbow macaroni
½ cup water
½ cup shredded cheddar cheese
2 tsp. milk
1. Combine the macaroni and water in a microwave safe bowl. Cook on HIGH 6
minutes, stopping to stir every 2 minutes.
2. Add the shredded cheese and microwave on HIGH 45 seconds. Stir in the milk
until smooth and serve.
Serves 1

Wards.com
Recipes
Italian Chicken Breasts
½ cup seasoned bread crumbs 2 chicken breasts, skinned
¼ cup Parmesan cheese, grated 1 cup pasta sauce
1 egg 2 oz. mozzarella cheese, grated
1. Mix the bread crumbs and Parmesan in a shallow bowl.
2. Beat the egg in another shallow bowl.
3. Dip the chicken in the egg, then roll in the bread crumb mixture to coat fully.
4. Place the coated chicken in the bottom of a microwave-safe dish with cover
(I used a glass casserole dish).
5. Cook at full power for 5 minutes. Turn the chicken, and cover with the sauce.
6. Cover and cook another 4 minutes at full power.
7. Add the mozzarella to the top of the chicken and sauce. Cover and cook 1 more
minute.
8. Let stand, covered, about 3 minutes. Chicken should reach internal temperature
of 165°F when done.
9. Serve over cooked pasta.
Serves 2
14

1•888•557•3848
Recipes
Pork Ribs
2–3 lbs. pork ribs 1 can (10–15 oz.) tomato sauce
1 large onion, minced 2–3 Tbsp. hot sauce (or more to taste)
2 Tbsp. brown sugar ½ tsp. salt (more or less to taste)
2 Tbsp. cider vinegar ¼ tsp. pepper (more or less to taste)
1 tsp. prepared mustard
1. Cut ribs to fit your microwave-safe dish with cover.
2. Mix remaining ingredients in a medium bowl.
3. Dip ribs in sauce to fully coat, and put ribs in the microwave-safe dish. Pour
remaining sauce over the top of the ribs.
4. Cover and cook on 50% power for 15 minutes.
5. Turn rib pieces. Cover and cook on 50% power for another 15 minutes.
6. When done, meat should be tender and reach internal temperature of 170°. (If
additional cooking time is needed, do so in 5-minute increments.)
7. Add more salt and pepper to taste.
Serves 2
10
15

Wards.com
Recipes
Quick and Easy Microwave Fudge
2 packs (8 squares each) semi sweet chocolate ¼ tsp. salt
1 can (14 oz.) sweetened condensed milk 1 cup walnuts, chopped
2 tsp. vanilla extract butter
1. Place half the chocolate and half the milk in a microwave-safe bowl. Heat on
HIGH for one minute, stir. Heat on HIGH for another minute. Repeat with
second half of chocolate and milk.
2. Combine and stir chocolate mixture until completely smooth.
3. Mix in vanilla, salt and walnuts. When blended well, pour into a cake pan or
cookie sheet that has been lightly greased with butter.
4. Refrigerate until firm (about 2 hours), then cut and serve.
Makes 30-40 pieces
Easy Old-Fashioned Peanut Brittle
1 Tbsp. butter 1 tsp. vanilla
1 cup sugar 1 cup cocktail peanuts
½ cup light corn syrup 1 tsp. baking soda
1. Put a piece of parchment paper (about 10" x 13") onto a cookie pan. Lightly
rub the parchment paper with butter (you’ll use just a little of the butter).
2. Combine the sugar and syrup in a microwave-safe bowl. Stir well and cook on
HIGH for 5 minutes.
3. Carefully add the remaining butter, vanilla and peanuts to the bowl and stir.
Cook on HIGH 1½ minutes.
4. Remove the bowl from the oven with an oven mitt and quickly stir in the
baking soda. Pour the mixture over the prepared parchment paper. Spread
into a rectangle with a spatula.
5. Cool for 1 hour, then break into pieces for serving.
10
16

1•888•557•3848
Recipes
Lemon Bars
Crust:
1 cup flour
3 Tbsp. powdered sugar
6 Tbsp. butter, melted
zest of 1 lemon
Filling:
1 cup sugar
zest of 2 lemons
3 eggs, at room temperature
juice from zested lemons (about ⅓ cup)10
1 Tbsp. flour
½ tsp. baking powder
¼ tsp. salt
powdered sugar
1. Spray a 9" square or round microwave-safe pan with cooking spray.
2. In a small bowl, mix the crust ingredients with a fork. When well-blended, press
the crust into the bottom of your pan (use your fingers or a spatula).
3. Microwave crust at 80% power for 3 ½minutes. The crust should be firm, but if it
is not, add another 30 seconds at 80% power. Set crust aside.
4. Using a mixer, beat together the first 4 ingredients for the filling on low–
medium speed.
5. Add the flour, baking powder and salt, and beat on medium speed for 2–3
minutes until smooth.
6. Pour the filling over the crust and cook in the microwave oven at 80% power for
4–5 minutes. The center should be set, not runny.
7. Cover and refrigerate for at least 4 hours. Dust with powdered sugar before
serving.
Makes 8-9 bars
10 10
17

Wards.com
Notes
18

1•888•557•3848
Notes
19

If any item, for any reason, does not meet your expectations, just
return it to us. We’ll gladly either:
• Refund your merchandise amount
• Credit your account
• Send a replacement
You can return any unused item in its original packaging within 60
days of its receipt for a full refund of the purchase price (excluding
shipping and handling charges).
Please send returns to:
Montgomery Ward, Inc.
Attn: Customer Returns
2000 Harrison Suite 100
Clinton, IA 52732-6676
When returning an item:
• Use the original packaging and pack it securely.
• Please adequately insure your item in case you need to
make a claim with the carrier you choose for returning your
item.
• Include your order number and reason for return.
• We recommend keeping the receipt for 4 weeks.
Returns
Wards.com
20
